Box Width 13.25"
JL Audio CP110LG-TW1-2 : 10" Thin Subwoofer Enclosure, 300W RMS 2Ω Ported
MicroSub-Series 10-Inch 300-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure This incredible MicroSub™ subwoofer system delivers the kind of output and extension that is normally possible with only much larger systems. The key to its performance lies in the precise tuning of its 10TW1 subwoofer driver into an efficient slot-ported design. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port. This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver. Construction: CNC-Cut High-Grade MDF Recommended amplifier power: 75 - 300WNominal Impedance: 2 Ω General Specifications Continuous Power Handling (RMS) 300 W System Nominal Impedance 2 Ω Enclosure Type Slot-ported, Low-profile Finish Black carpet Grille Included Black Steel Mesh Physical Specifications External Width (W) 20.875 in / 530 mm External Height (H) 13.25 in / 337 mm External Depth (D1) 6.375 in / 162 mm Net Weight 25.70 lb / 11.66 kg JL Audio CP110LG-TW1-2 Brochure
Kicker 48TRTP102 : 400W Dual 10" Thin Subwoofer Enclosure
Dual 10-Inch Thin Subwoofer Enclosure, 400-Watt RMS, 2-Ohm The Kicker CompRT series down-firing 10-inch subwoofer enclosure comes loaded with a passive reFLEX™ subwoofer and Kicker CompRT sub, then carpeted and loaded with a single 2Ω terminal. Covered in stylish black carpeting and built with thick MDF, these tough enclosures take serious power without taking up needed space. The TRTP 10-inch subwoofer enclosure works best with 400-watts of recommended power. Specifications TYPE: thin-profile WOOFER SIZE (in, cm): 10, 25 IMPEDANCE (Ohms): 2 Recommended Amplifier Power (watts RMS) 400 Peak Power (watts, per ANSI/CTA-2031-A) 800 SENSITIVITY (dB 1w/1m): 96.5 BOX TOP DEPTH (in, cm): 13-1/4, 33.5 BOX BOTTOM DEPTH (in, cm): 13-1/4, 33.5 BOX HEIGHT (in, cm): 5-5/8, 14.2 BOX WIDTH (in, cm): 25-5/8, 65 Kicker TRTP Subwoofer Enclosure Manual
