Alpine Advanced Bluetooth Mechless Receiver
With advanced Bluetooth® wireless technology, audio streaming, and FLAC support, the UTE-73BT mech-less digital receiver delivers quality phone calls and playback of various digital music files so you stay in touch and in tune.
This one-stop music player has an LCD display with one-line, RGB illumination for your choice of display color. The new high-contrast LCD display has five times the contrast of a conventional screen, so the display is always easy to read.
Alpine's signature rotary knob makes controlling all your music a breeze. This unit also comes with a convenient front panel auxiliary input - so you or your passenger can plug in a portable media player as an additional source.
The UTE-73BT uses a 24-Bit DAC for ultimate sound quality with all your digital media sources. The 3-band parametric EQ and high pass/low pass crossover lets you do fine-tune your sound system. The UTE-73BT can playback FLAC (Free Lossless Audio Codec) files via USB, for a more accurate listening experience.
Don’t get caught holding your phone while driving. The UTE-73BT is equipped with Bluetooth wireless technology so you can carry on your phone conversations without additional adapters or headpieces.
To bring sound balance to your hands-free experience, you can adjust the UTE-73BT’s mic gain, phone output and ringtone volume. If that’s not enough, there are two sound quality settings to choose from to get the balance just right for you. This flexibility will make your phone calls a pleasurable experience.
Specifications
50W x 4 High Power Amp
Built-in Bluetooth Module
BT Audio Streaming
Works with Pandora Music
Mech-less
FLAC/MP3/WMA/AAC Playback
Front USB port
Made for iPod and iPhone (requires KCU-445i)
Siri Eyes Free Mode
Android Open Accessory 2.0
Front AUX Input (3.5mm mini jack)
3-Band Parametric EQ
High-pass/Low-pass Filter
24-Bit DAC
Steering Wheel Remote Control Ready
KTP-445A Power Pack Ready
3 PreOuts (2V)
Hands-free Microphone Included
RGB Lighting
Bass Engine SQ
Radio Broadcast Data System (RBDS) Text Information
Alpine UTE-73BT Manual
Digital CD Receiver with Pioneer Smart-Sync App-Compatibility, Mixtrax, Bluetooth, HD-Radio and SiriusXM-Ready
Pandora is personalized internet radio that is designed to help you discover new music that you'll love mixed in with music that you already know. With the MVH-S720BHS, you can enjoy superior sound quality and full control of the Pandora experience in your car directly from the display of the receiver. You are able to give tracks "thumbs up" or "thumbs down", bookmark a song so you can purchase it later, easily switch between your personalized radio stations, and view full track data and album art. Pandora is compatible with Apple iOS, as well as Android devices that support the Bluetooth Serial Port Profile (SPP). Simply download the free Pandora Radio app to your iPhone or Android device, connect to the MVH-S720BHS and take your music to the next level.
Stay safe and obey local hands-free laws with built-in bluetooth (HFP). Easily pair a bluetooth enabled phone to the MVH-S720BHS without having to go through complicated settings. When a registered bluetooth device is in proximity to the receiver, the auto connection function automatically pairs the two units.
From hands-free calling, wireless audio streaming (A2DP) with artist, album, and song search, simple pairing, and control audio (AVRCP profile), bluetooth wireless technology has made life in the vehicle much more convenient.
The MVH-S720BHS with bluetooth also includes superior call quality reception using Wideband Speech Handsfree Profile 1.6. Wideband Speech nearly doubles the bandwidth of frequencies of a normal bluetooth call (when compared to calls without Wideband Speech).
Spotify gives you all the music you'll ever need. Find the songs you love instantly, or let Spotify play you something great. With support for Spotify, just connect your compatible smartphone to a Pioneer car stereo receiver to fill your ride with everything from classic tracks to the latest hits. Premium subscription may apply.
Integrate Your Smartphone with Your receiver. Pioneer Smart Sync is a highly evolved app available for both iOS and Android OS that utilizes the power of a connected smartphone to expand the features and user interface of compatible Pioneer in-dash receivers. With support for either a bluetooth or USB connection, the link between your smartphone and the in-dash receiver can be either wired or wireless.
Compatible Apps are Just a Tap Away
Say goodbye to complicated user interfaces. With your compatible apps just a tap away, your drive will be much smoother. In addition, Pioneer Smart Sync v4.3 enables you to keep up with your vehicle information including engine performance, live data, and more. Pioneer Smart Sync provides you with intuitive app-based features like:
Alexa Built-in
Maps
Voice Messaging
Music
Monitor Vehicle Performance** Optional OBD-II device required.
With built-in Bluetooth wireless technology, the DEH-S7200BHS provides the ability to utilize the voice recognition engine that is part of the operating system on a user’s smartphone. This feature is compatible with iOS devices that have voice recognition capability.
Users with an iPhone® 4s or newer can take advantage of Siri® Eyes Free functionality with a touch of a button. When activated, Siri voice prompts play through the vehicle’s speakers and the user’s commands and questions are received and transmitted to the receiver using the external microphone. Siri Eyes Free provides access to many iPhone functions such as music selection, making phone calls and listening to text messages, calendar information, and reminders.
The MVH-S720BHS features a built-in HD Radio tuner allowing you to enjoy your radio in an all-new way. With HD Radio, you can listen to the radio in the same unmatched fidelity as your digital music. Your FM stations now with CD-quality sound, AM stations now with FM-quality sound, and crystal-clear reception with no audio distortion. Discover new music and content with multi-cast programming available on select stations – all 100% subscription free!
The MVH-S720BHS is SiriusXM- Ready so you can get over 140 channels, including commercial-free music, plus the best sports and live events, comedy, news, exclusive talk and entertainment. SiriusXM programming is received through the SiriusXM Connect Vehicle Tuner (sold separately, SiriusXM subscription required).
Specifications
Continuous Power Output 22 W x 4-Channel
Load Impedence Allowance 4 Ohm (4 Ohm to 8 Ohm Allowable)
Max Power Output 50 W x 4-ch 4 ohm / 50 W x 2-ch 4 ohm 70 W X 1-ch (subwoofer) 2 Ohm
RCA Preamp Outputs 6-ch
RCA Preout Voltage 4V
RMS Power Output (CTA-2006) 14 W RMS x 4-ch 4 ohm
Back Light LED
Brightness Control Yes
Color Customization 210000 Colors, dual zone
Device (Non-DIN/Modular Unit) 1-DIN
Device Display VA LCD (2-Line)
Dimmer Automatic with vehicle illumination, Timer Controlled, Manual
Advanced Audio Distribution Profile (A2DP) Yes
AVRCP 1.6
Built-in Bluetooth® Yes
Dual Phone Connection Yes
Hands Free Version 1.6
Hands-Free Yes
Microphone Included
Phone Registation 5-phone
Secure Simple Pairing (SSP) Yes
Serial Port Profile (SPP) Yes
Sound Retriever Air Mode 1/Mode 2/Off
Best Station Memory Yes
HD Radio™ Built In / Multicasting
Local Seek tuning Yes
Presets 18 FM, 6 AM
RDS Yes
SiriusXM-Ready™ (Tuner Sold Separately) Yes
Amazon Alexa Paired with Pioneer Smart Sync
Mobile Operating System Android / Apple iOS
Pandora® Source through iPhone/Android
Pioneer App Compatibility Pioneer Smart Sync Android, Pioneer Smart Sync iPhone
Siri® Eyes Free (VR) (Internet Required) iPhone Only
Spotify Streaming audio through iPhone/Android via Bluetooth or AUX input
Voice Control Yes
Audio Playback via CD AAC Audio Playback / MP3 Audio Playback / WAV Audio Playback / WMA Audio Playback
Audio Playback via USB MP3 Audio Playback / WMA Audio Playback / AAC Audio Playback / FLAC Audio Playback (Hi-Res) / WAV Audio Playback (Hi-Res)
Advanced Sound Retriever Mode-1/Mode-2/Off
Auto EQ (CD-MC20 Microphone sold separately) Yes
Balance Yes
Built-in Amplifier MOSFET 50 W x 4
Crossover Network Mode HPF/Band Pass/LPF
Crossover Standard Mode HPF/LPF
Customizable Graphic Equalizer 13 Band, 31 Band with Pioneer Smart Sync app
DA Converter 24 Bit
Digital Signal Processor Built In
Dynamic Bass Enhancer Off/Low/High
Easy EQ (EEQ) Preset Equalizer Yes
FadeYes
Listening Position Selector Yes
Loudness High/Mid/Low/Off
MIXTRAX® Yes
Source Level Adjuster Yes
Speaker Output 4-ch
Spectrum Analyzer Yes
Subwoofer Control Yes
Time Alignment Manual
USB Front Type-A (5V, 1-1/2 A)
USB Direct Control for iPhone® 5s and newer
Input 1 AUX (Minijack)
Detachable Face Security Full
Multi-Language Display English, French, Spanish
Music Browser USB / With Smart Sync App
Remote Control Optional
Rotary Volume Control Yes
Steering Wheel Control Ready (Adapter Sold Separately) Yes
Pioneer DEH-S7200BHS Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2016-2020 Mercedes-Metris and 2007-2020 Sprinter Vans
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio utilizing our patented quick-release, snap-in ISOmount system with custom trim ring
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes mounting brackets with detailed installation instructions
A tech support number is available for installation help 7 days a week
Applications
DODGE
Sprinter
2007-2009
FREIGHTLINER
Sprinter
2007-2018
MERCEDES
Metris
2016-2020
Sprinter
2010-2018
Metra 99-6512 Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 1990-2012 Buick, Cadillac, Chevy, GMC, Honda, Hummer, Isuzu, Oldsmobile, Pontiac, Suzuki and Toyota Vehicles
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
BUICK
Century
1997-2005
LeSabre
1995-2005
Park Avenue
1995-2005
Rainier
2004-2007
Regal
1995-2004
Rendezvous
2002-2007
Riviera
1996-1999
Roadmaster
1995-1996
Skylark
1996-1998
CADILLAC
Brougham
1990-1992
Eldorado
1992-1995
Escalade
2003-2006
Escalade ESV
2003-2006
Escalade EXT
2003-2006
Fleetwood
1993-1995
Fleetwood Brougham
1990-1992
Seville
1992-1995
CHEVY
Avalanche
2003-2006
Cavalier
2000-2005
Classic (a.k.a. Malibu)
2004-2005
Colorado
2004-2012
Express
2001-2007
Impala
2000-2005
Kodiak C4500-8500
2003-2009
Malibu
2001-2003
Metro
1995-2001
Monte Carlo
2000-2005
S-10 Blazer
2002-2005
S-10 Pickup
2002-2004
Silverado Classic
2007
Silverado
2003-2006
SSR
2003-2006
Suburban
2003-2006
Tahoe
2003-2006
Tracker
1998-2004
Trailblazer
2002-2009
Venture
2000-2005
GEO
Metro
1991-1997
Tracker
1992-1997
GMC
Canyon
2004-2012
Envoy
2002-2009
Savana
2001-2007
Sierra Classic
2007
Sierra
2003-2006
Sonoma
2002-2004
Topkick C4500-8500
2003-2009
Yukon, Yukon XL
2003-2006
Yukon Denali, Yukon XL Denali
2003-2006
HONDA
Passport
1998-2002
HUMMER
H2
2003-2007
ISUZU
Ascender
2003-2008
Amigo
1998-2000
I-290, I-370
2007-2008
I-280, I-350
2006
Rodeo
1998-2004
Rodeo Sport
2001-2003
OLDSMOBILE
Achieva
1996-1998
Alero
1999-2004
Aurora
1995-2003
Bravada
1998-2004
Cutlass
1997-1999
Cutlass Supreme
1995-1997
Eighty-Eight
1994-1999
Intrigue
1998-2002
LSS
1996-1999
Ninety-Eight
1994-1996
Regency
1997-1998
Silhouette
2000-2004
PONTIAC
Aztec
2001-2005
Bonneville
2000-2005
Grand Am
2001-2005
Montana
2000-2005
Sunfire
2000-2005
SUZUKI
Aerio Sedan
2002
Aerio 5-door
2002
Esteem
1995-2003
Grand Vitara
1999-2002
Sidekick
1992-1998
Swift
1992-1994
Vitara
1999-2004
XL-7
2001-2002
TOYOTA
Matrix
2003-2004
Metra 99-2011 Installation Manual
Digital Mechless Receiver with Pioneer Smart-Sync App-Compatibility, Mixtrax, Bluetooth, HD-Radio and SiriusXM-Ready
Pandora is personalized internet radio that is designed to help you discover new music that you'll love mixed in with music that you already know. With the MVH-S720BHS, you can enjoy superior sound quality and full control of the Pandora experience in your car directly from the display of the receiver. You are able to give tracks "thumbs up" or "thumbs down", bookmark a song so you can purchase it later, easily switch between your personalized radio stations, and view full track data and album art. Pandora is compatible with Apple iOS, as well as Android devices that support the Bluetooth Serial Port Profile (SPP). Simply download the free Pandora Radio app to your iPhone or Android device, connect to the MVH-S720BHS and take your music to the next level.
Stay safe and obey local hands-free laws with built-in bluetooth (HFP). Easily pair a bluetooth enabled phone to the MVH-S720BHS without having to go through complicated settings. When a registered bluetooth device is in proximity to the receiver, the auto connection function automatically pairs the two units.
From hands-free calling, wireless audio streaming (A2DP) with artist, album, and song search, simple pairing, and control audio (AVRCP profile), bluetooth wireless technology has made life in the vehicle much more convenient.
The MVH-S720BHS with bluetooth also includes superior call quality reception using Wideband Speech Handsfree Profile 1.6. Wideband Speech nearly doubles the bandwidth of frequencies of a normal bluetooth call (when compared to calls without Wideband Speech).
Spotify gives you all the music you'll ever need. Find the songs you love instantly, or let Spotify play you something great. With support for Spotify, just connect your compatible smartphone to a Pioneer car stereo receiver to fill your ride with everything from classic tracks to the latest hits. Premium subscription may apply.
Integrate Your Smartphone with Your receiver. Pioneer Smart Sync is a highly evolved app available for both iOS and Android OS that utilizes the power of a connected smartphone to expand the features and user interface of compatible Pioneer in-dash receivers. With support for either a bluetooth or USB connection, the link between your smartphone and the in-dash receiver can be either wired or wireless.
Compatible Apps are Just a Tap Away
Say goodbye to complicated user interfaces. With your compatible apps just a tap away, your drive will be much smoother. In addition, Pioneer Smart Sync v4.3 enables you to keep up with your vehicle information including engine performance, live data, and more. Pioneer Smart Sync provides you with intuitive app-based features like:
Alexa Built-in
Maps
Voice Messaging
Music
Monitor Vehicle Performance** Optional OBD-II device required.
The MVH-S720BHS features a built-in HD Radio tuner allowing you to enjoy your radio in an all-new way. With HD Radio, you can listen to the radio in the same unmatched fidelity as your digital music. Your FM stations now with CD-quality sound, AM stations now with FM-quality sound, and crystal-clear reception with no audio distortion. Discover new music and content with multi-cast programming available on select stations – all 100% subscription free!
The MVH-S720BHS is SiriusXM- Ready so you can get over 140 channels, including commercial-free music, plus the best sports and live events, comedy, news, exclusive talk and entertainment. SiriusXM programming is received through the SiriusXM Connect Vehicle Tuner (sold separately, SiriusXM subscription required).
Specifications
Continuous Power Output 22 W x 4-Channel
Load Impedence Allowance 4 Ohm (4 Ohm to 8 Ohm Allowable)
Max Power Output 50 W x 4-ch 4 ohm / 50 W x 2-ch 4 ohm + 70 W X 1-ch (subwoofer) 2 Ohm
RCA Preamp Outputs 6-ch
RCA Preout Voltage 4V
RMS Power Output (CTA-2006) 14 W RMS x 4-ch 4 ohm
Back Light LED
Brightness Control Yes
Color Customization 210000 Colors, dual zone
Device (Non-DIN/Modular Unit) 1-DIN
Device Display VA LCD (2-Line)
Dimmer Automatic with vehicle illumination, Timer Controlled, Manual
Advanced Audio Distribution Profile (A2DP) Yes
AVRCP 1.6
Built-in Bluetooth® Yes
Dual Phone Connection Yes
Hands Free Version 1.6
Hands-Free Yes
Microphone Included Included
Phone Registation 5-phone
Secure Simple Pairing (SSP) Yes
Serial Port Profile (SPP) Yes
Sound Retriever Air Mode 1/Mode 2/Off
Best Station MemoryY es
HD Radio™ Built In / Multicasting
Local Seek tuning Yes
Presets 18 FM, 6 AM
RDS Yes
SiriusXM-Ready™ (Tuner Sold Separately) Yes
Amazon Alexa Paired with Pioneer Smart Sync
Mobile Operating System Android / Apple iOS
Music Playback (MTP) Yes
Pandora® Source through iPhone/Android
Pioneer App Compatibility Pioneer Smart Sync Android, Pioneer Smart Sync iPhone
Siri® Eyes Free (VR) (Internet Required) iPhone Only
Spotify Streaming audio through iPhone/Android via Bluetooth or AUX input
Voice Control Yes
Audio Playback via USB MP3 Audio Playback / WMA Audio Playback / AAC Audio Playback / FLAC Audio Playback (Hi-Res) / WAV Audio Playback (Hi-Res)
Advanced Sound Retriever Mode-1/Mode-2/Off
Auto EQ (CD-MC20 Microphone sold separately)Yes
Balance Yes
Built-in Amplifier MOSFET 50 W x 4
Crossover Network Mode HPF/Band Pass/LPF
Crossover Standard Mode HPF/LPF
Customizable Graphic Equalizer 13 Band, 31 Band with Pioneer Smart Sync app
DA Converter 24 Bit
Digital Signal Processor Built In
Dynamic Bass Enhancer Off/Low/High
Easy EQ (EEQ) Preset Equalizer Yes
FadeYes
Listening Position Selector Yes
Loudness High/Mid/Low/Off
MIXTRAX® Yes
Source Level Adjuster Yes
Speaker Output 4-ch
Spectrum Analyzer Yes
Subwoofer Control Yes
Time Alignment Manual
USB Front Type-A (5V, 1.5 A)
USB Direct Control for iPhone® 5s and newer
Input 1 AUX (Minijack)
Detachable Face Security Full
Multi-Language DisplayEnglish, French, Spanish Portuguese, Chinese (Simplified)
Music Browser USB / With Smart Sync App
Remote Control Optional
Rotary Volume Control Yes
Steering Wheel Control Ready (Adapter Sold Separately) Yes
Pioneer MVH-S720BHS Manual
DIN or DDIN-Size Head-Unit Replacement Dash Kit for Select 2008-2022 Toyota-Sequoia and Tundra Vehicles
This stereo installation kit has been engineered to help you install either a 2" tall (Single-DIN) or a 4" tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement easier and comes with a pocket that is installed below the 2" radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4" tall radio. The dash kit is painted high gloss black to match the original look and feel of the vehicle's dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn't offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2" or 4" tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
TOYOTA
Sequoia
2008-2022
Tundra
2007-2013
Metra 99-8220 Installation Manual
Mechless DIN-Size Weather-Resistant Bluetooth Receiver featuring a 3" Color Display
Receivers and amplifiers for marine and motor sports applications need to perform in harsh environments exposed to outdoor elements. JVC’s marine and motor sports receivers and amplifiers feature compact size for versatile installation even in tight spaces. Conformal coated main PCBs (printed circuit boards) offer additional protection against moisture and condensation from damaging the product.
A conformal coating is a protective chemical coating to safeguard electronic circuits from harsh environments that may contain moisture or chemical contaminants. It provides a barrier to airborne contaminants from the operating environment, such as salt-spray, thus preventing corrosion.
Linked with a back gear, the display automatically switches to the view from the rear camera.
With an optional rear camera connected, you can check the backward situation any time by just pressing the "CAMERA" key.
In addition to repeat and random playback of music files, you can also easily search for songs using the browsing function. Just look for and choose the song you want to hear from the folder name and song name lists.
With 9-Preset EQ patterns to choose from, it's easy to create the sound you like, based on musical genre or your personal preference. What's more, with 13-band Graphic EQ you can set the levels of Bass, Mid and High individually to finely adjust the sound and further optimize your listening environment.
By setting the time delay on each speaker, the receiver will automatically adjust the timing of the sound output from each of the speakers so that the sound from each of the speakers will arrive exactly at the same time to the listening position.
The reduced depth of the chassis contributes to a weight reduction and facilitates easier installation.
IPX7 Waterproof wired remote control (RM-RK62M) is optionally available.
DIN-Size Head-Unit Replacement Dash-Kit for Select 2007-2020 Chrysler, Dodge, Jeep, Mitsubishi, RAM and Volkswagen Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN or ISO Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
CHRYSLER
200
2011-2014
300
2008-2010
300C
2008-2010
Aspen
2008-2009
Sebring
2007-2010
Town & Country
2008-2017
DODGE
Avenger
2008-2014
Caliber
2009-2012
Caravan
2008-2020
Challenger
2008-2014
Charger
2008-2010
Dakota
2008-2011
Durango
2008-2009
Grand Caravan
2009-2020
Journey
2009-2010
Magnum
2008-2009
Nitro
2007-2011
Ram Pickup 1500
2009-2011
Ram Pickup 2500, 3500
2010-2011
Ram Pickup Chassis Cab 4500, 5500
2011-2012
JEEP
Commander
2008-2010
Compass
2009-2017.5
Grand Cherokee
2008-2010
Liberty
2008-2012
Patriot
2009-2017
Wrangler, Wrangler Unlimited
JK
2018
Wrangler, Wrangler Unlimited
2007-2017
MITSUBISHI
Raider
2008-2009
RAM
1500, 2500, 3500
2012
Chassis Cab 2500, 3500, 4500, 5500
2012
C/V Tradesman
2012-2015
VOLKSWAGEN
Routan
2009-2013
Metra 99-6511 Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 1984-2004 Toyota Vehicles
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Three different size trim rings are included to accommodate a variety of radios and dash openings
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
TOYOTA
4Runner
1984-2002
Camry
1987-1991
Celica
1986-1993
Corolla
1988-1997
MR2
1991-1995
Pickup
1984-1995
Supra
1986.5-1992
T-100
1993-1998
Tacoma
1995-2004
Metra 99-8104 Installation Manual
Alpine Din-Size Halo Aftermarket Stereo with 11" Touchscreen, Hi-Resolution Audio, Wireless Apple-CarPlay Android-Auto, and iDatalink Compatibility, GPS Upgradeable
The Next-Gen Alpine Halo11 features Apple CarPlay, Android Auto, and built-in Bluetooth hands-free which allow access to music, messages, phone calls, and maps on a smartphone via either a wired USB connection or wirelessly. Get even more entertainment options with built-in HD Radio, Pandora Internet Radio (via iPhone or Android connection), and SiriusXM for even more choices in entertainment (tuner and subscription sold separately).
Experience incredible music detail with Hi-Res Audio Playback. High-precision music reproduction brings out the full potential of every song and makes every drive feel like an intimate recording studio session with your favorite artist. Access your favorite songs on popular Hi-Res streaming services like Apple Music, Tidal, Amazon Music, HD and more. The Alpine Halo11 plays Hi-Res music at it's intended spec of 96kHz/24Bit via a wired USB connection to a smartphone or wirelessly through Bluetooth connection. You can also purchase and download Hi-Res music files onto a USB drive from platforms like HD-Tracks and plugs directly into the Alpine Halo11 for Hi-Res playback.
The iLX-F511 Works with Apple CarPlay wirelessly and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay® is accessed through the capacitive touchscreen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later.
The iLX-F511 includes Android Auto wirelessly and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices, and reply to text messages – hands- free.
The Alpine Halo11 has on-board tuning features including a 13-band parametric EQ per channel, for continuous frequency control. The 6-channel time correction ensures that music is staged properly in the front and center of the vehicle. If more power is needed, additional amplifiers can be added using the three sets of true 4V preamp outputs with front, rear, and subwoofer control.
Experience music as the artist originally intended with the industry’s first full TIDAL integration. The iLX-F511 allows you to access select TIDAL features directly on the head unit and receive a high-res streaming experience with the TIDAL catalog of over 90 million songs. Lossless audio and high-fidelity music options are also available for TIDAL HiFi and HiFi Plus Members, for superior sound quality that elevates the music experience. A TIDAL subscription is required and sold separately. To access TIDAL on the Alpine Head Unit, the head unit must be tethered to a mobile or smartphone hotspot. Data rates may apply.
The screen is attached to an adjustable mount on a single-DIN chassis that’s designed to fit in most dash openings. Once the unit is installed, the screen has five vertical adjustments and two separate depths that lock into position for a sturdy installation. A new pressure tilt mechanism allows for more flexibility when positioning the screen for optimized viewing and access to dash and HVAC controls.
The Alpine Halo11 is compatible with the iDatalink Maestro Module (sold separately) to retain and display vehicle information on the extra large, 11-inch screen. Information such as steering wheel controls, tire pressure, and engine codes, and HVAC control may be accessible from the ILX-F511 (information will vary by vehicle).
The Alpine Halo11 includes two camera inputs to add a front, side, or rearview camera (sold separately). The rearview camera includes a distance guide display that overlays guidelines onto the screen for ease when moving in reverse.
Take driving safety even further by connecting your Alpine Halo11 with the DVR-C320R Premium 1080P Front and Rear Dash Camera with built-in drive assist (sold separately). View real-time and recorded drives in high definition on your Alpine Halo11, plus receive drive assist features that help get you to your destination.
The new RUX-H02 Alpine Halo Subwoofer Controller (sold separately) easily mounts to the Alpine Halo Display and allows quick-access controls to the subwoofer and main volume through a wireless Bluetooth® connection. The sleek, tapered lines and silver trim of the RUX-H02 compliments the Alpine Halo Display design.
Features
11-inch Adjustable Floating Style Display (Adjustable Height, Depth, and Viewing Angle)
Standard 1-DIN Chassis for Flexible Vehicle Application
Tapered Display Housing and Silver Trim for a Clean, Modern Fit & Finish
Hi-Res Audio Playback (96kHz / 24bit)
Wireless Hi-Res Audio (requires LDAC compatible device)
Hi-Res music streaming with TIDAL (A TIDAL subscription is required and sold separately; Alpine Head Unit must be tethered to a mobile or smartphone hotspot; Data rates may apply)
Apple Carplay® (Wired & Wireless)
Android Auto™ (Wired & Wireless)
The Google Assistant is Available on Android Auto™
Bluetooth® Hands-Free
SiriusXM-Ready® (compatible with SXV300 (G2) add-on tuner, sold separately; SiriusXM subscription required)
Built-in HD Radio®
iDatalink® Maestro Compatible
Alpine DVR-C320R Dash Cam Compatible (sold separately)
Navigation Compatible with KTX-NS01 (sold separately)
Media Xpander®
Specifications
Screen Resolution: WXGA 1280 x 720px (720p HD)
AUX Input: 1
HDMI Input: 1
HDMI Output: 1
Camera Inputs: 2 Direct (1 Rear input & 1 input that can be set as Front, Side, or Other)
Dash Cam Input: 1 (Alpine DVR-C320R)
USB Inputs: 2 (1 data & 1 charge only port)
4V Pre-Outs: 3
Built-in Amplifier: 18W RMS x 4
EQ: 13-Band Parametric (per channel)
Time Correction: 6-Channel
DAC: 24 Bit
Crossover: High Pass / Low Pass
Audio Playback: AAC, APE, FLAC, MP3, WMA, WAV
Video Playback: AVC, FLV, H.263, H.264, MP4, MPEG-1, MPEG-2, MPEG-4, MKV, MOV
Alpine iLX-F511 Tech SheetAlpine iLX-F511 Manual Part 1Alpine iLX-F511 Manual Part 2
DIN-Size Head-Unit Replacement Dash-Kit for Select 2003-2007 Toyota-Sequoia and Tundra Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a built-in pocket that is located below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and detailed installation instructions
Applications
TOYOTA
Sequoia
2003-2007
Tundra
2003-2006
Metra 99-8207 Installation Manual
DIN-Size Stereo Replacement Dash Kit for Select 1990-2012 Buick, Cadillac, Chevy, Geo, GMC, Honda, Hummer, Isuzu, Oldsmobile, Pontiac, Suzuki and Toyota Vehicles
This stereo installation kit has been engineered to help you install a 2" tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a built-in pocket that is located below the 2" radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is designed to match the original look and feel of the vehicle's dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn't offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2" tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
BUICK
Century
1997-2005
LeSabre
1995-2005
Park Avenue
1995-2005
Rainier
2004-2007
Regal
1995-2004
Rendezvous
2002-2007
Riviera
1996-1999
Roadmaster
1995-1996
Skylark
1996-1998
CADILLAC
Brougham
1990-1992
Eldorado
1992-1993
Fleetwood
1993-1995
Seville
1992-1995
CHEVY
Cavalier
2000-2005
Colorado
2004-2012
Express
2001-2007
Impala
2000-2005
Metro
1994-2001
S-10 Blazer
2002-2005
S-10 Pickup
2002-2004
Tracker
1998-2004
GEO
Metro
1992-1997
Tracker
1992-1997
GMC
Canyon
2004-2012
Savana
2001-2007
Sonoma
2002-2004
Yukon
2003-2006
Yukon XL
2003-2006
HONDA
Passport
1998-2002
HUMMER
H2
2003-2007
ISUZU
Ascender
2003-2008
Amigo
1998-2000
I-290
2007-2008
I-370
2007-2008
I-280
2006-2007
I-350
2006-2007
Rodeo
1998-2004
Rodeo Sport
2001-2003
OLDMOBILE
Achieva
1996-1998
Alero
1999-2004
Aurora
1995-2003
Bravada
1998-2004
Cutlass
1997-1999
Cutlass Supreme
1995-1997
Eighty-Eight
1994-1999
Intrigue
1998-2001
LSS
1996-1999
Ninety-Eight
1994-1996
Regency
1997-1998
Silhouette
2000-2004
PONTIAC
Aztec
2001-2005
Bonneville
2000-2005
Grand Am
2001-2005
Montana
2000-2005
Sunfire
2000-2005
SUZUKI
Aerio Sedan
2002
Aerio 5-door
2002
Esteem
1995-2003
Grand Vitara
1999-2002
Sidekick
1992-1998
XL-7
2001-2002
TOYOTA
Matrix
2003-2004
Metra 99-2009 Installation Manual
Alpine Din-Size Halo Aftermarket Stereo with 9" Touchscreen, Hi-Resolution Audio, Wireless Apple-CarPlay Android-Auto, and iDatalink Compatibility, GPS Upgradeable
The Next-Gen Alpine Halo9 features Apple CarPlay, Android Auto, and built-in Bluetooth hands-free which allow access to music, messages, phone calls, and maps on a smartphone via either a wired USB connection or wirelessly. Get even more entertainment options with built-in HD Radio, Pandora Internet Radio (via iPhone or Android connection), and SiriusXM for even more choices in entertainment (tuner and subscription sold separately).
Experience incredible music detail with Hi-Res Audio Playback. High-precision music reproduction brings out the full potential of every song and makes every drive feel like an intimate recording studio session with your favorite artist. Access your favorite songs on popular Hi-Res streaming services like Apple Music, Tidal, Amazon Music, HD and more. The Alpine Halo9 plays Hi-Res music at it's intended spec of 96kHz/24Bit via a wired USB connection to a smartphone or wirelessly through Bluetooth connection. You can also purchase and download Hi-Res music files onto a USB drive from platforms like HD-Tracks and plugs directly into the Alpine Halo9 for Hi-Res playback.
The iLX-F509 Works with Apple CarPlay wirelessly and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay® is accessed through the capacitive touchscreen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later.
The iLX-F509 includes Android Auto wirelessly and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices, and reply to text messages – hands- free.
The Alpine Halo9 has on-board tuning features including a 13-band parametric EQ per channel, for continuous frequency control. The 6-channel time correction ensures that music is staged properly in the front and center of the vehicle. If more power is needed, additional amplifiers can be added using the three sets of true 4V preamp outputs with front, rear, and subwoofer control.
Experience music as the artist originally intended with the industry’s first full TIDAL integration. The iLX-F509 allows you to access select TIDAL features directly on the head unit and receive a high-res streaming experience with the TIDAL catalog of over 90 million songs. Lossless audio and high-fidelity music options are also available for TIDAL HiFi and HiFi Plus Members, for superior sound quality that elevates the music experience. A TIDAL subscription is required and sold separately. To access TIDAL on the Alpine Head Unit, the head unit must be tethered to a mobile or smartphone hotspot. Data rates may apply.
The screen is attached to an adjustable mount on a single-DIN chassis that’s designed to fit in most dash openings. Once the unit is installed, the screen has five vertical adjustments and two separate depths that lock into position for a sturdy installation. A new pressure tilt mechanism allows for more flexibility when positioning the screen for optimized viewing and access to dash and HVAC controls.
The Alpine Halo9 is compatible with the iDatalink Maestro Module (sold separately) to retain and display vehicle information on the extra large, 11-inch screen. Information such as steering wheel controls, tire pressure, and engine codes, and HVAC control may be accessible from the ILX-F509 (information will vary by vehicle).
The Alpine Halo9 includes two camera inputs to add a front, side, or rearview camera (sold separately). The rearview camera includes a distance guide display that overlays guidelines onto the screen for ease when moving in reverse.
Take driving safety even further by connecting your Alpine Halo9 with the DVR-C320R Premium 1080P Front and Rear Dash Camera with built-in drive assist (sold separately). View real-time and recorded drives in high definition on your Alpine Halo11, plus receive drive assist features that help get you to your destination.
The new RUX-H02 Alpine Halo Subwoofer Controller (sold separately) easily mounts to the Alpine Halo Display and allows quick-access controls to the subwoofer and main volume through a wireless Bluetooth® connection. The sleek, tapered lines and silver trim of the RUX-H02 compliments the Alpine Halo Display design.
Features
9-inch Adjustable Floating Style Display (Adjustable Height, Depth, and Viewing Angle)
Standard 1-DIN Chassis for Flexible Vehicle Application
Tapered Display Housing and Silver Trim for a Clean, Modern Fit & Finish
Hi-Res Audio Playback (96kHz / 24bit)
Wireless Hi-Res Audio (requires LDAC compatible device)
Hi-Res music streaming with TIDAL (A TIDAL subscription is required and sold separately; Alpine Head Unit must be tethered to a mobile or smartphone hotspot; Data rates may apply)
Apple Carplay® (Wired & Wireless)
Android Auto™ (Wired & Wireless)
The Google Assistant is Available on Android Auto™
Bluetooth® Hands-Free
SiriusXM-Ready® (compatible with SXV300 (G2) add-on tuner, sold separately; SiriusXM subscription required)
Built-in HD Radio®
iDatalink® Maestro Compatible
Alpine DVR-C320R Dash Cam Compatible (sold separately)
Navigation Compatible with KTX-NS01 (sold separately)
Media Xpander®
Specifications
Screen Resolution: WXGA 1280 x 720px (720p HD)
AUX Input: 1
HDMI Input: 1
HDMI Output: 1
Camera Inputs: 2 Direct (1 Rear input & 1 input that can be set as Front, Side, or Other)
Dash Cam Input: 1 (Alpine DVR-C320R)
USB Inputs: 2 (1 data & 1 charge only port)
4V Pre-Outs: 3
Built-in Amplifier: 18W RMS x 4
EQ: 13-Band Parametric (per channel)
Time Correction: 6-Channel
DAC: 24 Bit
Crossover: High Pass / Low Pass
Audio Playback: AAC, APE, FLAC, MP3, WMA, WAV
Video Playback: AVC, FLV, H.263, H.264, MP4, MPEG-1, MPEG-2, MPEG-4, MKV, MOV
Alpine iLX-F509 Tech SheetAlpine iLX-F509 Manual Part 1Alpine iLX-F509 Manual Part 2
Aftermarket DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2006-2012 Toyota Rav-4 Vehicles
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is painted scratch-resistant matte black to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio utilizing our patented quick-release, snap-in ISOmount system with custom trim ring
Painted scratch-resistant matte black
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and detailed installation instructions
Applications
TOYOTA
RAV4
2006-2012
Metra 99-8217 Installation Manual
DIN-Size Stereo Replacement Dash Kit for Select 1995-2005 Cadillac, Chevrolet and GMC Vehicles
This stereo installation kit has been engineered to help you install a 2" tall (Single-DIN) aftermarket radio into the original vehicle dashboard, making radio replacement simple. The dash kit is designed to match the original look and feel of the vehicle's dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn't offer but requires this dash kit to make it fit. Stereo installation kit designed to fit any standard 2" tall aftermarket radio
Multiple mounting depth options
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
CADILLAC
Escalade
1999-2002
Escalade EXT
2002
CHEVY
Astro Van
1996-2005
Avalanche
2002
C/K Pickup
1995-2000
Express
1996-2000
Silverado 1500, 2500
1999-2002
Silverado 3500
1999-2002
Suburban
1995-2002
Tahoe
1995-2002
GMC
C/K Pickup
1995-1998
Metra 99-3002 Installation Manual
DIN-Size or DDIN-Sized Head-Unit Replacement Dash-Kit for Select 2007-2011 Honda CR-V Vehicles
This stereo installation kit has been engineered to help you install either a 2" tall (Single-DIN) or a 4" tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2" radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4" tall radio. The dash kit is contoured and textured to match the original look and feel of the vehicle's dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn't offer but requires this dash kit to make it fit.
Stereo installation kit with a recessed opening designed to fit any standard 2" or 4" tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Contoured and textured to match factory dash
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Wiring Harness
70-1722 (sold separately)
Antenna Adapter
40-HD10 (sold separately)
Applications
HONDA
CR-V
2010-2011
CR-V
2007-2009
Metra 99-7873 Installation Manual
DIN or DDIN-Size Aftermarket Stereo-Replacement Dash-Kit for Select 2016-2023 Toyota Tacoma Vehicles, (High Gloss Finish)
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is painted scratch-resistant matte black to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Painted scratch-resistant matte black
Multiple trim plates are included to support all trim levels
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
TOYOTA
Tacoma
2016-2023
Metra 99-8251 Installation Manual
DIN or DDIN Aftermarket Radio Installation Dash-Kit for Select 2000-2001 Audi A4 Vehicles
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that can be installed above or below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is contoured and textured to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Contoured and textured to compliment the factory dash
Interchangeable design allows for the recessed Single-DIN opening to be above or below the included pocket
Two sets of our 86-9001 radio removal tool are recommended for easier removal of the factory radio from the dash
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and detailed installation instructions
* NOTE: Once the Double-DIN kit is installed, the factory dash will need to be removed if the dash kit or aftermarket radio should need to be replace
Applications
AUDI
A4, S4
w/ Symphony radio
2000-2001
Metra 99-9105 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 1974-2003 Chrysler, Dodge, Eagle, Ford, Jeep, and Plymouth Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard, making radio replacement simple. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio utilizing our patented “Side Arm Support System” for radio side support
Provides a recessed radio opening with an adjustable depth feature
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and the hardware parts needed with detailed installation instructions
A tech support number is available for installation help 7 days a week
Applications
CHRYSLER
Cordoba
1975-1983
E-Class
1983-1984
Fifth Avenue
1979-1993
Horizon
1978-1983
Imperial
1990-1993
Laser
1984-1989
LeBaron
1977-1995
LeBaron GTS
1984-1995
Newport
1977-1980
New Yorker
1975-1996
Town & Country
1990-2000
DODGE
Aries
1981-1989
Aspen
1976-1980
Avenger
1995-2000
Caravan
1984-2000
Charger
1974-1987
Dakota
1987-2000
Daytona
1984-1993
Diplomat
1980-1989
Durango
1998-2000
Dynasty
1988-1993
Lancer
1986-1989
Mirada
1979-1983
Neon
1995-1999
Omni
1978-1990
Ram Pickup 1500
1994-2001
Ram Pickup 2500, 3500
1994-2002
Ram Pickup 150, 250, 350
1974-1993
Ram Charger
1981-1993
Ram Van
1978-2003
Shadow
1987-1994
Spirit
1989-1995
St. Regis
1979-1981
EAGLE
Vision
1993-1997
JEEP
Cherokee
1997-2001
Grand Cherokee
1993-1998
Wrangler
1997-2002
PLYMOUTH
400
1982-1983
600E Class
1983-1987
Acclaim
1989-1995
Caravelle
1985-1988
Gran Fury
1978-1989
Horizon
1984-1990
Neon
1995-1999
Reliant
1981-1989
Sundance
1987-1994
TC3
1981-1982
Trail Duster
1975-1981
Turismo
1983-1987
Volare
1976-1980
Voyager
1984-2000
Metra 99-6501 Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2005-2011 Toyota-Tacoma Vehicles, textured gray
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is painted gray and “golf ball” textured to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” (with an ISO-mount provision) tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Painted gray and “golf ball” textured (also available in black: 99-8214TB)
Factory climate controls are retained in their current location
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
TOYOTA
Tacoma
w/ gray color dash
2005-2011
Metra 99-8214TB Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 1982-2000 GMC, Ford, Jeep, Lincoln, Mazda and Mercury Vehicles
This stereo installation kit has been engineered to help you install a 2" tall (Single-DIN) aftermarket radio into the original vehicle dashboard, making radio replacement simple. The dash kit is designed to match the original look and feel of the vehicle's dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn't offer but requires this dash kit to make it fit.
Professional Installer Series TurboKit designed to fit any standard 2” tall aftermarket radio
The Metra 86-5618 radio removal tool is required to pull the factory radio from the dash
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes factory-style rear support, brackets, and hardware parts needed with detailed installation instructions
A tech support number is available for installation help 7 days a week
Applications
FORD
Aerostar
1985-1997
Bronco
1987-1996
Bronco II
1985-1990
Crown Victoria
1992-1994
Econoline
1992-1996
Escort
1985-1996
Escort EXP
1985-1996
Explorer
1991-1994
F-Series
1987-1996
F-250/350
1997
Festiva
1988-1993
LTD
1982-1991
LTD Crown Victoria
1982-1991
Mustang
1994-2000
Probe
1993-1997
Ranger
1983-1994
Taurus
1986-1995
Tempo
1989-1994
Thunderbird
1983-1988
Windstar
1995-1998
LINCOLN
Continental
1985-1994
Mark VII
1984-1992
Mark VIII
1993-1994
Town Car
1985-1994
MAZDA
626
1993-2000
B-Series Pickup
1994
MX-3
1992-1996
MX-6
1993-1997
Navajo
1991-1993
Protégé
1995-2000
MERCURY
Capri
1991-1994
Cougar
1983-1997
Grand Marquis
1979-1994
Lynx
1985-1987
Marquis
1979-1986
Sable
1986-1995
Topaz
1989-1994
Tracer
1988-1996
Villager
1993-1995
JEEP
Cherokee
1984-1996
Comanche
1985-1992
Wrangler
1984-1996
Metra 99-5510 Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2014-2020 Dodge Durango Vehicles
ISO DIN radio provision with pocket
ISO DDIN radio provision
HVAC Interface and wiring harness included
Built-in ASWC-1 technology retains steering wheel controls
Painted black to match factory finish.
Touchscreen display for climate and personalization features
Wiring and Antenna Connections
Harness
Axxess interface built into touchscreen
Antenna Adapter
Included with kit
Steering wheel control interface
Included with kit
Applications
DODGE
Durango
2014-2020
Metra 99-6537B Installation Manual
DIN Sized Automotive Stereo Replacement Dash Kit for Select 1994-2004 Land Rover Vehicles. Designed to allow you to fit a DIN Head Unit into your Land Rover.
Applications
LAND ROVER
Discovery
1994-2004
Discovery II
2000-2004
Metra 89-9400 Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2013-2014 Ford F-Series Pickups with Factory 4.2" Radio Screen
ISO DIN radio provision with pocket
ISO DDIN radio provision
Touchscreen display for climate and personalization features
Integrated hazard button and passenger airbag light
DIN-Sized Radio can be mounted up top or at bottom
Painted matte black
Axxess interface included:
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (retained accessory power)
Provides NAV outputs (parking brake, reverse, speed sense)
Retains audio controls on the steering wheel
Retains SYNC
Retains the factory backup camera
Retains balance and fade
Micro B USB updatable
Wiring and Antenna Connections
Harness
Axxess interface built into touchscreen
Antenna Adapter
Included
Applications
FORD
F-150
w/ 4.2-inch color screen
2013-2014
Metra 99-5846B Installation Manual
DIN-Size Stereo Replacement Dash Kit for Select 2014-2021 Ram Promaster Vans with Factory 5" Screen
This stereo installation kit is engineered to help you install an aftermarket 2" tall (DIN) radio into the original vehicle dashboard. This dash kit helps make radio replacement simple and is custom textured to match the original look and feel of the vehicle's dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn't offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2" tall aftermarket radio
Custom textured to match factory finish
Metra 86-5618 (radio delete or factory Single-DIN) or 86-3528 (factory Double-DIN) radio removal tool is required to pull the factory radio from the dash
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
A tech support number is available for installation help 7 days a week
Applications
RAM
ProMaster
w/ 5-inch display (Uconnect 5.0)
2014-2021
Metra 99-6523 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 1995-2011 Ford, Lincoln, Mercury and Mazda Vehicles
This stereo installation kit has been engineered to help you install a 2" tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a built-in pocket that can be above or below the 2" radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is designed to match the original look and feel of the vehicle's dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn't offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2" tall aftermarket radio
Kit is designed to allow for the built-in pocket to be mounted above or below the radio
Constructed with support ribs to provide a stronger Single-DINopening and pocket
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes bracket, OEM-style rear support and hardware parts needed with detailed installation instructions
A tech support number is available for installation help 7 days a week
Applications
FORD
Crown Victoria
1995-2011
Econoline
1997-2008
Explorer
1995-1997
F-250
1998
Ranger
1995-1997
LINCOLN
Blackwood
2002
Continental
1995-1997
Navigator
1999-2002
Town Car
1995-2002
MAZDA
B-Series Pickup
1995-2009
MERCURY
Grand Marquis
1995-2010
Marauder
2003-2004
Mountaineer
1997-2001
Metra 99-5802 Installation Manual
BMW Head-Unit Replacement Heated-Seat Switch Relocation Pocket for Select 2006-2013 BMW 3-Series Vehicles (Non-NAV Models)
This switch relocation pocket has been designed to be used in installations when using the 95-9306B radio dash kit. The relocation pocket makes retention of the original factory heated seat switches possible. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this pocket to make it fit when installing an aftermarket radio.
Designed to be used with the 95-9306B radio dash kit when retaining the factory heated seat switches
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes an extension cable to relocate the switches with detailed installation instructions
Applications
BMW
3 Series
coupe, convertible, wagon
2012-2013
3 Series
2007-2011
3 Series
sedan, wagon
2006-2006
M3
2007-2013
DIN-Size Head-Unit Replacement Dash-Kit for Select 1982-1995 Toyota Vehicles
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
A tech support number is available for installation help 7 days a week
Applications
TOYOTA
Camry
1983-1986
Celica
1982-1993
Corolla
1984-1988
Land Cruiser
1982-1992
MR2
1985-1995
Pickup
1984-1995
Supra
1983-1992
Metra 99-8100 Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2015-2022 Ford F-Series Pickups
ISO DIN radio provision with pocket
ISO DDIN radio provision
Painted Charcoal
Touchscreen display for climate and personalization features
Built-in ASWC-1 Technology Retains Factory Steering Wheel Controls
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (retained accessory power)
Provides NAV outputs (parking brake, reverse, speed sense)
Retains audio controls on the steering wheel
Retains SYNC® (4.2-inch display screen models only)
Retains the factory backup camera
Can be used in both amplified and non-amplified models (including Sony)
Retains balance and fade
Micro “B” USB updatable
*This kit will not support the Pro Trailer Backup Assist™ feature, nor the massaging seats.*
Applications
FORD
F-150
w/ manual climate
2018-2020
F-150
w/ auto climate
2018-2020
F-150
w/ manual climate
2015-2017
F-150
w/ auto climate
2015-2017
F-250/350/450/550
w/8" Screen
2017-2022
F-250/350/450/550
4.2-inch color screen
2020-2022
F-250/350/450/550
4.2-inch color screen w/ auto climate
2017-2019
Metra 99-5834CH Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 2004-2019 Ford, Lincoln and Mercury Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN or ISO Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
FORD
E-Series
formerly known as Econoline (w/ AM/FM)
2014-2019
E-Series
formerly known as Econoline (w/ AM/FM/CD/SYNC)
2014-2019
Econoline
2009-2013
Econoline
AM/FM
2009-2013
Econoline
AM/FM/CD/SYNC
2009-2013
Edge
2007-2010
Expedition
fleet vehicle
2015-2015
Expedition
2007-2014
Expedition (SSV)
police vehicle
2015-2015
Explorer
2006-2010
Explorer
2009-2010
Explorer Sport Trac
2006-2010
F-150
2007-2008
F-150
2004-2006
F-250/350/450/550
XL,XLT w/ CD
2013-2016
F-250/350/450/550
XL, XLT w/o CD
2013-2016
F-250/350/450/550
2008-2010
F-250/350/450/550
2005-2007
F-250/350/450/550
2011-2012
F-250/350/450/550
2011-2012
F-650, F-750
AM/FM
2016-2019
F-650, F-750
AM/FM/CD
2016-2019
F-650, F-750
2011-2015
Five Hundred
2005-2007
Focus
2005-2007
Freestar
2004-2007
Freestyle
2005-2007
Fusion
2006-2009
Mustang
late 2008 build date
2008-2009
Mustang
early 2008 build date
2008-2008
Mustang
2007-2007
Mustang
2005-2006
Taurus, Taurus X
2008-2009
Transit Connect
late build, from 10/11
2012-2013
LINCOLN
Mark LT
2005-2008
Mark LT
2005-2008
MKX
2007-2010
Navigator
2008-2014
Navigator
2007-2007
MERCURY
Milan
2006-2008
Montego
2005-2007
Monterey
2004-2007
Mountaineer
2006-2010
Sable
2008-2009
Metra 99-5812 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 2008-2014 Subaru-Impreza and Forester Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a built-in pocket that is located below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and detailed installation instructions
Applications
SUBARU
Forester
w/ DVD based nav
2009-2013
Impreza
2008-2011
Impreza Outback Sport
2011
Impreza WRX
2013-2014
Impreza WRX STI
2008-2012
Metra 99-8902 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 2005-2009 Subaru-Outback and Legacy Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a built-in pocket that is located above the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is contoured, textured and painted gray to compliment the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Contoured, textured and painted gray to compliment the factory dash
Designed for models with manual climate controls
Retains factory climate controls in their original location
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
SUBARU
Legacy
w/o auto climate controls (2.5i)
2005-2009
Outback
w/o auto climate controls (2.5i)
2005-2009
Metra 99-8901 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 2005-2010 Chrysler, Dodge and Jeep Vehicles, without navigation
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN or ISO Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
CHRYSLER
Aspen
2007
PT Cruiser
2006-2010
DODGE
Caliber
2007-2008
Charger
2006-2007
Dakota
2005-2007
Durango
2004-2007
Magnum
2005-2007
Ram Pickup 1500
2006-2008
Ram Pickup 2500, 3500
2006-2009
Ram Pickup Chassis Cab 4500, 5500
2008-2010
JEEP
Commander
2006-2007
Compass
2007-2008
Grand Cherokee
2005-2007
Patriot
2007-2008
MITSUBISHI
Raider
2006-2007
Metra 99-6507 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 2019-2020 Mercedes Sprinter-Van Vehicles Without Touchscreen
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is a polished gloss black to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio
Polished gloss black
Designed for models without a touchscreen radio
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
MERCEDES
Sprinter
2019-2020
Metra 99-8731 Installation Manual
DIN or DDIN Aftermarket Radio Installation Dash-Kit for Select 2000-2005 Audi A6, RS 6, and S6 Vehicles
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is painted scratch-resistant matte black to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Painted scratch-resistant matte black
Two sets of our 86-9001 radio removal tool are required to remove the factory radio from the dash
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Wiring and Antenna Connections:
Harness
70-1787 (Allroad Quatro) (sold separately)
AXVI-9004 (2004-up models)(sold separately)
Antenna Adapter
40-VW54 (2004-up models)(sold separately)
Applications
AUDI
A6, RS 6, S6
2002-2004
A6
2000-2001
allroad quattro
2004-2005
allroad quattro
2001-2003
Metra 99-9108B Installation Manual
DIN-Size or DDIN-Size Aftermarket Radio Installation Dash-Kit for Select 2001-2004 Volvo Vehicles
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is painted to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Painted to match the factory finish
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
A tech support number is available for installation help 7 days a week
Wiring Harness
70-9221 (sold separately)
Antenna Adapter
40-VL10 (sold separately)
Antenna Adapter
40-VW10 (sold separately)
40-VW54 (sold separately)
Applications
VOLVO
S60
2001-2004
V70
2003-2004
V70, V70 Cross Country, V70 XC
2001-2002
XC70 a.k.a.Cross Country
2003-2004
Metra 99-9229G Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2015-2019 Ford Transit Vehicles with AM/FM radio, Passenger Airbag Light, with or without CD
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement easier and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is painted gray to match the original look and feel of the vehicle’s dashboard. Modifications to the sub-dash are necessary to use this dash kit and detailed instructions are included. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Painted gray to match the factory finish
Sub-dash modifications are necessary
Complete radio panel for a factory look
Retains the factory hazard switch and passenger airbag indicator
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
FORD
Transit 150/250/350
AM/FM radio, w/ pass. airbag light
2015-2019
Transit 150/250/350
AM/FM/CD radio
2015-2019
Metra 99-5835G Installation Manual
DIN-Size Aftermarket Radio Installation Dash-Kit for Select 1996-2007 Audi Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard, making radio replacement simple. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes the hardware parts needed and detailed installation instructions
A tech support number is available for installation help 7 days a week
Wiring And Antenna Connections:
Harness
70-1784 (non-amplified)(sold separately)
70-1785 (amplified)(sold separately)
70-1787 (amplified)(sold separately)
Antenna Adapter
40-VW10 (sold separately)
40-VW54 (sold separately)
Applications
AUDI
A3
w/ Concert radio
2006-2007
A4
w/ Concert radio
2000-2005
A4
1998-1999
A4
1996-1997
A6
1998-1999
A6
1996-1997
A8
1997-1999
TT
2002-2006
TT
2000-2001
Metra 99-9106 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 1995-2011 Ford Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a built-in pocket that can be located above or below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” tall aftermarket radio
Metra 86-5618 radio removal tool is required to pull the factory radio from the dash
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes two radio housing options, depending on vehicle model, and brackets with detailed installation instructions
Antenna Adapter
40-CR10 (sold separately)
Applications
FORD
Expedition
1999-2002
Explorer
1998-2001
F-150
Heritage edition
2004-2004
F-150
1999-2003
Ranger
1998-2011
Metra 99-5804 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 2001-2005 Honda Civic Vehicles - Without Si or SE Trim
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a built-in pocket that is located below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is painted dark charcoal gray to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
For ISO DIN and DIN mount radios
Incorporates pocket for two CD jewel cases
Patented Side Arm Support System built into kit
Rear radio supports included
High-grade ABS plastic
Applications
Honda
Civic
Excluding Si and SE Trims
2001-2005
Metra 99-7899 Installation Manual
DIN-Size with Hideaway 6.8-Inch Touchscreen Digital CD and DVD Media Receiver with Bluetooth, Apple CarPlay and Android Auto
Pioneer's NEX or Networked Entertainment eXperience line of receivers features an innovative and powerful new user interface that is responsive and highly customizable. The NEX models are designed especially for today's smartphone driven lifestyle.
Vozsis is a smartphone app available for both iOS and Android OS devices that brings Amazon Alexa capability to compatible Weblink-enabled Pioneer multimedia in-dash receivers. Downloading both the Vozsis and Weblink applications makes using Alexa in your car simple – just tap-and-ask, and Alexa will respond instantly. With Alexa, you can ask to play music, hear the news, check weather, control smart home devices, and more. Alexa lives in the cloud, so it’s always getting smarter, adding new capabilities that are delivered to your device automatically.
The AVH-3500NEX features Apple CarPlay, the smarter, safer and more fun way to use your iPhone in the car. Apple CarPlay gives iPhone users an incredibly intuitive way to make calls, use maps, listen to music, and verbally send and listen to messages with just a word or a touch. Apple CarPlay requires iPhone 5 or newer with the latest version of iOS.
The AVH-3500NEX also features Android Auto, which extends the Android platform into the car in a way that’s purpose-built for driving. Android Auto automatically brings you useful information and organizes it into simple cards that appear just when they’re needed. It’s designed to minimize distraction so you can stay focused on the road ahead.
Stay safe and obey local hands-free laws with built-in bluetooth (HFP). Easily pair a bluetooth enabled phone to the AVH-3500NEX without having to go through complicated settings. When a registered bluetooth device is in proximity to the receiver, the auto connection function automatically pairs the two units.
From hands-free calling, wireless audio streaming (A2DP) with artist, album, and song search, simple pairing, and control audio (AVRCP profile), bluetooth wireless technology has made life in the vehicle much more convenient.
The AVH-3500NEX with bluetooth also includes superior call quality reception using Wideband Speech Handsfree Profile 1.6. Wideband Speech nearly doubles the bandwidth of frequencies of a normal Bluetooth call (when compared to calls without Wideband Speech)
Pandora is personalized internet radio that is designed to help you discover new music that you'll love mixed in with music that you already know. With the AVH-3500NEX, you can enjoy superior sound quality and full control of the Pandora experience in your car directly from the touchscreen display of the receiver. You are able to give tracks "thumbs up" or "thumbs down," bookmark a song so you can purchase it later, easily switch between your personalized radio stations, and view full track data and album art.
Pandora is compatible with Apple iOS, as well as Android devices that support the Bluetooth Serial Port Profile (SPP). Simply download the free Pandora Radio app to your iPhone or Android device, connect to the AVH-3500NEX and take your music to the next level.
The AVH-3500NEX is SiriusXM ready so you can get over 140 channels, including commercial-free music, plus the best sports and live events, comedy, news, exclusive talk and entertainment. SiriusXM programming is received through the SiriusXM Connect Vehicle Tuner (sold separately, SiriusXM subscription required).
Users of an iPhone with Siri can take advantage of Siri Eyes Free functionality. With a simple touch of the NEX touchscreen, Siri starts listening through the NEX unit's external microphone and answers your questions and requests over the vehicle's speakers, helping you keep your eyes on the road and your hands on the wheel.
Specifications
Continuous Power Output 22 W x 4-Channel
Load Impedence Allowance 4 Ohm (4 Ohm to 8 Ohm Allowable)
Max Power Output 50 W x 4-ch 4 ohm / 50 W x 2-ch 4 ohm 70 W X 1-ch (subwoofer) 2 Ohm
RCA Preamp Outputs 6-ch
RCA Preout Voltage 4V
RMS Power Output (CTA-2006) 14 W RMS x 4-ch 4 ohm
Back LightLED
Brightness Control Yes
Color Customization 5 display colors, 112 key colors
Device (Non-DIN/Modular Unit) 2-DIN
Dimmer Automatic with vehicle illumination, Timer Controlled, Manual
Display Off Mode Yes
Home Screen Customization Yes
Monitor Mechanism Fixed
Resolution WVGA (800 x 480)
Screen Size/Aspect Ratio 7"/16:9
Touch Screen Resistive
Advanced Audio Distribution Profile (A2DP) Yes
AVRCP 1.6
Built-in Bluetooth® Yes
Dual Phone Connection Yes
Hands-Free Yes
Microphone Included
Phone Registation 5-phone
Secure Simple Pairing (SSP) Yes
Serial Port Profile (SPP) Yes
Sound Retriever Air Mode 1/Mode 2/Off
Best Station Memory Yes
Local Seek tuning Yes
Presets 18 FM, 6 AM
RDS Yes
SiriusXM-Ready™ (Tuner Sold Separately) Yes
Amazon Alexa Paired with Pioneer Vozsis
Android Auto™ Wired USB Connection
Apple® CarPlay Wired USB Connection
Mirroring Android / Apple iOS
Music Playback (MTP) Yes
Pandora® Source through iPhone/Android
Pioneer App Compatibility Vozsis Android, Vozsis iPhone
Siri® Eyes Free (VR) (Internet Required) iPhone Only
Spotify Streaming audio through iPhone/Android via Bluetooth or AUX input
Voice Control Yes
Weblink Yes
Audio Playback via CD MP3 Audio Playback / WMA Audio Playback / AAC Audio Playback / CD Audio Playback
Audio Playback via DVD AAC Audio Playback / MP3 Audio Playback / WMA Audio Playback
Audio Playback via USB MP3 Audio Playback / WMA Audio Playback / AAC Audio Playback / FLAC Audio Playback (Hi-Res) / WAV Audio Playback (Hi-Res)
Audio Video Playback via CD-R/CD-RW AVI Audio Video Playback / DivX Audio Video Playback / DVD Audio Video Playback
Audio Video Playback via DVD-R/RSL/-RDL/DVD-RW AVI Audio Video Playback / DivX Audio Video Playback / DVD Audio Video Playback
Audio Video Playback via USB .avi / .mpg/mpeg / .divx / .mp4 / .3gp / .mkv / .mov / .flv . .wmv/.asf / .m4v / .ts/.m2ts/.mts / H.263 / H.264
Image Display via USB BMP / JPEG / PNG
Advanced Sound Retriever Mode-1/Mode-2/Off
Bass Boost Yes
Auto EQ (CD-MC20 Microphone sold separately) Yes
Automatic Level Control Mode-1/Mode-2/Off
Built-in Amplifier MOSFET 50 W x 4
Crossover Network Mode HPF/Band Pass/LPF
Crossover Standard Mode HPF/LPF
Customizable Graphic Equalizer 13 Band
DA Converter 24 Bit
Digital Signal Processor Built In
Easy EQ (EEQ) Preset Equalizer Yes
Listening Position Selector Yes
Loudness High/Mid/Low/Off
Speaker Output 4-ch
Spectrum Analyzer Yes
Subwoofer Control Yes
Time AlignmentAuto / Manual
Parking Assist Lines Yes
RCA Video Output Yes
USB Single Rear Type-A (5 V, 1.5 A)
USB Direct Control for iPhone® Single Rear Type-A (5 V, 1.5 A)
Input 1 Backup Camera Dedicated
Input 2 AUX (Minijack)
Input 3 AV
Detachable Face Security Yes
Multi-Language Display English, French, Spanish Portuguese, Chinese (Simplified)
Music Browser USB
Remote Control Included
Rotary Volume Control Yes
Steering Wheel Control Ready (Adapter Sold Separately) Yes
Pioneer AVH-3500NEX ManualPioneer AVH-3500NEX Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2013-2017 RAM Vehicles
ISO DIN radio provision with pocket
ISO DDIN radio provision
Integrated 4.3 inch color touchscreen that displays the factory climate and personalization features
Retains audio controls on the steering wheel
Painted black to match the factory finish.
Notes:
The clock and compass in the drivers information center will no longer be functional.
The kit does not have the ability to adjust the Active-Level™ Four Corner Air-Suspension.
The kit does not retain the 5th wheel camera.
The kit does not retain the trailer brake adjustments.
The kit does not retain the key fob controller settings.
Interface features
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (retained accessory power)
Provides NAV outputs (parking brake, reverse, speed sense)
Retains audio controls on the steering wheel
Retains safety chimes
Retains the factory backup camera
Retains the factory AUX-IN jack
Can be used in amplified or non-amplified models
Retains balance and fade*
Micro-B USB updatable
Applications
RAM
1500/2500/3500
with 8.4-inch touchscreen
2013-2017
Chassis Cab 2500, 3500, 4500, 5500
with 8.4-inch touchscreen
2013-2017
Metra 99-6527B Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2009-2014 Ford F-150 Vehicles
This stereo installation kit has been engineered to help you install a 2" tall (Single-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2" radio to fill the extra space in the radio opening, which can be used for storage. The dash kit is painted scratch-resistant matte black to match the original look and feel of the vehicle's dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn't offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2" tall aftermarket radio
Painted scratch-resistant matte black
For vehicles without factory navigation
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
FORD
F-150
w/ CD, w/o color screen
2013-2014
F-150
FX, STX, XLT
2011-2012
F-150
SVT Raptor
2009-2012
F-150
FX, STX, XLT
2009-2010
F-150
XL w/ CD
2009-2014
Metra 99-5820B Installation Manual
DIN or DDIN-Size Head-Unit Replacement DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2005-2011 Toyota-Tacoma Vehicles, textured black
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is painted black and “golf ball” textured to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” (with an ISO-mount provision) tall aftermarket radio utilizing our patented quick-release, snap-in ISO mount system with custom trim ring
Painted black and “golf ball” textured (also available in gray: 99-8214TG)
Factory climate controls are retained in their current location
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
TOYOTA
Tacoma
w/ black color dash
2005-2011
Metra 99-8214TB Installation Manual
DIN or DDIN-Size Head-Unit Replacement Dash-Kit for Select 2005-2015 Nissan and Suzuki Vehicles
This stereo installation kit has been engineered to help you install either a 2” tall (Single-DIN) or a 4” tall (Double-DIN) aftermarket radio into the original vehicle dashboard. This dash kit makes radio replacement simple and comes with a pocket that is installed below the 2” radio to fill the extra space in the radio opening, which can be used for storage. The pocket is not needed when installing a 4” tall radio. The dash kit is designed to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Stereo installation kit designed to fit any standard 2” or 4” tall aftermarket radio
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
NISSAN
Frontier
radio delete option
2016-2017
Frontier
S trim with King Cab(w/ or w/o radio delete option)
2013-2015
Frontier
S trim
2012-2012
Frontier
S, SE-4 cyl., XE
2009-2011
Frontier
all except Base model
2008-2008
Frontier
Base model
2008-2008
Frontier
2005-2007
Pathfinder
S
2008-2012
Pathfinder
2005-2007
Xterra
w/o 4.3-inch screen
2013-2013
Xterra
X trim, 4WD
2009-2012
Xterra
late production (w/ factory amp)
2008.5-2008.5
Xterra
late production (w/o factory amp)
2008.5-2008.5
Xterra
early production
2008-2008
Xterra
2005-2007
SUZUKI
Equator
extended cab
2009-2011
Metra 99-7635 Installation Manual
DIN-Size Head-Unit Replacement Dash-Kit for Select 1998-2010 Volkswagen-Beetle Vehicles
This stereo installation kit has been engineered to help you install a 2” tall (Single-DIN) aftermarket radio into the original vehicle dashboard, making radio replacement simple. The dash kit is contoured and textured to match the original look and feel of the vehicle’s dashboard. Installing an aftermarket radio can upgrade the sound quality and provide additional features the original factory radio couldn’t offer but requires this dash kit to make it fit.
Professional Installer Series TurboKit designed to fit any standard 2” tall aftermarket radio
Made from the highest quality ABS plastic for an original factory-like fit and finish
Includes brackets and hardware parts needed with detailed installation instructions
Applications
VOLKSWAGEN
Beetle
1998-2010
Metra 99-9008 Installation Manual
