10" Drivers Under 8.5"

10-Inch Subwoofer Drivers that are Suitable for Enclosures with a Mounting Depth under 8 1/2-Inches

10-Inch Subwoofer Drivers that are Suitable for Enclosures with a Mounting Depth under 8 1/2-Inches

These 10" drivers are best recommended for subwoofer enclosures with a sub mounting clearance of 8.5". If your 10-inch sub box has a depth of less than 8.5-inches then not all of these drivers will fit in your box.

3 products

  • Alpine S-W10D : 10" 600W Subwoofer Driver, 2Ω or 4Ω DVC

    Alpine S-W10D : 10" 600W Subwoofer Driver, 2Ω or 4Ω DVC

    Pre-Order Today!

    Alpine S-Series 600-Watt 10-Inch Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil Along with the new 8” woofer, the 10” and 12” S-Series subwoofers have been re-designed from the ground up. The mounting depth of the 10” and 12” subwoofers are almost 1” more shallow than previous models at just over 4.5” for the 10” models and just over 5” for the 12” models, allowing them to fit into a wide variety of installation applications. Specifications 10" DVC High Performance Subwoofer Power Handling: 600W RMS/1800W Peak Push-type Insert Terminals with DVC jumper system Concealed Mount Gasket/Grille* System (*Grille sold separately) Frequency Response: 28Hz-200Hz Mounting Depth 4-11/16” Alpine S-W10D2, S-W10D4 Manual

    Pre-Order Today!

    $179.99

  • 500W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 45L7R10 500W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 45L7R10 side view.

    Kicker 45L7R10 : 500W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil

    Pre-Order Today!

    10-Inch 500-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC This L7 series 10" square woofer by Kicker hosts a heavy-duty motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. On board the chassis of this 500W driver you will find dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, ribbed santoprene surround with blue stitching and a UniPlate™ back plate and pole piece, plus perimeter venting for thermal heat management. The Kicker 45L7R102 and 45L7R104 square subwoofers are rated for 500W of RMS amplified power. Specifications SIZE [in, cm]: 10, 25 IMPEDANCE [Ohms]: 2 or 4 DVC Recommended Amplifier Power (watts RMS) 500 Peak Power (watts, per ANSI/CTA-2031-A) 1000 SENSITIVITY [dB 1w/1m]: 85.9 MOUNTING DEPTH [in, cm]: 6 1/8, 15.7 MOUNTING DIAMETER [in, cm]: 9 5/16, 23.7 MIN SEALED BOX VOL [cu. ft, L]: .66, 18.7 MAX SEALED BOX VOL [cu. ft, L]: 1, 28.3 MIN VENTED BOX VOL [cu. ft, L]: 1.25, 35.4 MAX VENTED BOX VOL [cu. ft, L]: 2.25, 63.7 Kicker L7R Subwoofer Manual

    Pre-Order Today!

    $219.99

  • 750W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 42CWQ10 750W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 42CWQ10, side view.

    Kicker 42CWQ10 : 750W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil

    Pre-Order Today!

    10-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC The 10" CompQ audiophile competition subwoofer driver by Kicker is the pinnacle of Kicker's round speaker line, with nearly identical construction and performance as the L7 Series square subs. The Kicker 42CWQ102 and 42CWQ104 have a 750W RMS power handling and extremely accurate bass reproduction featuring a ribbed Santoprene® surround and a BlueLace™ large-diameter progressive roll spider for extreme flexibility at 750-Watts of Continuous Power. The CompQ 10-Inch sub works best with a sealed or ported enclosure with 750 watts of recommended power. See below for more details. Specifications Rated Impedance [Ω] 2 or 4 DVC Fs [Hz 38 Sensitivity [1W, 1m] 85.7 Qts 0.437 Qms 8.916 Qes 0.46 Re [Ω] 6.52 Vas [ft³, L] .59, 16.75 Recommended Amplifier Power (watts RMS) 700 Outer Frame Dimension [in, cm] 10 11/16, 27.2 Mounting Depth [in, cm] 6 3/8, 16.2 Mounting Cutout [in, cm] 9 3/16, 23.4 Frequency Response [Hz] 24 – 100 Kicker CompQ Subwoofer Manual

    Pre-Order Today!

    $279.99
