Dual 2Ω

Alpine S2-Series 600-Watt 10-Inch Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil With an impressive power handling of 600W RMS and a peak power handling of 1800W, the Next-Gen 10” S-Series Subwoofers deliver outstanding performance value. Boasting a wide frequency response range of 25Hz to 215Hz and a sensitivity of 85dB (1W/1m), these subs ensure powerful and accurate bass reproduction across a diverse range of music genres. Featuring the lightweight yet sturdy combination of carbon fiber and polypropylene, the Next-Gen S-Series Subwoofer cone delivers deep, low-distortion bass that enhances the depth and richness of your music. The Next-Generation S-Series Subwoofers contain Alpine's High Amplitude Multi-Roll (H.A.M.R.) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 15mm of one-way excursion that creates incredible accuracy from the subwoofer. A Dual Voice Coil (DVC) with easy configuration jumpers make installing the S-Series subwoofers a breeze. A new twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. Maximize the potential of your S-Series subwoofers with Alpine's perfectly power-matched S-Series amps. Power a single S2-W10DVC subwoofer effortlessly with the 600W S2-A60M mono amplifier, or for an even bigger impact, pair two or more S2-W10DVC subs with the powerful 1200W S2- A120M amp to ensure optimal sound quality and performance. Features Dual Voice Coil Subwoofers with Configuration Jumpers  Carbon Fiber / Poly Propylene Cone Poly Propylene / Ceramic Dust Cap High-Grade Strontium Ferrite Magnets Twist-Lock Grille Mount System   High-Amplitude Multi-Roll (H.A.M.R.) Surround Push-Type Speaker Terminals (Up to 8AWG Wire Size) Specifications Power Handling: 600W RMS / 1800W Peak Nominal Impedance: 4Ω Frequency Response: 25Hz - 215Hz Sensitivity (1W/1M): 84.9dB Voice Coil: 2.6" X-Max (1-Way): 15mm Magnet Weight: 64oz

Read more less

10-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC The 10" CompQ audiophile competition subwoofer driver by Kicker is the pinnacle of Kicker's round speaker line, with nearly identical construction and performance as the L7 Series square subs. The Kicker 42CWQ102 and 42CWQ104 have a 750W RMS power handling and extremely accurate bass reproduction featuring a ribbed Santoprene® surround and a BlueLace™ large-diameter progressive roll spider for extreme flexibility at 750-Watts of Continuous Power. The CompQ 10-Inch sub works best with a sealed or ported enclosure with 750 watts of recommended power. See below for more details. Specifications Rated Impedance [Ω] 2 or 4 DVC Fs [Hz 38 Sensitivity [1W, 1m] 85.7 Qts 0.437 Qms 8.916 Qes 0.46 Re [Ω] 6.52 Vas [ft³, L] .59, 16.75 Recommended Amplifier Power (watts RMS) 700 Outer Frame Dimension [in, cm] 10 11/16, 27.2 Mounting Depth [in, cm] 6 3/8, 16.2 Mounting Cutout [in, cm] 9 3/16, 23.4 Frequency Response [Hz] 24 – 100 Kicker CompQ Subwoofer Manual

Read more less

10-Inch 500-Watt Square Subwoofer Driver, 2-Ohm or 4-Ohm DVC This L7 series 10" square woofer by Kicker hosts a heavy-duty motor structure that includes a large-diameter spider for less flex, longer life and superior accuracy. On board the chassis of this 500W driver you will find dual high-temp voice coils, an injection-molded polypropylene cone, SoloKon™ 360-degree back bracing, ribbed santoprene surround with blue stitching and a UniPlate™ back plate and pole piece, plus perimeter venting for thermal heat management. The Kicker 45L7R102 and 45L7R104 square subwoofers are rated for 500W of RMS amplified power. Specifications SIZE [in, cm]: 10, 25 IMPEDANCE [Ohms]: 2 or 4 DVC Recommended Amplifier Power (watts RMS) 500 Peak Power (watts, per ANSI/CTA-2031-A) 1000 SENSITIVITY [dB 1w/1m]: 85.9 MOUNTING DEPTH [in, cm]: 6 1/8, 15.7 MOUNTING DIAMETER [in, cm]: 9 5/16, 23.7 MIN SEALED BOX VOL [cu. ft, L]: .66, 18.7 MAX SEALED BOX VOL [cu. ft, L]: 1, 28.3 MIN VENTED BOX VOL [cu. ft, L]: 1.25, 35.4 MAX VENTED BOX VOL [cu. ft, L]: 2.25, 63.7 Kicker L7R Subwoofer Manual

Read more less
