10-Inch Subwoofer Drivers that are Suitable for Enclosures with a Mounting Depth under 10-Inches
These 10" drivers are best recommended for subwoofer enclosures with a sub mounting clearance of 10". If your 10-inch sub box has a depth of less than ten-inches then not all of these drivers will fit in your box.
10-Inch 500-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC This L7 series 10" square woofer by Kicker hosts a heavy-duty motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. On board the chassis of this 500W driver you will find dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, ribbed santoprene surround with blue stitching and a UniPlate™ back plate and pole piece, plus perimeter venting for thermal heat management. The Kicker 45L7R102 and 45L7R104 square subwoofers are rated for 500W of RMS amplified power. Specifications SIZE [in, cm]: 10, 25 IMPEDANCE [Ohms]: 2 or 4 DVC Recommended Amplifier Power (watts RMS) 500 Peak Power (watts, per ANSI/CTA-2031-A) 1000 SENSITIVITY [dB 1w/1m]: 85.9 MOUNTING DEPTH [in, cm]: 6 1/8, 15.7 MOUNTING DIAMETER [in, cm]: 9 5/16, 23.7 MIN SEALED BOX VOL [cu. ft, L]: .66, 18.7 MAX SEALED BOX VOL [cu. ft, L]: 1, 28.3 MIN VENTED BOX VOL [cu. ft, L]: 1.25, 35.4 MAX VENTED BOX VOL [cu. ft, L]: 2.25, 63.7 Kicker L7R Subwoofer Manual
$219.99
W3-Series 10-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC The JL Audio 10W3v3 subwoofer driver has excellent power handling, reasonable enclosure requirements, and a long excursion for its chassis to deliver excellent bass reproduction in 500W RMS power applications. JL Audio technologies and proprietary assembly designs in the 10W3v3-2 and 10W3v3-4 subwoofers enhance linearity and reliable performance results. The JL Audio 10W3v3 is best used with an amplifier in the 150W - 500W RMS range and is optimized to operate in a compact 0.625 cu. ft. (17.7 l) sealed enclosure, or a 1.25 cu. ft. (35.4 l) ported enclosure. General Specifications Continuous Power Handling 500W RMS Recommended Amplifier Power 150- 500W RMS Nominal Impedance 2Ω JL Audio 10W3v3 Manual
$399.99
