600W x 1 @ 2Ω

Alpine Mono Subwoofer Amplifier, 600-Watts @ 2-Ohm or 330-Watts @ 4-Ohm Impedance The S-Series amplifiers are designed to fit anywhere.  Measuring at 8”, these amplifiers can be mounted under seats or behind panels.  Though they sport a compact footprint on the outside, they produce impressive power on the inside. At 600 watts RMS, the S-A60M is a powerful partner to drive the versatile S-Series subwoofers. The S-Series amplifiers contain technology that was previously only available in our premium line up of amplifiers, the R- and X-Series models. The S-Series models are based on Alpine’s intelligent amplifier platform that ensures superior sound reproduction and precision imaging. With an improved heat sink, and protection circuit design that eliminates thermal shut-down, your music will keep playing no matter where your drive takes you. Specifications 330W RMS x 1 (4Ω, 14.4V, ≤ 1% THD+N) 600W RMS x 1(2Ω, 14.4V, ≤ 1% THD+N) S/N >85dB (ref. 1W into 4Ω) THD+N ≤ 0.03% (ref. 1W into 4Ω) Frequency response =10Hz to 400Hz (+/-3dB) Damping Factor: >1000 Alpine S-A60M Manual

Read more less

5-Channel Class-D System Amplifier with Integrated DSP, 100-Watt x 4 @ 2-Ohm + 600-Watt x 1 @ 2-Ohm Employing JL's second generation NexD2™ amplifier technology, the VX1000/5i efficiently powers a complete audio system. It can drive four main speakers with 75 W x 4 @ 4 ohms while also powering a subwoofer with up to 600W @ 2 ohms. Bridging the main channels converts it into a very powerful, 3-channel system amplifier with up to 200W x 2 @ 4 ohms on the main channels and 600W @ 2 ohms on the subwoofer channel. The NexD2™ full-range technology in the main channels of this amplifier is DSP-controlled and features a reduced loop area design utilizing DirectFET™ outputs for outstanding fidelity, very low noise and exceptional efficiency. The subwoofer channel features an optimized low-frequency variant of the NexD2™ technology. The amplifier chassis is ultra-compact, with all connections on one side, to greatly simplify installation into tight spaces. Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN™ Software application installed. Amplifier includes: Power Connector (for 2 AWG wire), Analog Input/Pre-Out Harness, Speaker Output Harness, Subwoofer Output Connector, 6 ft A/B USB Cable. TüN™ Software Applications Intuitive setup and tuning, all at your fingertips. Automatically recognizes connected amplifier and displays appropriate interface. TüN™ is available for download for free in a variety of applications, for computers and most handheld devices. Unprecedented, Onboard DSP Tuning Power Premium, triple-core AKM® DSP with an optimized configuration, developed in collaboration with AKM® Hi-Res audio processing at 24 bit/96 kHz High-performance AKM® A/D and D/A converters 10 Bands of fully parametric EQ, per output channel, including pre-outs Shelving EQ option for Band 1 and Band 10 High-Pass & Low-Pass Filters for each output channel, with selectable alignments and slopes: Linkwitz-Riley: 12, 24, 48 dB/octaveButterworth: 6, 12, 18, 24, 36, 48 dB/octave Signal Delay in 0.01 millisecond steps (equivalent to 1/8-inch, 3 mm) All-Pass Filter (Phase EQ), with variable "Q" and corner frequency Polarity Reversal (0 or 180 deg.) Output Level Trim in 0.1 dB steps NexD2™ Switching Amplifier Technology JL's latest generation of high-speed switching technology delivers superb low frequency power and efficiency. Specially optimized for subwoofer applications Ultra-Versatile Analog and Digital Inputs High-performance, differential-balanced analog inputs for outstanding noise rejection Accepts speaker level signals from 200 mV, up to 16V RMS, including those from many factory systems Optical Digital (Toslink) input permits direct connection of S/PDIF digital sources, bypassing A/D converter. Accepts up to 24 bit/192 kHz input. Independently configurable RCA analog and digital pre-outs (24 bit/96 kHz) Automatic turn-on options via Signal-Sensing or DC-Offset sensing Functional Compact Chassis Design Solid cast alloy main unibody and bottom plate deliver superb EMI performance and shielding All connections utilize compact mating connectors for maximum integrity and fitment into tight spaces. Configurable LED logo ring displays status and can display audio preset color code or user-defined color Logo badge can be oriented in 90 degree increments Corner caps engineered to conceal mounting holes and hardware JLid™ System Command and Control with Networking Capabilities JL Audio's digital protocol provides control interface and communication between VXi amplifiers and optional JLid™ accessories, including: DRC-100/DRC-200/DRC-205 Digital Remote Controllers: Offers convenient level and DSP preset control from the driver's seat. VXi-BTC Bluetooth® Communicator: Permits wireless configuration of VXi amplifiers using your compatible Apple® or Android® device. VXi-HUB Optical Network Hub: Provides network connectivity for up to five slave VXi amplifiers, allowing synchronization of DRC controllers and DSP presets. Up to two VXi-HUBs can be daisy-chained to network up to ten VXi amplifiers. Specifications Frequency Response (Main Channels) 12 Hz - 24 kHz (+0, -1dB) S/N Ratio, referred to highest rated power (Analog Inputs - Main Channels) 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Frequency Response (Subwoofer Channel) 12 Hz - 1 kHz (+0, -1dB) S/N Ratio, referred to highest rated power (Analog Inputs - Subwoofer Channel) 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W (Analog Inputs - Main Channels) 80 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W (Analog Inputs - Subwoofer Channel) 72 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to highest rated power (Digital Inputs - Main Channels) 100 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to highest rated power (Digital Inputs - Subwoofer Channel) 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W (Digital Inputs - Main Channels) 81 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W (Digital Inputs - Subwoofer Channel) 73 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Damping Factor @ 2 Ω >50 / 50 Hz Damping Factor @ 4 Ω >150 / 50 Hz THD+N @ Rated Power (Main Channels) <1% @ 2 Ω per Ch. THD+N @ Rated Power (Subwoofer Channels) <1% @ 2 Ω per Ch. Input Voltage Range @ RCA Inputs 200 mV - 16 V RMS Min.Copper Power / Ground Wire Gauge 4 AWG wire Fuse Rating 80 A (AFS, AGU or MaxiFuse™) Main Channels @ 4 Ω 75 W RMS x 4 Main Channels @ 2 Ω 100 W RMS x 4 Main Channels - Bridged @ 4Ω 200 W RMS x 2 Subwoofer Channel @ 4 Ω 400 W RMS x 1 Subwoofer Channel @ 3 Ω 500 W RMS x 1 Subwoofer Channel @ 2 Ω 600 W RMS x 1 Subwoofer Channel @ 1.5 Ω N/A JL Audio VX1000/5i Manual

Read more less

Monoblock Class D Subwoofer Amplifier with Integrated DSP, 600-Watt x 1 @ 2-Ohm / 400-Watt x 1 @ 4-Ohm Designed to simplify great audio, every VXi amplifier combines JL's advanced NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor. The VX600/1i monoblock subwoofer amplifier outputs up to 400 watts into 4 ohms, or a staggering 600 watts into 2 ohms. A specialized, low-frequency version of JL's NexD2™ amplifier technology delivers rock-solid bass performance and fidelity, with outstanding efficiency. Compact dimensions with all connections placed on one side, via mating plugs, greatly simplify installation into tight spaces. Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN™ Software application installed. Amplifier includes: Power Connector (for 4 AWG wire), Analog Input/Pre-Out Harness, Subwoofer Output Connector, 6 ft A/B USB Cable TüN™ Software Applications Intuitive setup and tuning, all at your fingertips. Automatically recognizes connected amplifier and displays appropriate interface. TüN™ is available for download for free in a variety of applications, for computers and most handheld devices. Unprecedented, Onboard DSP Tuning Power Premium, triple-core AKM® DSP with an optimized configuration, developed in collaboration with AKM® Hi-Res audio processing at 24 bit/96 kHz High-performance AKM® A/D and D/A converters 10 Bands of fully parametric EQ, per output channel, including pre-outs Shelving EQ option for Band 1 and Band 10 High-Pass & Low-Pass Filters for each output channel, with selectable alignments and slopes: Linkwitz-Riley: 12, 24, 48 dB/octaveButterworth: 6, 12, 18, 24, 36, 48 dB/octave Signal Delay in 0.01 millisecond steps (equivalent to 1/8-inch, 3 mm) All-Pass Filter (Phase EQ), with variable "Q" and corner frequency Polarity Reversal (0 or 180 deg.) Output Level Trim in 0.1 dB steps NexD2™ Switching Amplifier Technology JL's latest generation of high-speed switching technology delivers superb low frequency power and efficiency. Specially optimized for subwoofer applications Ultra-Versatile Analog and Digital Inputs High-performance, differential-balanced analog inputs for outstanding noise rejection Accepts speaker level signals from 200 mV, up to 16V RMS, including those from many factory systems Optical Digital (Toslink) input permits direct connection of S/PDIF digital sources, bypassing A/D converter. Accepts up to 24 bit/192 kHz input. Independently configurable RCA analog and digital pre-outs (24 bit/96 kHz) Automatic turn-on options via Signal-Sensing or DC-Offset sensing Functional Compact Chassis Design Solid cast alloy main unibody and bottom plate deliver superb EMI performance and shielding All connections utilize compact mating connectors for maximum integrity and fitment into tight spaces. Configurable LED logo ring displays status and can display audio preset color code or user-defined color Logo badge can be oriented in 90 degree increments Corner caps engineered to conceal mounting holes and hardware JLid™ System Command and Control with Networking Capabilities JL Audio's digital protocol provides control interface and communication between VXi amplifiers and optional JLid™ accessories, including: DRC-100/DRC-200/DRC-205 Digital Remote Controllers: Offers convenient level and DSP preset control from the driver's seat. VXi-BTC Bluetooth® Communicator: Permits wireless configuration of VXi amplifiers using your compatible Apple® or Android® device. VXi-HUB Optical Network Hub: Provides network connectivity for up to five slave VXi amplifiers, allowing synchronization of DRC controllers and DSP presets. Up to two VXi-HUBs can be daisy-chained to network up to ten VXi amplifiers. Specifications Frequency Response 12 Hz - 500 Hz (+0, -1dB) S/N Ratio, referred to highest rated power(Analog Inputs) 90 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W(Analog Inputs) 64 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to highest rated power(Digital Inputs) 90 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W(Digital Inputs) 64 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Damping Factor @ 4 Ω >125 / 50 Hz Damping Factor @ 2 Ω >125 / 50 Hz THD+N @ Rated Power <1% @ 2 Ω per Ch. Input Voltage Range @ RCA Inputs 200 mV - 16 V RMS Min.Copper Power / Ground Wire Gauge 4 AWG wire Fuse Rating 50 A (AFS, AGU or MaxiFuse™) @ 4 Ω 400 W RMS x 1 @ 3 Ω 500 W RMS x 1 @ 2 Ω 600 W RMS x 1 @ 1.5 Ω N/A JL Audio VX600/1i Manual

Read more less

XDM-Series Five-Channel Class-D Marine-Grade Amplifier, 75-Watts x Four-Channels @ 4-Ohm and 600-Watt Mono @ 2-Ohm The XDM1000/5 delivers up to 1000W of clean power and is ideal for an audiophile-grade, subwoofer + four satellite system. With this potent powerhouse, you can drive two pairs of quality component speaker systems with plenty of clean power (75W x 4 @ 4Ω), while also generating a stout 600W of power for a subwoofer system. The technology that makes this much power possible in such a small chassis is JL-Audio's high-speed NexD switching amplifier design. Suitable for car or boat installations, the XDM1000/5 is built with marine-grade materials and features an exclusive, dual-mode input filter for noise-free performance in boats or cars. Automatic turn-on capability (via signal sensing or DC-offset sensing) is also onboard for easy factory system upgrades. The XDM1000/5 includes a 12dB / octave high-pass filter for one main channel pair, a 12dB octave high-pass or bandpass filter for the other main channel pair, plus a variable slope low-pass filter for its subwoofer channel. All three filters offer continuously variable cutoff frequency selection from 50-500Hz. This amplifier's filters can also be configured as a true 3-way crossover, with a low-pass filter for the subwoofer channel, a bandpass filter on Ch. 3 & 4, and a high-pass filter on Ch. 1 & 2. An "x10" multiplier switch on the Ch. 1 & 2 high-pass filter allows its cutoff frequency to be adjusted from 50-500Hz or 500-5000Hz. With the addition of an optional HD-RLC or MHD-RLC (water-resistant) remote level controller (each sold separately), you have the ability to adjust the level of all amplifier channels or just the subwoofer channel directly from the driver's seat or helm. Finished in a sleek, black powder-coat, all controls are protected beneath a gasketed, removable top cover for easy access. Specifications Main Channels @ 4 Ω 75 W RMS x 4 @ 14.4V Main Channels @ 2 Ω 100 W RMS x 4 @ 14.4V Main Channels - Bridged @ 4Ω 200 W RMS x 2 @ 14.4V Subwoofer Channel @ 4 Ω 400 W RMS x 1 @ 14.4V Subwoofer Channel @ 3 Ω 500 W RMS x 1 @ 14.4V Subwoofer Channel @ 2 Ω 600 W RMS x 1 @ 14.4V Subwoofer Channel @ 1.5 Ω N/A Main Channels @ 4 Ω 60 W RMS x 4 @ 12.5V Main Channels @ 2 Ω 90 W RMS x 4 @ 12.5V Main Channels - Bridged @ 4Ω 180 W RMS x 2 @ 12.5V Subwoofer Channel @ 4 Ω 360 W RMS x 1 @ 12.5V Subwoofer Channel @ 3 Ω 480 W RMS x 1 @ 12.5V Subwoofer Channel @ 2 Ω 600 W RMS x 1 @ 12.5V Subwoofer Channel @ 1.5 Ω N/A Frequency Response (Main Channels) 12 Hz - 22 kHz (+0, -1dB) Frequency Response (Subwoofer Channel) 10 Hz - 1 kHz (+0, -1dB) S/N Ratio, referred to highest rated power (Main Channels) >104 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W >84 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Damping Factor @ 4 Ω >150 / 50 Hz Damping Factor @ 2 Ω >75 / 50 Hz THD+N @ Rated Power (Main Channels) <1% @ 2 Ω per Ch. THD+N @ Rated Power (Subwoofer Channels) <1% @ 2 Ω per Ch. Input Voltage Range @ RCA Inputs 200 mV - 4 V RMS Min.Copper Power / Ground Wire Gauge 4 AWG wire Fuse Rating 80 A (AFS, AGU or MaxiFuse™) Filter Mode(s): Channels 1 & 2 (front) High-Pass only Filter Slope(s): Channels 1 & 2 (front) 12 dB/octave Filter Frequency Range: Channels 1 & 2 (front) 50 Hz - 5 kHz Filter Mode(s): Channels 3 & 4 (rear) High-Pass or Bandpass Filter Slope(s): Channels 3 & 4 (rear) 12 dB/octave Filter Frequency Range: Channels 3 & 4 50 Hz - 500 Hz Filter Mode(s): Subwoofer Channel Low-Pass only Filter Slope(s): Subwoofer Channel 12/24 dB/octave Filter Frequency Range: Subwoofer Channel 50 Hz - 500 Hz Detented, Calibrated Filter Freq. Potentiometers Yes Filter Defeat Function Yes Infrasonic Filter: Subwoofer Channel none Remote Level Control Optional HD-RLC or MHD-RLC (water-resistant) Remote Level Modes Sub Ch. or All Channels Channel Input Mode Switch Yes (2/4/6 ch.) Pass-Through Preamp Output None Source Channel Selection for PreOuts N/A Height (H) 2.05 in / 52 mm Width (W) 14.73 in / 374 mm Depth (D) 7.09 in / 180 mm JL Audio XDM1000/5v2 Manual

Read more less

XDM-Series Monoblock Class-D Marine-Grade Amplifier, 600-Watts @ 2-Ohm or 400-Watts @ 4-Ohm This potent monoblock amplifier employs JL-Audio's high-speed NexD switching design to achieve unprecedented efficiency and amazing power output from a very compact chassis. Don't let its small size fool you, though... the XDM/600/1 generates serious subwoofer power, delivering a full 600W of continuous power into a 2-ohm load (14.4V, 1% THD). Designed for car or boat installations, the XDM600/1 is built with marine-grade materials and features an exclusive, dual-mode input filter for noise-free performance in boats or cars. Automatic turn-on capability (via signal sensing or DC-offset sensing) is also onboard for easy factory system upgrades. Targeted specifically for subwoofer applications, the XDM600/1 includes a variable slope low-pass filter with continuously variable cutoff frequency selection from 50-500Hz. With the addition of an optional HD-RLC or MHD-RLC (water-resistant) remote level controller (each sold separately), the amplifier's level can be adjusted directly from the driver's seat or captain’s chair. Finished in a sleek, black powder-coat, all controls are protected beneath a gasketed, removable top cover for easy access. Specifications @ 4 Ω 400 W RMS x 1 @ 14.4V @ 3 Ω 500 W RMS x 1 @ 14.4V @ 2 Ω 600 W RMS x 1 @ 14.4V @ 1.5 Ω N/A @ 4 Ω 300 W RMS x 1 @ 12.5V @ 3 Ω 400 W RMS x 1 @ 12.5V @ 2 Ω 500 W RMS x 1 @ 12.5V @ 1.5 Ω N/A Frequency Response 7 Hz - 500 Hz (+0, -1dB) S/N Ratio, referred to highest rated power >87 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W >67 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Damping Factor @ 4 Ω >1000 / 50 Hz Damping Factor @ 2 Ω >500 / 50 Hz THD+N @ Rated Power <1% @ 2 Ω per Ch. Input Voltage Range @ RCA Inputs 200 mV - 4 V RMS Min.Copper Power / Ground Wire Gauge 4 AWG wire Fuse Rating 50 A (AFS, AGU or MaxiFuse™) Filter Mode(s) Low-Pass only Filter Slope(s) 12/24 dB/octave Filter Frequency Range 50 Hz - 500 Hz Detented, Calibrated Filter Freq. Potentiometer Yes Filter Defeat Function Yes Infrasonic Filter 30 Hz, defeatable Bass Boost EQ No Output Polarity Switch No Remote Subwoofer Level Control Optional HD-RLC or MHD-RLC (water-resistant) Remote Bass EQ Boost Control No Pass-Through Preamp Output Buffered Height (H) 2.05 in / 52 mm Width (W) 8.52 in / 216 mm Depth (D) 7.09 in / 180 mm Net Weight 6.3 lb / 2.86 kg JL Audio XDM600/1 Manual

Read more less

Mono Amplifier, 600-Watts at 2-Ohm, 300-Watts at 4-Ohm This CX-Series 1-channel amplifier by Kicker has an optimized circuit layout and the highest-grade internal components. Highly efficient heat sinks keep the amp cool with a sophisticated new look. Mono amps offer an optional remote level control to adjust your bass right from the dash. Efficient Class-D amplifier Three-second turn-on/off delay to eliminate unwanted interference Variable 12dB crossovers provides control to dial in perfect sound KickEQ™ 6dB variable bass boost for those additional low frequencies 24dB subsonic filter for protection from potentially damaging frequencies FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio Accepts up to 40-volt input signal Small footprint for easier installation Vertical mounting hardware included for another unique look This Kicker 46CXA8001t amplifier delivers as much as 600W into one bass channel. Specifications MODEL CXA800.1 Power (watts/ch) 4 Ohm 300x1 Power (watts/ch) 2 Ohm 600x1 Power (watts/ch) 1 Ohm 800x1 CXRC Remote Bass Capable (sold sep.) yes Dimensions (in, cm) (all models 2-3/8, 5.9H x 6-3/4, 17W x ...L)8-1/8, 20.6 Frequency Response (Hz): 25-200, +0/-1dB Input Sensitivity: 250mV-10V (Low Level)1V-40V (High Level) Signal-to-Noise Ratio: >95dB, a-weighted, re: rated power Active Crossover: Variable Lo-pass 50Hz–200Hz, 12dB/octave Subsonic Filter: 25Hz @24dB/octave KickEQ™ Boost Variable 0-6dB @40Hz Kicker CXA Mono Amplifier Manual

Read more less
