Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1988-1998 Chevrolet-Silverado and GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1988 – 1998 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.9 Cubic Feet Net Volume internal air space is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.25” which is ideal for most standard * lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, Mounting Depth: 6.25”, Height: 9”, Width: 30.25
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width: 30.25"
Height: 9.00"
Depth: 15.50"
Max Mounting Depth: 6.25"
Gross Volume Per Sub: 1.00
Net Volume Per Sub: 1.00
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1988-1998 Chevrolet-Silverado and GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Subwoofer mounting depth: 7.00"
Designed specifically for 1988-1998 Chevy Silverado and GMC Sierra Extended Cab Trucks
Premium carpeted finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Box volume: 0.93 cubic feet (per chamber)
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 51.75"
Height: 9.25" front height - 6.75" rear height
Depth: 14.75" front depth - 13.13" rear depth
Max Mounting Depth: 7.00"
Gross VolumePer Sub: 0.93 per sub
Net Volume Per Sub: 0.93 per sub
Dual 12-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1988-1998 Chevrolet-Silverado and GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Subwoofer mounting depth: 7.00"
Designed specifically for 1988-1998 Chevy Silverado and GMC Sierra Extended Cab Trucks
Premium carpeted finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Box volume: 0.93 cubic feet (per chamber)
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 51.75"
Height: 9.25" front height - 6.75" rear height
Depth: 14.75" front depth - 13.13" rear depth
Max Mounting Depth: 7.00"
Gross VolumePer Sub: 0.93 per sub
Net Volume Per Sub: 0.93 per sub
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2004-2014 Chevrolet-Colorado or GMC-Canyon Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1999-2007 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
1.1 Cubic Feet Gross and 1.0 Net Volume internal net air space are ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.25” which is ideal for full size and lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 6.25”, Width: 27.25”, Height: 8.75”, Depth: 11.875”
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width: 27.25"
Height: 8.25"
Depth: 11.88"
Max Mounting Depth: 6.25"
Gross VolumePer Sub: 1.35
Net Volume Per Sub: 1.00
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 2007-2013 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2007-2013 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
1.1 Cubic Feet Gross and 1.0 Net Volume internal net air space are ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.25” which is ideal for full size and lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 6.25”, Width: 27.25”, Height: 8.75”, Depth: 11.875”
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width: 27.25"
Height: 8.25"
Depth: 11.88"
Max Mounting Depth: 6.25"
Gross VolumePer Sub: 1.35
Net Volume Per Sub: 1.00
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 2014-2018 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Single 10" Vented Subwoofer Enclosure
Designed specifically for 2014 - 2018 Chevy Silverado and GMC Sierra Extended Cab Trucks
May work with some 2019 Models
Premium carpeted finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 6.25"
Box volume: 0.9 cubic feet (per chamber)
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width: 27.25"
Height: 6.25"
Depth:11.88"
Max Mounting Depth: 6.25"
Gross VolumePer Sub: 0.91
Net Volume Per Sub: 0.91
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1999-2007 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 7.25”, Width: 24”, Height: 9.125”, Depth: 24”
Specifications
Width
24
Height
9.125
Depth
24
Vent Width
1.25
Vent Height
5
Vent Depth
9
Mounting Depth
7.25
Gross Cubic Feet Per Side
1
Net Cubic Feet Per Side
0.93
HZ
41
Excursion
1.625
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2007-2014 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom downfire fit under rear seat. Fits bench style, 60/40 style seats
Designed specifically for 2007-2014 Chevy Silverado and GMC Sierra Extended Cab Trucks
Dual 10" Subwoofer Enclosure
Premium Carpet Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 6.25"
Box volume: 0.8 cubic feet (per chamber)
Specifications
Width
52.75
Height
6.875
Depth
11.875
Mounting Depth
6.25
Gross Cubic Feet Per Side
0.8
Net Cubic Feet Per Side
0.8
Excursion
3.625
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2014-2019 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom downfire under rear seat
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2014-2019 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction. 2.42 Cubic Feet Net Volume internal air space(.93 per sub) is ideal for tight accurate bass reproduction. Subwoofer Mounting Depth is 7” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue. Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, mounting depth:7”, front height: 6.88”, rear height: 6.25”, width: 51.75”, front depth: 11.88”, rear depth: 13.25”
Specifications
Width
52.75
Height
6.875
Depth
11.875
Mounting Depth
5.25
Gross Cubic Feet Per Side
0.8
Net Cubic Feet Per Side
0.8
Excursion
3
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom downfire fit under rear driver side seat. No modification required. Doesn't affect rear seat latching.
Single 10" Subwoofer Enclosure
Designed specifically for 1999-2007 Chevy Silverado and GMC Sierra Extended Cab Trucks
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 7.25"
Box volume: 0.93 cubic feet (per chamber)
Specifications
Width
24
Height
9.125
Depth
14.75
Mounting Depth
7.25
Gross Cubic Feet Per Side
0.93
Net Cubic Feet Per Side
0.93
Excursion
1.625
Single 12-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom down fire fit under rear driver side seat. No modification required. Doesn't affect rear seat latching.
Single 12" Carpeted Finish Subwoofer Enclosure
Designed specifically for 1999-2007 Chevy Silverado and GMC Sierra Extended Cab Trucks
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 7.25"
Box volume: 0.93 cubic feet (per chamber)
Specifications
Width
24
Height
9.125
Depth
14.75
Mounting Depth
7.25
Gross Cubic Feet Per Side
0.93
Net Cubic Feet Per Side
0.93
Excursion
1.625
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 99-07 Chevy Silverado and GMC Sierra Extended Cab Trucks
Premium Carpet Finish
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 7.00"
Box volume: 0.93 cubic feet (per chamber)
Installation Note: Custom down fire fit under rear driver side seat. No modification required. Doesn't affect rear seat latching.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 51.25"
Height: 6.75" REAR - 9.25" FRONT
Depth: 14.75"
Max Mounting Depth: 7.00"
Gross VolumePer Sub: 0.93
Net Volume Per Sub : 0.93
Dual 12-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 99-07 Chevy Silverado and GMC Sierra Extended Cab Trucks
Premium Carpet Finish
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 7.00"
Box volume: 0.93 cubic feet (per chamber)
Installation Note: Custom down fire fit under rear driver side seat. No modification required. Doesn't affect rear seat latching.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 51.25"
Height: 6.75" REAR - 9.25" FRONT
Depth: 14.75"
Max Mounting Depth: 7.00"
Gross VolumePer Sub: 0.93
Net Volume Per Sub : 0.93
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1999-2006 Chevrolet-Silverado and GMC-Sierra HD-Crew -Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1999-2006 Chevrolet / GMC trucks to ensure an OEM fit with out impeding the operation of the back seat.
High Grade MDF for Ultimate structural rigidity and no-flex construction. 1.5 Cubic Feet Net Volume internal air space (.75 per sub) is ideal for tight accurate bass reproduction. Subwoofer Mounting Depth is 6” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Dimensions Sub cut out: 9.125”, mounting depth: 6”, front height: 7.875”, rear height: 5.5”, width: 43.625”, front depth: 13.125”, rear depth: 12.5”
Installation Note: Custom downfire fit under rear seat, enclosure will only fit heavy duty crew cabs (1500, 2500, 3500). Heavy duty crew cabs will have the jack located under the seat on the passenger side.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 43.63"
Height: 5.50" Rear - 8.875" Front
Depth: 12.50" Rear - 13.13" Front
Max Mounting Depth: 6.00
Gross Volume Per Sub: 1.50
Net Volume Per Sub: 1.50
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2003-2007 Chevrolet-Silverado or GMC-Sierra Crew-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom downfire fit under rear seat, enclosure only fits lightduty 1500 crewcabs. Doesn’t affect rear seat latching. Forward folding function slightly affected. Lightduty crewcabs have jack located behind seat.
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2003-2007 Chevrolet / GMC trucks to ensure an OEM fit with out impeding the operation of the back seat.
Max Mounting Depth - 5.5""
Net Volume - 1.08""
(Front Height) 6.5"" x (Rear Height) 4.5"" x (Width) 42.25"" x (Depth) 12.5"" x (2nd Depth) 12""
Percise drop of enclosure required for seats to fold down completely
No modifications are required
Premium Carpet Finish
This box does NOT fit the Z71 models.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 42.25"
Height: 6.50"
Depth: 12.50"
Max Mounting Depth: 5.50"
Gross VolumePer Sub: 1.65
Net Volume Per Sub: 1.08
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2007-2013 Chevrolet-Silverado or GMC-Sierra Standard-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2007 -2013 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat and there is a designated area for mounting and amplifier to the enclosure.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.7 Cubic Feet Net Volume internal air space per subwoofer is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.25” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, sub mounting depth: 6.25”
Installation Note: Installs behind the seats. Tools on the hump must be removed to install. You will not have to take out your jack or cut off the bolt that holds your tool kit in place. The main limitation is depth. This truck seems to have less space behind the seats than the previous model, so speaker depth is somewhat limited. Check out the speaker depth guide before buying your subs. You will likely have to sacrifice the last 2-3 clicks on your seat travel to give the box and subs enough space. In most cases, this will still leave you with plenty of legroom to drive comfortably while enjoying your new boom.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 52.00"
Height: 14.89"
Depth: 6.85"
Max Mounting Depth: 6.25"
Gross VolumePer Sub: 0.70
Net Volume Per Sub: 0.70
Dual 12-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2007-2013 Chevrolet-Silverado or GMC-Sierra Regular-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 12” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2007 -2013 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat and there is a designated area for mounting and amplifier to the enclosure.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.7 Cubic Feet Net Volume internal air space per subwoofer is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.25” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions
Sub cut out: 11.125”, sub mounting depth: 6.25”
Installation Note: Installs behind the seats. Tools on the hump must be removed to install. What's nice is that you will not have to take out your jack or cut off the bolt that holds your tool kit in place. The main limitation is depth. This truck seems to have less space behind the seats than the previous model, so speaker depth is somewhat limited. Check out the speaker depth guide before buying your subs. You will likely have to sacrifice the last 2-3 clicks on your seat travel to give the box and subs enough space. In most cases, this will still leave you with plenty of legroom to drive comfortably while enjoying your new boom.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 52.00"
Height: 14.89"
Depth: 6.85"
Max Mounting Depth: 6.25"
Gross VolumePer Sub: 0.70
Net Volume Per Sub: 0.70
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 2007-2020 Chevrolet-Silverado or GMC-Sierra HD-Crew-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
New body style Silverado or GM Sierra CrewCabs. Custom downfire fit under rear seat, enclosure will only fit heavy duty crew cabs (1500, 2500, 3500).
Single 10" Vented Subwoofer Enclosure
Designed specifically for 2007-2020 Chevrolet-GMC Silverado / Sierra Crew Cab
Premium Carpet Finish
Underseat Upfire
No Modification is required
Easy drop-in installation
5.5" Mounting depth
Installation Note: Does not fit Xcab, New body style Silverado, or GMC Sierra CrewCabs. Custom down fire fit under the rear seat, the enclosure will only fit heavy-duty crew cabs (1500, 2500, 3500)
Specifications
Width
28.875
Height
6.75
Depth
17.75
Vent Width
1.37
Vent Height
5
Vent Depth
10
Mounting Depth
6.5
Gross Cubic Feet Per Side
1
Net Cubic Feet Per Side
0.83
HZ
39
Excursion
1.875
Single 12-Inch Vented Carpeted Subwoofer-Enclosure for Select 2007-2020 Chevrolet-Silverado or GMC-Sierra HD-Crew-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Installation Note: Does not fit Xcab, New body style Silverado or GM Sierra CrewCabs. Custom down fire fit under the rear seat, the enclosure will only fit heavy-duty crew cabs (1500, 2500, 3500)
Single 12" Vented Subwoofer Enclosure
Designed specifically for 2007-2020 Chevrolet-GMC Silverado / Sierra Crew Cab
Premium Carpet Finish
Underseat Upfire
No Modification is required
Easy drop-in installation
5.5" Mounting depth
Installation Note: Does not fit Xcab, New body style Silverado or GM Sierra CrewCabs. Custom down fire fit under the rear seat, the enclosure will only fit heavy-duty crew cabs (1500, 2500, 3500)
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width: 28.88"
Height: 4.50"
Depth: 17.75"
Max Mounting Depth: 6.50"
Gross VolumePer Sub: 1.50
Net Volume Per Sub: .95
Single 12-Inch Vented Tuff-Coat Lined Sub-Box for Select 2007-2020 Chevrolet-Silverado and GMC-Sierra Crew-Cab Trucks
Accu-Tuned 12” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2007-2020 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
1.7 Cubic Feet Gross and 0.83 Net Volume internal net air space are ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 9” which is ideal for full size and lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium Rugged Spray Liner for durability and enhanced airtight seal.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 6.5”, Width: 28.87”, Height: 6.75”, Depth: 17.75”
Specifications
Configuration: Single Vented
Finish: Tuff Coat Finish
Width: 28.88"
Height: 4.50"
Depth: 17.75"
Max Mounting Depth: 6.50"
Gross VolumePer Sub: 1.50
Net Volume Per Sub: .95
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2007-2013 Chevrolet-Silverado and GMC-Sierra Crew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Amplifier Mounting Location Built-In
Thickness: 0.625”
Cutout Diameter: 9.125”
Max Mounting Depth: 6.50”
Net Volume: .83 cu. Ft Per Sub
Installation Note: This amp space box makes installing your amp and subs simple, fast, and easy. Almost downright enjoyable. Just mount your amp on the shelf, run your wires and call it a day. The amp space is 14" wide by 17" long. Longer amps can actually run off the box in the back if needed. You can also drill thru the shelf to help hide some of the wires as shown to the left. Not only does this box look and fit great, but it adds a whole new dimension of functionality and usability.
Dual 12-Inch Sealed Carpeted Subwoofer-Enclosure With AMP Space for Select 2007-2013 Chevrolet-Silverado and GMC-Sierra Crew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 12” Dual sealed subwoofer enclosure with designated amp room designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2007 - 2013 Chevrolet / GMC Silverado / Sierra Crew Cab to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.83 Cubic Feet Net Volume internal air space per sub is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.5” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, Mounting Depth: 6.5”, Width: 52.5”, Height: 6.75”, Depth: 17.75”
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width: 52.50"
Height: 6.75"
Depth: 14.75"
Max Mounting Depth: 6.50"
Gross VolumePer Sub: 1.30
Net Volume Per Sub: .65
Installation Note: This amp space box makes installing your amp and subs simple, fast, and easy. Almost downright enjoyable. Just mount your amp on the shelf, run your wires and call it a day. The amp space is 14" wide by 17" long. Longer amps can actually run off the box in the back if needed. You can also drill thru the shelf to help hide some of the wires as shown to the left. Not only does this box look and fit great, but it adds a whole new dimension of functionality and usability.
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure With AMP Space for Select 2014-2018 Chevrolet-Silverado and GMC-Sierra Crew-Cab Truck
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2014-2018 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
Will work with some 2018 Legacy model vehicles
Mounting Depth For 10" subs = 6"
Volume: .6 cu.ft per chamber
Amp Space Area: 14" x 15" with box to floor clearance: 1.75"
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:52.50"
Height:4.50"
Depth:14.75"
Max Mounting Depth:6.50"
Gross VolumePer Sub:2.50
Net Volume Per Sub:1.69
Installation Note: Installs under the rear seat with no further modifications required. Rear seat functionality is un-affected
Dual 12-Inch Sealed Carpeted Subwoofer-Box With AMP Space for Select 2014-2018 Chevrolet-Silverado and GMC -Sierra Crew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 12” Dual sealed subwoofer enclosure with designated amp room designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2014-2018 Chevrolet / GMC Silverado / Sierra Crew Cab to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.85 Cubic Feet Net Volume internal air space per sub is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:52.50"
Height:4.50"
Depth:14.75"
Max Mounting Depth:6.50"
Gross VolumePer Sub:2.50
Net Volume Per Sub:1.69
Installation Note: Installs under the rear seat with no further modifications required. Rear seat functionality is un-affected
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2001-2013 Cadillac-Escalade and Chevrolet-Avalanche Vehicles
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Dual 10" Subwoofer Enclosure
Designed specifically for 2001-2013 Chevy Avalanche and Cadillac Escalade
Premium carpeted finish
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 5.5"
Box volume: 0.8 cubic feet (per chamber)
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:51.00"
Height:6.00"
Depth:14.63"
Max Mounting Depth:6.00"
Gross VolumePer Sub:1.25
Net Volume Per Sub:0.89
Factory Reverse Camera Wiring-Harness Adapter for Select 2008-2017 Cadillac, Chevy and GMC Vehicles
The AXBUCH-GM2 is designed to retain factory back up cameras to be viewed through the aftermarket radio.
Retains the factory backup camera to an aftermarket radio
Note: For use in 44-way connector vehicles that have OEM installed backup camera.
Applications
CADILLAC
CTS
2008-2014
CTS-V
2008-2014
Escalade
2012-2014
Escalade ESV
2012-2014
Escalade EXT
2012-2014
CHEVEROLET
Avalanche
2012-2013
Camaro
2010-2015
Equinox
2010-2017
Malibu
2013-2015
Silverado 2500 HD, 3500 HD, Chassis Cab
2014
Silverado
2012-2013
Suburban
2012-2014
Tahoe
2012-2014
GMC
Sierra 2500 HD, 3500 HD, Chassis Cab
2014
Sierra
2012-2013
Terrain
2010-2017
Yukon, Yukon XL
2012-2014
Yukon Denali, Yukon XL Denali
2012-2014
Axxess AXBUCH-GM2 Installation Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2014-2020 Buick, Chevrolet and GMC Vehicles
For use with the Axxess AXDSP-L line converter.
Applications
BUICK
Enclave
IO5 IO6
2018-2019
CHEVROLET
Colorado
IO5 IO6
2015-2019
Cruze
IO5 or IO6
2016-2018
Equinox
IO5 or IO6
2018-2018
Malibu
IP1
2016-2018
Silverado
IO3, IO5 or IO6
2014-2018
Silverado (LD)
IO5 or IO6
2019-2019
Suburban
2015-2020
Suburban
2015-2020
Tahoe
2015-2020
GMC
Canyon
IO5 or IO6
2015-2018
Sierra
IO3, IO5 or IO6
2014-2018
Sierra Limited
IO5 or IO6
2019-2019
Terrain
IO5 or IO6
2018-2018
Yukon
2015-2020
Axxess AXDSPH-GL9 ManualAxxess AXDSPL-GL9 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2019-UP Chevy and GMC Vehicles
For use with the Axxess AXDSP-L line converter.
Applications
CHEVEROLET
Blazer
IOT or IOU
2019-2023
Camaro
IOS or IOT
2019-2023
Cheyenne
IOS or IOT
2019-2021
Colorado (New Style)
IOS or IOT
2019-2022
Equinox
IOS or IOT
2019-2023
Malibu
IOU or IOS
2019-2022
Silverado
IOS or IOT
2019-2021
Traverse
IOS or IOT
2020-2022
GMC
Acadia
IOU
2020-2022
Canyon
IOS or IOT
2019-2022
Sierra
2019-2021
Terrain
IOS, IOT or IOU
2019-2022
Axxess AXDSPH-GM30 ManualAxxess AXDSPL-GM30 Manual
Add-On Amplifier OEM Integration Line Converter with DSP for Select 2006-2020 Buick, Cadillac, Chevrolet, GMC, Hummer and Saturn Vehicles
Upgrade the sound system with this cost-effective, easy-to-install DSP“Lite” package that includes a vehicle-specific T-harness. It works with OEM or aftermarket radios to take fixed level/digitally controlled analog audio and convert it to 6 channels of analog signal for use with an aftermarket amplifier or DSP.
Retain Features with a Built-in InterfaceWhile this may be a “Lite” version, it still provides retention of many important vehicle functions utilizing Axxess’s cutting-edge technology. It features chime control, retains OEM voice prompts and sonar sensors, and has clipping detection and limiting circuits, going beyond what a traditional DSP can do.
Complete Tuning ControlThere are 4 inputs and 6 outputs, including front, rear and subwoofer, and the front and rear outputs can be delayed independently up to 10ms. Full tuning control settings are adjusted via a smart device application for tablets or mobile phones and can be password-protected once set up. Once tuning has been completed, installers can password-protect their settings to prevent anyone else from adjusting, and the information is stored for future recall.
Designed for non-amplified models
Package includes the AXDSP-L and vehicle-specific T-harness
Selectable 15-band graphic EQ or 5-band Parametric EQ
Selectable high pass, low pass, or bandpass filters on each channel
4 inputs and 6 individually assignable outputs
Independent equalization for front, rear and sub
Selectable crossover slope (12, 24, 36, or 48db per octave)
Each channel can be delayed independently for up to 10ms
Easy behind the radio installation with pre-wired harness
Can be used with OE and aftermarket radios
Clipping detection and limiting circuits
Internal header port for adding interface modules
Bass knob included for level control of subwoofer amp
Settings adjusted via Bluetooth® in a smart device application (tablet or mobile phone) compatible with both Android and Apple devices
Read, write, and store configurations for future recall
Password-protect feature is available in the mobile app
Applications
BUICK
Enclave
2008-2017
Lucerne
2006-2011
CADILLAC
DTS
2006-2011
Escalade
2007-2011
SRX
2007-2009
CHEVROLET
Avalanche
2007-2011
Avalanche
Non-NAV
2012-2013
Captiva Sport
2012-2015
Equinox
2007-2009
Express
(-UYS)
2008-2015
Express
2016-2020
Impala
2006-2013
Impala Limited
2014-2016
Monte Carlo
2006-2007
Silverado
2007-2011
Silverado
Non-Nav
2012-2013
Silverado 2500 / 3500
Non-NAV
2014-2014
Suburban
2007-2011
Suburban
Non-NAV
2012-2014
Tahoe
2007-2011
Tahoe
Non-NAV
2012-2014
Traverse
2009-2016
GMC
Acadia
2007-2016
Acadia Limited
2017-2017
Savana
(-UYS)
2008-2015
Savana
2016-2020
Sierra
2007-2011
Sierra
Non-Nav
2012-2013
Sierra 2500 / 3500
Non-Nav
2014-2014
Yukon / XL
2007-2011
Yukon / XL
Non-NAV
2012-2014
HUMMER
H2
2008-2009
SATURN
Outlook
2007-2010
Vue
2008-2010
Axxess AXDSPL-GL1 Manual
Add-On Amplifier OEM Integration Line Converter with DSP for Select 2014-2020 Buick, Chevrolet and GMC Vehicles
Upgrade the sound system with this cost-effective, easy-to-install DSP“Lite” package that includes a vehicle-specific T-harness. It works with OEM or aftermarket radios to take fixed level/digitally controlled analog audio and convert it to 6 channels of analog signal for use with an aftermarket amplifier or DSP.
Retain Features with a Built-in InterfaceWhile this may be a “Lite” version, it still provides retention of many important vehicle functions utilizing Axxess’s cutting-edge technology. It features chime control, retains OEM voice prompts and sonar sensors, and has clipping detection and limiting circuits, going beyond what a traditional DSP can do.
Complete Tuning ControlThere are 4 inputs and 6 outputs, including front, rear and subwoofer, and the front and rear outputs can be delayed independently up to 10ms. Full tuning control settings are adjusted via a smart device application for tablets or mobile phones and can be password-protected once set up. Once tuning has been completed, installers can password-protect their settings to prevent anyone else from adjusting, and the information is stored for future recall.
Designed for non-amplified models only
Package includes the AXDSP-L and vehicle-specific T-harness
15-band graphic EQ or 5-band Parametric EQ
Selectable high pass, low pass, or bandpass filters on each channel
4 inputs and 6 individually assignable outputs
Independent equalization on each of the 6 outputs
Selectable slope (12, 24, 36, or 48db per octave)
Each channel can be delayed independently for up to 10 ms
Easy behind the radio installation in most applications
Can be used with OE and aftermarket radios
Clipping detection and limiting circuits
Internal header port for adding interface modules
Bass knob included
Retains OE voice prompts (OnStar®)
Retains factory chimes, including parking sensor and cross path detection alerts with adjustable chime level
Settings adjusted wirelessly in a smart device application (tablet or mobile phone)
Read, write, and store configurations for future recall
Password-protect feature is available in the mobile app
Applications
BUICK
Enclave
IO5 IO6
2018-2019
CHEVROLET
Colorado
IO5 IO6
2015-2019
Cruze
IO5 or IO6
2016-2018
Equinox
IO5 or IO6
2018-2018
Malibu
IP1
2016-2018
Silverado
IO3, IO5 or IO6
2014-2018
Silverado (LD)
IO5 or IO6
2019-2019
Suburban
2015-2020
Suburban
2015-2020
Tahoe
2015-2020
GMC
Canyon
IO5 or IO6
2015-2018
Sierra
IO3, IO5 or IO6
2014-2018
Sierra Limited
IO5 or IO6
2019-2019
Terrain
IO5 or IO6
2018-2018
Yukon
2015-2020
Axxess AXDSPL-GL9 Manual
Add-On Amplifier OEM Integration Line Converter with DSP and Factory-Amplifier Bypass-Harness for Select 2019-UP Factory Amplified and Non-Amplified GM Vehicles
The AXDSP-X offers installers a fast, cost-effective solution for improving the sound system with 10 individually assigned output channels, the ability to password-protect your settings, and an easy-to-use smartphone app. It has an onboard digital amplifier turn-on capability with built-in technology to retain many of the vehicle features commonly lost when installing a DSP.
Complete Tuning ControlInstallers will have full control to fine-tune each of the 10 channel outputs individually, controlled wirelessly via a free app available for smartphones and tablets. The app makes tuning easy with a 31-band graphic EQ and up to 10ms time delay for each channel, with independent high pass, low pass, and bandpass filters.
Retain Features with a Built-in InterfaceUtilizing Axxess’s data interface technology, the AXDSP-X goes beyond what a traditional DSP can do and retains many of the features commonly lost when upgrading a sound system. Voice prompts, parking sensor chimes, and other factory chimes are retained with an adjustable volume control that many traditional DSPs cannot offer. This is a cost-effective solution for customers who want to retain their factory radio and improve their vehicle sound quality, while still retaining systems like SYNC or OnStar®.
One Solution, Many ApplicationsThe AXDSP-X solution already works with a wide range of vehicle applications and systems, including OE or aftermarket radios, and fixed-level analog and/or digitally controlled amplified systems, in addition to non-amplified vehicles that do not have chimes. The AXDSP-X works with all the existing DSP T-harnesses and still offers the same easy installation behind the radio.
See the AXDSP-X application chart for up-to-date vehicle-specific information.
Designed for Ethernet amplifiers
Ethernet data interface included
AXDSP-X included
Includes an amp bypass harness
Retains factory chimes, including parking sensor chimes
Retains OnStar voice prompts
All chimes/voice prompts go through the aftermarket amp
Adjustable chime level
Micro “B” USB updatable
Applications
CADILLAC
XT4
Bose
2019-2023
CHEVROLET
Blazer
IOT or IOU & Bose
2019-2023
Camaro
IOS or IOT & Bose
2019-2023
Cheyenne
IOS or IOT & Bose
2019-2021
Colorado (New Style)
IOS or IOT & Bose
2019-2022
Corvette
2020-2023
Equinox
IOS or IOT & Bose
2019-2023
Malibu
IOU or IOS & Bose
2019-2022
Silverado
Bose
2022-2024
Silverado
IOS or IOT & Bose
2019-2021
Suburban
Bose
2021-2023
Tahoe
Bose
2021-2024
Traverse
IOS or IOT & Bose
2020-2022
GMC
Acadia
IOU & Bose
2020-2022
Acadia
IOU & Bose
2019-2019
Canyon
IOS or IOT & Bose
2019-2022
Sierra
Bose
2019-2024
Terrain
IOS, IOT or IOU & Bose
2019-2022
Yukon
Bose
2021-2024
Axxess AXDSPX-ETH1 Installation Manual
Add-On Amplifier OEM Integration Interface for Select 2019-UP Chevy and GMC Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Note: A single pole double throw (SPDT) relay is recommended when installing multiple amplifiers.
Contents
AXLOC-GM31 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications
CHEVEROLET
Camaro
IOR
2019-2023
Cheyenne
IOR
2019-2021
Colorado
IOR
2019-2022
Cruze
IOR
2019-2019
Equinox
IOR
2019-2022
Malibu
IOR
2019-2022
Silverado
IOR
2019-2022
Sonic
IOR
2019-2020
Spark
IOR
2019-2022
GMC
ACADIA
IOR
2020-Up*
Canyon
IOR
2019-Up*
Sierra
IOR
2019-Up*
SIERRA HD
IOR
2020-Up*
Terrain
IOR
2019-Up*
Axxess AXLOC-GM31 Manual
Add-On Amplifier OEM Integration Interface for Select 2010-2017 Chevy and GMC Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-GM44 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications
CHEVEROLET
Avalanche
with NAV
2012-2013
Camaro
non-amplified
2010-2015
Cruze
non-amplified
2011-2015
Equinox
non-amplified
2010-2017
Express
non-amplified
2013-2015
Malibu
non-amplified
2013-2015
Sonic
non-amplified
2012-2014
Spark
non-amplified
2013-2015
Suburban
IOR
2012-2014
Tahoe
non-amplified
2012-2014
Trax
non-amplified
2015-2016
GMC
Savanna
non-amplified
2013-2015
Terrain
non-amplified
2010-2017
Yukon/XL
With Nav without amp
2012-2014
Axxess AXLOC-GM44 Manual
Add-On Amplifier OEM Integration Interface for Select 2006-2012 Chevy, Pontiac and Saturn Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-GMLN1 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications
CHEVY
Cobalt
non-amplified
2007-2010
HHR
non-amplified
2006-2011
Malibu
non-amplified
2008-2012
PONTIAC
G5
non-amplified
2007-2009
G6
non-amplified
2009-2012
Solstice
non-amplified
2006-2009
SATURN
Aura
non-amplified
2007-2009
Sky
non-amplified
2007-2009
Axxess AXLOC-GMLN1 Manual
Add-On Amplifier OEM Integration Interface for Select 2016-2020 Non-Amplified Chevy and GMC Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-GM10 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications
CHEVEROLET
Camaro ‡
2016-2018
Colorado ‡
2016-2018
Cruze †
2016-2018
Equinox ‡
2018-2018
Malibu †
2016-2018
Silverado 1500 LD ‡
2019-2019
Silverado 1500 ‡
2016-2018
Silverado 2500 HD/3500 HD ‡
2016-2019
Trax †
2017-2020
GMC
Acadia ‡
2017-2019
Canyon ‡
2017-2018
Sierra 1500 ‡
2016-2018
Sierra Limited ‡
2019-2019
Sierra 2500 HD/3500 HD ‡
2016-2019
† RPO IOA‡ RPO IOB
Axxess AXLOC-GMLN10 Manual
Overhead Monitor Video Retention Wiring-Harness Adapter for Select 2012-2014 Cadillac, Chevy and GMC Vehicles
Retains the A/V-IN jack (if applicable)
Provides A/V output to the factory installed rear seat overhead entertainment system (1)
Designed for models that have a DVD player built into the factory radio
(1) Only applicable for models with a second row RSE
Applications
CADILLAC
Escalade
2012-2014
Escalade ESV
2012-2014
Escalade EXT
2012-2014
CHEVY
Avalanche
2012-2013
Silverado 2500 HD, 3500 HD, Chassis Cab
2014
Silverado
2012-2013
Suburban
2012-2014
Tahoe
2012-2014
GMC
Sierra 2500 HD, 3500 HD, Chassis Cab
2014
Sierra
2012-2013
Yukon, Yukon XL
2012-2014
Yukon Denali, Yukon XL Denali
2012-2014
Axxess AXRSEH-G2 Installation Manual
Add-On Amplifier OEM Integration Interface for Select 2021-UP Buick, Chevy and GMC Vehicles
This add-a-sub interface is installed at the radio location and features a 2-channel non-fading 5V RMS output, a fixed low pass frequency of 234Hz, and 250mA remote turn-on output. It includes a bass knob & vehicle-specific harness for easy installation and customization.
Interface Features:
2 Channel non-fading 5V RMS output
Fixed low pass frequency of 234Hz
250mA remote turn-on output
Designed for non-amplified vehicles
Bass knob & vehicle-specific harness included
Install done at radio location
Micro USB updateable
Applications
BUICK
Envision
IOS or IOU
2022-2023
CHEVROLET
Cheyenne 1500
IOK non-amplified
2022-2024
Colorado (New Style)
Non-amplified
2023-2024
Silverado 1500
IOK non-amplified
2022-2024
Silverado 2500/3500
IOK non-amplified
2024-2024
Suburban
IOK non-amplified
2021-2024
Tahoe
Non-amplified
2021-2024
GMC
Canyon
non-amplified
2023-2024
Sierra 1500
IOK non-amplified
2023-2024
Sierra 2500/3500
IOK non-amplified
2024-2024
Yukon
Non-amplified
2021-2024
Axxess AXSUB-GM5 Installation Manual
