Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series 10-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W10D2 and R2-W10D4 is compatible with the KTE-10G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
750W RMS
2250W Peak Power Handling
Frequency Response: 26Hz-200Hz
Sensitivity (1W/1m): 82.4dB
Nominal Impedance: 4Ω
Voice Coil: 65mm
X-Max: 20mm
Magnet Weight: 123oz
Mounting Depth: 6” (152mm)
Cutout Size: 9-1/16” (231mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W10D Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series 12-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W12D2 and R2-W12D4 is compatible with the KTE-12G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
750W RMS
2250W Peak Power Handling
Frequency Response: 24Hz-200Hz
Sensitivity (1W/1m): 84.5dB
Nominal Impedance: 4Ω
Voice Coil: 65mm
X-Max: 20mm
Magnet Weight: 144oz
Mounting Depth: 6-1/2” (152mm)
Cutout Size: 10-7/8” (231mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W12D Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series 8-Inch 350-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W8D2 and R2-W8D4 is compatible with the KTE-8G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
350W RMS
1000W Peak Power Handling
Frequency Response: 30Hz-200Hz
Sensitivity (1W/1m): 83.5dB
Nominal Impedance: 4Ω
Voice Coil: 35mm
X-Max: 12mm
Magnet Weight: 56oz
Mounting Depth: 4-3/8” (118mm)
Cutout Size: 6-15/16” (176mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W8D Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Alpine S-Series 600-Watt 10-Inch Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil
Along with the new 8” woofer, the 10” and 12” S-Series subwoofers have been re-designed from the ground up. The mounting depth of the 10” and 12” subwoofers are almost 1” more shallow than previous models at just over 4.5” for the 10” models and just over 5” for the 12” models, allowing them to fit into a wide variety of installation applications.
Specifications
10" DVC High Performance Subwoofer
Power Handling: 600W RMS/1800W Peak
Push-type Insert Terminals with DVC jumper system
Concealed Mount Gasket/Grille* System (*Grille sold separately)
Frequency Response: 28Hz-200Hz
Mounting Depth 4-11/16”
Alpine S-W10D2, S-W10D4 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Alpine S-Series 600-Watt 12-Inch Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil
Along with the new 8” woofer, the 10” and 12” S-Series subwoofers have been re-designed from the ground up. The mounting depth of the 10” and 12” subwoofers are almost 1” more shallow than previous models at just over 4.5” for the 10” models and just over 5” for the 12” models, allowing them to fit into a wide variety of installation applications.
Specifications
Power Handling: 600W RMS/1800W Peak @ 2Ω
Push-type Insert
Terminals with DVC jumper system
Concealed Mount Gasket/Grille* System (*Grille sold separately)
Frequency Response: 26Hz-200Hz
Mounting Depth 5-1/16”
Alpine S-W12D2, S-W12D4 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Alpine S-Series 300-Watt 8-Inch Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil
Don’t think you have room for a subwoofer? Think again. The new S-W8D2 and S-W8D4 8” S-Series subwoofers have a shallow mounting depth of just 3-3/4” and can be used in a sealed box enclosure as small as .15 cubic foot. It is perfect for under seats, behind rear bench seats in trucks, or even in some door applications.
Specifications
8" DVC High Performance Subwoofer
Power Handling: 300W RMS/900W Peak
Push-type Insert Terminals with DVC jumper system
Concealed Mount Gasket/Grille* System(*Grille sold separately)
Frequency Response: 34Hz-200Hz
Mounting Depth 3-3/4”
Alpine S-W8D2, S-W8D4 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 750-Watt Square Subwoofer, 2-Ohm or 4-Ohm DVC
The 10" L7 series automotive subwoofer driver by Kicker stands alone as the most unique subwoofer on the market, with a cone shape that is exclusively designed to produce more output.
The Kicker 41L7102 and the 41L7104 subwoofers again reach new heights in technology and design. A 2015 CES® Innovation Award winner, Kicker L7 branded itself as the crown jewel among competition subwoofers. For more than a decade, Kicker’s square woofer earned numerous awards including several CES accolades, and the 2015 version once again makes distinctive improvements on its way to another honor.
These 10-Inch L7 square subwoofers deliver 20% more surface area than a comparable circular 10" sub. A bigger cone means more air gets dispersed for each excursion cycle thus producing more sound! Kicker included oversized magnets and an aluminum voice coil, to help keep heat to a minimum. The Uniplate™ is a KICKER original design, combining the pole piece and back plate as a single, seamless unit to pull damaging heat away from the sub.
Kicker's patented Santoprene™ corners allow your KICKER subs to play smooth, distortion-free music at any volume level. Kicker's Blue Lace™ spider and ribbed surround work together to give you the best suspension for your L7. You get unparalleled accuracy and volume to feel every note - every time.
Specifications
Rated Impedance [Ω]
2 or 4 DVC
Fs [Hz]
37.5
Sensitivity [1W, 1m]
85.9
Qts
0.507
Qms
9.791
Qes
0.535
Re [Ω]
7.9
Vas [ft³, L]
1, 28.32
Recommended Amplifier Power (watts RMS)
750
Outer Frame Dimension [in, cm]
10 11/16, 27.2
Mounting Depth [in, cm]
6 7/8, 17.5
Mounting Cutout [in, cm]
9 5/16, 23.7
Frequency Response [Hz]
24 - 100
Minimum Sealed Volume ft3 (L)
.8 (22.65)
Maximum Sealed Volume ft3 (L)
1.25 (35.4)
Kicker L7 Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 900-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 12" L7 square subwoofer driver by Kicker stands alone as the most unique subwoofer on the market, with a cone shape that is exclusively designed to produce more output.
The Kicker 41L712 and 41L714 subwoofers again reaches new heights in technology and design. A winner of the 2015 CES® Innovation Award, the Kicker L7 series solidified itself as the crown jewel among competition subwoofers. For more than a decade, Kicker’s square woofer design has earned numerous awards including several CES accolades, and the 2015 version once again makes distinctive improvements on its way to another honor.
A KICKER® original design, their square subwoofers deliver 20% more surface area than a comparable circular sub. A larger cone area disperses more air for each excursion thus producing more sound! Oversized magnets and an aluminum voice coil ensures maximum output while remaining cool. The Uniplate™ is a Kicker original design, combining the pole piece and back plate as a single, seamless unit to pull damaging heat away from the sub.
Kicker's patented Santoprene™ corners allow the Kicker 12-Inch L7 series subs to play smooth, distortion-free music at any volume level. Kicker's Blue Lace™ spider and ribbed surround work together to give you the best suspension for your L7. You get unparalleled accuracy and volume to feel every note - every time.
Specifications
Rated Impedance [Ω]
2 or 4 DVC
Fs [Hz]
34
Sensitivity [1W, 1m]
86.9
Qts
0.539
Qms
9.488
Qes
0.571
Re [Ω]
6.8
Vas [ft³, L]
1.92, 54.274
Recommended Amplifier Power (watts RMS)
900
Outer Frame Dimension [in, cm]
12 9/16, 32
Mounting Depth [in, cm]
7 7/8, 20
Mounting Cutout [in, cm]
11 1/16, 28.1
Frequency Response [Hz]
20 - 100
Kicker L7 Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 1200-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC L7 Series Driver
The 15" L7 series automotive subwoofer by Kicker stands alone as the most unique subwoofer on the market, with a cone shape that is exclusively designed to produce more output.
The Kicker 41L7152 and 41L7154 subwoofer is winner of the 2015 CES® Innovation Award solidifying itself as the crown jewel among competition subwoofer enthusiasts. For more than a decade, Kicker’s square woofer design has earned numerous awards including several CES accolades, and the 2015 version once again makes distinctive improvements on its way to another honor.
The 15-Inch L7 square subwoofer drivers deliver 20% more surface area than a comparable circular sub. A bigger cone disperses more air for each excursion thus creating more sound!
Oversized magnets and an aluminum voice coil allow maximum performance over long periods while remaining cool in operation. The Uniplate™ is a Kicker original, combining the pole piece and back plate as a single, seamless unit to pull damaging heat away from the sub.
Kicker's patented Santoprene™ corners allow the Kicker 41L7152 and the 41L7154 subs to play smooth, distortion-free music at any volume level. Kicker's Blue Lace™ spider and ribbed surround work together to give you the best suspension. You get unparalleled accuracy and volume to feel every note - every time.
Specifications
Rated Impedance [Ω]
2 DVC
Fs [Hz]
26.3
Sensitivity [1W, 1m]
88.6
Qts
0.539
Qms
11.868
Qes
0.565
Re [Ω]
7
Vas [ft³, L]
5.263, 149.048
Recommended Amplifier Power (watts RMS)
1200
Outer Frame Dimension [in, cm]
15 5/8, 39.6
Mounting Depth [in, cm]
9 3/8, 23.9
Mounting Cutout [in, cm]
13 3/4, 34.9
Frequency Response [Hz]
18 - 100
Kicker L7 Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch 500-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 8" L7 automotive square subwoofers by Kicker stand alone as the most unique 8-Inch subwoofer on the market, with a cone shape that is exclusively designed to produce more output.
The Kicker 41L78 subwoofer again reaches new heights in technology and design. A winner of the 2015 CES® Innovation Award solidified the L7 series sub as the crown jewel among competition subwoofers. For more than a decade, KICKER’s square woofer earned numerous awards including several CES accolades, and the 2015 version once again makes distinctive improvements on its way to another honor.
The Kicker 41L782 and 41L784 square subwoofers deliver 20% more surface area than a comparable 8" circular sub. A bigger cone disperses more air for each excursion thus producing more sound! Oversized magnets and an aluminum voice coil allow maximum performance while remaining cool in operation. The Uniplate™ is a KICKER original, combining the pole piece and back plate as a single, seamless unit to pull damaging heat away from the sub.
Kicker's patented Santoprene™ corners allow the L7 subs to play smooth, distortion-free music at any volume level. Kicker's Blue Lace™ spider and ribbed surround work together to give you the best suspension. You get unparalleled accuracy and volume to feel every note - every time.
Specifications
Rated Impedance [Ω]
2 DVC
Fs [Hz]
47.2
Sensitivity [1W, 1m]
82.4
Qts
0.735
Qms
8.828
Qes
0.802
Re [Ω]
6.6
Vas [ft³, L]
.322, 9.127
Recommended Amplifier Power (watts RMS)
500
Outer Frame Dimension [in, cm]
8 13/16, 22.4
Mounting Depth [in, cm]
5 7/16, 13.8
Mounting Cutout [in, cm]
7 1/4, 18.4
Frequency Response [Hz]
28 - 100
Kicker L7 Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 10" CompQ audiophile competition subwoofer driver by Kicker is the pinnacle of Kicker's round speaker line, with nearly identical construction and performance as the L7 Series square subs.
The Kicker 42CWQ102 and 42CWQ104 have a 750W RMS power handling and extremely accurate bass reproduction featuring a ribbed Santoprene® surround and a BlueLace™ large-diameter progressive roll spider for extreme flexibility at 750-Watts of Continuous Power.
The CompQ 10-Inch sub works best with a sealed or ported enclosure with 750 watts of recommended power. See below for more details.
Specifications
Rated Impedance [Ω]
2 or 4 DVC
Fs [Hz
38
Sensitivity [1W, 1m]
85.7
Qts
0.437
Qms
8.916
Qes
0.46
Re [Ω]
6.52
Vas [ft³, L]
.59, 16.75
Recommended Amplifier Power (watts RMS)
700
Outer Frame Dimension [in, cm]
10 11/16, 27.2
Mounting Depth [in, cm]
6 3/8, 16.2
Mounting Cutout [in, cm]
9 3/16, 23.4
Frequency Response [Hz]
24 – 100
Kicker CompQ Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 850-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompQ 12” audiophile subwoofer by Kicker is the pinnacle of their round speaker line, with nearly identical construction and performance as their L7 square subs.
The Kicker 42CWQ122 and 42CWQ124 subs were designed for high power handling and reference competition bass reproduction, this KICKER sub features Ribbed Santoprene® surrounds and a BlueLace™ large-diameter progressive roll spider for extreme flexibility at any volume level.
The CompQ series 12-Inch subwoofer works best with a sealed or ported enclosure rated for 850W RMS.
Specifications
Rated Impedance [Ω]
2 or 4 DVC
Fs [Hz]
37
Sensitivity [1W, 1m]
86.2
Qts
0.546
Qms
8.878
Qes
0.582
Re [Ω]
5.94
Vas [ft³, L]
.91 ,26
Recommended Amplifier Power (watts RMS)
850
Outer Frame Dimension [in, cm]
12 1/2, 31.8
Mounting Depth [in, cm]
7 1/8, 18.1
Mounting Cutout [in, cm]
11 1/16, 28.1
Frequency Response [Hz]
20 – 100
Kicker CompQ Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 1100-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompQ 15” audiophile subwoofer from Kicker is their flagship round subwoofer line, with nearly identical construction and performance as the L7 square subs.
The Kicker 42CWQ152 and 42CWQ154 were designed for high power handling and audiophile competition bass reproduction, this 15-Inch CompQ sub features Ribbed Santoprene® surrounds and a BlueLace™ large-diameter progressive roll spider for extreme flexibility at any volume level.
This 15” subwoofer driver works best with a sealed or ported enclosure with 1,100-Watts of RMS power. See below for more details.
Specifications
Rated Impedance [Ω]
2 or 4 DVC
Fs [Hz]
30.6
Sensitivity [1W, 1m]
88.6
Qts
0.472
Qms
9.672
Qes
0.496
Re [Ω]
6.03
Vas [ft³, L]
2.5, 70.747
Recommended Amplifier Power (watts RMS)
1100
Outer Frame Dimension [in, cm]
15 3/8, 39.1
Mounting Depth [in, cm]
8 15/16, 22.6
Mounting Cutout [in, cm]
13 7/8, 35.2
Frequency Response [Hz]
18 – 100
Kicker CompQ Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 350-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This 43CVR 10" subwoofer by Kicker uses an advanced heat dispersion system with perimeter venting to allow air to circulate while the Kicker proprietary UniPlate™ system redirects even more heat away from the motor.
The chassis of this 10-Inch sub holds a pair of high-temp voice coils that move an injection molded woofer. The CompVR 10" subwoofer is available in a 2Ω or 4Ω dual voice coil design.
The 43CVR102 and 43CVR104 10-Inch subwoofers works best with a sealed or ported enclosure and 350 watts of recommended power. See below for more details.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
350
Peak Power (watts, per ANSI/CTA-2031-A)
700
SENSITIVITY [dB 1w/1m]:
83.6
MOUNTING DEPTH [in, cm]:
5 1/2, 14
MOUNTING DIAMETER [in, cm]:
9 3/16, 23.3
MIN SEALED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX SEALED BOX VOL [cu. ft, L]:
3, 85
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Kicker CompVR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 400-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This 43CVR 12" subwoofer by Kicker uses an advanced heat dispersion system with perimeter venting to allow air to circulate while the Kicker proprietary UniPlate™ system redirects even more heat away from the motor.
The chassis of this 12-Inch sub holds a pair of high-temp voice coils that move an injection molded woofer. The CompVR 12" subwoofer is available in a 2Ω or 4Ω dual voice coil design.
The 43CVR122 and 43CVR124 12-Inch subwoofers works best with a sealed or ported enclosure and 400 watts of recommended power. See below for more details.
Specifications
SIZE [in, cm]:
12, 30
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
86.9
MOUNTING DEPTH [in, cm]:
6-1/4, 15.9
MOUNTING DIAMETER [in, cm]:
11, 27.8
MIN SEALED BOX VOL [cu. ft, L]:
1, 28.3
MAX SEALED BOX VOL [cu. ft, L]:
4.6, 130
MIN VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
MAX VENTED BOX VOL [cu. ft, L]:
2.25, 63.7
Kicker CompVR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This 43CVR 15" subwoofer by Kicker uses an advanced heat dispersion system with perimeter venting to allow air to circulate while the Kicker proprietary UniPlate™ system redirects even more heat away from the motor.
The chassis of this 15-Inch sub holds a pair of high-temp voice coils that move an injection molded woofer. The CompVR 15" subwoofer is available in a 2Ω or 4Ω dual voice coil design.
The Kicker 43CVR152 and 43CVR154 15" subs works best with a sealed or ported enclosure and 500 watts of recommended power. See below for more details.
Specifications
SIZE [in, cm]:
15, 38
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
500
Peak Power (watts, per ANSI/CTA-2031-A)
1000
SENSITIVITY [dB 1w/1m]:
89.2
MOUNTING DEPTH [in, cm]:
8 3/16, 20.7
MOUNTING DIAMETER [in, cm]:
13 11/16, 34.7
MIN SEALED BOX VOL [cu. ft, L]:
1.8, 51
MAX SEALED BOX VOL [cu. ft, L]:
5.2, 147
MIN VENTED BOX VOL [cu. ft, L]:
3, 85
MAX VENTED BOX VOL [cu. ft, L]:
5, 142
Kicker CompVR Subwoofer Manual
8-Inch 300-Watt Thin Subwoofer Driver, 2-Ohm DVC
The CompRT 8" thin subwoofer by Kicker is a weather resistant thin sub with a 2Ω dual voice coil design. This thin 8 inch sub magnet structure delivers 300W RMS of power with a chassis mounting depth of just under 2 3/4". The Kicker designed UniPlate™ back plate and solid pole piece serve as a single heat-absorbing unit to keep this 8" CompRT thin subwoofer driver nice and cool.The CompRT 8-Inch subwoofer works best with a sealed or ported enclosure and 300 watts of recommended power.
Specifications
SIZE [in, cm]:
8, 20
IMPEDANCE [Ohms]:
2 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
600
SENSITIVITY [dB 1w/1m]:
81.8
MOUNTING DEPTH [in, cm]:
2 11/16, 6.7
MOUNTING DIAMETER [in, cm]:
7, 17.7
MIN SEALED BOX VOL [cu. ft, L]:
0.2, 5.66
MAX SEALED BOX VOL [cu. ft, L]:
1.0, 28.32
MIN VENTED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX VENTED BOX VOL [cu. ft, L]:
1.2, 34
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 600-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompVX 10" subwoofer driver by Kicker is designed with high-temp dual voice coils that deliver up to 600W of amplified RMS power. A solid pole-piece provides more mass to disperse heat. A thick polypropylene cone complements the SoloKon™ cone reinforcement system and the oversized suspension system.
The Kicker 44CVX102 and 44CVX104 10 inch subwoofers have a UniPlate™ extended pole piece & backplate for superior heat dissipation and satin nickel spring-loaded speaker terminals.
Specifications
Size (IN.,CM)
10, 25
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
600
Peak Power (watts, per ANSI/CTA-2031-A)
1200
Sensitivity (dB 1w/1m)
85.7
Frequency Response (Hz)
24-500
Mounting Depth (in, cm)
5 15/16, 15.1
Mounting Cutout (in, cm)
9 3/16, 23.3
Min Sealed Box Vol (cu. ft, L)
.8, 22.7
Max Sealed Box Vol (cu. ft, L)
3.0, 85.0
Min Vented Box Vol (cu. ft, L)
1.25, 35.4
Max Vented Box Vol (cu. ft, L)
1.75, 49.6
Kicker CompVX Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompVX 12" subwoofer driver by Kicker is designed with high-temp dual voice coils that deliver up to 750W of amplified RMS power. A solid pole-piece provides more mass to disperse heat. A thick polypropylene cone complements the SoloKon™ cone reinforcement system and the oversized suspension system.
The Kicker 44CVX122 and 44CVX124 12 inch subwoofers have a UniPlate™ extended pole piece & backplate for superior heat dissipation and satin nickel spring-loaded speaker terminals.
Specifications
Size (IN.,CM)
12, 30
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
750
Peak Power (watts, per ANSI/CTA-2031-A)
1500
Sensitivity (dB 1w/1m)
87.1
Frequency Response (Hz)
20-500
Mounting Depth (in, cm)
6 11/16, 16.9
Mounting Cutout (in, cm)
11 1/16, 28
Min Sealed Box Vol (cu. ft, L)
1.0, 28.3
Max Sealed Box Vol (cu. ft, L)
4.6, 130
Min Vented Box Vol (cu. ft, L)
1.75, 49.6
Max Vented Box Vol (cu. ft, L)
2.25, 63.7
Kicker CompVX Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 1000-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompVX 15" subwoofer driver by Kicker is designed with high-temp dual voice coils that deliver up to 1000W of amplified RMS power. A solid pole-piece provides more mass to disperse heat. A thick polypropylene cone complements the SoloKon™ cone reinforcement system and the oversized suspension system.
The Kicker 44CVX152 and 44CVX154 15 inch subwoofers have a UniPlate™ extended pole piece & backplate for superior heat dissipation and satin nickel spring-loaded speaker terminals.
Specifications
Size (IN.,CM)
15, 38
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
1000
Peak Power (watts, per ANSI/CTA-2031-A)
2000
Sensitivity (dB 1w/1m)
91.6
Frequency Response (Hz)
18-500
Mounting Depth (in, cm)
8 1/2, 21.5
Mounting Cutout (in, cm)
13 13/16, 35
Min Sealed Box Vol (cu. ft, L)
1.8, 51.0
Max Sealed Box Vol (cu. ft, L)
5.2, 147.0
Min Vented Box Vol (cu. ft, L)
3.0, 85.0
Max Vented Box Vol (cu. ft, L)
5.0, 142.0
Kicker CompVX Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch Square 600-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The audiophile competition 10" L7 square sub by Kicker has an advanced motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. This 10 inch 600W driver has two dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, a ribbed Santoprene surround with blue surround stitching and Kicker's patented UniPlate™ back plate and pole piece. Perimeter venting for thermal heat dispersion management keeps this earth shattering 10 inch square sub nice and cool.
This 10" L7 square sub can handle up to 600W RMS of amplifier power and comes with dual spring-loaded speaker terminals for a solid speaker wire connection.
Specifications
Size (IN.,CM)
10, 25.4
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
600
Peak Power (watts, per ANSI/CTA-2031-A)
1200
Sensitivity (dB 1w/1m)
86.8
Frequency Response (Hz)
24-100
Mounting Depth (IN.,CM)
6-1/4, 15.9
Mounting Cutout, Square (IN.,CM)
9-5/16, 23.7
Min Rec Sealed Box Volume (CU. FT., Liters)
1, 28.32
Max Rec Sealed Box Volume (CU. FT., Liters)
1.25, 35.4
Min Rec Vented Box Volume (CU. Ft., Liters)**
1.25, 35.4
Max Rec Vented Box Volume (CU. Ft., Liters)**
2.25, 63.8
Kicker Solo-Baric L7 Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch Square 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The audiophile competition 12" L7 square sub by Kicker has an advanced motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. This 12 inch 750W driver has two dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, a ribbed Santoprene surround with blue surround stitching and Kicker's patented UniPlate™ back plate and pole piece. Perimeter venting for thermal heat dispersion management keeps this earth shattering 12 inch square sub nice and cool.
This 12" L7 square sub can handle up to 750W RMS of amplifier power and comes with dual spring-loaded speaker terminals for a solid speaker wire connection.
Specifications
Size (IN.,CM)
12, 30.5
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
750
Peak Power (watts, per ANSI/CTA-2031-A)
1500
Sensitivity (dB 1w/1m)
88.6
Frequency Response (Hz)
20-100
Mounting Depth (IN.,CM)
6 11/16, 16.9
Mounting Cutout, Square (IN.,CM)
11 1/16, 28.1
Min Rec Sealed Box Volume (CU. FT., Liters)
1.25, 35.4
Max Rec Sealed Box Volume (CU. FT., Liters)
2.0, 56.64
Min Rec Vented Box Volume (CU. Ft., Liters)**
1.75, 49.6
Max Rec Vented Box Volume (CU. Ft., Liters)**
3.25, 92.1
Kicker Solo-Baric L7 Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch Square 1000-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The audiophile competition 15" L7 square sub by Kicker has an advanced motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. This 15 inch 1000W driver has two dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, a ribbed Santoprene surround with blue surround stitching and Kicker's patented UniPlate™ back plate and pole piece. Perimeter venting for thermal heat dispersion management keeps this earth shattering 15 inch square sub nice and cool.
This 15" L7 square sub can handle up to 1000W RMS of amplifier power and comes with dual spring-loaded speaker terminals for a solid speaker wire connection.
Specifications
Size (IN.,CM)
15, 38.1
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
1000
Peak Power (watts, per ANSI/CTA-2031-A)
2000
Sensitivity (dB 1w/1m)
89.4
Frequency Response (Hz)
18-100
Mounting Depth (IN.,CM)
8 11/16, 22.1
Mounting Cutout, Square (IN.,CM)
13 3/4, 34.9
Min Rec Sealed Box Volume (CU. FT., Liters)
2.0, 56.64
Max Rec Sealed Box Volume (CU. FT., Liters)
6.0, 169.9
Min Rec Vented Box Volume (CU. Ft., Liters)**
3.0, 85.0
Max Rec Vented Box Volume (CU. Ft., Liters)**
6.0, 169.9
Kicker Solo-Baric L7 Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch Square 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The audiophile competition 8" L7 square sub by Kicker has an advanced motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. This 8 inch 750W driver has two dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, a ribbed Santoprene surround with blue surround stitching and Kicker's patented UniPlate™ back plate and pole piece. Perimeter venting for thermal heat dispersion management keeps this earth shattering 8 inch square sub nice and cool.
This 8" L7 square sub can handle up to 750W RMS of amplifier power and comes with dual spring-loaded speaker terminals for a solid speaker wire connection.
Specifications
Size (IN.,CM)
8, 20.32
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
450
Peak Power (watts, per ANSI/CTA-2031-A)
900
Sensitivity (dB 1w/1m)
83.6
Frequency Response (Hz)
28-100
Mounting Depth (IN.,CM)
4 3/4, 12.1
Mounting Cutout, Square (IN.,CM)
7 1/4, 18.4
Min Rec Sealed Box Volume (CU. FT., Liters)
.5, 14.16
Max Rec Sealed Box Volume (CU. FT., Liters)
.75, 21.24
Min Rec Vented Box Volume (CU. Ft., Liters)**
.66, 18.6
Max Rec Vented Box Volume (CU. Ft., Liters)**
1.0, 28.3
Kicker Solo-Baric L7 Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 500-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This L7 series 10" square woofer by Kicker hosts a heavy-duty motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. On board the chassis of this 500W driver you will find dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, ribbed santoprene surround with blue stitching and a UniPlate™ back plate and pole piece, plus perimeter venting for thermal heat management.
The Kicker 45L7R102 and 45L7R104 square subwoofers are rated for 500W of RMS amplified power.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
500
Peak Power (watts, per ANSI/CTA-2031-A)
1000
SENSITIVITY [dB 1w/1m]:
85.9
MOUNTING DEPTH [in, cm]:
6 1/8, 15.7
MOUNTING DIAMETER [in, cm]:
9 5/16, 23.7
MIN SEALED BOX VOL [cu. ft, L]:
.66, 18.7
MAX SEALED BOX VOL [cu. ft, L]:
1, 28.3
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
2.25, 63.7
Kicker L7R Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 600-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This L7 series 12" square woofer by Kicker hosts a heavy-duty motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. On board the chassis of this 600W driver you will find dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, ribbed santoprene surround with blue stitching and a UniPlate™ back plate and pole piece, plus perimeter venting for thermal heat management.
The Kicker 45L7R122 and 45L7R124 square subwoofers are rated for 600W of RMS amplified power.
Specifications
SIZE [in, cm]:
12, 30
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
600
Peak Power (watts, per ANSI/CTA-2031-A)
1200
SENSITIVITY [dB 1w/1m]:
86.7
MOUNTING DEPTH [in, cm]:
6 7/8, 17.4
MOUNTING DIAMETER [in, cm]:
11 1/16, 28.1
MIN SEALED BOX VOL [cu. ft, L]:
.88, 24.92
MAX SEALED BOX VOL [cu. ft, L]:
2, 56.64
MIN VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
MAX VENTED BOX VOL [cu. ft, L]:
3.25, 92
Kicker L7R Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 900-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This L7 series 15" square woofer by Kicker hosts a heavy-duty motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. On board the chassis of this 900W driver you will find dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, ribbed santoprene surround with blue stitching and a UniPlate™ back plate and pole piece, plus perimeter venting for thermal heat management.
The Kicker 45L7R152 and 45L7R154 square subwoofers are rated for 900W of RMS amplified power.
Specifications
SIZE [in, cm]:
15, 38
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
900
Peak Power (watts, per ANSI/CTA-2031-A)
1800
SENSITIVITY [dB 1w/1m]:
88.05
MOUNTING DEPTH [in, cm]:
8 3/8, 21.5
MOUNTING DIAMETER [in, cm]:
13 3/4, 34.9
MIN SEALED BOX VOL [cu. ft, L]:
1.5, 42.48
MAX SEALED BOX VOL [cu. ft, L]:
3, 85
MIN VENTED BOX VOL [cu. ft, L]:
3, 85
MAX VENTED BOX VOL [cu. ft, L]:
6, 170
Kicker L7R Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch Thin Subwoofer Driver, 500-Watt RMS, 2-Ohm or 4-Ohm Dual-Voice-Coil
The Kicker Solo-Baric® L7T square subwoofer delivers more bass than a round driver, giving you up to 20% more cone area than a round sub while fitting where only a thin driver will do. Match any L7T thin sub with a KX-Series mono amplifier for an outstanding combination of power and size.
Uses a sealed or ported enclosure
Square sub design moves 20% more air than round subwoofers
Easily mounts under or behind a deat
Dual voice coil design
Ribbed santoprene surround resists heat And degrading
Bumped top plate for more excursion & smoother performance
SoloKon™ cone with 360-degree back bracing
UniPlate™ solid pole pPiece & backplate for excellent heat dissipation
Durable steel basket
Specifications
Size (IN.,CM)
10, 25
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
500
Peak Power (watts, per ANSI/CTA-2031-A)
1000
Sensitivity (dB 1w/1m)
85.98
Frequency Response (Hz)
25-100
Mounting Depth (IN.,CM)
3-3/4, 9.5
Mounting Cutout, Square (IN.,CM)
9-5/16, 23.7
Min Rec Sealed Box Volume (CU. FT., Liters)
.4, 11.3
Max Rec Sealed Box Volume (CU. FT., Liters)
1.25, 28.3
Min Rec Vented Box Volume (CU. Ft., Liters)**
1.25, 35.4
Max Rec Vented Box Volume (CU. Ft., Liters)**
1.75, 49.6
Kicker L7T Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch Thin Subwoofer Driver, 600-Watt RMS, 2-Ohm or 4-Ohm Dual-Voice-Coil
The Kicker Solo-Baric® L7T square subwoofer delivers more bass than a round driver, giving you up to 20% more cone area than a round sub while fitting where only a thin driver will do. Match any L7T thin sub with a KX-Series mono amplifier for an outstanding combination of power and size.
Uses a sealed or ported enclosure
Square sub design moves 20% more air than round subwoofers
Easily mounts under or behind a deat
Dual voice coil design
Ribbed santoprene surround resists heat And degrading
Bumped top plate for more excursion & smoother performance
SoloKon™ cone with 360-degree back bracing
UniPlate™ solid pole pPiece & backplate for excellent heat dissipation
Durable steel basket
Specifications
Size (IN.,CM)
12, 30
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
600
Peak Power (watts, per ANSI/CTA-2031-A)
1200
Sensitivity (dB 1w/1m)
86.54
Frequency Response (Hz)
25-100
Mounting Depth (IN.,CM)
4-1/8, 9.5
Mounting Cutout, Square (IN.,CM)
11-1/16, 28.1
Min Rec Sealed Box Volume (CU. FT., Liters)
.55, 15.6
Max Rec Sealed Box Volume (CU. FT., Liters)
1.25, 35.4
Min Rec Vented Box Volume (CU. Ft., Liters)**
1.75, 49.6
Max Rec Vented Box Volume (CU. Ft., Liters)**
2.25, 63.7
Kicker L7T Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch Thin Subwoofer Driver, 350-Watt RMS, 2-Ohm or 4-Ohm Dual-Voice-Coil
The Kicker Solo-Baric® L7T square subwoofer delivers more bass than a round driver, giving you up to 20% more cone area than a round sub while fitting where only a thin driver will do. Match any L7T thin sub with a KX-Series mono amplifier for an outstanding combination of power and size.
Uses a sealed or ported enclosure
Square sub design moves 20% more air than round subwoofers
Easily mounts under or behind a deat
Dual voice coil design
Ribbed santoprene surround resists heat And degrading
Bumped top plate for more excursion & smoother performance
SoloKon™ cone with 360-degree back bracing
UniPlate™ solid pole pPiece & backplate for excellent heat dissipation
Durable steel basket
Specifications
Size (IN.,CM)
8, 20
Impedance (OHMS)
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
350
Peak Power (watts, per ANSI/CTA-2031-A)
700
Sensitivity (dB 1w/1m)
84.835
Frequency Response (Hz)
30-100
Mounting Depth (IN.,CM)
2-3/4, 7
Mounting Cutout, Square (IN.,CM)
7-3/8, 18.8
Min Rec Sealed Box Volume (CU. FT., Liters)
0.2, 5.66
Max Rec Sealed Box Volume (CU. FT., Liters)
.75, 21.2
Min Rec Vented Box Volume (CU. Ft., Liters)**
.8, 22.7
Max Rec Vented Box Volume (CU. Ft., Liters)**
1.2, 34
Kicker L7T Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 400-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR10 10" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.The Kicker 48CWR102 and 48CWR104 12" subs work best with a sealed or ported enclosure and 400 watts of recommended power.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
84.6
MOUNTING DEPTH [in, cm]:
5-1/4, 13.3
MOUNTING DIAMETER [in, cm]:
9-1/8, 23.1
MIN SEALED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX SEALED BOX VOL [cu. ft, L]:
1.25, 35.4
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR12 12" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.The Kicker 48CWR122 and 48CWR124 12" subs work best with a sealed or ported enclosure and 500 watts of recommended power.
Specifications
SIZE [in, cm]:
12, 30
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
500
Peak Power (watts, per ANSI/CTA-2031-A)
1000
SENSITIVITY [dB 1w/1m]:
86.9
MOUNTING DEPTH [in, cm]:
5 3/4, 14.6
MOUNTING DIAMETER [in, cm]:
11, 27.9
MIN SEALED BOX VOL [cu. ft, L]:
1.0, 28.3
MAX SEALED BOX VOL [cu. ft, L]:
2.0, 56.64
MIN VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
MAX VENTED BOX VOL [cu. ft, L]:
2.25, 63.7
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 800-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR15 15" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.
The Kicker 48CWR152 and 48CWR154 15" subs work best with a sealed or ported enclosure and 800 watts of recommended power.
Specifications
SIZE [in, cm]:
15, 38
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
800
Peak Power (watts, per ANSI/CTA-2031-A)
1600
SENSITIVITY [dB 1w/1m]:
89.4
MOUNTING DEPTH [in, cm]:
7 15/16, 20
MOUNTING DIAMETER [in, cm]:
13 3/4, 35
MIN SEALED BOX VOL [cu. ft, L]:
1.8, 51
MAX SEALED BOX VOL [cu. ft, L]:
3.0, 85
MIN VENTED BOX VOL [cu. ft, L]:
3.0, 85
MAX VENTED BOX VOL [cu. ft, L]:
5.0, 142
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR8 8" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.The Kicker 48CWR82 and 48CWR84 8" subs work best with a sealed or ported enclosure and 300 watts of recommended power.
Specifications
SIZE [in, cm]:
8, 20
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
600
SENSITIVITY [dB 1w/1m]:
82.1
MOUNTING DEPTH [in, cm]:
4-1/8, 10.5
MOUNTING DIAMETER [in, cm]:
7, 17.7
MIN SEALED BOX VOL [cu. ft, L]:
0.4, 11.3
MAX SEALED BOX VOL [cu. ft, L]:
1.0, 28.52
MIN VENTED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX VENTED BOX VOL [cu. ft, L]:
1.2, 34
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 400-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompRT 10-inch subwoofer is an all-weather thin bassb driver with a pair of 2-Ohm or 4-Ohm voice coils. With a mounting depth under four inches and plenty of power handling, this go-anywhere sub is as flexible as it is powerful. A UV-resistant cone and surround help make the CompRT sound great wherever the road (or trail) takes you.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent. To make Kicker subs even more reliable, their engineers developed Forced-Air Cooling™ to help these thin subs run 20 percent cooler than before.
Kicker signature red double stitching makes an outstanding bond between the improved Santoprene surround and polypropylene woofer cone. Revolutionary SoloKon™ technology joins the cone to the vented back brace, creating a single integrated unit that both cools the motor and eliminates distortion.The CompRT 10-Inch 48CWRT102 and 48CWRT104 subwoofers work best with a sealed or ported enclosure and 400 watts of recommended power.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
84.8
MOUNTING DEPTH [in, cm]:
3 7/16, 8.8
MOUNTING DIAMETER [in, cm]:
9 1/8, 23.1
MIN SEALED BOX VOL [cu. ft, L]:
0.4, 11.3
MAX SEALED BOX VOL [cu. ft, L]:
1.25, 35 .4
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 500-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompRT 12-inch subwoofer is an all-weather thin bassb driver with a pair of 2-Ohm or 4-Ohm voice coils. With a mounting depth under four inches and plenty of power handling, this go-anywhere sub is as flexible as it is powerful. A UV-resistant cone and surround help make the CompRT sound great wherever the road (or trail) takes you.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent. To make Kicker subs even more reliable, their engineers developed Forced-Air Cooling™ to help these thin subs run 20 percent cooler than before.
Kicker signature red double stitching makes an outstanding bond between the improved Santoprene surround and polypropylene woofer cone. Revolutionary SoloKon™ technology joins the cone to the vented back brace, creating a single integrated unit that both cools the motor and eliminates distortion.The CompRT 12-Inch 48CWRT122 and 48CWRT124 subwoofers work best with a sealed or ported enclosure and 500 watts of recommended power.
Specifications
SIZE [in, cm]:
12, 30
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
500
Peak Power (watts, per ANSI/CTA-2031-A)
1000
SENSITIVITY [dB 1w/1m]:
85.5
MOUNTING DEPTH [in, cm]:
3 3/4,9.6
MOUNTING DIAMETER [in, cm]:
11, 27.9
MIN SEALED BOX VOL [cu. ft, L]:
0.55, 15.57
MAX SEALED BOX VOL [cu. ft, L]:
2.0, 56.64
MIN VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
MAX VENTED BOX VOL [cu. ft, L]:
2.25, 63.7
Kicker CompRT Subwoofer Manual
6.75-Inch 150-Watt Thin Subwoofer Driver, 1-Ohm or 2-Ohm DVC
The CompRT 6.75" thin subwoofer by Kicker is a weather resistant thin sub with a 1Ω or 2Ω dual voice coil design. This thin 6.75 inch sub magnet structure delivers 150W RMS of power with a chassis mounting depth of 2 3/4". The Kicker designed UniPlate™ back plate and solid pole piece serve as a single heat-absorbing unit to keep this 6.75" CompRT thin subwoofer driver nice and cool.The CompRT 6.75-Inch subwoofer works best with a sealed or ported enclosure and 150 watts of recommended power.
Specifications
SIZE [in, cm]:
6 13/16, 17.3
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
150
Peak Power (watts, per ANSI/CTA-2031-A)
300
SENSITIVITY [dB 1w/1m]:
82.6
MOUNTING DEPTH [in, cm]:
2 3/4, 7
MOUNTING DIAMETER [in, cm]:
5 5/8, 14.3
MIN SEALED BOX VOL [cu. ft, L]:
0.18, 5.1
MAX SEALED BOX VOL [cu. ft, L]:
0.75, 21.24
Kicker CompRT Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch 300-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompRT 8-inch subwoofer is an all-weather thin bass driver with a pair of 2-Ohm or 4-Ohm voice coils. With a mounting depth under three inches and plenty of power handling, this go-anywhere sub is as flexible as it is powerful. A UV-resistant cone and surround help make the CompRT sound great wherever the road (or trail) takes you.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent. To make Kicker subs even more reliable, their engineers developed Forced-Air Cooling™ to help these thin subs run 20 percent cooler than before.
Kicker signature red double stitching makes an outstanding bond between the improved Santoprene surround and polypropylene woofer cone. Revolutionary SoloKon™ technology joins the cone to the vented back brace, creating a single integrated unit that both cools the motor and eliminates distortion.
The CompRT 8-Inch 48CWRT82 and 48CWRT84 subwoofers work best with a sealed or ported enclosure and 300 watts of recommended power.
Specifications
SIZE [in, cm]:
8, 20
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
600
SENSITIVITY [dB 1w/1m]:
81.8
MOUNTING DEPTH [in, cm]:
2 11/16, 6.7
MOUNTING DIAMETER [in, cm]:
7, 17.7
MIN SEALED BOX VOL [cu. ft, L]:
0.2, 5.66
MAX SEALED BOX VOL [cu. ft, L]:
1.0, 28.32
MIN VENTED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX VENTED BOX VOL [cu. ft, L]:
1.2, 34
Kicker CompRT Subwoofer Manual
