Driver Depth 3-3.25"

C1-Series 6x9-Inch 60-Watt Coaxial Speaker System, 3-Way C1 speakers deliver real substance and great audio performance in a format designed for easy fit behind factory grilles. To facilitate fit, spacer adaptor rings are included allowing the C1-690tx to be installed in bottom-mount applications. C1 woofer drivers benefit from proprietary FEA modeling and JL Audio's expertise in low-frequency driver design. This knowledge is used to create speakers that can play loudly, while maintaining a smooth, dynamic, low distortion sound. At the core of the C1-690tx is a proprietary, stamped, steel 6 x 9-inch (150 x 230 mm) oval frame and a DMA-optimized motor system. A mineral-filled, injection-molded polypropylene cone is suspended with a rubber surround on the front, and a carefully engineered flat Conex® spider at the top of the voice coil, to precisely control motion and prevent impact between the voice coil and the back plate. Tinsel leads are carefully routed and attached to the spider to prevent fatigue and buzzing. These are the same kinds of features and materials normally found on much more expensive loudspeakers. Equipped with dual true, edge-driven, aluminum dome tweeters, the C1-690tx stands apart from others in its category with superior high-frequency clarity and separation. The design of each tweeter delivers inherently excellent off-axis response and high-frequency extension. Both high-frequency drivers also benefit from the damping of silk surround suspensions and Ferrofluid in the voice coil gaps, along with the superior strength of neodymium magnetics. A true, mixed order filter network is employed to further enhance smoothness and improve power handling. When it comes to value, C1 is the real deal! Sold as a pair. Grilles not available. General Specifications Continuous Power Handling (RMS) 60 W Peak Music Power 225 W Recommended Amplifier Power (RMS) 10 - 100 W / Ch. System Efficiency 90.5 dB @ 1 W / 1 m System Nominal Impedance 4 Ω System Frequency Response 36 Hz - 24 KHz ± 3 dB JL Audio C1-690tx Manual

Read more less

C2-Series 6x9" 70-Watt  3-Way Coaxial Speaker System The Evolution C2 systems deliver sparkling high-frequency detail, smooth mid-range and powerful mid-bass, thanks to real silk dome tweeters and precision-engineered woofer designs. The C2-690tx system features 6 x 9-inch (150 x 230 mm) woofers with mineral-filled polypropylene cones, long excursion capabilities and stamped steel frames. The woofer design benefits from JL Audio's vast woofer design experience and advanced modeling systems. The 6 x 9-inch (150 x 230 mm) format is a direct fit in many vehicles. The Mid-Range driver is ferrofluid-cooled, with a 2-inch Mylar® cone diaphragm to smoothly bridge the gap between the woofer and the dome tweeter. Tweeters are mounted next to the mid-range driver and built with 0.75-inch silk dome diaphragms that deliver smooth, extended response, on and off axis. The small size of the C2 tweeter minimizes tweeter protrusion, allowing C2 coaxials to fit behind most factory speaker grilles. Woofer grilles are included, each consisting of a black grille tray with satin silver accents and a black steel mesh grille with an electroformed JL Audio logo. Sonic character: Clean and Dynamic Sold as a pair. General Specs Continuous Power Handling (RMS) 70 W Peak Music Power 225 W Recommended Amplifier Power (RMS) 15 - 125 W / Ch. System Efficiency 93 dB @ 1 W / 1 m System Nominal Impedance 4 Ω System Frequency Response 53 Hz - 22 KHz ± 3 dB JL Audio C2-690tx Manual

Read more less

150-Watt 6x9-Inch Coaxial Speakers, 4-Ohm These CS series 6x9" coaxial speakers by Kicker are a significant upgrade in your sound. A stamped-steel speaker driver chassis supports a rigid polypropylene cone and UV-treated foam surrounds that stand up to heat and direct sunlight. These 150W coaxial's have neodymium tweeter magnets allow for increased volume in high frequencies. These Kicker CS series 6 by 9" speakers work best with 150 watts of recommended power. Specifications Speaker Design 3 - way Woofer Size | in [mm] 6x9 [160x230] Mid Size | in [mm] 2 [50] Tweeter Size | in [mm] 1/2 [13] DC Resistance | ohm 3.5 Peak Power | Watts 450 Continuous Power | Watts, RMS 150 Sensitivity [SPLo] | dB @ 1W, 1m 92 Effective Frequency Range | Hz 30-20k Mounting Hole Diameter | in [mm] 5 5/8 x 8 7/16 [143x215] Top Mount Depth | in [mm] 7/16 [12] Bottom Mount Depth | in [mm] 3 3/16 [81] Tweeter Protrusion | in [mm] 1/16 [1] Grilles Yes Tweeter Magnet Material Electric Crystal Motor Tweeter Dome Material PEI [polyether imide] Tweeter Design Balanced dome Woofer Cone Material Polypropylene Woofer Surround Material Polyester foam Kicker CS Series Coaxial Speaker Manual

Read more less
