Amplified Head-Unit Replacement Wiring-Harness Interface for Select 2005-2009 Land Rover LR3 and Range-Rover-Sport Vehicles
Interface Features:
Designed for MOST*25 amplified systems
Provides accessory power (12-volt)
Retains audio controls on the steering wheel controls
Easy to set Dipswitches for SWC configuration
Provides NAV outputs (parking brake, reverse, and speed sense)
Micro B USB updatable
Note: Backup Camera not retained if equipped.
Interface Components:
AXDIS-LR92 harness
AXDIS-LR92 interface
SWC harness
Fiber cap
Applications
LAND ROVER
LR3
M.O.S.T. 25 amplified
2005-2009
Range Rover Sport
M.O.S.T. 25 amplified
2006-2009
Axxess Interface AXDIS-LR92 Manual
Amplified Head-Unit Replacement Wiring-Harness Interface for Select 2005-2011 Mercedes-Benz E-Class, SLK, ML and GL Vehicles
*There are two different radio possibilities for this year range of vehicle, please see below for ways to distinguish between which interface kit you will need.
*Vehicles equipped with Command NTG1 will use the AXDIS-MB132. NTG1 radios will be built by Harman/Becker and have the 6-Disc Changer separate from the radio, if equipped with a SINGLE-disc player, it will be built in to the radio. They will typically have buttons on the sides of, and below the radio screen, also the optical light will come from the fiber cable when removed.
*Vehicles equipped with Command NTG2.5 will use the AXDIS-MB82. NTG2.5 radios will be built by Alpine, and have the 6-Disc changer built in to the radio. They will not have buttons directly below the radio screen, and the optical light will come from the radio when the fiber cable is removed.
Applications
MERCEDES
E-Class
2009
GL-Class
2007-2012
ML-Class
2006-2011
SLK-Class
2005-2011
Axxess Interface AXDIS-MB82 Manual
Amplified Head-Unit Replacement Wiring-Harness Interface for Select 2006-2013 BMW 1-Series and 3-Series Vehicles
Provides accessory power (12 volt 10 amp)
Retains R.A.P. (retained accessory power)
Designed for amplified models
Retains audio controls on the steering wheel
Retains phone buttons (radio dependent)
Retains factory features: date, time, temperature display
Warning and parking sensor chimes are not retained
Micro-B USB updatable
*Note:* Warning and Parking sensor chimes are not retained
Applications
BMW
1 Series
2008-2013
3 Series
2006-2013
Axxess AXDIS-BW122 Installation Manual
Amplified Head-Unit Replacement Wiring-Harness Adapter for Select 2003-2011 Mercedes CLS, E and SLK Class Vehicles
Provides accessory power
Designed for amplified models
Provides NAV outputs (parking brake, reverse, speed sense)
Retains audio controls on the steering wheel
Retains balance
Micro B USB updatable
Applications
MERCEDES
CLS-Class
2006-2011
E-Class
2003-2008
Axxess Interface AXDIS-MB132 Installation ManualAxxess Interface AXDIS-MB132 Can Hub Tech Tip
Add-on Aftermarket Camera-to-Factory-Stereo Wiring Harness for Select 2013-UP Dodge, Jeep and RAM Vehicles with uConnect Radio
To be used when adding cameras to an OEM screen
(4) Camera inputs
Programmable 12V 5-amp switched output (configured through the Axxess Updater program)
Reverse signal trigger generated via CAN bus communication of the vehicle
Turn signal trigger generated via CAN bus communication of the vehicle
(4) Programmable camera control wires (configured through the Axxess Updater program)
Can also be manually controlled and used along with an aftermarket radio
VSS (Vehicle Speed Sense) input and output
Micro-B USB updatable
Retains backup camera
Applications
DODGE
Challenger
2015-2021
(w/ uConnect Radio)
Charger
2015-2021
(w/ uConnect Radio)
Durango
2014-2021
(w/ uConnect Radio)
JEEP
Cherokee
2014-2021
(w/ uConnect Radio)
Grand Cherokee
2014-2021
(w/ uConnect Radio)
RAM
1500 (DS)
2013-2019
(w/ uConnect Radio)
2500
2013-2018
(w/ uConnect Radio)
3500
2013-2018
(w/ uConnect Radio)
Axxess Interface AXAC-CH5 Manual
Non-Amplified Head-Unit Replacement Wiring-Harness Adapter for Select 2019-2021 Sprinter Vans With Base Radio (No Touchscreen)
Make installing an aftermarket radio easier with these harnesses
For use with 2019-2021 Sprinters equipped with non-MBUX radios (base radio)
Full kit includes plug-and-play solutions to integrate factory radio harness with aftermarket radio, and OEM Antenna (with amplification), relocates OEM rearview camera to aftermarket radio screen, SOS mic bypass, and supply IGN power from fuse box
Seamless integration using OEM connectors – no cutting or soldering factory wires required
Retains SOS system (Audio only) and avoid errors on the dash
Interfaces with retained accessory power circuit (allows radio to stay after ignition is off until door is opened)
Provides electrical power to the radio for a four-speaker connection
Applications
MERCEDES
Sprinter
2019-2021
Dual-Camera Channel Quick-Disconnect Add-On Trailer Wiring
2 camera connection – 1 audio and video 1 video only
32 foot extension to monitor
4-pin din connections for camera
6.5 ft trailer coil
1.5 ft dual camera cable
IP68
The TE-TCEX-1 gives the user the ability to add on two cameras for added visibilty to the sides, back, front, or even inside the trailer.
One camera connection even allows a provision for audio feed with a compatible camera. The thread-sealed water resistant connectors provide a safe and secure connection at the trailer hitch in all types of weather. Pair this universal trailer camera cable with any of our iBEAM commercial monitors and cameras.
RadioPRO Radio Replacement Interface Harness for Select Mercedes Sprinter and Metris
The RP4.2-MB11 radio replacement interface is your plug-n-play solution to upgrade your factory radio with an aftermarket radio in Mercedes Sprinter or Metris vehicles.
Steering wheel controls, 3.5mm AUX input, USB port and the back-up camera function are all retained with the RP4.2-MB11. By adding on the PAC VS41, you have the ability to add front and blind-spot cameras creating a complete camera system. PAC quality and engineering provides you the most professional installation solution available!
Retains:
Steering wheel controls
3.5mm AUX input
USB port
Back-up camera function
Features:
Includes wired outputs for navigation radio installation
Rear camera activation while in motion
10 Amp ACC 12 volt output
Direct USB updatable
Camera system ready - requires PAC VS41
Includes:
Vehicle specific harness
Interface module
Installation instructions
Applications
2016
MERCEDES-BENZ
METRIS
2013-2018
MERCEDES-BENZ
SPRINTER
Pac Audio RP4.2-MB11 ManualPac Audio RP4.2-MB11 Technical Bulletin
Amplified and Non-Amplified Head-Unit Replacement Wiring-Harness Interface for Select 2012-2016 Chevy and GMC Vehicles with Factory Navigation
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (Retained Accessory Power)
Provides NAV output (parking brake, reverse and speed sense)
Retains chimes
Retains audio controls on the steering wheel
Retains OnStar®/OEM Bluetooth®
Adjustable volume for OnStar®
Retains the factory AUX-IN jack
Can be used in non-amplified, or analog/digital amplified models
Retains balance and fade (excluding digital amplified models)
Micro-B USB updatable
Applications
Chevrolet
Avalanche 2012-2013 (1) (3)
Express 2013-2015 (3)
Malibu (with monochrome display) 2013-2015
Malibu Limited (with monochrome display) 2016
Silverado 2500 / 3500 2014 (1) (3)
Silverado 2012-2013 (1) (3)
Suburban 2012-2014 (2) (3)
Tahoe 2012-2014 (2) (3)
Trax 2015-2016
GMC
Savana 2013-2015 (3)
Sierra 2500 / 3500 2014 (1) (3)
Sierra 2012-2013 (1) (3)
Yukon / Yukon XL 2012-2014 (2) (3)
(1) These vehicles have a digital amp option. Please reference the “Service Parts Identification” sticker located in the glove box for the RPO code Y91. If Y91 is present, then the vehicle is equipped witha digital amplifier.
(2) These vehicles have a digital amp option. Please reference the “Service Parts Identification” sticker located in the glove box for the RPO codes; Y91, STZ, UQS. If Y91, STZ or UQS is present, then thevehicle is equipped with a digital amplifier.
(3) Only for models with NAV.
Axxess AXDIS-GMLN44 Installation Manual
