Box Width 15.75"

TW1-Series 400-Watt Amplified 12-Inch Ported Subwoofer System With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency. Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 12TW1 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port. Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems. Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage. Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver. Construction: CNC-Cut High-Grade MDF Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω Enclosure and Subwoofer Built in USA with global components General Specifications Continuous Power Handling (RMS) Built-in amplifier 400 W @ 0.25 Ω System Nominal Impedance 0.25 Ω Input Voltage Range @ RCA Inputs 70 mV - 1.40 V RMS Input Voltage Range @ High-Level Inputs 280 mV - 5.4 V RMS Recommended Copper Power / Ground Wire Gauge 8 AWG wire Fuse Rating 30 A (ATO or ATC) Enclosure Type Slot-ported, Low-profile Finish Black carpet Grille Included Black Steel Mesh JL Audio MicroSub+/PowerWedge+ Manual

Read more less

MicroSub-Series 12-Inch 300-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure This incredible MicroSub™ subwoofer system delivers the kind of output and extension that is normally possible with only much larger systems. The key to its performance lies in the precise tuning of its 12TW1 subwoofer driver into an efficient slot-ported design. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port. This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver. Construction: CNC-Cut High-Grade MDF Recommended amplifier power: 75 - 300WNominal Impedance: 2 Ω General Specifications Continuous Power Handling (RMS) 300 W System Nominal Impedance 2 Ω Enclosure Type Slot-ported, Low-profile Finish Black carpet Grille Included Black Steel Mesh Physical Specifications External Width (W) 23.75 in / 603 mm External Height (H) 15.751 in / 400 mm External Depth (D1) 9.25 in / 235 mm Net Weight 38.3 lb / 17.37 kg JL Audio CP112LG-TW1-2 Brochure

Read more less

PowerWedge-Series 12-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure In this low-profile PowerWedge™ subwoofer system, JL harnesses the performance of the 12TW3 to deliver amazing sub-bass from an enclosure that is only 4.5 in. (114 mm) deep. This low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12TW3-D4 and has been fine-tuned through extensive real-world listening. The PowerWedge™ subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver. Construction: CNC-Cut High-Grade MDF Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω General Specifications Continuous Power Handling (RMS) 400 W System Nominal Impedance 2 Ω Enclosure Type Sealed Finish Black carpet Grille Included Black Steel Mesh Physical Specifications External Width (W) 23.75 in / 603 mm External Height (H) 15.625 in / 397 mm External Depth (D1) 5.0625 in / 129 mm Net Weight 30.5 lb / 13.8 kg JL Audio CS112LG-TW3 Brochure

Read more less

PowerWedge-Series 13-Inch 600-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure The 13TW5v2 low-profile subwoofer driver has received awards from around the world for its breakthrough performance capabilities in impossibly tight spaces. In this sealed Truck PowerWedge™ subwoofer system, JL harnessed the performance of this patented subwoofer driver to deliver amazing sub-bass performance from an enclosure that is only 7.25 in. (184 mm) deep at its base and 4.5 in. (114 mm) at the top. This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 13TW5v2 and has been fine-tuned through extensive real-world listening. This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver. Construction: CNC-Cut High-Grade MDF Recommended amplifier power: 250 - 600WNominal Impedance: 2 Ω General Specifications Continuous Power Handling (RMS) 600 W System Nominal Impedance 2 Ω Enclosure Type Sealed, truck enclosure Finish Black carpet Grille Included Black Steel Mesh Physical Specifications External Width (W) 21.25 in / 540 mm External Height (H) 15.75 in / 400 mm External Depth (D1) 7.25 in / 184 mm External Top Surface Depth (D2) 4.5 in / 114 mm Net Weight 34 lb / 15.42 kg JL Audio CS113TG-TW5v2 Brochure

Read more less
