10" Drivers Under 9"

10-Inch Subwoofer Drivers that are Suitable for Enclosures with a Mounting Depth under 9-Inches

10-Inch Subwoofer Drivers that are Suitable for Enclosures with a Mounting Depth under 9-Inches

Please use the filter bar to narrow down your search.

These 10" drivers are best recommended for subwoofer enclosures with a sub mounting clearance of 9". If your 10-inch sub box has a depth of less than nine-inches then not all of these drivers will fit in your box.

8 products

  • Sale -$10.01 Alpine S-W10D : 10" 600W Subwoofer Driver, 2Ω or 4Ω DVC

    Alpine S-W10D : 10" 600W Subwoofer Driver, 2Ω or 4Ω DVC

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    Alpine S-Series 600-Watt 10-Inch Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil Along with the new 8” woofer, the 10” and 12” S-Series subwoofers have been re-designed from the ground up. The mounting depth of the 10” and 12” subwoofers are almost 1” more shallow than previous models at just over 4.5” for the 10” models and just over 5” for the 12” models, allowing them to fit into a wide variety of installation applications. Specifications 10" DVC High Performance Subwoofer Power Handling: 600W RMS/1800W Peak Push-type Insert Terminals with DVC jumper system Concealed Mount Gasket/Grille* System (*Grille sold separately) Frequency Response: 28Hz-200Hz Mounting Depth 4-11/16” Alpine S-W10D2, S-W10D4 Manual

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    $190.00$179.99

  • 500W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 45L7R10 500W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 45L7R10 side view.

    Kicker 45L7R10 : 500W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    10-Inch 500-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC This L7 series 10" square woofer by Kicker hosts a heavy-duty motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. On board the chassis of this 500W driver you will find dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, ribbed santoprene surround with blue stitching and a UniPlate™ back plate and pole piece, plus perimeter venting for thermal heat management. The Kicker 45L7R102 and 45L7R104 square subwoofers are rated for 500W of RMS amplified power. Specifications SIZE [in, cm]: 10, 25 IMPEDANCE [Ohms]: 2 or 4 DVC Recommended Amplifier Power (watts RMS) 500 Peak Power (watts, per ANSI/CTA-2031-A) 1000 SENSITIVITY [dB 1w/1m]: 85.9 MOUNTING DEPTH [in, cm]: 6 1/8, 15.7 MOUNTING DIAMETER [in, cm]: 9 5/16, 23.7 MIN SEALED BOX VOL [cu. ft, L]: .66, 18.7 MAX SEALED BOX VOL [cu. ft, L]: 1, 28.3 MIN VENTED BOX VOL [cu. ft, L]: 1.25, 35.4 MAX VENTED BOX VOL [cu. ft, L]: 2.25, 63.7 Kicker L7R Subwoofer Manual

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    $199.99

  • 600W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 44CVX10 600W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 44CVX10, front side view.

    Kicker 44CVX10 : 600W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    10-Inch 600-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC The CompVX 10" subwoofer driver by Kicker is designed with high-temp dual voice coils that deliver up to 600W of amplified RMS power. A solid pole-piece provides more mass to disperse heat. A thick polypropylene cone complements the SoloKon™ cone reinforcement system and the oversized suspension system. The Kicker 44CVX102 and 44CVX104 10 inch subwoofers have a UniPlate™ extended pole piece & backplate for superior heat dissipation and satin nickel spring-loaded speaker terminals. Specifications Size (IN.,CM) 10, 25 Impedance (OHMS) 2 or 4 DVC Recommended Amplifier Power (watts RMS) 600 Peak Power (watts, per ANSI/CTA-2031-A) 1200 Sensitivity (dB 1w/1m) 85.7 Frequency Response (Hz) 24-500 Mounting Depth (in, cm) 5 15/16, 15.1 Mounting Cutout (in, cm) 9 3/16, 23.3 Min Sealed Box Vol (cu. ft, L) .8, 22.7 Max Sealed Box Vol (cu. ft, L) 3.0, 85.0 Min Vented Box Vol (cu. ft, L) 1.25, 35.4 Max Vented Box Vol (cu. ft, L) 1.75, 49.6 Kicker CompVX Subwoofer Manual

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    $199.99

  • 750W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 42CWQ10 750W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 42CWQ10, side view.

    Kicker 42CWQ10 : 750W 10" Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    10-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC The 10" CompQ audiophile competition subwoofer driver by Kicker is the pinnacle of Kicker's round speaker line, with nearly identical construction and performance as the L7 Series square subs. The Kicker 42CWQ102 and 42CWQ104 have a 750W RMS power handling and extremely accurate bass reproduction featuring a ribbed Santoprene® surround and a BlueLace™ large-diameter progressive roll spider for extreme flexibility at 750-Watts of Continuous Power. The CompQ 10-Inch sub works best with a sealed or ported enclosure with 750 watts of recommended power. See below for more details. Specifications Rated Impedance [Ω] 2 or 4 DVC Fs [Hz 38 Sensitivity [1W, 1m] 85.7 Qts 0.437 Qms 8.916 Qes 0.46 Re [Ω] 6.52 Vas [ft³, L] .59, 16.75 Recommended Amplifier Power (watts RMS) 700 Outer Frame Dimension [in, cm] 10 11/16, 27.2 Mounting Depth [in, cm] 6 3/8, 16.2 Mounting Cutout [in, cm] 9 3/16, 23.4 Frequency Response [Hz] 24 – 100 Kicker CompQ Subwoofer Manual

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    $249.99

  • 750W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 41L710 750W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil : Kicker 41L710, rear view.

    Kicker 41L710 : 750W 10" Square Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    10-Inch 750-Watt Square Subwoofer, 2-Ohm or 4-Ohm DVC The 10" L7 series automotive subwoofer driver by Kicker stands alone as the most unique subwoofer on the market, with a cone shape that is exclusively designed to produce more output. The Kicker 41L7102 and the 41L7104 subwoofers again reach new heights in technology and design. A 2015 CES® Innovation Award winner, Kicker L7 branded itself as the crown jewel among competition subwoofers. For more than a decade, Kicker’s square woofer earned numerous awards including several CES accolades, and the 2015 version once again makes distinctive improvements on its way to another honor. These 10-Inch L7 square subwoofers deliver 20% more surface area than a comparable circular 10" sub. A bigger cone means more air gets dispersed for each excursion cycle thus producing more sound! Kicker included oversized magnets and an aluminum voice coil, to help keep heat to a minimum. The Uniplate™ is a KICKER original design, combining the pole piece and back plate as a single, seamless unit to pull damaging heat away from the sub. Kicker's patented Santoprene™ corners allow your KICKER subs to play smooth, distortion-free music at any volume level. Kicker's Blue Lace™ spider and ribbed surround work together to give you the best suspension for your L7. You get unparalleled accuracy and volume to feel every note - every time. Specifications Rated Impedance [Ω] 2 or 4 DVC Fs [Hz] 37.5 Sensitivity [1W, 1m] 85.9 Qts 0.507 Qms 9.791 Qes 0.535 Re [Ω] 7.9 Vas [ft³, L] 1, 28.32 Recommended Amplifier Power (watts RMS) 750 Outer Frame Dimension [in, cm] 10 11/16, 27.2 Mounting Depth [in, cm] 6 7/8, 17.5 Mounting Cutout [in, cm] 9 5/16, 23.7 Frequency Response [Hz] 24 - 100 Minimum Sealed Volume ft3 (L) .8 (22.65) Maximum Sealed Volume ft3 (L) 1.25 (35.4) Kicker L7 Subwoofer Manual

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    $299.99

  • JL Audio 10W3v3 : 10-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC, front side view. JL Audio 10W3v3 : 10-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC

    JL Audio 10W3v3 : 500W 10" Subwoofer Driver, 2Ω or 4Ω Single Voice Coil

    2 Available for pickup

    W3-Series 10-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC The JL Audio 10W3v3 subwoofer driver has excellent power handling, reasonable enclosure requirements, and a long excursion for its chassis to deliver excellent bass reproduction in 500W RMS power applications. JL Audio technologies and proprietary assembly designs in the 10W3v3-2 and 10W3v3-4 subwoofers enhance linearity and reliable performance results. The JL Audio 10W3v3 is best used with an amplifier in the 150W - 500W RMS range and is optimized to operate in a compact 0.625 cu. ft. (17.7  l) sealed enclosure, or a 1.25 cu. ft. (35.4 l) ported enclosure. General Specifications Continuous Power Handling 500W RMS Recommended Amplifier Power 150- 500W RMS Nominal Impedance 2Ω JL Audio 10W3v3 Manual

    2 Available for pickup

    $359.99

  • 600W 10" Subwoofer Driver, 4Ω Dual Voice Coil : JL Audio 10W6v3, shown with grille. JL Audio 10W6v3 : 10-inch 600-Watt Subwoofer Driver, 4-Ohm DVC

    JL Audio 10W6v3 : 600W 10" Subwoofer Driver, 4Ω Dual Voice Coil

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    W6-Series 10-Inch 600-Watt Subwoofer Driver, 4-Ohm DVC The 10W6v3 subwoofer driver offers several technologies similar to JL Audio's W7AE top line of subwoofers to provide powerful advantages in motor linearity and suspension behavior. This 10" automotive sub has a very efficient cooling circuit to deliver reduced distortion and outstanding dynamic balance. This 10" W6v3 driver is best used with an amplifier in the 200W - 600W RMS range and is optimized to operate in a sealed enclosure with only 0.55 cu. ft. (15.6 l) of air space, or a 0.75 cu. ft. (21.2 l) ported enclosure. The JL Audio 10W6V3-D4 subwoofer driver comes with Dual 4Ω voice coils that allow the 10W6v3 to be installed in a 2Ω or 8Ω configuration. General Specifications Continuous Power Handling 600W RMS Recommended Amplifier Power 200 - 600W RMS Nominal Impedance Dual 4Ω JL Audio 10W6v3 Manual

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    $799.99

  • JL Audio 10W7AE : 10-Inch 750-Watt Subwoofer Driver, 3-Ohm SVC, 10th Anniversary Edition JL Audio 10W7AE : 10-Inch 750-Watt Subwoofer Driver, 3-Ohm SVC, 10th Anniversary Edition, side view.

    JL Audio 10W7AE : 750W 10" Subwoofer Driver, 3Ω Single Voice Coil

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    W7-Series 10-Inch 750-Watt Subwoofer Driver, 3-Ohm SVC The audiophile 10W7AE subwoofer driver delivers amazing excursion capability while maintaining undeniable tracking accuracy under power in the low end sound spectrum. This 10" W7AE sub is best used with an amplifier in the 300W - 750W RMS range and is optimized to operate in a 1.25 cu. ft. (35.4 l) sealed enclosure, or a 1.5 cu. ft. (42.5 l) ported enclosure. The JL Audio 10W7AE-3 Anniversary Edition subwoofer driver is the 10th Anniversary of the launch of the JL W7 subwoofers. They are identical to the original W7's drivers but they are distinguished by the following cosmetic differences: Satin-Black Powdercoated Baskets Bright Anodized Surround Clamp Ring Anniversary Edition Cone Badge Anniversary Edition Terminal Label  General Specifications Continuous Power Handling 750W RMS Recommended Amplifier Power 300W - 750W RMS Nominal Impedance 3Ω JL Audio 10W7AE Manual

    Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!

    $999.99
