10" Drivers Under 9"

10-Inch 500-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC This L7 series 10" square woofer by Kicker hosts a heavy-duty motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. On board the chassis of this 500W driver you will find dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, ribbed santoprene surround with blue stitching and a UniPlate™ back plate and pole piece, plus perimeter venting for thermal heat management. The Kicker 45L7R102 and 45L7R104 square subwoofers are rated for 500W of RMS amplified power. Specifications SIZE [in, cm]: 10, 25 IMPEDANCE [Ohms]: 2 or 4 DVC Recommended Amplifier Power (watts RMS) 500 Peak Power (watts, per ANSI/CTA-2031-A) 1000 SENSITIVITY [dB 1w/1m]: 85.9 MOUNTING DEPTH [in, cm]: 6 1/8, 15.7 MOUNTING DIAMETER [in, cm]: 9 5/16, 23.7 MIN SEALED BOX VOL [cu. ft, L]: .66, 18.7 MAX SEALED BOX VOL [cu. ft, L]: 1, 28.3 MIN VENTED BOX VOL [cu. ft, L]: 1.25, 35.4 MAX VENTED BOX VOL [cu. ft, L]: 2.25, 63.7 Kicker L7R Subwoofer Manual

Read more less

Alpine S2-Series 600-Watt 10-Inch Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil With an impressive power handling of 600W RMS and a peak power handling of 1800W, the Next-Gen 10” S-Series Subwoofers deliver outstanding performance value. Boasting a wide frequency response range of 25Hz to 215Hz and a sensitivity of 85dB (1W/1m), these subs ensure powerful and accurate bass reproduction across a diverse range of music genres. Featuring the lightweight yet sturdy combination of carbon fiber and polypropylene, the Next-Gen S-Series Subwoofer cone delivers deep, low-distortion bass that enhances the depth and richness of your music. The Next-Generation S-Series Subwoofers contain Alpine's High Amplitude Multi-Roll (H.A.M.R.) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 15mm of one-way excursion that creates incredible accuracy from the subwoofer. A Dual Voice Coil (DVC) with easy configuration jumpers make installing the S-Series subwoofers a breeze. A new twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. Maximize the potential of your S-Series subwoofers with Alpine's perfectly power-matched S-Series amps. Power a single S2-W10DVC subwoofer effortlessly with the 600W S2-A60M mono amplifier, or for an even bigger impact, pair two or more S2-W10DVC subs with the powerful 1200W S2- A120M amp to ensure optimal sound quality and performance. Features Dual Voice Coil Subwoofers with Configuration Jumpers  Carbon Fiber / Poly Propylene Cone Poly Propylene / Ceramic Dust Cap High-Grade Strontium Ferrite Magnets Twist-Lock Grille Mount System   High-Amplitude Multi-Roll (H.A.M.R.) Surround Push-Type Speaker Terminals (Up to 8AWG Wire Size) Specifications Power Handling: 600W RMS / 1800W Peak Nominal Impedance: 4Ω Frequency Response: 25Hz - 215Hz Sensitivity (1W/1M): 84.9dB Voice Coil: 2.6" X-Max (1-Way): 15mm Magnet Weight: 64oz

Read more less
