W0-Series 12-Inch 300-Watt Subwoofer Driver, 4-Ohm SVC
The 12" W0v3 subwoofer driver by JL Audio delivers excellent efficiency, excursion capability and linearity. This 12" subwoofer comes with a price point under $150.00 while supporting a beefy 2 in. diameter voice coil and JL's patented Elevated Frame Cooling design for enhanced power handling and reliability.
The JL Audio 12W0v3-4 sub is best used with amplifier power in the 75W - 300W range and is optimized to operate in a moderately sized 1.375 cu. ft. (38.9 l) sealed enclosure, or a 1.75 cu. ft. (49.6 l) ported enclosure.
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
4Ω
JL Audio 12W0v3 Manual
W1-Series 12-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The 12" W1v3 automotive subwoofer driver by JL Audio is a lightweight 12-inch driver with excellent performance capabilities at a moderate 300-Watts. The design of the chassis allows an average mounting depth with no pole-vent on the back side of the magnet so the rear of the motor structure can be placed directly against an enclosure boundary. This 12" subwoofer can reproduce sub-bass with shocking extension and quality.
The JL Audio 12W1v3-2 and 12W1v3-4 subwoofers are best used with an amplifier in the 75W - 300W range and is optimized to operate in a compact 1.10 cu. ft. (31.5 l) sealed enclosure.
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
2Ω
JL Audio 12W1v3 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch 500-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 8" L7 automotive square subwoofers by Kicker stand alone as the most unique 8-Inch subwoofer on the market, with a cone shape that is exclusively designed to produce more output.
The Kicker 41L78 subwoofer again reaches new heights in technology and design. A winner of the 2015 CES® Innovation Award solidified the L7 series sub as the crown jewel among competition subwoofers. For more than a decade, KICKER’s square woofer earned numerous awards including several CES accolades, and the 2015 version once again makes distinctive improvements on its way to another honor.
The Kicker 41L782 and 41L784 square subwoofers deliver 20% more surface area than a comparable 8" circular sub. A bigger cone disperses more air for each excursion thus producing more sound! Oversized magnets and an aluminum voice coil allow maximum performance while remaining cool in operation. The Uniplate™ is a KICKER original, combining the pole piece and back plate as a single, seamless unit to pull damaging heat away from the sub.
Kicker's patented Santoprene™ corners allow the L7 subs to play smooth, distortion-free music at any volume level. Kicker's Blue Lace™ spider and ribbed surround work together to give you the best suspension. You get unparalleled accuracy and volume to feel every note - every time.
Specifications
Rated Impedance [Ω]
2 DVC
Fs [Hz]
47.2
Sensitivity [1W, 1m]
82.4
Qts
0.735
Qms
8.828
Qes
0.802
Re [Ω]
6.6
Vas [ft³, L]
.322, 9.127
Recommended Amplifier Power (watts RMS)
500
Outer Frame Dimension [in, cm]
8 13/16, 22.4
Mounting Depth [in, cm]
5 7/16, 13.8
Mounting Cutout [in, cm]
7 1/4, 18.4
Frequency Response [Hz]
28 - 100
Kicker L7 Subwoofer Manual
10-Inch 400-Watt Subwoofer Driver, 4-Ohm DVC
The 43CWR10 10" subwoofer by Kicker has an advanced suspension system that includes a ribbed polypropylene surround and a large-diameter spider for linear movement, and a distortion-free sound. Bigger magnets, a thicker cone and an improved suspension system help make this 10-Inch 400W CompR sub to be a workhorse of a driver.The Kicker 43CWR104 12" sub work best with a sealed or ported enclosure and 400 watts of recommended power.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
4 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
84.6
MOUNTING DEPTH [in, cm]:
5-1/4, 13.3
MOUNTING DIAMETER [in, cm]:
9-1/8, 23.1
MIN SEALED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX SEALED BOX VOL [cu. ft, L]:
1.25, 35.4
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Kicker CompR Subwoofer Manual
12-Inch 300-Watt Subwoofer Driver, 4-Ohm SVC or 4-Ohm DVC
This CompC 12" sub driver from Kicker has a thick stamped steel basket that holds an injection-molded polypropylene cone with stabilizing ribs in the surround.
The 44CWCS124 and 44CWCD124 12-Inch subs are available in a 4Ω Single Voice or 4Ω Dual Voice coil design with spring loaded speaker terminals. These CompC drivers are rated for 300W RMS of amplified power.
Specifications
Size (IN.,CM)
12, 30
Impedance (OHMS)
4 SVC or 4 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
600
Sensitivity (dB 1w/1m)
88.3
Frequency Response (Hz)
27-500
Mounting Depth (in, cm)
5-3/8, 13.6
Mounting Cutout (in, cm)
11, 27.9
Min Sealed Box Vol (cu. ft, L)
1.25, 35.4
Max Sealed Box Vol (cu. ft, L)
3.5, 99.1
Min Vented Box Vol (cu. ft, L)
1.75, 49.6
Max Vented Box Vol (cu. ft, L)
2.25, 63.7
Kicker CompC Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 400-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR10 10" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.The Kicker 48CWR102 and 48CWR104 12" subs work best with a sealed or ported enclosure and 400 watts of recommended power.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
84.6
MOUNTING DEPTH [in, cm]:
5-1/4, 13.3
MOUNTING DIAMETER [in, cm]:
9-1/8, 23.1
MIN SEALED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX SEALED BOX VOL [cu. ft, L]:
1.25, 35.4
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Kicker CompR Subwoofer Manual
