Alpine Advanced Bluetooth Mechless Receiver
With advanced Bluetooth® wireless technology, audio streaming, and FLAC support, the UTE-73BT mech-less digital receiver delivers quality phone calls and playback of various digital music files so you stay in touch and in tune.
This one-stop music player has an LCD display with one-line, RGB illumination for your choice of display color. The new high-contrast LCD display has five times the contrast of a conventional screen, so the display is always easy to read.
Alpine's signature rotary knob makes controlling all your music a breeze. This unit also comes with a convenient front panel auxiliary input - so you or your passenger can plug in a portable media player as an additional source.
The UTE-73BT uses a 24-Bit DAC for ultimate sound quality with all your digital media sources. The 3-band parametric EQ and high pass/low pass crossover lets you do fine-tune your sound system. The UTE-73BT can playback FLAC (Free Lossless Audio Codec) files via USB, for a more accurate listening experience.
Don’t get caught holding your phone while driving. The UTE-73BT is equipped with Bluetooth wireless technology so you can carry on your phone conversations without additional adapters or headpieces.
To bring sound balance to your hands-free experience, you can adjust the UTE-73BT’s mic gain, phone output and ringtone volume. If that’s not enough, there are two sound quality settings to choose from to get the balance just right for you. This flexibility will make your phone calls a pleasurable experience.
Specifications
50W x 4 High Power Amp
Built-in Bluetooth Module
BT Audio Streaming
Works with Pandora Music
Mech-less
FLAC/MP3/WMA/AAC Playback
Front USB port
Made for iPod and iPhone (requires KCU-445i)
Siri Eyes Free Mode
Android Open Accessory 2.0
Front AUX Input (3.5mm mini jack)
3-Band Parametric EQ
High-pass/Low-pass Filter
24-Bit DAC
Steering Wheel Remote Control Ready
KTP-445A Power Pack Ready
3 PreOuts (2V)
Hands-free Microphone Included
RGB Lighting
Bass Engine SQ
Radio Broadcast Data System (RBDS) Text Information
Alpine UTE-73BT Manual
The iLX-507 features Apple CarPlay, Android Auto, and built-in bluetooth hands-free which allow access to music, messages, phone calls, and maps on a smartphone via either a wired USB connection or wirelessly. Get even more entertainment options with built-in HD Radio, Pandora Internet Radio (via iPhone or Android connection), and SiriusXM for even more choices in entertainment (tuner and subscription sold separately).
Experience incredible music detail with Hi-Res audio playback. High-precision music reproduction brings out the full potential of every song and makes every drive feel like an intimate recording studio session with your favorite artist. Access your favorite songs on popular Hi-Res streaming services like Apple Music and more. The Alpine iLX-507 plays Hi-Res music at it's intended spec of 96kHz/24Bit via a wired USB connection to a smartphone or wirelessly through Bluetooth connection. You can also purchase and download Hi-Res music files onto a USB drive from platforms like HD-tracks for Hi-Res playback on the iLX-507.
The iLX-507 Works with Apple CarPlay and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touchscreen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later.
The iLX-507 includes Android Auto and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices, and reply to text messages – hands-free.
Enhanced on-board tuning features now include a 13-band parametric EQ per channel, for continuous frequency control. The 6-channel time correction ensures that music is staged properly in the front and center of the vehicle. If more power is needed, additional amplifiers can be added using the three sets of true 4V preamp outputs with front, rear, and subwoofer control.
Experience music as the artist originally intended with the industry’s first full TIDAL integration. The iLX-507 allows you to access select TIDAL features directly on the head unit and receive a high-res streaming experience with the TIDAL catalog of over 90 million songs. Lossless audio and high-fidelity music options are also available for TIDAL HiFi and HiFi Plus members, for superior sound quality that elevates the music experience. A TIDAL subscription is required and sold separately. To access TIDAL on the Alpine head unit, the head unit must be tethered to a mobile or smartphone hotspot. Data rates may apply.
The iLX-507 is compatible with the iDatalink Maestro Module (sold separately) to retain and display vehicle information. Information such as steering wheel controls, tire pressure, engine codes, and HVAC control may be accessible from the iLX-507 (information will vary by vehicle).
The iLX-507 includes two camera inputs to add a front, side, or rearview camera (sold separately). The rearview camera includes a distance guide display that overlays guidelines onto the screen for ease when moving in reverse.
Take driving safety even further by connecting your iLX-507 with the DVR-C320R premium 1080P front and rear dash camera with built-in drive assist (sold separately). View real-time and recorded drives in high definition right on the screen, plus receive drive assist features that help get you to your destination safely.
The new RUX-H02 Alpine Halo subwoofer controller (sold separately) can be mounted to the dash for quick- access controls to the subwoofer and main volume through a wireless bluetooth connection.
Features
7-inch 720p HD Display
Standard Double-Din Fitment
Hi-Res Audio Playback (96kHz / 24bit)
Wireless Hi-Res Audio (requires LDAC compatible device)
Hi-Res Music Streaming with TIDAL (A TIDAL subscription is required and sold separately; Alpine Head Unit must be tethered to a mobile or smartphone hotspot; Data rates may apply)
Apple Carplay® (Wired & Wireless)
Android Auto™ (Wired & Wireless)
The Google Assistant is Available on Android Auto™
Bluetooth® Hands-Free
SiriusXM-Ready® (compatible with SXV300 (G2) add-on tuner, sold separately; SiriusXM subscription required)
Built-in HD Radio®
iDatalink® Maestro Compatible
Alpine DVR-C320E Dash Cam Compatible(sold separately)
Navigation Compatible with KTX-NS01 (sold separately)
Media Xpander®
Specifications
Screen Size: 7”
Screen Resolution: WXGA 1280 x 720px (720p HD)
AUX Input: 1
HDMI Input: 1
HDMI Output: 1
Camera Inputs: 2 Direct (1 Rear input & 1 input that can be set as Front, Side, or Other)
Dash Cam Input: 1 (Alpine DVR-C320R)
USB Inputs: 2 (1 data & 1 charge only port)
4V Pre-Outs: 3
Built-in Amplifier: 18W RMS x 4
EQ: 13-Band Parametric (per channel)
Time Correction: 6-Channel
DAC: 24 Bit
Crossover: High Pass / Low Pass
Audio Playback: AAC, APE, FLAC, MP3, WMA, WAV
Video Playback: AVC, FLV, H.263, H.264, MP4, MPEG-1, MPEG-2, MPEG-4, MKV, MOV
Alpine iLX-507 Tech SheetAlpine iLX-507 Manual Part 1Alpine iLX-507 Manual Part 2
45W RMS x 4 (4Ω/2Ω, 14.4V, ≤ 1% THD+N)
82dB S/N (ref: 1W into 4Ω)
Compact size (fits easily inside dashboard of most vehicles)
Works with any aftermarket and most OEM head units
Bridgeable
Gain, high-pass crossovers and input select
Add higher output and more dynamic response with this easy-to-install Universal Power Pack upgrade.
Compact size lets the KTP-445U fit where most amplifiers won’t. The KTP-445U comes equipped with the RCA and Auto-Sensing-Speaker level connectors and it fits behind the head unit in the dash of most vehicles. It's small and compact at only 7-7/16” x 1-1/2” x 2-1/2”. The size and flexible wires make the Power Pack an easy choice to save space.
High-Pass selectable switches for Front & Rear allow frequency filtering for a wide variety of speakers. Choose from full range to selectable range: 60Hz, 80Hz or 120Hz to fine-tune your crossover points.
Need configurable options for Speaker-Level or RCA inputs to the Power Pack? On the bottom panel of the Power Pack there are selectable input options to accommodate Speaker-Level (0.5V-10V) or RCA (0.2V – 4V) inputs. Selectable 2 Channel and 4 Channel options give you the control to determine source inputs, and can eliminate the need for Y-adapters.
The Power Pack provides simple variable gain controls on the end panel for flexibility and a wide variety of system applications.
In order to ensure that Alpine sound quality is heard at your ears, we’ve created a platform that offers an unbelievably low noise floor, taking extra care to ensure a clean signal path, with no extraneous interference. The end result: The Power Pack boasts 1 Watt Signal-to-Noise Ratio of 82dB or better.
Uniquely, the Power Pack distortion actually decreases at higher frequencies, resulting in a clean and clear signal where your ear is most sensitive to distortion. - < 0.03% THD+N @ 1W, 1% THD+N @ rated power.
Alpine KTP-445U Manual
45W RMS x 4 (4Ω/2Ω, 14.4V, ≤ 1% THD+N)
82dB S/N (ref: 1W into 4Ω)
Compact size (fits easily inside dashboard of most vehicles)
Works with select 2005+Alpine head units
The KTP-445A Power Pack amplifies power output on select 2005 and newer Alpine head units, resulting in up to a 150 percent power increase over the original power from the head unit's built-in amplifier.
Compact size lets the KTP-445A fit where most amplifiers won’t. The KTP-445A comes equipped with direct plug-in connectors for select 2005 and newer Alpine head units and it fits behind the dash of most vehicles. It's small and compact at only 7-7/16” x 1-1/2” x 2-1/2”. Its size and flexible wires make the Power Pack an easy choice to save space.
In order to ensure that Alpine sound quality is heard, we’ve created a platform that offers an unbelievably low noise floor, taking extra care to ensure a clean signal path, with no extraneous interference. The end result: The Power Pack boasts 1 Watt Signal-to-Noise Ratio of 82dB or better.
No Manual Avialable
Control your music while keeping your eyes on the road with the iLX-W670. Use two-finger swipe motions anywhere on the 7-inch touchscreen to control volume up or down, skip forward or back, and pause by swiping up, down, left, or right.
The iLX-W670 “Works with Apple CarPlay” and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touch screen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later (iPhone must be connected via Apple lightning cable).
Enhance your music with the new Sound Boost menu, featuring expanded Bass Boost & Mid-Bass Boost controls, subwoofer controls, and a new Lighting Link feature which allows you to control the lighting on Alpine’s PrismaLink subwoofer enclosures directly from your screen, creating a visual symphony that complements your music.
Stay connected effortlessly with Apple CarPlay (Wired) and Android AutoTM (Wired) compatibility. Access your favorite apps, receive calls, send texts, and enjoy music, all while keeping your focus on the road. The iLX-W670 brings the power of your smartphone to your car’s display.
Unleash the full potential of your music with the 13-band graphic EQ, 6-channel time correction, and versatile crossovers for the front speakers, rear speakers, and subwoofer. The iLX-W670 gives you the tools to fine-tune your sound to perfection.
Measuring only 2.4” deep, the iLX-W670 features an ultra-shallow chassis that is PowerStack capable, allowing you to mount the Alpine KTA-450 or KTA-200M Power Pack Amplifiers (sold separately) directly to the back. This award-winning design allows you to add more power to your sound system while occupying the same depth as a traditional 2-DIN radio.
With an integrated camera input, he Alpine iLX-W670 allows you to add a front or rear-view camera to your vehicle making parking and maneuvering in tight spaces a breeze.
Stay connected and hands-free on the road with Bluetooth Hands-free. Simply pair your smartphone with the iLX-W670 and take calls, stream music, and navigate through your playlist without ever having to take your hands off the wheel.
Experience your music in the highest possible audio quality with the iLX-W670's support for FLAC audio files. This lossless audio format provides a superior listening experience, allowing you to enjoy every detail of your favorite music as it was meant to be heard.
Stream your favorite personalized radio stations from Pandora directly from the iLX-W670 via Apple Carplay or Android Auto. With easy access to your stations, skip, and thumbs up/down controls, you can stay focused on the road while enjoying your music.
Stream your favorite songs and playlists from Spotify directly from the iLX-W670 via Apple Carplay or Android Auto. With voice control, you can access your music and browse playlists without ever taking your hands off the wheel.
Get real-time traffic updates, turn-by-turn directions, and alternative routes with the iLX-W670's integration with Waze maps via Apple Carpaly or Android Auto. Never get stuck in traffic again and arrive at your destination on time and stress-free.
With the iLX-W670's compatibility with SiriusXM, you can enjoy your favorite satellite radio stations on the go. With a subscription, you'll have access to commercial-free music, sports, news, and entertainment.
Features
6.75" Touchscreen Display
Standard Double-Din Fitment
5-Color Key Illumination (Red, Green, Blue, Amber, White)
Customizable Home Screen (Add your own background image)
Apple Carplay® (Wired)
Android Auto™ (Wired)
Bluetooth® Hands-Free
SiriusXM-Ready®
PowerStack™ Capable (Mount the Alpine KTA-200M or KTA-450 amplifiers directly to the back)
Lighting Link Control (Compatible with Alpine PrismaLink™ Subwoofers; S2-SB8, S2-SB10, & S2-SB12)
Sound Boost Menu (Bass Boost, Mid-Bass Boost, and Subwoofer Controls)
Specifications
Screen Size: 6.75”
Screen Resolution: 800 x 480px
AUX Input: 1
Camera Input: 1
USB Input: 1
4V Pre-Outs: 3 (Front, Rear, and Subwoofer)
Built-in Amplifier: 16W RMS x 4
EQ: 13-Band Graphic
Time Correction: 6-Channel
Crossovers: Front, Rear, and Subwoofer
Audio Playback: AAC, FLAC, MP3, WMA
Video Playback: AVC, FLV, H.264, MP4, MPEG-4, MKV, MOV
Alpine iLX-W670 Manual Part 1Alpine iLX-W670 Manual Part 2
Alpine 6-1/2-Inch Coaxial 2-Way Speakers, 80-Watt RMS
Newly redesigned and Hi-Res Audio Certified, the Next-Generation S-Series S2-S65 6.5” Coaxial Speakers offer a new standard in entry-level sound performance.
Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status system, the Next-Generation Alpine S-Series Speakers are now Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This new benchmark in sound quality elevates the Next-Gen S-Series Speakers resulting in a more accurate and natural sound at an entry-level price point.
Crafted with a unique combination of Poly Propylene, Glass Fiber, and Mica Cone materials, the S2-S65 is designed for lightweight construction, high output, and low distortion, giving you a clean and accurate audio experience.
Alpine-exclusive High Amplitude Multi- Roll (HAMR) surround technology is integrated into the speaker design which allows for maximum cone movement, delivering powerful and accurate bass notes.
The S-Series S2-S65 is compatible with the KTE-S65G Speaker Grille (sold separately). This sleek and stylish grille will not only add a visual upgrade to your speakers but also provide protection against any damage.
Specifications
Hi-Res Audio Certified (Up to 40kHz)
Poly Propylene, Glass Fiber, and Mica Cone Material
Lightweight Design with High Output and Low Distortion
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Integrated 1” Tweeters (Coaxial)
Compatible with KTE-S65G Speaker Grille (sold separately)
Woofer Size: 6.5”
Tweeter Size: 1” (Coaxial)
Power Handling: 80W RMS / 240W Peak
Frequency Response: 70Hz - 40kHz (Hi-Res)
Sensitivity: 88dB
Alpine 6X9-Inch Component 2-Way Speakers, 85-Watt RMS
Newly redesigned and Hi-Res Audio Certified, the Next-Generation S-Series S2-S69C 6x9” Component Speakers offer a new standard in entry-level sound performance.
Using “trickle-down” technology, inspired design, and performance cues from the Ultra- High-Resolution AlpineF#1Status system, the Next-Generation Alpine S-Series Speakers are now Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This new benchmark in sound quality elevates the Next-Gen S-Series Speakers resulting in a more accurate and natural sound at an entry- level price point.
Crafted with a unique combination of Poly Propylene, Glass Fiber, and Mica Cone materials, the S2-S69C is designed for lightweight construction, high output, and low distortion, giving you a clean and accurate audio experience.
Experience a fuller and richer sound with the S2-S69C's unique 3" midrange speakers with built-in 3/4" tweeters. Designed to capture the midrange frequencies present in vocals and acoustic instruments, this added midrange speaker enhances your music like never before.
Alpine-exclusive High Amplitude Multi- Roll (HAMR) surround technology is integrated into the speaker design which allows for maximum cone movement, delivering powerful and accurate bass notes.
The S-Series S2-S69C is compatible with the KTE-S69G Speaker Grille (sold separately). This sleek and stylish grille will not only add a visual upgrade to your speakers but also provide protection against any damage.
Specifications
Hi-Res Audio Certified (Up to 40kHz)
Poly Propylene, Glass Fiber, and Mica Cone Material
Lightweight Design with High Output and Low Distortion
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Included 3” Mid-Range with built-in 3/4" Tweeter (Coaxial)
OEM Fitment with In-Line Crossovers
Compatible with KTE-S69G Speaker Grille (sold separately)
Woofer Size: 6x9”
Mid-Range/Tweeter: 3" with built-in 3/4” Tweeters (Coaxial)
Power Handling: 85W RMS / 260W Peak
Frequency Response: 65Hz - 40kHz (Hi-Res)
Sensitivity: 90dB
Customize the screen exactly the way you want it by using drag-and-drop motions with your finger to add, remove, or move over 29 available widgets. You can prioritize your three home screens so you can quickly find the apps you want like Apple CarPlay®, Android Auto™, Camera, Bluetooth® functions, and more. Add a customizable wallpaper from your photos through a thumb drive.
Measuring at only 2.4” deep, the iLX-407 can fit into vehicles that don’t have a lot of space behind the dashboard. The shallow chassis is optimized to mount either the KTA-450 4-channel or KTA-200M Mono Power Pack Amplifiers (sold separately). Alpine’s award-winning PowerStack™ design adds more power to your sound system while occupying the same depth as a traditional 2-DIN radio.
The iLX-407 “Works with Apple CarPlay” and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touch screen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later (iPhone must be connected via Apple lightning cable).
The iLX-407 includes Android Auto and works with the Google Assistant (requires both a USB cable and Bluetooth® connection; requires an Android™ phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say "OK Google" or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices and reply to text messages – hands-free.
While the iLX-407 is mech-less (no CD/DVD player), you still have plenty of entertainment options that will make every drive exciting. A rear USB port allows you to listen to your music or video file via USB or connect your smartphone to access your music by searching song title, artist info, or album. The iLX-407 has built-in HD-Radio and can also connect to Pandora internet radio through your iPhone or Android smartphone. SiriusXM radio is also available with an optional tuner and paid subscription. And HDMI input is available should you choose to connect a CD or DVD player for all-digital audio and video connection through a single cable.
Upgrading dash technology can often result in a loss of factory functionality, such as climate controls and vehicle function settings. The iLX-407 is compatible with the iDatalink Maestro Module (sold separately) some select OEM features are retained and vehicle information is displayed on the screen.
See your drive on a 7-inch, anti-glare screen with dual camera inputs that allow you to add a front or rear-view camera to your vehicle. The iLX-407 comes with a built-in rearview camera distance guide display that makes blindspots a distant memory.
Get the most from your music by using the 5-band graphic equalizer and 6-channel time correction tool to customize the sound the way you want it. If you’re looking for more power, add additional amplifiers using the three sets of true 4V preamp outputs with subwoofer level control on the third set.
Features
7-inch Anti-glare 2-DIN Touchscreen Display
Shallow Mount Design (2-6/16" Depth)
PowerStack™ Capable with the KTA-450 and KTA-200M (sold separately)
Customizable User Interface (29 available widgets/apps)
Customizable Wallpaper
Works with Apple CarPlay®
The Google Assistant is available on Android Auto™
Bluetooth® built-in for hands-free calling and audio streaming
SiriusXM-Ready® (SXV300 Connect Vehicle Tuner Kit sold separately; SiriusXM subscription required)
Built-in HD Radio®
HDMI Input
iDatalink® Maestro Connectivity
2 RCA Camera Inputs
Rearview Camera Distance Guide Display
MediaXpander®
Specifications
Width: 7" (178mm)
Height: 4" (100mm)
Depth: 2-6/16" (60mm)
Screen Size: 7"
Screen Resolution: WVGA 800 x 480px
PowerStack™ Capable: Yes
HDMI Input: 1
Camera Input: 2 RCA
USB Input: 1
4V Pre-Outs: 3
Built-in Amplifier: 16W RMS/50W peak x 4
EQ: 5-Band Graphic
DAC: 24 Bit
Subwoofer level control
High pass crossover/ low pass crossover
6-channel time correction
Audio Playback: AAC, FLAC, MP3, WMA, WAV
Photo Playback: JPG, PNG, BMP
Video Playback: AVI, MP4, MPG, MOV, WMV
CTA-2006 compliant
Alpine iLX-407 Manual Part 1Alpine iLX-407 Manual Part 2
Alpine 6-1/2-Inch Coaxial 2-Way Speakers, 80-Watt RMS
The S-Series speakers have a large voice coil. The 6.5-inch and 6x9-inch models have a 35-mm voice coil, and this large voice coil size increases their driving power and control of the motor. The S-Series speakers are the first in the industry to use a material called CFRP (Carbon Fiber Reinforced Plastic), a very lightweight yet rigid material. On a standard, off-the-shelf oval cone, the edges are naturally weaker than the center due to the elongated shape. Since the CFRP material is directional, it can be manipulated during the molding process to strengthen the areas of the cone that are normally weak. The result is rigidity throughout the cone that delivers accurate and efficient performance. The ability to manipulate the CFRP material during the molding process is currently exclusive to Alpine and the S-Series speakers. Alpine has three patent-pending procedures in support of this innovative manufacturing process.
Alpine’s patented H.A.M.R. (High Amplitude Multi-Roll) surround is now found on the S-Series speakers. This proven technology increases excursion while maintaining accuracy and linearity. The multi-roll design allows for an even unfolding of the surround which creates incredible linearity and colorization rejection.
Specifications
80W RMS/240W Peak
Nominal Impedance 4Ω
Frequency Response: 70-22kHz
1” Silk Dome Tweeter CFRP (Carbon Fiber Reinforced Plastic) Cone
H.A.M.R. Surround
CustomStamped Steel Frame
35mm voice coil
Optional grille sold separately (KTE-S65G)
The Next-Gen Alpine Halo11 features Apple CarPlay, Android Auto, and built-in Bluetooth hands-free which allow access to music, messages, phone calls, and maps on a smartphone via either a wired USB connection or wirelessly. Get even more entertainment options with built-in HD Radio, Pandora Internet Radio (via iPhone or Android connection), and SiriusXM for even more choices in entertainment (tuner and subscription sold separately).
Experience incredible music detail with Hi-Res Audio Playback. High-precision music reproduction brings out the full potential of every song and makes every drive feel like an intimate recording studio session with your favorite artist. Access your favorite songs on popular Hi-Res streaming services like Apple Music, Tidal, Amazon Music, HD and more. The Alpine Halo11 plays Hi-Res music at it's intended spec of 96kHz/24Bit via a wired USB connection to a smartphone or wirelessly through Bluetooth connection. You can also purchase and download Hi-Res music files onto a USB drive from platforms like HD-Tracks and plugs directly into the Alpine Halo11 for Hi-Res playback.
The iLX-F511 Works with Apple CarPlay wirelessly and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay® is accessed through the capacitive touchscreen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later.
The iLX-F511 includes Android Auto wirelessly and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices, and reply to text messages – hands- free.
The Alpine Halo11 has on-board tuning features including a 13-band parametric EQ per channel, for continuous frequency control. The 6-channel time correction ensures that music is staged properly in the front and center of the vehicle. If more power is needed, additional amplifiers can be added using the three sets of true 4V preamp outputs with front, rear, and subwoofer control.
Experience music as the artist originally intended with the industry’s first full TIDAL integration. The iLX-F511 allows you to access select TIDAL features directly on the head unit and receive a high-res streaming experience with the TIDAL catalog of over 90 million songs. Lossless audio and high-fidelity music options are also available for TIDAL HiFi and HiFi Plus Members, for superior sound quality that elevates the music experience. A TIDAL subscription is required and sold separately. To access TIDAL on the Alpine Head Unit, the head unit must be tethered to a mobile or smartphone hotspot. Data rates may apply.
The screen is attached to an adjustable mount on a single-DIN chassis that’s designed to fit in most dash openings. Once the unit is installed, the screen has five vertical adjustments and two separate depths that lock into position for a sturdy installation. A new pressure tilt mechanism allows for more flexibility when positioning the screen for optimized viewing and access to dash and HVAC controls.
The Alpine Halo11 is compatible with the iDatalink Maestro Module (sold separately) to retain and display vehicle information on the extra large, 11-inch screen. Information such as steering wheel controls, tire pressure, and engine codes, and HVAC control may be accessible from the ILX-F511 (information will vary by vehicle).
The Alpine Halo11 includes two camera inputs to add a front, side, or rearview camera (sold separately). The rearview camera includes a distance guide display that overlays guidelines onto the screen for ease when moving in reverse.
Take driving safety even further by connecting your Alpine Halo11 with the DVR-C320R Premium 1080P Front and Rear Dash Camera with built-in drive assist (sold separately). View real-time and recorded drives in high definition on your Alpine Halo11, plus receive drive assist features that help get you to your destination.
The new RUX-H02 Alpine Halo Subwoofer Controller (sold separately) easily mounts to the Alpine Halo Display and allows quick-access controls to the subwoofer and main volume through a wireless Bluetooth® connection. The sleek, tapered lines and silver trim of the RUX-H02 compliments the Alpine Halo Display design.
Features
11-inch Adjustable Floating Style Display (Adjustable Height, Depth, and Viewing Angle)
Standard 1-DIN Chassis for Flexible Vehicle Application
Tapered Display Housing and Silver Trim for a Clean, Modern Fit & Finish
Hi-Res Audio Playback (96kHz / 24bit)
Wireless Hi-Res Audio (requires LDAC compatible device)
Hi-Res music streaming with TIDAL (A TIDAL subscription is required and sold separately; Alpine Head Unit must be tethered to a mobile or smartphone hotspot; Data rates may apply)
Apple Carplay® (Wired & Wireless)
Android Auto™ (Wired & Wireless)
The Google Assistant is Available on Android Auto™
Bluetooth® Hands-Free
SiriusXM-Ready® (compatible with SXV300 (G2) add-on tuner, sold separately; SiriusXM subscription required)
Built-in HD Radio®
iDatalink® Maestro Compatible
Alpine DVR-C320R Dash Cam Compatible (sold separately)
Navigation Compatible with KTX-NS01 (sold separately)
Media Xpander®
Specifications
Screen Resolution: WXGA 1280 x 720px (720p HD)
AUX Input: 1
HDMI Input: 1
HDMI Output: 1
Camera Inputs: 2 Direct (1 Rear input & 1 input that can be set as Front, Side, or Other)
Dash Cam Input: 1 (Alpine DVR-C320R)
USB Inputs: 2 (1 data & 1 charge only port)
4V Pre-Outs: 3
Built-in Amplifier: 18W RMS x 4
EQ: 13-Band Parametric (per channel)
Time Correction: 6-Channel
DAC: 24 Bit
Crossover: High Pass / Low Pass
Audio Playback: AAC, APE, FLAC, MP3, WMA, WAV
Video Playback: AVC, FLV, H.263, H.264, MP4, MPEG-1, MPEG-2, MPEG-4, MKV, MOV
Alpine iLX-F511 Tech SheetAlpine iLX-F511 Manual Part 1Alpine iLX-F511 Manual Part 2
Alpine 6-1/2-Inch Component 2-Way Speakers, 80-Watt RMS
Newly redesigned and Hi-Res Audio Certified, the Next-Generation S-Series S2-S65C 6.5” Component Speakers offer a new standard in entry-level sound performance.
Using “trickle-down” technology, inspired design, and performance cues from the Ultra- High-Resolution AlpineF#1Status system, the Next-Generation Alpine S-Series Speakers are now Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This new benchmark in sound quality elevates the Next-Gen S-Series Speakers resulting in a more accurate and natural sound at an entry- level price point.
Crafted with a unique combination of Poly Propylene, Glass Fiber, and Mica Cone materials, the S2-S65 is designed for lightweight construction, high output, and low distortion, giving you a clean and accurate audio experience.
Alpine-exclusive High Amplitude Multi- Roll (HAMR) surround technology is integrated into the speaker design which allows for maximum cone movement, delivering powerful and accurate bass notes.
Engineered for versatility, these speakers offer seamless OEM fitment and simplified installation. With in-line crossovers, you can achieve optimal sound separation and precise tuning. The adjustable tweeters feature a flush mount housing that is removable allowing for installations in small OEM tweeter locations.
The S-Series S2-S65 is compatible with the KTE-S65G Speaker Grille (sold separately). This sleek and stylish grille will not only add a visual upgrade to your speakers but also provide protection against any damage.
Specifications
Hi-Res Audio Certified (Up to 40kHz)
Poly Propylene, Glass Fiber, and Mica Cone Material
Lightweight Design with High Output and Low Distortion
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Included 1” Adjustable Tweeters with Threaded Removable Housing (Component)
OEM Fitment with In-Line Crossovers
Compatible with KTE-S65G Speaker Grille (sold separately)
Woofer Size: 6.5”
Tweeter Size: 1” (Component)
Power Handling: 80W RMS / 240W Peak
Frequency Response: 70Hz - 40kHz (Hi-Res)
Sensitivity: 88dB
The Next-Gen Alpine Halo9 features Apple CarPlay, Android Auto, and built-in Bluetooth hands-free which allow access to music, messages, phone calls, and maps on a smartphone via either a wired USB connection or wirelessly. Get even more entertainment options with built-in HD Radio, Pandora Internet Radio (via iPhone or Android connection), and SiriusXM for even more choices in entertainment (tuner and subscription sold separately).
Experience incredible music detail with Hi-Res Audio Playback. High-precision music reproduction brings out the full potential of every song and makes every drive feel like an intimate recording studio session with your favorite artist. Access your favorite songs on popular Hi-Res streaming services like Apple Music, Tidal, Amazon Music, HD and more. The Alpine Halo9 plays Hi-Res music at it's intended spec of 96kHz/24Bit via a wired USB connection to a smartphone or wirelessly through Bluetooth connection. You can also purchase and download Hi-Res music files onto a USB drive from platforms like HD-Tracks and plugs directly into the Alpine Halo9 for Hi-Res playback.
The iLX-F509 Works with Apple CarPlay wirelessly and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay® is accessed through the capacitive touchscreen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later.
The iLX-F509 includes Android Auto wirelessly and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices, and reply to text messages – hands- free.
The Alpine Halo9 has on-board tuning features including a 13-band parametric EQ per channel, for continuous frequency control. The 6-channel time correction ensures that music is staged properly in the front and center of the vehicle. If more power is needed, additional amplifiers can be added using the three sets of true 4V preamp outputs with front, rear, and subwoofer control.
Experience music as the artist originally intended with the industry’s first full TIDAL integration. The iLX-F509 allows you to access select TIDAL features directly on the head unit and receive a high-res streaming experience with the TIDAL catalog of over 90 million songs. Lossless audio and high-fidelity music options are also available for TIDAL HiFi and HiFi Plus Members, for superior sound quality that elevates the music experience. A TIDAL subscription is required and sold separately. To access TIDAL on the Alpine Head Unit, the head unit must be tethered to a mobile or smartphone hotspot. Data rates may apply.
The screen is attached to an adjustable mount on a single-DIN chassis that’s designed to fit in most dash openings. Once the unit is installed, the screen has five vertical adjustments and two separate depths that lock into position for a sturdy installation. A new pressure tilt mechanism allows for more flexibility when positioning the screen for optimized viewing and access to dash and HVAC controls.
The Alpine Halo9 is compatible with the iDatalink Maestro Module (sold separately) to retain and display vehicle information on the extra large, 11-inch screen. Information such as steering wheel controls, tire pressure, and engine codes, and HVAC control may be accessible from the ILX-F509 (information will vary by vehicle).
The Alpine Halo9 includes two camera inputs to add a front, side, or rearview camera (sold separately). The rearview camera includes a distance guide display that overlays guidelines onto the screen for ease when moving in reverse.
Take driving safety even further by connecting your Alpine Halo9 with the DVR-C320R Premium 1080P Front and Rear Dash Camera with built-in drive assist (sold separately). View real-time and recorded drives in high definition on your Alpine Halo11, plus receive drive assist features that help get you to your destination.
The new RUX-H02 Alpine Halo Subwoofer Controller (sold separately) easily mounts to the Alpine Halo Display and allows quick-access controls to the subwoofer and main volume through a wireless Bluetooth® connection. The sleek, tapered lines and silver trim of the RUX-H02 compliments the Alpine Halo Display design.
Features
9-inch Adjustable Floating Style Display (Adjustable Height, Depth, and Viewing Angle)
Standard 1-DIN Chassis for Flexible Vehicle Application
Tapered Display Housing and Silver Trim for a Clean, Modern Fit & Finish
Hi-Res Audio Playback (96kHz / 24bit)
Wireless Hi-Res Audio (requires LDAC compatible device)
Hi-Res music streaming with TIDAL (A TIDAL subscription is required and sold separately; Alpine Head Unit must be tethered to a mobile or smartphone hotspot; Data rates may apply)
Apple Carplay® (Wired & Wireless)
Android Auto™ (Wired & Wireless)
The Google Assistant is Available on Android Auto™
Bluetooth® Hands-Free
SiriusXM-Ready® (compatible with SXV300 (G2) add-on tuner, sold separately; SiriusXM subscription required)
Built-in HD Radio®
iDatalink® Maestro Compatible
Alpine DVR-C320R Dash Cam Compatible (sold separately)
Navigation Compatible with KTX-NS01 (sold separately)
Media Xpander®
Specifications
Screen Resolution: WXGA 1280 x 720px (720p HD)
AUX Input: 1
HDMI Input: 1
HDMI Output: 1
Camera Inputs: 2 Direct (1 Rear input & 1 input that can be set as Front, Side, or Other)
Dash Cam Input: 1 (Alpine DVR-C320R)
USB Inputs: 2 (1 data & 1 charge only port)
4V Pre-Outs: 3
Built-in Amplifier: 18W RMS x 4
EQ: 13-Band Parametric (per channel)
Time Correction: 6-Channel
DAC: 24 Bit
Crossover: High Pass / Low Pass
Audio Playback: AAC, APE, FLAC, MP3, WMA, WAV
Video Playback: AVC, FLV, H.263, H.264, MP4, MPEG-1, MPEG-2, MPEG-4, MKV, MOV
Alpine iLX-F509 Tech SheetAlpine iLX-F509 Manual Part 1Alpine iLX-F509 Manual Part 2
Alpine Spare-Tire Rear-View Camera has a 7-inch diameter footprint and fits directly onto the spare tire mount, along with the tire itself. The result is a clean, integrated look that eliminates the need to drill holes to mount the camera into the bumper. The 6.25” W x 2” H LED third brake light provides added safety, while an additional reverse LED light illuminates the camera’s viewing angle for increased image visibility when your Wrangler is backing up. The optimized camera angle provides visibility for near and far objects behind your Jeep Wrangler; straight down and rear view (+5° up from horizontal which can be displayed on a factory or aftermarket in-dash screen (sold separately).
The HCE-TCAM1-WRA is ready for your off-road adventures. The camera is waterproof and, dust-proof (at IP66 ratings), and the camera’s angle is optimized for viewing both near and far objects. The camera housing has a matte black finish with gun metal gray powder coat accents.
Specifications
Compatible with most Aftermarket and OEM wheels using spare tire mount
Works with Aftermarket or OEM in-dash display
P66 waterproof and dust-proof rugged camera system design
Built-in brake and reverse lights for increased visibility
Lug nut mounting for easy removal and wheel locking
Optimized camera angle for near and far objects
3 mounting posts included for wheel/tire depth
Alpine HCE-TCAM1-WRA Manual
You can rely on INE-W970HD’s navigation system for access to the most up-to-date maps of the United States and Canada. Choose 3D mapping for a realistic viewing option that allows you to see your map in vivid detail or get fast and easy directions from start to finish with turn-by-turn instructions delivered by Text-to-Speech (TTS) technology.
Listen to your music, answer calls, respond to texts, and get directions hands-free with Apple CarPlay and Android Auto. Connect your smartphone via a USB input (additional bluetooth connection required for Android Auto).
Keep your eyes on the road and hands on the wheel with the INE-W970HD’s built-in bluetooth hands-free calling and streaming. The external pre-tuned microphone reduces noise interference and feedback for the best sound quality possible, so you can stay focused on your drive.
Now there are even more ways to listen to your favorite music with the INE-W970HD’s built-in HD Radio and SiriusXM capable (tuner and subscription required). The INE-W970HD also comes with a built-in DVD and CD mechanism and included HDMI input for non-stop entertainment (HDMI cable sold separately).
The INE-W970HD “Works with Apple CarPlay” and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the WVGA touchscreen and is compatible with iPhone 5 and later (iPhone must be connected via USB input).The INE-W970HD includes Android Auto and works with the Google Assistant (requires both a USB cable and bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices and reply to text messages – hands-free.
Features
6.5” Touchscreen
Apple CarPlay® (requires USB connection)
Android Auto™ (requires USB connection)
Bluetooth® Audio with Hands-Free
Built-in Navigation
Built-in HD Radio™
DVD/CD Player
SiriusXM-Ready™ (tuner sold separately)
Smartphone Mirroring via HDMI
Quick Access Sound Key
Specifications
Dimensions (WxHxD): 7" x 3.9" x 5.6"
Screen Resolution: WVGA (800x480)
Aspect Ratio: 16:9
Built-in Amplifier: 45W x 4
RCA Preouts: 3 (4V)
AUX Inputs: 1
USB Inputs: 2
Camera Inputs: 2 (Front and Rear)
HDMI Inputs: 1
Component Video Outputs: 1
16W RMS CEA-2006
Alpine INE-W970HD Manual Part 1Alpine INE-W970HD Manual Part 2Alpine INE-W970HD Installation Manual
Composite RCA to Direct Camera Adaptor for Alpine Head Units
Add an additional universal camera to your Alpine Head Unit with the KCX-CAM1 Additional Composite RCA to Direct Camera Adaptor (universal camera sold separately). The KCX-CAM1 is compatible with all Alpine Head Units that include a Direct Camera Input.
While all Alpine Head Units with Direct Camera Input include one Composite RCA to Direct Camera Adaptor, an adaptor is now available to purchase separately to add an additional universal camera to your vehicle for increased safety during your drive or assistance when maneuvering in and out of parking spots.
Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status systems, the Next-Generation R-Series Speakers are Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This ultra-wide bandwidth brings music even closer to the original source while the classic R-Series design maintains the “loud and fun” performance quality that long-time fans have come to enjoy.
The Next-Generation R-Series speakers now come in upgraded 'Pro' models in addition to the standard model lineup. The pro models utilize a highly rigid, die-cast aluminum basket that eliminates flexing and resonance during playback to ensure the highest quality sound performance.
The new lightweight and rigid glass fiber-reinforced cone material allows for extreme movement and low distortion which results in an incredibly accurate and clean sound during playback.
The Next-Generation R-Series speakers utilize a ferrite magnet, different from the neodymium from previous generations, and a larger motor structure that contributes to more mid-bass during the playback. Despite the larger motor structure, the speakers still maintain the same depth for easy installation.
Continuing with the Next-Generation R-Series speaker line is Alpine-exclusive High Amplitude Multi-Roll (HAMR) surround technology that increased excursions while maintaining linearity for more accurate music reproduction.
Magnesium, hard-dome tweeters contribute to the “loud and fun” R-series sound signature and feature a swivel- mount design for optimal listening positioning and threaded removable housing for flexible factory applications.
The Next-Generation R-Series speaker line offers two pathways for performance: the “Pro” and “Standard” models. The R2-S65C is a standard component speaker set that includes a 6.5” Mid-Range and 1” Tweeter with a flexible in-line crossover network that simplifies installation.
Sold as a pair.
Features
Hi-Res Audio Certified
Glass Fiber Reinforced Cone
Die-Cast Aluminum Basket
Ferrite Magnet Structure
High-Amplitude Multi-Roll (H.A.M.R.) Surround
2 Premium-Grade Full Passive Performance Crossover Networks
Magnesium Hard-Dome Tweeters with Swivel Mount Design and Threaded Removable Housing
Protective Open Mesh Grille Pair Included
Specifications
6.5” Mid-Bass with 1” Tweeter
Frequency Response: 65Hz -40kHz
Power Handling: 100W RMS / 300W Peak
Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status systems, the Next-Generation R-Series Speakers are Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This ultra-wide bandwidth brings music even closer to the original source while the classic R-Series design maintains the “loud and fun” performance quality that long-time fans have come to enjoy.
The new lightweight and rigid glass fiber-reinforced cone material allows for extreme movement and low distortion which results in an incredibly accurate and clean sound during playback.
The Next-Generation R-Series speakers utilize a ferrite magnet, different from the neodymium from previous generations, and a larger motor structure that contributes to more mid-bass during the playback. Despite the larger motor structure, the speakers still maintain the same depth for easy installation.
Continuing with the Next-Generation R-Series speaker line is Alpine-exclusive High Amplitude Multi-Roll (HAMR) surround technology that increased excursions while maintaining linearity for more accurate music reproduction.
Magnesium, hard-dome tweeters contribute to the “loud and fun” R-series sound signature and feature a swivel- mount design for optimal listening positioning and threaded removable housing for flexible factory applications.
The Next-Generation R-Series speaker line offers two pathways for performance: the “Pro” and “Standard” models. The R2-S65C is a standard component speaker set that includes a 6.5” Mid-Range and 1” Tweeter with a flexible in-line crossover network that simplifies installation.
Sold as a pair.
Features
Hi-Res Audio Certified
Glass Fiber Reinforced Cone
Ferrite Magnet Structure
High-Amplitude Multi-Roll (H.A.M.R.) Surround
2 Premium-Grade In-Line Crossover Networks
Magnesium Hard-Dome Tweeters with Swivel Mount Design and Threaded Removable Housing
Protective Open Mesh Grille Pair Included
Specifications
6.5” Mid-Bass with 1” Tweeter
Frequency Response: 65Hz -40kHz
Power Handling: 100W RMS / 300W Peak
Alpine 6X9-Inch Coaxial 2-WAY Speakers, 85-Watt RMS
The S-Series speakers have a large voice coil. The 6.5-inch and 6x9-inch models have a 35-mm voice coil, and this large voice coil size increases their driving power and control of the motor. The S-Series speakers are the first in the industry to use a material called CFRP (Carbon Fiber Reinforced Plastic), a very lightweight yet rigid material. On a standard, off-the-shelf oval cone, the edges are naturally weaker than the center due to the elongated shape. Since the CFRP material is directional, it can be manipulated during the molding process to strengthen the areas of the cone that are normally weak. The result is rigidity throughout the cone that delivers accurate and efficient performance. The ability to manipulate the CFRP material during the molding process is currently exclusive to Alpine and the S-Series speakers. Alpine has three patent-pending procedures in support of this innovative manufacturing process.
Alpine’s patented H.A.M.R. (High Amplitude Multi-Roll) surround is now found on the S-Series speakers. This proven technology increases excursion while maintaining accuracy and linearity. The multi-roll design allows for an even unfolding of the surround which creates incredible linearity and colorization rejection.
Specificatons
85W RMS/260W Peak
Nominal Impedance 4Ω
Frequency Response: 65-22kHz
1” Silk Dome Tweeter
CFRP (Carbon Fiber Reinforced Plastic) Cone
H.A.M.R. Surround
CustomStamped Steel Frame
35mm voice coil
Optional grille sold separately (KTE-S69G)
Alpine 1-Inch Type-S Silk Dome Tweeter Set, 100-Watts RMS
The S-S10TW Tweeter’s motor structure was designed to reduce distortion and increase output at high volumes, so you can turn your music up and still experience crystal clear sound. Brighten up your sound stage without sounding overpowering or compromising sound quality. The silk dome design minimizes harsh highs and instead produces a warm and mellow tone.
The S-S10TW includes a small, in-line crossover made of high-grade electrical components that seamlessly rolls off your midrange while also passively protecting your tweets from low frequency damage. The small size of the crossover also makes installation fast and convenient.
Specifications
Max RMS Power Capacity: 80W
Peak Power Capacity: 240W
Material: Silk
Magnet Type: Neodymium
Voice Coil Type: Copper Clad Aluminum
Crossover: Passive 12dB/Octave High-Pass Filter
Frequency Response: 1kHz-22kHz
Sensitivity: 88dB (1W / 1m)
Impedance: 6 Ohm
Flush Mounting Depth: 17.6mm
Cutout Diameter: 51mm
The display is housed in a Jeep-specific trim bezel that emulates the look and feel of the Jeep® dash. A Jeep-specific harness is included with the receiver to take out the guesswork during installation and make it a true plug-and-play solution. The weather-resistant display features a Jeep-specific opening screen and LED color scheme for a consistent design with factory Jeep® settings.
Experience incredible music detail with Hi-Res Audio Playback. High-precision music reproduction brings out the full potential of every song and makes every drive feel like an intimate recording studio session with your favorite artist. Access your favorite songs on popular Hi-Res streaming services like Apple Music, Tidal, Amazon Music HD, and more. The i509-WRA-JK plays Hi-Res music at it's intended spec of 96kHz/24Bit via a wired USB connection to a smartphone or wirelessly through Bluetooth connection. You can also purchase and download Hi-Res music files onto a USB drive from platforms like HDtracks and plug directly into the receiver for Hi-Res playback.
The i509-WRA-JK Works with Apple CarPlay wirelessly and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay® is accessed through the capacitive touchscreen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later.
The i509-WRA-JK includes Android Auto and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices, and reply to text messages – hands-free.
Enhance your Jeep driving experience with the high-resolution i509-WRA-JK. Features Apple CarPlay, Android AutoTM, and built-in bluetooth hands- free which allow access to music, messages, phone calls, and maps on a smartphone via either a wired USB connection or wirelessly. Get even more entertainment options with built-in HD Radio, Pandora Internet Radio (via iPhone or Android connection), and SiriusXM for even more choices in entertainment (tuner and subscription sold separately).
The i509-WRA-JK has on-board tuning features including a 13-band parametric EQ per channel, for continuous frequency control. The 6-channel time correction ensures that music is staged properly in the front and center of the vehicle. If more power is needed, additional amplifiers can be added using the three sets of true 4V preamp outputs with front, rear, and subwoofer control.
The i509-WRA-JK includes an iDatalink® Maestro module to allow select factory features like voice- activated media player, Bluetooth® technology, and steering wheel controls to be retained and vehicle information displayed on the screen. The iDatalink® can also integrate with the Jeep® diagnostic port so select vehicle information like tire pressure, battery voltage, door status, engine codes, and user-customizable gauges can be monitored on the display.
Whether commuting or off-roading, the i509-WRA-JK includes two camera inputs to add a front, side, or rearview camera (sold separately) and make blind spots a distant memory. The rearview camera includes a distance guide display that overlays guidelines onto the screen for ease when moving in reverse.
Take driving safety even further by connecting your i509-WRA-JK with the DVR-C320R Premium 1080P Front and Rear Dash Camera with built-in drive assist (sold separately). View real-time and recorded drives in high definition on your i509-WRA-JK, plus receive drive assist features that help get you to your destination.
Features
9-inch HD Anti-Glare Display with Jeep Specific Trim Bezel
Weather-Resistant (Rated IP53)
Plug-and-Play Installation
Jeep® Specific Tuning
Hi-Res Audio Playback (96kHz / 24bit)
Wireless Hi-Res Audio (requires LDAC compatible device)
Hi-Res music streaming with TIDAL (A TIDAL subscription is required and sold separately; Alpine Head Unit must be tethered to a mobile or smartphone hotspot; Data rates may apply)
Apple Carplay® (Wired & Wireless)
Android Auto™ (Wired & Wireless)
The Google Assistant is Available on Android Auto™
Bluetooth® Hands-Free
SiriusXM-Ready® (compatible with SXV300 (G2) add-on tuner, sold separately; SiriusXM subscription required)
Built-in HD Radio®
Retain Factory Media Controls and Vehicle Info with the included iDatalink Maestro module
Retain Factory Amplifier with KCX-F200INT (sold separately)
Alpine DVR-C320R Dash Cam Compatible (sold separately)
Media Xpander®
Specifications
Screen Resolution: WXGA 1280 x 720px (720p HD)
AUX Input: 1
HDMI Input: 1
HDMI Output: 1
Camera Inputs: 2 Direct (1 Rear input & 1 input that can be set as Front, Side, or Other)
Dash Cam Input: 1 (Works best with Alpine DVR-C320R - sold separately)
USB Inputs: 2 (1 data & 1 charge only port)
4V Pre-Outs: 3
Built-in Amplifier: 18W RMS x 4
EQ: 13-Band Parametric (per channel)
Time Correction: 6-Channel
DAC: 24 Bit
Crossover: High Pass / Low Pass
Audio Playback: AAC, APE, FLAC, MP3, WMA, WAV
Video Playback: AVC, FLV, H.263, H.264, MP4, MPEG-1, MPEG-2, MPEG-4, MKV, MOV
Alpine i509-WRA-JK Installation ManualAlpine i509-WRA-JK Tech SheetAlpine I509-WRA-JK Manual Part 1Alpine i509-WRA-JK Manual Part 2
300-Watt Door-Speaker and Add-On Subwoofer Kit for Select 2018-2023 Jeep Wrangler, Gladiator Vehicles
Complete Sound System Upgrade Package for the four-door, non-amplified 2018-23 Jeep® Wrangler and non-amplified 2020-23 Jeep® Gladiator. Also compatible with two-door, non-scissor front seats in 2019-23 Jeep® Wrangler
Go beyond your wildest expectations for sound with this complete sound upgrade package. The PSS-24WRA has 5-channels of powered sound that replaces your factory system. The package includes two sets of 6.5” weather-resistant mid-bas drivers and 1” weather-resist tweeters that replace the front and rear soundbar factory speakers, an 8” powered, compact subwoofer and a 4-channel power pack amplifier.
Specifications
Complete, five-channel powered sound system upgrade package
Compatible with four-door, non-amplified 2018-23 Jeep® Wrangler and non-amplified 2020-23 Jeep® Gladiator (not compatible with OEM Alpine amplified system)
Compatible with two-door, non-scissor front seats in 2019-23 Jeep® Wrangler
Includes Alpine’s SPV-65X-WRA, SPV-65-JLT, PWE-S8, and KTP-445U
180W, 4-channel Power Pack amplifier
120W, 8” powered subwoofer
(2x) 6.5” weather-resistant mid-bass drivers
(2x) 1” weather-resistant teteron dome tweeters with vehicle-specific connectors and crossovers
Vehicle-specific front speaker pods with vehicle-specific connectors
Tweeter adapter plates allow for the use of the original factory tweeter locations
SPV-65-JLT weather-resistant rear soundbar speaker system
Rugged, premium grills designed to emulate the factory look and appeal
Vehicle-specific connectors for plug-and-play speaker installation
Utilizes factory bolt locations
Durable stamped, steel frame speaker basket design
Includes template for mounting
Vehicle-specific T-harness for installation with OEM radio into compatible 2018-23 Jeep® Wrangler and 2020-23 Jeep® Gladiator vehicles
Vehicle-specific mounting brackets allow for the powered sub and amp to be secured under the passenger seat without drilling
What's in the Box:
KTP-445U Universal 4-Channel Power Amplifier
PWE-S8 8" Compact Powered Subwoofer
SPV-65X-WRA Front Component Speakers
SPV-65-JLT Rear Sound Bar Speakers
ALP-POD-JLT Front Speaker Pod
PSU-BKT-JL-R PWE Right Bracket JL
PSU-BKT-JL-L PWE Left Bracket JL
ALP-HRN-PSU300 PSU Power Harness
ALP-THRN-CH2 Chrysler T-Harness
CT6 6" Cable Ties
PHPSM412 Pan Head Phillips Screw M4x12
SLWM4 M4 Split Lock Washers
PHSCR832 8-32 Pan Head Phillips screws
PSS-WRA-IM Installation Manual
Specifications
Front (SPV-65X-WRA)
Power handling: 75 watts RMS (225 watts peak)
Frequency response: 65kHz – 22kHz
Nominal impedance: 4 ohms
Weather-resistant: IP55
Rear (SPV-65-JLT)
Power handling: 90 watts RMS (270 watts peak)
Frequency response: 50kHz – 22kHz
Nominal impedance: 4 ohms
Weather-resistant: IP55
Powered Subwoofer (PWE-S8)
120 watts RMS (240 watts peak)
Frequency response: 32 - 150Hz
Variable low-pass crossover (80-200 Hz)
Variable phase control (0-180 degrees)
preamp- and speaker-level inputs
Four Channel Power Pack Amplifier (KTP-445U)
45 watts RMS x 4 at 4 or 2 ohms
90 watts RMS x 2 bridged at 4 ohms
Selectable high-pass filters (60, 80, or 120 Hz at 12 dB/octave)
Switchable RCA or speaker-level inputs|
Dimensions:
27” L x 18.5” W x 19.5” H
40lbs
Direct fit for non-amplified 2018–Up 4-door Jeep Wrangler JL Unlimited
Direct fit for non-amplified 2019–Up 2-door Jeep Wrangler
Direct fit for non-amplified 2020–Up Jeep Gladiator JT
Alpine PSS-24WRA Installation Manual
Replacement Tip-Sleeve Microphone for Select Alpine Head-Units
Replacement Microphone for Bluetooth enabled Alpine stereos with a tip and sleeve connector.
Alpine Amplifier Bass Control Knob
The optional RUX-KNOB remote bass control knob plugs right in to select Alpine amplifiers for quick direct subwoofer control to make bass adjustments on the fly.
The R-Series amplifiers utilize Alpine’s advanced amplifier platform that takes the classic Class-D amplifier circuit and adds dual post-filter feedback loops for unmatched accuracy and control. This technology., originally launched in the premium X-Series amplifiers,, produces efficient power with enhanced dynamic range, qualifying the R-Series amplifiers to be Hi-Resolution Audio compliant.
This new technology minimizes audible imperfections like excessive phase shift and internal noise which can deteriorate sound quality. With an incredibly low phase shift of 46°, the R-A60F 4-channel amplifier delivers accurate imaging compared to well over 100° of phase shift by a competitive amplifier model. This superior phase curve ensures a proper sound stage among the singers and instruments.
Specifications
Alpine's Class D amplifier circuit
100W RMS x 4 (4Ω, 14.4V, ≤ 1% THD+N)
150W RMS x 4 (2Ω, 14.4V, ≤ 1% THD+N)
Bridged: 300W x 2 (4Ω, 14.4V, ≤ 1% THD+N)
S/N >85dB (ref. 1W into 4Ω) • THD+N≤ 0.03% (ref. 1W into 4Ω)
Frequency response =10Hz to 45kHz (+/- 3dB)
Damping Factor >500
Alpine R-A60F Manual
The HCE-RCAM-WRA lets you easily add an Alpine rear-view camera to your 2007-2018 Jeep Wrangler JK. It is compatible with Alpine in-dash screen systems, the factory Jeep screen or other aftermarket screens. If used with the factory screen, you can add the Alpine SGS-CH01 Camera Interface (sold separately) with Active Guide Lines, – without factory screen re-programming.
With tons of wheel choices for the Wrangler, you need a versatile camera that works with any of them. The HCE-RCAM-WRA consists of the HCE-C1100 Rear-View Camera and bracket that is mounted between the spare tire and the Wrangler’s 5x5 wheel pattern. The upper portion of the bracket can be positioned to the left or right of the wheel’s spokes, ensuring that the attached camera has a clear line of sight behind the vehicle and is not blocked by the wheel.
Backing out of garages or riding through shady trails can be tough on a back-up camera. Standard cameras have difficulty managing changes in light, causing images to wash out and making it difficult to see what’s behind you at times. The HCE-RCAM-WRA has High Dynamic Range (HDR) technology for improved image quality. HDR technology can manage a wider range of luminance through the camera’s sensor as compared to standard cameras. Bright and dark areas are captured and adjusted for even exposure and white balance, preventing the image from being washed-out or too dark as you drive between sunlight and low-light conditions.
Specifications
Includes HCE-C1100 Rear Camera
Adjustable bracket positions the camera in-between the wheel spokes
Adjustable camera angle and height
Alpine HCE-RCAM-WRA Manual
From towing to travel, you depend on your truck to get you where you want to go, but can you rely on getting the best performance from your sound system? Now you can add deep, accurate bass in your truck without compromising valuable cabin space with the new R2-DB8V-TRK dual 8” Alpine Halo R-Series preloaded truck subwoofer enclosure with the ProLink system and amplifier space.
The enclosures were intentionally crafted to fit most full-size trucks. Two 8” subwoofers are preloaded into a compact enclosure for under the seat installation and linked with a ProLink bracket that can adjust from 51”-40”. Centered on the enclosures is an integrated amplifier mount tray that’s optimized for Alpine’s S-A75M Mono Power Amplifier (sold separately). Rubber “feet” are adjustable in height to accommodate uneven truck floors.
These ported subwoofer enclosures feature the next-generation 8” R-Series subwoofers with a more powerful motor that creates deeper bass while Alpine’s High Amplitude Multi-Roll (HAMR) surround technology allows the subwoofer cone to efficiently move air while staying cool for incredible accuracy. A new ceramic composite dust cap has higher heat resistance that ensures non-stop bass performance.
Alpine’s new preloaded truck subwoofer enclosures join the Alpine Halo family with a premium, unmistakable design. The enclosure pulls design cues from the Alpine Halo display with unique, curved edges outlined by a silver trim and a front link bracket cover with an Alpine logo badge. The 5/8” MDF enclosures are covered in a premium black carpet that will elevate the look of your truck.
With two preloaded R2-W8D2 8” R- Series subwoofers that are tuned to 36Hz, R2-DB8V-TRK is optimized to perform with Alpine’s R-Series sound system line. Dual voice coils are wired in parallel for a 2Ω load that’s compatible with Alpine’s R-Series R2-A75M mono power amplifier.
Features
Groundbreaking Alpine Halo Design
ProLink™ Ported Enclosure
Expandable Width from 40" to 51"
Compact, Under-the-Seat Installation in Most Full-Size Trucks
Integrated Amplifier Tray (not applicable with all vehicles)
Rubber, Modular Stackable Foot Design Accommodates Uneven Truck Floor Areas
Ported Enclosures with High-Performance S-Series Subwoofers
Front Link Alpine Branded Bracket
Side-Firing Cabin Loading Ports
Premium Alpine Wire Terminals
CARB Compliant 5/8" MDF Construction
Premium Black Carpet
Specifications
Dimensions: 40"-51" (Adjustable Width) x 8-3/4” (H) x 13-3/4” (D)
750W RMS
Frequency Response: 32Hz-200Hz
Sensitivity: 84dB
Dual voice coils Wired in Parallel for a 2Ω Load (Compatible with R-A75M)
Vented Enclosure Tuning Frequency: 36Hz
Custom spring-loaded speaker terminals fit up to 12AWG speaker wire
Alpine R2-DB8V-TRK BrochureAlpine R2-DB8V-TRK Manual
S-Series Dual Loaded 600-Watt 8-Inch 2-Ohm Subwoofer Enclosure for Select Jeep Wrangler-JL Gladiator-JT and other Pickup Vehicles
From towing to travel, you depend on your truck to get you where you want to go, but can you rely on getting the best performance from your sound system? Now you can add deep, accurate bass in your truck without compromising valuable cabin space with the new S-DB8V-TRK dual 8” Alpine Halo S-Series preloaded truck subwoofer enclosure with the ProLink system and amplifier space.
The enclosures were intentionally crafted to fit most full-size trucks. Two 8” subwoofers are preloaded into a compact enclosure for under the seat installation and linked with a ProLink bracket that can adjust from 51”-40”. Centered on the enclosures is an integrated amplifier mount tray that’s optimized for Alpine’s S-A60M Mono Power Amplifier (sold separately). Rubber “feet” are adjustable in height to accommodate uneven truck floors.
The enclosures are designed for the unique cabin environment of your truck. The ported subwoofer enclosures feature Alpine’s reliable 8” S-Series subwoofers. The subwoofers are designed with an improved voice coil that brings out the full potential of the subwoofer. The custom-stamped steel frame is designed to withstand the rigors of the strong S-Series motor. Frame leg vents, as well as a vented backplate, keep the subwoofer cool for non-stop bass performance.
Alpine’s new preloaded truck subwoofer enclosures join the Alpine Halo family with a premium, unmistakable design. The enclosure pulls design cues from the Alpine Halo display with unique, curved edges outlined by a silver trim and a front link bracket cover with an Alpine logo badge. The 5/8” MDF enclosures are covered in a premium black carpet that will elevate the look of your truck.
With two preloaded S-W8D2 8” S- Series subwoofers that are tuned to 36Hz, the S-DB8V-TRK is optimized to perform with Alpine’s S-Series sound system line. Dual voice coils are wired in parallel for a 2Ω load that’s compatible with Alpine’s S-Series S-A60M mono power amplifier.
Features
Groundbreaking Alpine Halo Design
ProLink™ Ported Enclosure
Expandable Width from 40" to 51"
Compact, Under-the-Seat Installation in Most Full-Size Trucks
Integrated Amplifier Tray (not applicable with all vehicles)
Rubber, Modular Stackable Foot Design Accommodates Uneven Truck Floor Areas
Ported Enclosures with High-Performance S-Series Subwoofers
Front Link Alpine Branded Bracket
Side-Firing Cabin Loading Ports
Premium Alpine Wire Terminals
CARB Compliant 5/8" MDF Construction
Premium Black Carpet
Specifications
Dimensions: 40"-51" (Adjustable Width) x 8-3/4” (H) x 13-3/4” (D)
600W RMS
Frequency Response: 34Hz-200Hz
Sensitivity: 84dB
Dual voice coils Wired in Parallel for a 2Ω Load (Compatible with S-A60M)
Vented Enclosure Tuning Frequency: 36Hz
Custom spring-loaded speaker terminals fit up to 12AWG speaker wire
Alpine S-DB8V-TRK BrochureAlpine S-DB8V-TRK Manual
R-Series Loaded 600-Watt Thin 10-Inch 2-Ohm Subwoofer Enclosure
Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow preloaded subwoofer enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.
Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series shallow subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
Integrated cooling fins located in the core of the subwoofer help dissipate the heat generated by the rapid subwoofer movement for enhanced cooling reliability and hours of uninterrupted playtime. The unique CoolMount dual-panel mount subwoofer motor enhances cooling.
Alpine’s Gen2 DD-Linear Magnetic Circuit technology, a compact and efficient dual-gap voice coil structure, allows for better control over the motor, resulting in lower distortion and precise bass control. The preloaded enclosures use the subwoofer frame as bracing fora more ridged design and better bass response.
A lightweight yet rigid aluminum dust cap allows the R-Series shallow subwoofer to transition sound quickly with minimal distortion and project the bass off the surface of the speaker for hard-hitting yet smooth bass performance. The included adjustable mounting brackets allow for a downfire mount configuration.
With dual voice coils wired in parallel for a 2Ω load, the Alpine R-Series 10" shallow subwoofer enclosure is optimized to perform with Alpine's S-A60M or R-A75M mono amplifiers.
Features
Optimal sealed cabinet quality
Aluminum Dust Cap
Neodymium Magnet
Alpine Gen2 DD Linear Magnetic Circuit
CARB compliant ¾” MDF construction
Premium Alpine embroidered black carpet
Alpine-branded terminal cup
Pre-installed steel mesh grille
Includes a 10” R-Shallow Subwoofer (RS-W10D4)
Rubber, modular stackable foot design
Specifications
Dimensions: 21.15” W x 5.25” H x 16” L
600W RMS Power Handling
Frequency response: 29Hz – 200Hz
Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)
Nominal Impedance: 2Ω
Voice Coil: 4”(101.6mm)
R-Series Loaded 600-Watt Thin 12-Inch 2-Ohm Subwoofer Enclosure
Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow preloaded subwoofer enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.
Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series shallow subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
Integrated cooling fins located in the core of the subwoofer help dissipate the heat generated by the rapid subwoofer movement for enhanced cooling reliability and hours of uninterrupted playtime. The unique CoolMount dual-panel mount subwoofer motor enhances cooling.
Alpine’s Gen2 DD-Linear Magnetic Circuit technology, a compact and efficient dual-gap voice coil structure, allows for better control over the motor, resulting in lower distortion and precise bass control. The preloaded enclosures use the subwoofer frame as bracing fora more ridged design and better bass response.
A lightweight yet rigid aluminum dust cap allows the R-Series shallow subwoofer to transition sound quickly with minimal distortion and project the bass off the surface of the speaker for hard-hitting yet smooth bass performance. The included adjustable mounting brackets allow for a downfire mount configuration.
With dual voice coils wired in parallel for a 2Ω load, the Alpine R-Series 12" shallow subwoofer enclosure is optimized to perform with Alpine's S-A60M or R-A75M mono amplifiers.
Features
Optimal sealed cabinet quality
Aluminum Dust Cap
Neodymium Magnet
Alpine Gen2 DD Linear Magnetic Circuit
CARB compliant ¾” MDF construction
Premium Alpine embroidered black carpet
Alpine-branded terminal cup
Pre-installed steel mesh grille
Includes a 12” R-Shallow Subwoofer (RS-W12D4)
Rubber, modular stackable foot design
Specifications
Dimensions: 26.5” W x 5.25” H x 17” D
600W RMS Power Handling
Frequency response: 26Hz – 200Hz
Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)
Nominal Impedance: 2Ω
Voice Coil: 4”(101.6mm)
R-Series 8-Inch 350-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W8D2 and R2-W8D4 is compatible with the KTE-8G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
350W RMS
1000W Peak Power Handling
Frequency Response: 30Hz-200Hz
Sensitivity (1W/1m): 83.5dB
Nominal Impedance: 4Ω
Voice Coil: 35mm
X-Max: 12mm
Magnet Weight: 56oz
Mounting Depth: 4-3/8” (118mm)
Cutout Size: 6-15/16” (176mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W8D Manual
R-Series 10-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W10D2 and R2-W10D4 is compatible with the KTE-10G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
750W RMS
2250W Peak Power Handling
Frequency Response: 26Hz-200Hz
Sensitivity (1W/1m): 82.4dB
Nominal Impedance: 4Ω
Voice Coil: 65mm
X-Max: 20mm
Magnet Weight: 123oz
Mounting Depth: 6” (152mm)
Cutout Size: 9-1/16” (231mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W10D Manual
R-Series 12-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W12D2 and R2-W12D4 is compatible with the KTE-12G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
750W RMS
2250W Peak Power Handling
Frequency Response: 24Hz-200Hz
Sensitivity (1W/1m): 84.5dB
Nominal Impedance: 4Ω
Voice Coil: 65mm
X-Max: 20mm
Magnet Weight: 144oz
Mounting Depth: 6-1/2” (152mm)
Cutout Size: 10-7/8” (231mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W12D Manual
Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status systems, the Next-Generation R-Series Speakers are Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This ultra-wide bandwidth brings music even closer to the original source while the classic R-Series design maintains the “loud and fun” performance quality that long-time fans have come to enjoy.
The new lightweight and rigid glass fiber-reinforced cone material allows for extreme movement and low distortion which results in an incredibly accurate and clean sound during playback.
The Next-Generation R-Series speakers utilize a ferrite magnet, different from the neodymium from previous generations, and a larger motor structure that contributes to more mid-bass during the playback. Despite the larger motor structure, the speakers still maintain the same depth for easy installation.
Continuing with the Next-Generation R-Series speaker line is Alpine-exclusive High Amplitude Multi-Roll (HAMR) surround technology that increased excursions while maintaining linearity for more accurate music reproduction.
Magnesium, hard-dome tweeters contribute to the “loud and fun” R-series sound signature and feature a swivel- mount design for optimal listening positioning and threaded removable housing for flexible factory applic
The Next-Generation R-Series speaker line offers two pathways for performance: the “Pro” and “Standard” models. The R2-S69 is a standard coaxial speaker set that includes a 6x9” Mid-Range and 1” Tweeter with a flexible in-line crossover network that simplifies installation.
Sold as a pair.
Features
Hi-Res Audio Certified
Glass Fiber Reinforced Cone
Die-Cast Aluminum Basket
Ferrite Magnet Structure
High-Amplitude Multi-Roll (H.A.M.R.) Surround
2 Premium-Grade Full Passive Performance Crossover Networks
Magnesium Hard-Dome Tweeters with Swivel Mount Design and Threaded Removable Housing
Protective Open Mesh Grille Pair Included
Specifications
6x9” Mid-Bass with 1” Tweeter
Frequency Response: 60Hz -40kHz
Power Handling: 100W RMS / 300W Peak
Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status systems, the Next-Generation R-Series Speakers are Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This ultra-wide bandwidth brings music even closer to the original source while the classic R-Series design maintains the “loud and fun” performance quality that long-time fans have come to enjoy.
The new lightweight and rigid glass fiber-reinforced cone material allows for extreme movement and low distortion which results in an incredibly accurate and clean sound during playback.
The Next-Generation R-Series speakers utilize a ferrite magnet, different from the neodymium from previous generations, and a larger motor structure that contributes to more mid-bass during the playback. Despite the larger motor structure, the speakers still maintain the same depth for easy installation.
Continuing with the Next-Generation R-Series speaker line is Alpine-exclusive High Amplitude Multi-Roll (HAMR) surround technology that increased excursions while maintaining linearity for more accurate music reproduction.
The Next-Generation R-Series speaker line offers two pathways for performance: the “Pro” and “Standard” models. The R2-S69 is a standard coaxial speaker set that includes a 6x9” Mid-Range and 1” Tweeter with a flexible in-line crossover network that simplifies installation.
Sold as a pair.
Features
Hi-Res Audio Certified
Glass Fiber Reinforced Cone
Die-Cast Aluminum Basket
Ferrite Magnet Structure
High-Amplitude Multi-Roll (H.A.M.R.) Surround
2 Premium-Grade Full Passive Performance Crossover Networks
Magnesium Hard-Dome Tweeters with Swivel Mount Design and Threaded Removable Housing
Protective Open Mesh Grille Pair Included
Specifications
6x9” Mid-Bass with 1” Tweeter
Frequency Response: 60Hz -40kHz
Power Handling: 100W RMS / 300W Peak
Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status systems, the Next-Generation R-Series Speakers are Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This ultra-wide bandwidth brings music even closer to the original source while the classic R-Series design maintains the “loud and fun” performance quality that long-time fans have come to enjoy.
The Next-Generation R-Series speakers now come in upgraded 'Pro' models in addition to the standard model lineup. The pro models utilize a highly rigid, die-cast aluminum basket that eliminates flexing and resonance during playback to ensure the highest quality sound performance.
The new lightweight and rigid glass fiber-reinforced cone material allows for extreme movement and low distortion which results in an incredibly accurate and clean sound during playback.
The Next-Generation R-Series speakers utilize a ferrite magnet, different from the neodymium from previous generations, and a larger motor structure that contributes to more mid-bass during the playback. Despite the larger motor structure, the speakers still maintain the same depth for easy installation.
Continuing with the Next-Generation R-Series speaker line is Alpine-exclusive High Amplitude Multi-Roll (HAMR) surround technology that increased excursions while maintaining linearity for more accurate music reproduction.
Magnesium, hard-dome tweeters contribute to the “loud and fun” R-series sound signature and feature a swivel- mount design for optimal listening positioning and threaded removable housing for flexible factory applications.
The Next-Generation R-Series speaker line offers two pathways for performance: the “Pro” and “Standard” models. The R2-S652 is a standard component speaker set that includes a 6.5” Mid-Range and 1” Tweeter with an outboard crossover network the professional installation.
Sold as a pair.
Features
Hi-Res Audio Certified
Glass Fiber Reinforced Cone
Die-Cast Aluminum Basket
Ferrite Magnet Structure
High-Amplitude Multi-Roll (H.A.M.R.) Surround
2 Premium-Grade Full Passive Performance Crossover Networks
Magnesium Hard-Dome Tweeters with Swivel Mount Design and Threaded Removable Housing
Protective Open Mesh Grille Pair Included
Specifications
6.5” Mid-Bass with 1” Tweeter
Frequency Response: 65Hz -40kHz
Power Handling: 100W RMS / 300W Peak
Using “trickle-down” technology, inspired design, and performance cues from the Ultra-High-Resolution AlpineF#1Status systems, the Next-Generation R-Series Speakers are Hi-Res Audio Certified and able to reproduce up to 40kHz frequency response. This ultra-wide bandwidth brings music even closer to the original source while the classic R-Series design maintains the “loud and fun” performance quality that long-time fans have come to enjoy.
The new lightweight and rigid glass fiber-reinforced cone material allows for extreme movement and low distortion which results in an incredibly accurate and clean sound during playback.
The Next-Generation R-Series speakers utilize a ferrite magnet, different from the neodymium from previous generations, and a larger motor structure that contributes to more mid-bass during the playback. Despite the larger motor structure, the speakers still maintain the same depth for easy installation.
Continuing with the Next-Generation R-Series speaker line is Alpine-exclusive High Amplitude Multi-Roll (HAMR) surround technology that increased excursions while maintaining linearity for more accurate music reproduction.
The Next-Generation R-Series speaker line offers two pathways for performance: the “Pro” and “Standard” models. The R2-S65 is a standard coaxial speaker set that includes a 6.5” Mid-Range and 1” Coaxial Tweeter with a flexible in-line crossover network that simplifies installation.
Sold as a pair.
Features
Hi-Res Audio Certified
Glass Fiber Reinforced Cone
Ferrite Magnet Structure
High-Amplitude Multi-Roll (H.A.M.R.) Surround
2 Premium-Grade Crossover Networks
Magnesium Hard-Dome Tweeters with Swivel Mount Design and Threaded Removable Housing
Protective Open Mesh Grille Pair Included
Specifications
6.5” Mid-Bass with 1” Tweeter
Frequency Response: 65Hz -40kHz
Power Handling: 100W RMS / 300W Peak
This custom-designed dash solution gives you the latest smartphone and entertainment features, all on an intuitive, 7-inch touchscreen. The dash kit replaces your factory radio and includes Jeep-specific wiring adapters that plug directly into your factory setup for plug-and-play installation.
The i407-WRA-JK allows you to use features on your smartphone while keeping your hands on the wheel and eyes on the road. Apple CarPlay, Android Auto, and bluetooth hands-free calling and music streaming can be controlled with voice commands so you can access your phone calls, text messages, and more with a simple voice command on the included external microphone. Use your smartphone for third-party navigation apps like Google Maps or Waze.
The i407-WRA-JK “Works with Apple CarPlay” and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touch screen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later (iPhone must be connected via Apple lightning cable).
The i407-WRA-JK includes Android Auto and works with the Google Assistant (requires both a USB cable and Bluetooth® connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say "OK Google" or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices and reply to text messages – hands free.
Customize the screen exactly the way you want it by using drag-and-drop motions with your finger to add, remove, or move over 29 available widgets. You can prioritize your three home screens so you can quickly find the apps you want like Apple CarPlay, AndroidAuto, Camera, bluetooth functions, and more. Add a customizable wallpaper from your photos through a thumb drive.
Keep the factory controls you use the most, like voice-activated media player, bluetooth technology, and steering wheel controls with the included iDataLink Maestro Module. The iDatalink adapter can also integrate with the Jeep diagnostic port so select vehicle information like tire pressure, battery voltage, door status, engine codes, and user-customizable gauges can be monitored on the 7-inch touchscreen. The i407-WRA-JK also retains the factory backup camera with rear-guideline display.
While the i407-WRA-JK is mech-less (no CD/DVD player), you still have plenty of entertainment options that will make every drive exciting. A rear USB port allows you to listen to your music or video file via USB or connect by searching song title, artist info, or your smartphone to access your music album. The i407-WRA-JK has built-in HD Radio. SiriusXM Radio is also available with an optional SXV-300 tuner and paid subscription. And HDMI input is available should you choose to connect a CD or DVD player for all-digital audio and video connection through a single cable.
Retain the Alpine OEM Premium Amplified System with the KCX-F200INT premium audio interface. The KCX-F200INT is designed to retain the Alpine OEM Premium Amplifier when installing the i407-WRA-JK into the 2007–2018 Jeep Wrangler JK. The KCX-F200INT mimics the signals from your Alpine OEM Premium Amplifier to retain the integrity of your system while upgrading the technology on your dash.
Features
7-inch Anti-glare 2-DIN Touchscreen Display
Premium Quality OEM-fit Dash System
Plug-and-Play Installation
Shallow Mount Design (2-6/16" Depth)
Customizable User Interface (29 available widgets/apps)
Customizable Background/Wallpaper
PowerStack™ Capable with the KTA-450 and KTA-200M (sold separately)
Works with Apple CarPlay®
The Google Assistant is available on Android Auto™
Bluetooth® built-in for hands-free calling and audio streaming
SiriusXM-Ready® (SXV300 Connect Vehicle Tuner Kit sold separately; SiriusXM subscription required)
Built-in HD Radio®
HDMI Input
iDatalink® Maestro Connectivity (retains factory controls)
2 RCA Camera Inputs
Rearview Camera Distance Guide Display
MediaXpander®
Specifications
Width: 7" (178mm)
Height: 4" (100mm)
Depth: 2-6/16" (60mm)
Screen Size: 7"
Screen Resolution: WVGA 800 x 480px
PowerStack™ Capable: Yes
HDMI Input: 1
Camera Input: 2 RCA
USB Input: 1
4V Pre-Outs: 3
Built-in Amplifier: 16W RMS/50W peak x 4
EQ: 5-Band Graphic
DAC: 24 Bit
Subwoofer level control
High pass crossover/ low pass crossover
6-channel time correction
Audio Playback: AAC, FLAC, MP3, WMA, WAV
Photo Playback: JPG, PNG, BMP
Video Playback: AVI, MP4, MPG, MOV, WMV
CTA-2006 compliant
Alpine i407-WRA-JK Installation ManualAlpine i407-WRA-JK Manual Part-1Alpine i407-WRA-JK Manual Part-2
DDIN-Style Mechless Bluetooth Stereo with a Seven-Inch Touchscreen for Select 2018-2022 Jeep Wrangler-JL and Gladiator-JT Vehicles
This custom-designed dash solution gives you the latest smartphone and entertainment features, all on an intuitive, 7-inch touchscreen. The dash kit replaces your factory radio and includes Jeep-specific wiring adapters that plug directly into your factory setup for plug-and-play installation.
The i407-WRA-JL allows you to use features on your smartphone while keeping your hands on the wheel and eyes on the road. Apple CarPlay, Android Auto, and bluetooth hands-free calling and music streaming can be controlled with voice commands so you can access your phone calls, text messages, and more with a simple voice command on the included external microphone. Use your smartphone for third-party navigation apps like Google Maps or Waze.
The i407-WRA-JL “Works with Apple CarPlay” and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touch screen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later (iPhone must be connected via Apple lightning cable).
The i407-WRA-JL includes Android Auto and works with the Google Assistant (requires both a USB cable and Bluetooth® connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say "OK Google" or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices and reply to text messages – hands free.
Customize the screen exactly the way you want it by using drag-and-drop motions with your finger to add, remove, or move over 29 available widgets. You can prioritize your three home screens so you can quickly find the apps you want like Apple CarPlay, AndroidAuto, Camera, bluetooth functions, and more. Add a customizable wallpaper from your photos through a thumb drive.
Keep the factory controls you use the most, like voice-activated media player, bluetooth technology, and steering wheel controls with the included iDataLink Maestro Module. The iDatalink adapter can also integrate with the Jeep diagnostic port so select vehicle information like tire pressure, battery voltage, door status, engine codes, and user-customizable gauges can be monitored on the 7-inch touchscreen. The i407-WRA-JL also retains the factory backup camera with rear-guideline display.
While the i407-WRA-JL is mech-less (no CD/DVD player), you still have plenty of entertainment options that will make every drive exciting. A rear USB port allows you to listen to your music or video file via USB or connect by searching song title, artist info, or your smartphone to access your music album. The i407-WRA-JL has built-in HD Radio. SiriusXM Radio is also available with an optional SXV-300 tuner and paid subscription. And HDMI input is available should you choose to connect a CD or DVD player for all-digital audio and video connection through a single cable.
Retain the Alpine OEM Premium Amplified System with the KCX-F200INT premium audio interface. The KCX-F200INT is designed to retain the Alpine OEM Premium Amplifier when installing the i407-WRA-JL into the 2018–Up Jeep Wrangler and 2020–Up Jeep Gladiator. The KCX-F200INT mimics the signals from your Alpine OEM Premium Amplifier to retain the integrity of your system while upgrading the technology on your dash.
Features
7-inch Anti-glare 2-DIN Touchscreen Display
Premium Quality OEM-fit Dash System
Plug-and-Play Installation
Shallow Mount Design (2-6/16" Depth)
Customizable User Interface (29 available widgets/apps)
Customizable Background/Wallpaper
Works with Apple CarPlay®
The Google Assistant is available on Android Auto™
Bluetooth® built-in for hands-free calling and audio streaming
SiriusXM-Ready® (SXV300 Connect Vehicle Tuner Kit sold separately; SiriusXM subscription required)
Built-in HD Radio®
HDMI Input
iDatalink® Maestro Connectivity (retains factory controls)
2 RCA Camera Inputs
Rearview Camera Distance Guide Display
MediaXpander®
Retain the Alpine OEM Premium Amplified System with the KCX-F200INT Premium Audio System Interface (sold separately)
Specifications
Width: 7" (178mm)
Height: 4" (100mm)
Depth: 2-6/16" (60mm)
Screen Size: 7"
Screen Resolution: WVGA 800 x 480px
HDMI Input: 1
Camera Input: 2 RCA
USB Input: 1
4V Pre-Outs: 3
Built-in Amplifier: 16W RMS/50W peak x 4
EQ: 5-Band Graphic
DAC: 24 Bit
Subwoofer level control
High pass crossover/ low pass crossover
6-channel time correction
Audio Playback: AAC, FLAC, MP3, WMA, WAV
Photo Playback: JPG, PNG, BMP
Video Playback: AVI, MP4, MPG, MOV, WMV
CTA-2006 compliant
Alpine i407-WRA-JL Installation ManualAlpine i407-WRA-JL Manual Part-1Alpine i407-WRA-JL Manual Part-2
DDIN-Style Mechless Bluetooth Stereo with a Nine-Inch Touchscreen for Select 2018-2022 Jeep Wrangler-JL and Gladiator-JT Vehicles
The display is housed in a Jeep-specific trim bezel that emulates the look and feel of the Jeep dash. A Jeep-specific harness is included with the receiver to take out the guesswork during installation and make it a true plug-and-play solution. The weather-resistant display features a Jeep-specific opening screen and LED color scheme for a consistent design with factory Jeep settings.
Experience incredible music detail with Hi-Res Audio Playback. High-precision music reproduction brings out the full potential of every song and makes every drive feel like an intimate recording studio session with your favorite artist. Access your favorite songs on popular Hi-Res streaming services like Apple Music, Tidal, Amazon Music HD, and more. The i509-WRA-JL plays Hi-Res music at it's intended spec of 96kHz/24Bit via a wired USB connection to a smartphone or wirelessly through Bluetooth® connection. You can also purchase and download Hi-Res music files onto a USB drive from platforms like HDtracks and plug directly into the receiver for Hi-Res playback.
The i509-WRA-JL Works with Apple CarPlay wirelessly and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touchscreen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later.
The i509-WRA-JL includes Android Auto wirelessly and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices, and reply to text messages – hands-free.
Enhance your Jeep driving experience with the high-resolution i509-WRA-JL. Features Apple CarPlay, Android Auto, and built-in bluetooth hands-free which allow access to music, messages, phone calls, and maps on a smartphone via either a wired USB connection or wirelessly. Get even more entertainment options with built-in HD Radio, Pandora Internet Radio (via iPhone or Android connection), and SiriusXM for even more choices in entertainment (tuner and subscription sold separately).
The i509-WRA-JL has on-board tuning features including a 13-band parametric EQ per channel, for continuous frequency control. The 6-channel time correction ensures that music is staged properly in the front and center of the vehicle. If more power is needed, additional amplifiers can be added using the three sets of true 4V preamp outputs with front, rear, and subwoofer control.
The i509-WRA-JL includes an iDatalink Maestro module to allow select factory features like voice- activated media player, bluetooth technology, and steering wheel controls to be retained and vehicle information displayed on the screen. The iDatalink can also integrate with the Jeep diagnostic port so select vehicle information like tire pressure, battery voltage, door status, engine codes, and user-customizable gauges can be monitored on the display.
Whether commuting or off-roading, the i509-WRA-JL includes two camera inputs to add additional front, side, or rearview cameras (sold separately) and make blind spots a distant memory. The factory rearview camera and dynamic guidelines are retained.
Take driving safety even further by connecting your i509-WRA-JL with the DVR-C320R Premium 1080P Front and Rear Dash Camera with built-in drive assist (sold separately). View real-time and recorded drives in high definition on your i509-WRA-JL, plus receive drive assist features that help get you to your destination.
Features
9-inch HD Anti-Glare Display with Jeep Specific Trim Bezel
Weather-Resistant (Rated IP53)
Plug-and-Play Installation
Jeep® Specific Tuning
Hi-Res Audio Playback (96kHz / 24bit)
Wireless Hi-Res Audio (requires LDAC compatible device)
Hi-Res music streaming with TIDAL (A TIDAL subscription is required and sold separately; Alpine Head Unit must be tethered to a mobile or smartphone hotspot; Data rates may apply)
Apple Carplay® (Wired & Wireless)
Android Auto™ (Wired & Wireless)
The Google Assistant is Available on Android Auto™
Bluetooth® Hands-Free
SiriusXM-Ready® (compatible with SXV300 (G2) add-on tuner, sold separately; SiriusXM subscription required)
Built-in HD Radio®
Retain Factory Media Controls and Vehicle Info with the included iDatalink Maestro module
Retain Factory Amplifier with KCX-F200INT (sold separately)
Alpine DVR-C320R Dash Cam Compatible (sold separately)
Media Xpander®
Specifications
Screen Resolution: WXGA 1280 x 720px (720p HD)
AUX Input: 1
HDMI Input: 1
HDMI Output: 1
Camera Inputs: 2 Direct (1 Rear input & 1 input that can be set as Front, Side, or Other)
Dash Cam Input: 1 (Works best with Alpine DVR-C320R - sold separately)
USB Inputs: 2 (1 data & 1 charge only port)
4V Pre-Outs: 3
Built-in Amplifier: 18W RMS x 4
EQ: 13-Band Parametric (per channel)
Time Correction: 6-Channel
DAC: 24 Bit
Crossover: High Pass / Low Pass
Audio Playback: AAC, APE, FLAC, MP3, WMA, WAV
Video Playback: AVC, FLV, H.263, H.264, MP4, MPEG-1, MPEG-2, MPEG-4, MKV, MOV
Alpine i509-WRA-JL Installation ManualAlpine i509-WRA-JL Tech SheetAlpine i509-WRA-JL Manual Part 1Alpine i509-WRA-JL Manual Part 2
Using expertise gleaned from over five decades of crafting premium car audio products and trickle-down engineering and design from the Ultra Hi-Res AlpineF#1Status system technologies, the Alpine Status system features exceptional tooling and rich build quality for the best possible sound reproduction. Each component was hand-picked from the highest-quality materials for the highest in-class audio performance, that when used as a complete system, can achieve 192kHz/24bit playback.
Drawing inspiration from the AlpineF#1Status system, the HDZ-653S features a unified carbon composite cone construction throughout the speaker components for a unified timbre identity. Alpine Proprietary Double Gathered Edge Surround technology gives the speakers ultra-low distortion and linear diaphragm movement that reproduces music true to the artist’s original intentions.
Custom developed for Hi-Res Audio Playback, the HDZ-653S has an ultra-wide bandwidth of 55Hz-40kHz which is perfectly suited for accurate reproduction of even the highest quality of studio recordings. Each speaker component is designed to cover a wider range of playback spectrum giving the tuner a wider range of adjustability.
The Alpine Status speaker line features two fitments for flexible installation options including a custom-fix model for custom applications and factory-fit models that were intentionally designed to fit into most factory speaker holes without custom work. The HDZ-653S is a custom-fit model that includes a 6.5- inch Mid-Bass driver, a 3.5-inch Midrange driver, and 1.25-inch High-Range driver.
The Alpine Status System is sold separately and can be used to build a custom sound system. Three sets of true 4V preamp outputs are included to add additional amplifiers if more power is needed. For best results, install the complete Alpine Status system together as a full system to achieve the highest in-class audio performance only second to the Ultra High-Resolution AlpineF#1System.
Features
Hi-Res Audio Playback (192kHz/24Bit) w/full Alpine Status system
Carbon Composite Diaphragm Material
Alpine Proprietary Double Gathered Edge Surround
6.5” Mid-Bass Driver (16.5cm)
3.5" Midrange Driver (8.5cm)
1.25” High Range Driver (3.2cm)
Specifications
100W RMS
300W Peak Power Handling
Frequency response: 55Hz – 40kHz
Sensitivity: 88dB
Sold by the Pair
Alpine HDZ-653S Manual
Using expertise gleaned from over five decades of crafting premium car audio products and trickle-down engineering and design from the Ultra Hi-Res AlpineF#1Status system technologies, the Alpine Status system features exceptional tooling and rich build quality for the best possible sound reproduction. Each component was hand-picked from the highest-quality materials for the highest in-class audio performance, that when used as a complete system, can achieve 192kHz/24bit playback.
Drawing inspiration from the AlpineF#1Status system, the HDZ-653 features a unified carbon composite cone construction throughout the speaker components for a unified timbre identity. Alpine Proprietary Double Gathered Edge Surround technology gives the speakers ultra-low distortion and linear diaphragm movement that reproduces music true to the artist’s original intentions.
Custom developed for Hi-Res Audio Playback, the HDZ-653 has an ultra-wide bandwidth of 55Hz-40kHz which is perfectly suited for accurate reproduction of even the highest quality of studio recordings. Each speaker component is designed to cover a wider range of playback spectrum giving the tuner a wider range of adjustability.
The Alpine Status speaker line features two fitments for flexible installation options including a custom-fix model for custom applications and factory-fit models that were intentionally designed to fit into most factory speaker holes without custom work. The HDZ-653 is a custom-fit model that includes a 6.5- inch Mid-Bass driver, a 3.5-inch Midrange driver, and 1.25-inch High-Range driver.
The Alpine Status System is sold separately and can be used to build a custom sound system. Three sets of true 4V preamp outputs are included to add additional amplifiers if more power is needed. For best results, install the complete Alpine Status system together as a full system to achieve the highest in-class audio performance only second to the Ultra High-Resolution AlpineF#1System.
Features
Hi-Res Audio Playback (192kHz/24Bit) w/full Alpine Status system
Carbon Composite Diaphragm Material
Alpine Proprietary Double Gathered Edge Surround
6.5” Mid-Bass Driver (16.5cm)
3.5" Midrange Driver (8.5cm)
1.25” High Range Driver (3.2cm)
Specifications
100W RMS
300W Peak Power Handling
Frequency response: 55Hz – 40kHz
Sensitivity: 88dB
Sold by the Pair
Alpine HDZ-653 Manual
Using expertise gleaned from over five decades of crafting premium car audio products and trickle-down engineering and design from the Ultra Hi-Res AlpineF#1Status system technologies, the Alpine Status system features exceptional tooling and rich build quality for the best possible sound reproduction. Each component was hand-picked from the highest-quality materials for the highest in-class audio performance, that when used as a complete system, can achieve 192kHz/24bit playback.
Drawing inspiration from the AlpineF#1Status system, the HDZ-65CS features a unified carbon composite cone construction throughout the speaker components for a unified timbre identity. Alpine Proprietary Double Gathered Edge Surround technology gives the speakers ultra-low distortion and linear diaphragm movement that reproduces music true to the artist’s original intentions.
Custom developed for Hi-Res Audio Playback, the HDZ-65CS has an ultra-wide bandwidth of 55Hz-40kHz which is perfectly suited for accurate reproduction of even the highest quality of studio recordings. Each speaker component is designed to cover a wider range of playback spectrum giving the tuner a wider range of adjustability.
The Alpine Status speaker line features two fitments for flexible installation options including a custom-fix model for custom applications and factory-fit models that were intentionally designed to fit into most factory speaker holes without custom work. The HDZ-65CS is a factory-fit model that includes a 6.5-inch mid-bass driver and a 1-inch coaxial high-range driver.
The Alpine Status System is sold separately and can be used to build a custom sound system. Three sets of true 4V preamp outputs are included to add additional amplifiers if more power is needed. For best results, install the complete Alpine Status system together as a full system to achieve the highest in-class audio performance only second to the Ultra High-Resolution AlpineF#1System.
Features
Hi-Res Audio Playback (192kHz/24Bit) w/full Alpine Status system
Carbon Composite Diaphragm Material
Alpine Proprietary Double Gathered Edge Surround
6.5” Mid-Bass Driver (16.5cm)
1.25” High Range Driver (3.2cm)
Specifications
100W RMS
300W Peak Power Handling
Frequency response: 55Hz – 40kHz
Sensitivity: 88dB
Sold by the Pair
Alpine HDZ-65CS Manual
Using expertise gleaned from over five decades of crafting premium car audio products and trickle-down engineering and design from the Ultra Hi-Res AlpineF#1Status system technologies, the Alpine Status system features exceptional tooling and rich build quality for the best possible sound reproduction. Each component was hand-picked from the highest-quality materials for the highest in-class audio performance, that when used as a complete system, can achieve 192kHz/24bit playback.
Drawing inspiration from the AlpineF#1Status system, the HDZ-65C features a unified carbon composite cone construction throughout the speaker components for a unified timbre identity. Alpine Proprietary Double Gathered Edge Surround technology gives the speakers ultra-low distortion and linear diaphragm movement that reproduces music true to the artist’s original intentions.
Custom developed for Hi-Res Audio Playback, the HDZ-65C has an ultra-wide bandwidth of 55Hz-40kHz which is perfectly suited for accurate reproduction of even the highest quality of studio recordings. Each speaker component is designed to cover a wider range of playback spectrum giving the tuner a wider range of adjustability.
The Alpine Status speaker line features two fitments for flexible installation options including a custom-fix model for custom applications and factory-fit models that were intentionally designed to fit into most factory speaker holes without custom work. The HDZ-65C is a factory-fit model that includes a 6.5-inch mid-bass driver and a 1-inch coaxial high-range driver.
The Alpine Status System is soldseparately and can be used to build acustom sound system. Three sets of true4V preamp outputs are included to add needed. For best results, install the additional amplifiers if more power iscomplete Alpine Status system togetheras a full system to achieve the highestin-class audio performance only second to the Ultra Hi-Resolution AlpineF#1System.
Features
Hi-Res Audio Playback (192kHz/24Bit) w/full Alpine Status system
Carbon Composite Diaphragm Material
Alpine Proprietary Double Gathered Edge Surround
6.5” Mid-Bass Driver (16.5cm)
1.25” High Range Driver (3.2cm)
Specifications
100W RMS
300W Peak Power Handling
Frequency response: 55Hz – 40kHz
Sensitivity: 88dB
Sold by the Pair
Alpine HDZ-65C Manual
Using expertise gleaned from over five decades of crafting premium car audio products and trickle-down engineering and design from the Ultra Hi-Res AlpineF#1Status system technologies, the Alpine Status system features exceptional tooling and rich build quality for the best possible sound reproduction. Each component was hand-picked from the highest- quality materials for the highest in-class audio performance, that when used as a complete system, can achieve 192kHz/24bit playback.
Drawing inspiration from the AlpineF#1Status system, the HDZ-65 features a unified carbon composite cone construction throughout the speaker components for a unified timbre identity. Alpine Proprietary Double Gathered Edge Surround technology gives the speakers ultra-low distortion and linear diaphragm movement that reproduces music true to the artist’s original intentions.
Custom developed for Hi-Res Audio Playback, the HDZ-65 has an ultra-wide bandwidth of 55Hz-40kHz which is perfectly suited for accurate reproduction of even the highest quality of studio recordings. Each speaker component is designed to cover a wider range of playback spectrum giving the tuner a wider range of adjustability.
The Alpine Status speaker line features two fitments for flexible installation options including a custom-fix model for custom applications and factory-fit models that were intentionally designed to fit into most factory speaker holes without custom work. The HDZ-65 is a factory-fit model that includes a 6.5-inch mid-bass driver and a 1-inch coaxial high-range driver.
The Alpine Status System is sold separately and can be used to build a custom sound system. Three sets of true 4V preamp outputs are included to add additional amplifiers if more power is needed. For best results, install the complete Alpine Status system together as a full system to achieve the highest in-class audio performance only second to the Ultra High-Resolution AlpineF#1System.
Features
Hi-Res Audio Playback (192kHz/24Bit) w/full Alpine Status system
Carbon Composite Diaphragm Material
Alpine Proprietary Double Gathered Edge Surround
6.5” Mid-Bass Driver (16.5cm)
1” Coaxial Tweeter (2.5cm)
Specifications
100W RMS
300W Peak Power Handling
Frequency response: 55Hz – 40kHz
Sensitivity: 88dB
Sold by the Pair
Alpine HDZ-65 Manual
The R-A90S has a unique staggered power channel layout that has double the power on the last two channels. When looking to power a dual subwoofer configuration, the R-A90S’s 5th and 6th channels can be bridged to provide up to 500-watts at 4Ω. The R-A90S is matched in power and performance for the Dual 10-inch Alpine Halo S-Series Preloaded Subwoofer Enclosures with ProLink™.
Thanks to the unique staggered power channel layout, the R-A90S can host different levels of power on each channel, compared to traditional, multi-channel amplifiers. This allows the R-A90S to grow with you as it can effectively function as both a 3-way active amplifier and a 5-channel amplifier by delivering the power you need to the channels where you need it the most.
Hear the subtle details you’ve been missing in your music. The R-A90S maintains an extremely low phase shift throughout the music spectrum, which minimizes audible imperfections in your music and allows your music to stay faithful to the original recording. With a hi-resolution frequency response, the R- A90S can reproduce sound with incredible accuracy that stays true to the artist’s intention.
Using custom Alpine internal components originally launched in Alpine’s premium X-Series amplifiers, the R-A90S has dual post-filter feedback loops that correct signal distortion by making the output as close as possible to the original input for accurate sound reproduction.
For the best possible sound experience, use the built-in bandpass, high pass, or low pass filter to individually power each component in your sound system and assign frequency bands for accurate and reliable sound reproduction.
The R-A90S has input capability to add an optional RUX-KNOB.2 Remote Bass Control Knob (sold separately). The remote bass knob controls the bass in your subwoofer by adjusting the gain on your amplifier for quick bass adjustments when needed.
Alpine’s R-Series line of speakers, subwoofers, and amplifiers have a heritage of sound quality that can be heard from a block away. The R-A90S is tuned to emphasize the characteristics of the R- Series speakers and subwoofers for a legendary R-Series experience.
Features
6-Channel Amp with 5-Channel Power– With double the power on the last two channels, the R-A90S’s 5th and 6th channels can be bridged to provide up to 500-watts at 4Ω to a subwoofer system such as a pair of S-SB12Vs.
An Amp that Grows with You – When you’re ready to upgrade your Alpine system, use the R-A90S to amplify a 3-way active system with enough mid-bass power to create the up-front bass impact you crave.
Accurate Sound Reproduction – With incredibly low phase shift and hi-resolution frequency response, the R-A90S can reproduce sound with incredible accuracy that stays true to the artist’s intention.
Specifications
Dimensions: 12.75" x 10.75" x 2"
Hi-Resolution Audio Compliant (40k Hz)
Alpine’s Class D Amplifier Circuit
75W x 4 + 150W x 2 (4Ω, 14.4V, < 1% THD +N)
100W x 4 + 250W x 2 (2Ω, 14.4V, < 1% THD +N)
Bridged: 200W x 2 + 500W x 1 (4Ω, 14.4V, < 1% THD +N)
S/N > 85dB (ref. 1W into 4Ω)
THD + N < 0.03% (ref. 10W into 4Ω)
Frequency response: 10-45kHz (0/-3dB)
Damping factor > 500
CTA-2006
Alpine R-A90S Manual
The R-Series amplifiers utilize Alpine’s advanced amplifier platform that takes the classic Class-D amplifier circuit and adds dual post-filter feedback loops for unmatched accuracy and control. This technology., originally launched in the premium X-Series amplifiers,, produces efficient power with enhanced dynamic range, qualifying the R-Series amplifiers to be Hi-Resolution Audio compliant.
This new technology minimizes audible imperfections like excessive phase shift and internal noise which can deteriorate sound quality. With an incredibly low phase shift of 46°, the R-A60F 4-channel amplifier delivers accurate imaging compared to well over 100° of phase shift by a competitive amplifier model. This superior phase curve ensures a proper sound stage among the singers and instruments.
R-Series amplifiers have a built-in bandpass filter which lets you design an active speaker set-up without a separate processor. Improve the sound quality of component speakers by ditching your passive network. Avoid added phase shifts and power losses by individually powering each component and assigning your own frequency bands for the incredible sound you’re looking for.
The “R” line of speakers and subwoofers have a heritage of sound quality you can hear from a block away, and the newly added R-Series amplifiers are no exception. Aside from their best-in-class performance, these amplifiers are tuned to emphasize the characteristics of the R-Series speakers and subwoofers, giving you that legendary R-Series experience.
Specifications
Alpine’s Class D Amplifier Circuit
CTA-2006-B Power Rating: 500W RMS x 1 (4omh, 14.4V, < 1% THD+N); 750W RMS x 1 (2ohm, 14.4V, < 1% THD+N)
S/N ratio: > 85dB (ref. 1W into 4ohm)
THD+N < 0.02% (ref. 1W into 4ohm)
Frequency Response: 10Hz to 400 Hz (+/- 3dB)
Damping Factor: > 1500
Remote bass knob compatible (requires RUX-KNOB.2, sold separately)
Alpine R-A75M Manual
