Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2000-2003 Ford-F150 Super-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2000-2003 Super CAB trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.7 Cubic Feet Net Volume internal air space (per sub) is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.5” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 5.75”, Width: 50.5” Height: 8”, Depth: 14.38”
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:50.50"
Height:7.50"
Depth:14.38"
Max Mounting Depth:5.50"
Gross VolumePer Sub:0.75
Net Volume Per Sub:0.75
Dual 12-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2000-2003 Ford F-150 Super-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 12” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2000-2003 Super CAB trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.7 Cubic Feet Net Volume internal air space (per sub) is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.75” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 11.125”, Mounting Depth: 5.75”, Net Air Volume: 0.7 cu. ft., Width: 50.5” Height: 8”, Depth: 14.38”
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:50.50"
Height:7.50"
Depth:14.38"
Max Mounting Depth:5.50"
Gross VolumePer Sub:0.75
Net Volume Per Sub:0.75
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1983-2012 Ford-Ranger Extended-Cab and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1983-2012 Ford ranger Extended Cab / Super Cab trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
1.0 Cubic Feet Net Volume internal air space is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.12” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 9.125”, Sub Mounting Depth: 6.12”, Width:43.25”, Height: 7.5”, Depth: 13.5”
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:43.25"
Height:7.50"
Depth:13.50"
Max Mounting Depth:5.50"
Gross VolumePer Sub:2.39
Net Volume Per Sub:1.70
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1997-1999 Ford F-150 Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1997-1999 F150 Extended Cab trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.7 Cubic Feet Net Volume internal air space (per sub) is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.25” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 5.25”, Width: 48” Height: 7.75”, Depth: 13.75”
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:48.00"
Height:7.00"
Depth:13.75"
Max Mounting Depth:5.00"
Gross VolumePer Sub:2.83
Net Volume Per Sub:2.03
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2009-2018 Ford F-150 & 2017-2018 F-250, F-350 and F-450 SuperCrew and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 2009-2018 Ford F150 Super Crew/Super Cab
Will also work in 2017 - 2018 F250/350/450 Super Crew / Super Cab
Premium Carpeted Finish
3/4" Hardwood MDF
Glued and Braced construction
CNC Grooved custom finish
Rounded edges
Silver spring loaded terminal cups
Subwoofer mounting depth: 4.5"
Box volume: 0.8 cubic feet (per chamber)
Sub Cut Out: 9.125”, Width:26”, Height: 9”, Depth: 13.25”
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:26.00"
Height:4.63"
Depth:13.25"
Max Mounting Depth:4.50"
Gross VolumePer Sub:1.37
Net Volume Per Sub:0.92
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2009-2018 Ford F-150 Extended-Cab & 2017-2018 F-250, F-350 and F-450 SuperCrew and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 2009-2018 Ford F150 Extended Cab Trucks
2015-2018 Models causes the enclosure to stick out 2" near the foot area
Will also work with 2017-2018 F250, F350, F450 Super Crew / Super Cab
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 5.375"
Box volume: 0.8 cubic feet (per chamber)
Installation Note: Will also work with 2017-2018 F250, F350, F450 Super Crew / Super Cab. OEM Jack removal required on some models during installation.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:50.50"
Height:5.00"
Depth:13.25"
Max Mounting Depth:4.50"
Gross VolumePer Sub:0.00
Net Volume Per Sub:0.80
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1997 -2003 Ford F-150 SuperCrew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1997-2003 Super Crew trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
.91 Cubic Feet Net Volume internal air space (per sub) is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.75” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 5.75”, Width: 43.75” Height: 10.25”, Depth: 13.5”
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:43.75"
Height:5.63"
Depth:13.50"
Max Mounting Depth:5.75"
Gross VolumePer Sub:2.55
Net Volume Per Sub:1.83
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2009-2018 Ford F-150 SuperCrew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 2009-2018 Ford F150 Crew Cab Trucks
May fit some 2019 legacy models
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 6"
Box volume: 0.8 cubic feet
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:26.00"
Height:5.75"
Depth:13..625"
Max Mounting Depth:5.00"
Gross VolumePer Sub:1.49
Net Volume Per Sub:1.01
Installation Note: Installs under the rear seat with Subwoofers facing down.
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2009-2018 Ford F-150 SuperCrew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 2009-2018 Ford F150 Crew Cab Trucks
May fit some 2019 legacy models
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 6"
Box volume: 0.8 cubic feet (per chamber)
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:50.63"
Height:5.75"
Depth:13.63"
Max Mounting Depth:5.00"
Gross VolumePer Sub:2.90
Net Volume Per Sub:2.07
Installation Note: Installs under the rear seat with Subwoofers facing down.
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2004-2008 Ford F-150 SuperCrew and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2004-2008 Super Crew / Super Cab trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
.76 Cubic Feet Net Volume internal air space is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.25” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, mounting depth: 7” Front Height: 7.75”, Rear Height: 6.75”, Depth: 11.75”
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:23.38"
Height:6.75"
Depth:11.75"
Max Mounting Depth:5.25"
Gross VolumePer Sub:1.15
Net Volume Per Sub:0.76
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 2004-2008 Ford F-150 SuperCrew and Super-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single Vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2004-2008 Super Crew / Super Cab trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
.76 Cubic Feet Net Volume internal air space is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.25” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, mounting depth: 7” Front Height: 7.75”, Rear Height: 6.75”, Depth: 11.75”
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width:32.00"
Height:6.75"
Depth:11.75"
Max Mounting Depth:5.25"
Gross VolumePer Sub:1.58
Net Volume Per Sub:1.04
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2004-2008 Ford F-150 SuperCrew and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Dual sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2004-2008 Super Crew / Super Cab trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
.825 Cubic Feet Net Volume internal air space (per sub) is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.25” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium Carpet Finish
Dimensions Sub cut out: 9.125”, mounting depth: 5.25”
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:49.25"
Height:6.75"
Depth:11.75"
Max Mounting Depth:5.25"
Gross VolumePer Sub:2.36
Net Volume Per Sub:1.65
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 1999-2007 Ford F-250, F-350 and F-450 Crew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 1999-2007 Ford F250/F350/F450 Crew Cab Trucks
Premium carpeted finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 4.75"
Box volume: 1.19 cubic feet (per chamber)
Installation Note: Fits behind the rear seat, removal of jack kit is required along with rear seat belt cover and carpet. The power motor will need to be removed during installation
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width:55.25"
Height:16.13"
Depth:6.13"
Max Mounting Depth:5.50"
Gross VolumePer Sub:2.46
Net Volume Per Sub:1.55
Installation Note: Fits behind the rear seat, removal of jack kit is required along with rear seat belt cover and carpet. The power motor will need to be removed during installation
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2008-2016 Ford F-250, F-350, and F-450 Crew-Cab Trucks
Designed specifically for 2008-2016 Ford F250/F350/F450 Crew Cab Trucks
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 4.75"
Box volume: 0.65 cubic feet (per chamber)
Installation Note: Fits models with and without electric rear window. Fits behind the rear seat. Removal of jack kit is required. Removal of rear seat belt cover and rear carpet is required. The power window motor will need to be removed during installation.
Specifications
Configuration: Dual Sealed
Finish: Charcoal Carpeted
Width:55.25"
Height:16.13"
Depth:6.13"
Max Mounting Depth:5.50"
Gross VolumePer Sub:2.46
Net Volume Per Sub:1.55
Factory OEM Amplifier Bypass Wiring Harness for Select 2011-UP Ford (works with Sony Compatible Systems)
Amplifier bypass harness
Vehicle-specific harness to bypass the factory amplifier
Allows loose wires to wire to an aftermarket amplifier
Saves the installer unnecessary labor and wire
Applications
FORD
Edge
Sony or Non-amplified
2011-2018
Escape
2015-2019
Expedition
Sony or Non-amplified
2015-2017
Explorer
Sony or Non-amplified
2011-2019
F-150
Sony or Non-amplified
2014-2016
Flex
2013-2019
Focus
2012-2019
Fusion
2013-2020
Super Duty
Sony or Non-amplified
2019-2020
Taurus
2013-2019
Axxess AXABH-FD1 Brochure
Amplifier Add-On OEM Line-Converter T-Harness for Select 2011-UP Ford Vehicles
For use with the Axxess AXDSP-L line converter.
Applications
FORD
CMAX
non-amplified
2013-2017
Edge
Sony or Non-amplified
2011-2018
Edge
2019-2023
Escape
2015-2019
Expedition
Sony or Non-amplified
2015-2017
Expedition
2018-2022
Explorer
Sony or Non-amplified
2011-2019
F-150
Sony or Non-amplified
2014-2016
F-150
2017-2020
Fiesta
2011-2019
Flex
2013-2019
Focus
2012-2019
Fusion
2013-2020
Mustang
2015-2023
Ranger
2019-2023
Super Duty
Sony or Non-amplified
2019-2019
Taurus
2013-2019
Axxess AXDSPH-FD2 ManualAxxess AXDSPL-FD2 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2016-UP Ford Vehicles
For use with the Axxess AXDSP-L line converter.
Applications
FORD
Bronco
2020-2023
Bronco Sport
2020-2023
E series
2021-2023
EcoSport
2018-2023
Escape
2020-2023
Expedition
non-amplified
2018-2021
Explorer
2020-2023
F-150
2021-2022
F-250
non-amplified
2020-2020
Axxess AXDSPH-FD3 ManualAxxess AXDSPL-FD3 Manual
Add-On Amplifier OEM Integration Line Converter with DSP for Select 2006-2014 Ford Vehicles
Upgrade the sound system with this cost-effective, easy-to-install DSP“Lite” package that includes a vehicle-specific T-harness. It works with OEM or aftermarket radios to take fixed level/digitally controlled analog audio and convert it to 6 channels of analog signal for use with an aftermarket amplifier or DSP.
Retain Features with a Built-in InterfaceWhile this may be a “Lite” version, it still provides retention of many important vehicle functions utilizing Axxess’s cutting-edge technology. It features chime control, retains OEM voice prompts and sonar sensors, and has clipping detection and limiting circuits, going beyond what a traditional DSP can do.
Complete Tuning ControlThere are 4 inputs and 6 outputs, including front, rear and subwoofer, and the front and rear outputs can be delayed independently up to 10ms. Full tuning control settings are adjusted via a smart device application for tablets or mobile phones and can be password-protected once set up. Once tuning has been completed, installers can password-protect their settings to prevent anyone else from adjusting, and the information is stored for future recall.
Designed for amplified and non-amplified models
Package includes the AXDSP-L and vehicle-specific T-harness
15-band graphic EQ or 5-band Parametric EQ
Selectable high pass, low pass, or bandpass filters on each channel
4 inputs and 6 individually assignable outputs
Independent equalization on each of the 6 outputs
Selectable slope (12, 24, 36, or 48db per octave)
Each channel can be delayed independently for up to 10 ms
Easy behind the radio installation in most applications
Can be used with OE and aftermarket radios
Clipping detection and limiting circuits
Internal header port for adding interface modules
Bass knob included
Retains OE voice prompts (Sync®)
Retains factory chimes, including parking sensor and cross path detection alerts with adjustable chime level
Settings adjusted wirelessly in a smart device application (tablet or mobile phone)
Read, write, and store configurations for future recall
Password-protect feature is available in the mobile app
Applications
FORD
Edge
2007-2010
Escape
2008-2012
Expedition
Non-Sony
2007-2014
F-150
2006-2013
Flex
2009-2012
Focus
2008-2011
Fusion
2006-2012
Mustang
2006-2014
Taurus
2008-2011
Axxess AXDSPL-FD1 Manual
Add-On Amplifier OEM Integration Line Converter with DSP for Select 2011-UP Ford Vehicles
Upgrade the sound system with this cost-effective, easy-to-install DSP“Lite” package that includes a vehicle-specific T-harness. It works with OEM or aftermarket radios to take fixed level/digitally controlled analog audio and convert it to 6 channels of analog signal for use with an aftermarket amplifier or DSP.
Retain Features with a Built-in InterfaceWhile this may be a “Lite” version, it still provides retention of many important vehicle functions utilizing Axxess’s cutting-edge technology. It features chime control, retains OEM voice prompts and sonar sensors, and has clipping detection and limiting circuits, going beyond what a traditional DSP can do.
Complete Tuning ControlThere are 4 inputs and 6 outputs, including front, rear and subwoofer, and the front and rear outputs can be delayed independently up to 10ms. Full tuning control settings are adjusted via a smart device application for tablets or mobile phones and can be password-protected once set up. Once tuning has been completed, installers can password-protect their settings to prevent anyone else from adjusting, and the information is stored for future recall.
Designed for amplified and non-amplified models
Package includes the AXDSP-L and vehicle-specific T-harness
15-band graphic EQ or 5-band Parametric EQ
Selectable high pass, low pass, or bandpass filters on each channel
4 inputs and 6 individually assignable outputs
Independent equalization on each of the 6 outputs
Selectable slope (12, 24, 36, or 48db per octave)
Each channel can be delayed independently for up to 10 ms
Easy behind the radio installation in most applications
Can be used with OE and aftermarket radios
Clipping detection and limiting circuits
Internal header port for adding interface modules
Bass knob included
Retains OE voice prompts (Sync®)
Retains factory chimes, including parking sensor and cross path detection alerts with adjustable chime level
Settings adjusted wirelessly in a smart device application (tablet or mobile phone)
Read, write, and store configurations for future recall
Password-protect feature is available in the mobile app
Applications
FORD
CMAX
non-amplified
2013-2017
EcoSport
2016-2019
Edge
Sony or Non-amplified
2011-2018
Edge
2019-2023
Escape
2015-2019
Expedition
Sony or Non-amplified
2015-2017
Expedition
2018-2022
Explorer
Sony or Non-amplified
2011-2019
F-150
Sony or Non-amplified
2014-2016
F-150
2017-2020
Fiesta
2011-2019
Flex
2013-2019
Focus
2012-2019
Fusion
2013-2020
Mustang
2015-2023
Ranger
2019-2023
Super Duty
Sony or Non-amplified
2019-2020
Axxess AXDSPL-FD2 Manual
Add-On Amplifier OEM Integration Line Converter with DSP for Select 2020-UP Ford Vehicles
Upgrade the sound system with this cost-effective, easy-to-install DSP“Lite” package that includes a vehicle-specific T-harness. It works with OEM or aftermarket radios to take fixed level/digitally controlled analog audio and convert it to 6 channels of analog signal for use with an aftermarket amplifier or DSP.
Retain Features with a Built-in InterfaceWhile this may be a “Lite” version, it still provides retention of many important vehicle functions utilizing Axxess’s cutting-edge technology. It features chime control, retains OEM voice prompts and sonar sensors, and has clipping detection and limiting circuits, going beyond what a traditional DSP can do.
Complete Tuning ControlThere are 4 inputs and 6 outputs, including front, rear and subwoofer, and the front and rear outputs can be delayed independently up to 10ms. Full tuning control settings are adjusted via a smart device application for tablets or mobile phones and can be password-protected once set up. Once tuning has been completed, installers can password-protect their settings to prevent anyone else from adjusting, and the information is stored for future recall.
Designed for non-amplified models
Package includes the AXDSP-L and vehicle-specific T-harness
Selectable 15-band graphic EQ or 5-band Parametric EQ
Selectable high pass, low pass, or bandpass filters on each channel
4 inputs and 6 individually assignable outputs
Independent equalization for front, rear and sub
Selectable crossover slope (12, 24, 36, or 48db per octave)
Each channel can be delayed independently for up to 10ms
Easy behind the radio installation with pre-wired harness
Can be used with OE and aftermarket radios
Clipping detection and limiting circuits
Internal header port for adding interface modules
Bass knob included for level control of subwoofer amp
Settings adjusted via Bluetooth® in a smart device application (tablet or mobile phone) compatible with both Android and Apple devices
Read, write, and store configurations for future recall
Password-protect feature is available in the mobile app
Applications
FORD
Bronco
2020-2023
Bronco Sport
2020-2023
E series
2021-2023
EcoSport
2020-2023
Escape
2020-2023
Expedition
non-amplified
2018-2021
Explorer
2020-2023
F-150
2021-2022
Axxess AXDSPL-FD3 Manual
Add-On Amplifier OEM Integration Line Converter with DSP and Factory-Amplifier Bypass-Harness for Select 2015-UP Amplified Ford Vehicles with Bang and Olufsen Sound Systems
Upgrade your sound system with this cost-effective, easy-to-install DSP package that includes a vehicle-specific T-harness.
Complete Tuning ControlInstallers will have full control to fine-tune each of the 10 channel outputs individually, controlled wirelessly via a free app available for smartphones and tablets. The app makes tuning easy with a 31-band graphic EQ and up to 10ms time delay for each channel, with independent high pass, low pass, and bandpass filters.
Retain Features with a Built-in InterfaceUtilizing Axxess’s data interface technology, the AXDSP-X goes beyond what a traditional DSP can do and retains many of the features commonly lost when upgrading a sound system. Voice prompts, parking sensor chimes, and other factory chimes are retained with an adjustable volume control that many traditional DSPs cannot offer. This is a cost-effective solution for customers who want to retain their factory radio and improve their vehicle sound quality, while still retaining systems like SYNC or OnStar®.
One Solution, Many ApplicationsThe AXDSP-X solution already works with a wide range of vehicle applications and systems, including OE or aftermarket radios, and fixed-level analog and/or digitally controlled amplified systems, in addition to non-amplified vehicles that do not have chimes. The AXDSP-X works with all the existing DSP T-harnesses and still offers the same easy installation behind the radio.
Package includes the A2B interface, vehicle-specific T-harness, and amplifier bypass harness
Designed for select vehicles with a B&O A2B amplifier
Uses AXDSP-X technology
31-band graphic EQ or 5-band Parametric EQ
Selectable high pass, low pass, or bandpass filters on each channel
6 inputs and 10 individually assignable outputs
Independent equalization on each of the 6 outputs
Selectable slope (12, 24, 36, or 48db per octave)
Each channel can be delayed independently for up to 10ms
Easy behind the radio installation in most applications
Can be used with OE and aftermarket radios
Clipping detection and limiting circuits
Internal header port for adding interface modules
Bass knob included
Retains OE voice prompts (SYNC) with adjustable level
Retains factory chimes, including parking sensor and cross path detection alerts with adjustable chime level
Chimes and voice prompts go through the aftermarket amplifier
Factory amplifier CANNOT be retained
Settings adjusted wirelessly in a smart device application (tablet or mobile phone)
Read, write, and store configurations for future recall
Password-protect feature is available in the mobile app
Micro “B” USB updatable
1-year limited warranty
Applications
FORD
Bronco
B&O system
2020-2023
Bronco Sport
B&O system
2020-2023
EcoSport
B&O system
2016-2019
EcoSport
B&O system
2020-2023
Edge
B&O system
2019-2023
Edge
B&O system
2019-2023
Edge
B&O system
2019-2023
Escape
B&O system
2020-2023
Explorer
B&O system
2020-2023
F-150
B&O system
2017-2020
F-150
B&O system
2018-2020
F-150
B&O system
2021-2022
F-250
B&O system
2020-2020
F-250
B&O system
2020-2020
Ranger
B&O system
2019-2023
Axxess AXDSPX-A2B2 Manual
Add-On Amplifier OEM Integration Interface for Select 2003-2019 Ford, Lincoln, Mazda and Mercury Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-FD1 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications
FORD
Crown Victoria
non-amplified
2003-2011
E-Series
non-amplified
2009-2019
Edge
non-amplified
2007-2010
Explorer
non-amplified
2006-2010
F-Series
non-amplified
2004-2016
F650/F750
non-amplified
2011-2019
Five Hundred
non-amplified
2005-2007
Flex
non-amplified
2009-2012
Focus
non-amplified
2005-2011
Freestar
non-amplified
2004-2007
Freestyle
non-amplified
2005-2007
Fusion
non-amplified
2006-2012
Mustang
non-amplified
2004-2014
Taurus
non-amplified
2008-2012
Thunderbird
non-amplified
2004-2005
Transit Connect
non-amplified
2010-2013
LINCOLN
LS
non-amplified
2003-2006
MKX
non-amplified
2007-2010
MKZ
non-amplified
2007-2009
Navigator
non-amplified
2003-2006
Towncar
non-amplified
2003-2011
Zephyr
non-amplified
2006-2006
MAZDA
Tribute
non-amplified
2008-2011
MERCURY
Grand Marquis
non-amplified
2003-2011
Mariner
non-amplified
2005-2011
Milan
non-amplified
2006-2011
Montego
non-amplified
2005-2007
Monterey
non-amplified
2004-2011
Mountainer
non-amplified
2006-2010
Sable
non-amplified
2008-2009
Axxess AXLOC-FD1 Manual
Add-On Amplifier OEM Integration Interface for Select 2011-UP Ford Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-FD2 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications
FORD
Edge
non-amplified
2011-2020
Escape
non-amplified
2013-2019
Explorer
non-amplified
2011-2019
F-150
non-amplified
2013-2020
F250/F350/F450/F550
non-amplified
2013-2019
Fiesta
non-amplified
2011-Up*
FLEX
non-amplified
2013-2019
Focus
non-amplified
2012-2018
Fusion
non-amplified
2013-2020
Mustang
non-amplified
2015-2020
Ranger
non-amplified
2019-2020
TAURUS
non-amplified
2013-2019
Transit 150/250/350
non-amplified
2015-2019
Transit Connect
non-amplified
2014-2018
Axxess AXLOC-FD2 Manual
Non-Amplified Head-Unit Replacement Wiring-Harness Adapter for Select 2011-2019 Ford Vehicles
Provides accessory power (12 volt 10 amp)
Retains R.A.P. (retained accessory power)
Provides illumination, parking brake, reverse, and speed sense outputs
Prewired AXSWC harness
Retains balance and fade
USB Micro-B updatable
Note: The AXVI-5524 does not retain SYNC.
Non-Amplified Applications
FORD
F-250/350/450/550
manual climate w/o color screen
2017-2019
Focus
w/o MyFord Touch
2012-2014
Transit Connect
w/ cd (black color dash)
2014-2018
Transit Connect
w/ cd (gray color dash)
2014-2018
Escape
S trim w/ 4.2" screen
2019-2019
Escape
w/ 4.2-inch screen
2013-2018
Transit 150/250/350
AM/FM/CD radio
2015-2019
Fiesta
w/o 6-inch SYNC-3 radio or NAV (black color dash)
2016-2019
Fiesta
w/o 6-inch SYNC-3 radio or NAV (silver color dash)
2016-2019
Fiesta
w/o 6-inch MyFord Touch radio (black color dash)
2014-2015
Fiesta
w/o 6-inch MyFord Touch radio (silver color dash)
2014-2015
Fiesta
w/ SYNC (black color dash)
2011-2013
Fiesta
w/ SYNC (silver color dash)
2011-2013
Axxess Interface AXVI-5524 Installation Manual
Tailgate-Handle Style Backup-Camera with Chrome-Finish for Select 2005-2016 Ford F-Series Pickups
Add an unobtrusive rear-view backup camera that matches your vehicles factory tailgate with iBeams new replacement tailgate handle camera. A 150 degree viewing angle with 0.5 LUX night vision and defeatable parking lines offer added visibility for drivers to see what is behind them. A 1/3inch CMOS camera provides a sharp clear picture during the day or night. A 26 foot harness is included to connect the camera to your aftermarket radio (radio not included) for video input.
Chrome finished handle
1/3in CMOS Camera
150 Degree Viewing Angle
Replaces the OEM tailgate handle
0.5 lux night vision
Defeatable parking lines
26 foot harness included
Applications
FORD
F-150, F-250, F-350, F-450
Excludes 2004 Heritage model
2005-2014
F-250, F-350, F-450, F-550
Superduty
2008-2016
iBeam TE-FCTGC Manual
Tailgate-Mountable Backup-Camera for Select 1997-2004 Ford F-150 and 1999-2007 F-150 Super-Duty Pickups
Upgrade the factory tailgate handle with an unobtrusive rearview backup camera. This CMOS .25” sensor provides a sharp, clear picture and is rated IP69. With a wide field of view, 0.1 lux night vision and defeatable parking lines, it allows the driver to backup their vehicle day or night with confidence.
Fits Ford F-150 1997-2005 & Super Duty 1999-2007
Replaces OE handle
CMOS 1/4 sensor
Resolution: 400 TV lines
Field of view: diagonal 168 degrees, horizontal 136 degrees, Vertical 100 degrees
0.1 LUX
IP69
defeatable parking lines
26 ft extension cable
3 year warranty
Applications
FORD
F-150
1997-2004
F-250, F-350, F-450, F-550
SuperDuty
1999-2007
iBeam TE-FDFTG Manual
Add-on or Replacement Tailgate-Handle Style Backup-Camera for Select 2015-2020 Ford F-150 Pickups
Add an unobtrusive rear-view backup camera that matches your vehicles factory tailgate with iBeams new replacement tailgate handle camera. A 150 degree viewing angle with 0.5 LUX night vision and defeatable parking lines offer added visibility for drivers to see what is behind them. A 1/3 inch CMOS camera provides a sharp clear picture during the day or night. A 26 foot harness is included to connect the camera to your aftermarket radio (radio not included) for video input.
1/3in CMOS Camera
150 Degree Viewing Angle
Replaces the OEM tailgate handle
0.5 lux night vision
Defeatable parking lines
Applications
FORD
F-150
2015-2020
iBeam TE-FDH Manual
Head-Unit Replacement USB-Retention Adapter-Cable for Select 2006-UP Chrysler, GM and Ford Vehicles
Converts the factory USB port cable into standard full size male USB so it can be plugged into an aftermarket radio.
Click Here to View Vehicle Compatibility
Factory Backup-Camera Retention for Select 2011-UP Ford and Lincoln Vehicles
Universal noise filter for factory backup cameras with double ended composite video output. Converts the signal to single ended for use with aftermarket radios, eliminating blurry or fuzzy picture quality. Comes pre-wired to connect directly to any vehicle specific T-harness used with Maestro RR or RR2.
Click Here to view ACC-VID1 vehicle compatibility chart (Confirmed 5/30/2023)
Aftermarket Head-Unit Replacement Maestro-Module T-Harness for Select 2011-UP Ford Vehicles
Radio replacement T-harness for select Ford vehicles 2011 and up. Greatly simplifies the installation of the Maestro RR module.
Click Here to View Vehicle Coverage Information - confirmed through 2022
DDIN-Size Head-Unit Replacement Dash-Kit for Select 2013-2014 Ford F-Series Pickups with Factory 4.2" Radio Screen
Dash kit and T-harness solution for 2013-2014 Ford F150 with the 4.3 inch “MyFord” radio. Features factory grade fit & finish and adds a convenient storage pocket with flush mounted ports to connect to the aftermarket radio. Includes T-harness, radio panel, steel radio brackets and USB adapter. Maestro RR and iDatalink-compatible aftermarket radio are required and sold separately.
Applications
FORD
F-150
w/ 4.2-inch color screen
2013-2014
Single 300-Watt 2-Ohm Thin 10-Inch Stealthbox Subwoofer-Enclosure for Select 2018-Up Ford Expedition Vehicles, with OEM Subwoofer
Ford's full-sized SUV delivers first-rate comfort with outstanding gear-hauling capability and towing capacity. This is why JL's Stealthbox solution is designed to retain 100% of your cargo space, while delivering first-class bass performance.
This model replaces the stock subwoofer and installs discreetly behind the factory cargo area trim to protect and hide its 10-inch subwoofer.
The Hard Data: Contains one 10TW1-2 subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs behind driver side panel in the cargo area. Requires removal of the OEM "subwoofer".
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
Expedition
2018-2025
Expedition Max
2018-2025
JL Audio SB-F-EXPED4G/10TW1 Installation Manual
Single 400-Watt 2-Ohm 10-Inch Stealthbox Subwoofer Enclosure for Select 2015-UP Ford F-150 SuperCab and 2017-UP SuperDuty SuperCab Trucks
Benefitting from JL's revolutionary thin-woofer technology, this Stealthbox® for F-150 SuperCab and SuperDuty SuperCab trucks is designed to install neatly under the rear seat with no intrusion on cab space.
Featuring an all-fiberglass, sealed enclosure design, JL's Stealthbox® houses a 10-inch TW3 thin-line subwoofer and fills your truck with loads of deep bass output. Seat folding and reclining are unaffected, and JL even incorporated a recess on the Stealthbox’s top for mounting an amplifier, if desired.
The Hard Data: Contains one 10TW3-D4 subwoofer in a sealed enclosure. 400 watt power handling. Wired for 2 ohm mono. Installs under rear bench seat and requires removal of the storage divider panel. Stealthbox® includes a steel-mesh grille to protect the driver. Does not affect folding or reclining of seat.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
F-150
SuperCab
2015-2025
F-250, 350, 450, 550
SuperCab
2017-2025
JL Audio SB-F-F150SPRCB/10TW3 Installation Manual
Single 400-Watt 2-Ohm Thin 12-Inch Subwoofer-Enclosure for Select 2015-UP Ford Mustang-Coupe Vehicles
The latest all-American pony car gets a big dose of horsepower and major technology enhancements, all packaged in a new sleek and sexy body. Sadly though, the stock audio systems just can't deliver enough bass to keep up with the Mustang's high-performance muscle.
JL's Stealthbox® features an all-fiberglass, sealed enclosure design that fits in the same location as the optional factory subwoofer (and requires no holes to be drilled for installation). Equipped with their revolutionary 12TW3 thin-line subwoofer, this Stealthbox delivers deep, powerful bass that's worthy of your Mustang's heritage.
The Hard Data: Contains one 12TW3-D4 in a sealed enclosure. 400 watt power handling. Wired for 2 ohm mono. Installs in the passenger side rear corner of the trunk. Factory subwoofer (if equipped) must be removed for installation of Stealthbox®. Installation in Mustang Shelby GT350 models requires relocation of additional OEM equipment. Will not fit convertible models!
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
Mustang
Coupe
2015-2025
JL Audio SB-F-MUSCPE/12TW3 Installation Manual
Single 10-Inch 2-Ohm 300-Watt Subwoofer-Enclosure for Select 2019-UP Ford-Ranger SuperCrew Vehicles
Ford's mid-sized pickup promises practical utility and performance for everyday commutes or rugged terrains. To make every drive even more enjoyable, JL-Audio's Stealthbox solution tucks under the rear seat on the passenger side and encloses a 10-inch driver for impressive sub-bass performance. Seat folding is unaffected with plenty of room remaining on the driver side for storage. Best of all, the Stealthbox virtually disappears once installed.
The Hard Data: Contains one 10TW1-2 subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs under passenger side rear seat in place of storage compartment. Will not fit SuperCab.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
Ranger
SuperCrew
2019-2025
JL Audio SB-F-RNGSCG4/10TW1 Manual
Single 600-Watt 2-Ohm Thin 13-Inch Subwoofer-Enclosure for Select 2004-2016 Ford SuperDuty Crew-Cab Trucks with FlexFold 60/40 Split-Bench Rear-Seat
Ford's big trucks were designed to haul people and serious payloads with ease. They also present a tough challenge for a conventional subwoofer solution due to a severe shortage of unused space in the cab. It's a good thing JL didn't let convention get in the way of creating outstanding sub-bass.
JL Audio now offers two clever Stealthbox® solutions for Ford's biggest hauler: one that installs inside the center console and this one: a super-thin, all fiberglass enclosure loaded with JL's revolutionary 13TW5v2 subwoofer and designed to install under the rear bench seat. So, if your console space is non-negotiable, you can still get world-class sub-bass that remains invisible and doesn't compromise your truck's people space.
Whether your miles pile up towing a boat or using your truck for work, you can now enjoy every one of them with one of our Stealthbox® solutions.
The Hard Data: Contains one 13TW5v2-2 subwoofer in a sealed enclosure. 600 watt power handling. Wired for 2 ohm mono. Installs under driver side of rear bench seat. Does not affect folding or reclining of seat.
Please Note: “Black (leather)”, as indicated in the chart below is the OEM color/material. The Stealthbox® model that matches that OEM color is carpeted
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-SUPRCC/13TW5v2 Installation Manual
Single 500-Watt 2-Ohm 10-Inch Subwoofer-Enclosure for Select 1998-2007 Ford-Excursion and F-Series SuperDuty Trucks with Front Bucket-Seats
If you drive Ford's biggest SUV or if your SuperDuty truck is equipped with bucket seats and a center console, this Stealthbox® model is right up your alley. Without infringing on people space and without being visible, it will fill your interior with rich, deep bass.
This compact unit installs inside the factory center console. The cup holders remain unaffected and some console storage is retained. A powerful JL Audio 10-inch subwoofer driver fires down into the floor for intense up-front bass presence.
The Hard Data: Contains one 10W3v3-2 in a sealed enclosure. 500 watt power handling. Wired for 2 ohm mono. Stealthbox® installs inside factory center console and fires down on the floor. Cupholders are not affected. For installation into front console only. Console storage is reduced. The factory console is not supplied with the Stealthbox®. After installation, the factory console is raised approximately 1.5 inches above the floor. Will not fit in SuperDuty trucks with bench seats. Will not fit consoles with rear cup holders and rear audio controls.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-SUPRCNSL/10W3v3 Installation Manual
Dual 12-Inch 800-Watt 2-Ohm Subwoofer-Enclosure for Select 2009-Up Ford F-150 SuperCrew, 2017-Up SuperDuty Crew Cab Trucks
The Ford F-150 is an American icon with impressive hauling capabilities and a spacious interior, especially in SuperCrew configurations. Unfortunately, Ford’s factory sound systems leave a lot to be desired in the low frequency department.
JL's Stealthbox® for F-150 SuperCrew and SuperDuty Crew Cab trucks fills your truck with stunning sub bass output and quality, with no intrusion on cab space. Featuring a sealed enclosure design, this Stealthbox® houses two of JL Audio's revolutionary 12TW3 thin-line subwoofers and installs neatly under the rear seat, without compromising rear seat comfort.
The Hard Data: Contains two 12TW3-D8 subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Installs under rear bench seat and requires removal of under-seat storage tray, if so equipped. Installation requires removal of OEM “subwoofer”, if so equipped. Does not affect folding or reclining of seat.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
F-150
SuperCrew
2009-2025
F-250, 350, 450, 550
Crew Cab
2017-2025
JL Audio SB-F-150-SCDBL/12TW3 Installation Manual
Single 300-Watt 2-Ohm Thin 10-Inch Stealthbox Subwoofer-Enclosure for Select 2021-UP Ford-Bronco Vehicles
Ford’s legendary SUV combines cool retro styling with impressive on and off-road capabilities, along with a highly functional interior for passengers and cargo alike. Regrettably, this stallion's factory audio options lack the horsepower to quench our thirst for meaningful bass reproduction.
Featuring an all-fiberglass, custom-formed, sealed enclosure, this Stealthbox houses JL Audio's innovative, 10-inch TW1 thin-line driver. The result is powerful, deep bass that's worthy of Ford's celebrated nameplate. Installs behind the passenger side panel in the cargo area and includes a custom grille.The Hard Data: Contains one 10TW1-2 Subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs behind factory panel in the passenger side rear cargo area. Subwoofer is protected by a black steel mesh grille and concealed by a cosmetic grille (both included). Installation requires removal of OEM subwoofer, if equipped and permanent modification of the factory panel. Fits 2-Door and 4-Door models. Will not fit Bronco Sport models.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
Bronco
2021-2025
JL Audio SB-F-BRONCG6/10TW1 Installation Manual
