A premium sound system for your Jeep Wrangler JK Unlimited is. The PSS-22WRA is a 1200-watt, 9-speaker sound system for 2011-2018 Jeep Wrangler JK Unlimited, providing excellent sound performance with the top on or off.
Caught with the top off in inclement weather? Not to worry. The PSS-22WRA is IP55 rated, so it can withstand rain and dust. The subwoofer uses rust resistant hardware and can handle water from off-roading adventures or a quick rinse down.
The PSS-22WRA’s subwoofer and amplifier don’t take up any usable space since they mount under the passenger’s seat for an easy bolt-in installation with simple wire routing. All necessary installation accessories are included.
The included T-harness gets the necessary audio signal connections from behind the Wrangler’s radio, making installation a breeze. The PSS-22WRA is compatible with any Alpine Restyle Jeep Wrangler dash system, the Jeep factory base radio, or other aftermarket radio.
Specifications
Direct fit weather resistant (IP55) speaker package for non-amplified 2011– 2018 4-door Jeep® Wrangler JK Unlimited
600W RMS System
SPV-65X-WRA 6.5-inch Convertible Component/Coax water resistant speaker kit
SBV-10-WRA 10-inch under passenger seat water resistant enclosed subwoofer
KTA-30FW – 75W X 4ch Water Resistant Amplifier
KTA-30MW – 300W Water Resistant Mono Amplifier
Plug & play sound system
Compatible with an Alpine Restyle In-Dash system, aftermarket head unit, or with the factory Jeep radio
Includes remote bass knob, vehicle specific harnesses and mounting brackets
Alpine PSS-22WRA Manual
Alpine 300-Watt Powered Speaker-System Upgrade with Built-in Subwoofer for Select 2018-2022 Jeep-Wrangler and Gladiator-JT Vehicles
Enjoy premium sound quality even with your JL’s top off! The PSS-23WRA is a 300 watt powered system upgrade featuring a powered subwoofer, amplifier, and tweeters for the 2018-Up Jeep Wrangler-Unlimited-JL and Gladiator-JT vehicles without the factory amplified system. The PSS-23WRA provides excellent sound performance whether the JL’s top is on or off.
The PWE-S8 subwoofer is engineered to load and disperse lower frequency sound into the passenger’s foot well area to maximize bass extension throughout the Jeep for great sound with the top on or off. Included with the subwoofer is a remote bass knob so you can control the bass level from the convenience of your dashboard. The Included 4-channel amplifier more than doubles the power over the factory system allowing you to enjoy your tunes with the top off.
The PWE-S8 Powered Subwoofer and KTP-445U Power Pack Amplifier don’t take up much since they mount under the passenger’s seat. The two products come pre-connected for easy, bolt-in installation with simple wire routing. Mounting brackets for the products are included as well.
The SPR-10TW Component Tweeters replace the factory tweeters on the top of the dash. These high performance tweeters add much needed high frequency response that is lacking in the factory Jeep JL systems. An EQ Ring improves the tweeter’s dispersion characteristics and delivers a wide, flat frequency response.
The included T-harness gets the necessary audio signal connections from behind the Wrangler’s radio, making installation a breeze. The PSS-23WRA is compatible with Alpine universal head units, the factory Jeep base radio, or other aftermarket radios.
Specifications
Direct fit for non-amplified 2018–Up 4-door Jeep Wrangler JL Unlimited
Direct fit for non-amplified 2019–Up 2-door Jeep Wrangler
Direct fit for non-amplified 2020–Up Jeep Gladiator JT
300 Watts RMS
Plug & Play Sound System
Compatible with aftermarket radio, or with factory Jeep Radio
Includes remote bass knob, vehicle specific harnesses and mounting bracket
Alpine PSS-23WRA Manual
Alpine 8-Inch 120-Watt Compact Powered Subwoofer-System for 2011-UP 4-Door Jeep-Wrangler Unlimited
The small, but powerful PWE-S8-WRA consists of an 8-inch powered subwoofer with a built-in 120 watt amp, a bracket designed to bolt the subwoofer under the Wrangler driver’s seat, a remote bass knob and Wrangler-specific wiring harnesses for plug-and-play connection to your aftermarket or factory in-dash system. The powered subwoofer measures just 13.5” L x 9” W x 3” D, so you can add low, punchy, accurate bass to your Jeep without taking up usable storage space.
Subwoofer controls like Phase, Gain, LP Crossover and Remote Sub Level are found on the side panel, or mount the remote bass knob on your dash and use it to easily make bass level adjustments.
Specifications
120 Watts bass upgrade for 2011-UP 4-door Jeep Wrangler*
Under driver seat plug & play system for improved bass/mid-bass performance
Works with an Alpine or aftermarket head unit, or with the factory Jeep radio
Includes powered 8" subwoofer, remote bass knob, harnesses and mounting brackets
Not compatible with the factory equipped subwoofer system
Alpine PWE-S8-WRA Manual
10-Inch 300-Watt 2-Ohm or 4-Ohm Subwoofer Enclosure for Select 2018-2023 Jeep Wrangler-Unlimited, Driver Side
Combining JL's advanced thin-line subwoofer technology with a form fitting enclosure design, these Stealthbox® systems deliver outstanding sub-bass performance in your 4-door Wrangler, without consuming excess cargo space.
Constructed from 100% fiberglass, each Stealthbox® houses a 10TW1 thin-line subwoofer and mounts solidly above each rear wheel well. A matching trim panel and sturdy steel-mesh grille are included, so you can carry plenty of gear without worrying about damage. Separate driver and passenger side Stealthbox® models are available, each with 2 or 4 ohm drivers.
The Hard Data: Contains one 10TW1 in a sealed enclosure with 300 watt power handling. Choose from 2 ohm or 4 ohm models, driver or passenger side. Each enclosure installs above one rear wheel well. Black steel mesh grille is included with each.
If vehicle is factory-equipped with Premium Audio, passenger side Stealthbox® installation requires removal of OEM “subwoofer” and purchase of interior trim parts from Jeep®.
Will not fit any "JK" Jeep® model or 2-Door "JL" models.
Soft-top models: Stealthbox® installation does not interfere with normal top operation, except for the final position where the top mechanism is detached from the rails.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-J-JL4DDRV/10TW1-2 Installation Manual
10-Inch 300-Watt 2-Ohm or 4-Ohm Thin Subwoofer-Enclosure for Select 2018-2023 Jeep Wrangler-Unlimited, Passenger-Side
Combining JL's advanced thin-line subwoofer technology with a form fitting enclosure design, these Stealthbox® systems deliver outstanding sub-bass performance in your 4-door Wrangler, without consuming excess cargo space.
Constructed from 100% fiberglass, each Stealthbox® houses a 10TW1 thin-line subwoofer and mounts solidly above each rear wheel well. A matching trim panel and sturdy steel-mesh grille are included, so you can carry plenty of gear without worrying about damage. Separate driver and passenger side Stealthbox® models are available, each with 2 or 4 ohm drivers.
The Hard Data: Contains one 10TW1 in a sealed enclosure with 300 watt power handling. Choose from 2 ohm or 4 ohm models, driver or passenger side. Each enclosure installs above one rear wheel well. Black steel mesh grille is included with each.
If vehicle is factory-equipped with Premium Audio, passenger side Stealthbox® installation requires removal of OEM “subwoofer” and purchase of interior trim parts from Jeep®.
Will not fit any "JK" Jeep® model or 2-Door "JL" models.
Soft-top models: Stealthbox® installation does not interfere with normal top operation, except for the final position where the top mechanism is detached from the rails.
Jeep Part #CFWLR-74-24 carpet needs to be ordered from jeep to remove the Factor Subwoofer.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-J-JL4DPAS/10TW1-2 Installation Manual
Single 10-Inch 300-Watt 2-Ohm or 4-Ohm Thin Subwoofer-Enclosure for Select 2007-2017 Jeep-Wrangler JK-Unlimited with Black-Trunk, Driver Side
Whether your adventures are urban, suburban or on the roughest trails... these Stealthbox® systems for the 4-door Wrangler Unlimited will make them all more exciting.
These systems are designed to provide powerful, audiophile bass quality without significantly compromising precious cargo space. JL Audios patented, low-profile thinline subwoofer technology extracts amazing bass from very thin enclosures that bolt solidly above each rear wheel well. Rugged, 100% fiberglass construction is as tough as your Jeep® and sturdy steel-mesh grilles mean you can still toss all your gear in the back without worrying about damage.
Because Jeep® owners customize their vehicles in all kinds of creative ways, the driver side and passenger side Stealthbox® systems are sold individually. A single one is enough for most people to be very happy, but you can go for two if maximum performance is your goal.
The Hard Data: Each system contains one 10TW1 in a sealed enclosure with 300 watt power handling. Each enclosure is wired for 2 or 4 ohms. A steel mesh grille is included with each to protect the subwoofer driver. Each enclosure installs above one rear wheel well, with specific models for passenger and driver side. Does not affect hard top installation.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-J-WRUD/10TW1-2 Installation Manual
Single 10-Inch 300-Watt 2-Ohm or 4-Ohm Thin Subwoofer-Enclosure for Select 2007-2017 Jeep-Wrangler Unlimited, Passenger Side
Whether your adventures are urban, suburban or on the roughest trails... these Stealthbox® systems for the 4-door Wrangler Unlimited will make them all more exciting.
These systems are designed to provide powerful, audiophile bass quality without significantly compromising precious cargo space. JL's patented, low-profile thin line subwoofer technology extracts amazing bass from very thin enclosures that bolt solidly above each rear wheel well. Rugged, 100% fiberglass construction is as tough as your Jeep® and sturdy steel-mesh grilles mean you can still toss all your gear in the back without worrying about damage.
Because Jeep® owners customize their vehicles in all kinds of creative ways, the driver side and passenger side Stealthbox® systems are sold individually. A single one is enough for most people to be very happy, but you can go for two if maximum performance is your goal.
The Hard Data: Each system contains one 10TW1 in a sealed enclosure with 300 watt power handling. Each enclosure is wired for 2 or 4-ohms. A steel mesh grille is included with each to protect the Subwoofer. Each enclosure installs above one rear wheel well, with specific models for passenger and driver side. Does not affect hard top installation.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-J-WRUP/10TW1-2 Installation Manual
Fuse-Holder Mounting Bracket for Under-The-Hood Locations in Select 2007-2018 Jeep Wrangler-JK Vehicles
The SBA-J-JK-FHB Fuse Holder Bracket easily and securely mounts up to two JL Audio XB-MFBU-ANL Master Fuse Blocks (sold separately). Attaches to the firewall of your 2-door or 4-door Wrangler using factory hardware (no drilling required). Powder-coated steel, engineered and built in USA.
JL Audio SBA-J-JK-FHB Installation Manual
Amplifier Mounting Bracket for Under-The-Seat Locations in Select 2007-2017 Jeep Wrangler-JK Vehicles
The SBA-J-JKU-UAR Universal Amplifier Rack fits under either front seat of your 4-door Wrangler to securely mount one of several different JL Audio amplifier models (sold separately). Installs using factory hardware and requires no drilled holes. Powder-coated steel, engineered and built in USA.
Will not fit 2-Door models.
Includes predrilled mounting locations and hardware to install one of the following amplifier models:
VXi: All models.XDv2: All models, except XD800/8v2, XD1000/1v2 and XD1000/5v2.*M-Series: All models, except M800/8v2, M1000/1v2 and M1000/5v2.RD: All models, except RD1000/1, RD1500/1 and RD900/5.MX: All models; up to two of MX280/4 and MX300/1.*** includes XD versions** includes HX and MHX versions
JL Audio SBA-J-JKU-UAR Installation Manual
Amplifier Mounting Bracket for Under-The-Seat Locations in Select 2018-UP Jeep Wrangler-JL and Gladiator-JL Vehicles
The SBA-J-JLU-UAR Universal Amplifier Rack fits under either front seat to securely mount one of several different JL Audio amplifier models (sold separately). Featuring an angled design to maximize rear seat foot space, the SBA-J-JLU-UAR Amplifier Rack requires no drilled holes and installs using factory hardware. Engineered and Built in USA.
Includes predrilled mounting locations and hardware to install one of the following amplifier models:
VXi: All models.XDv2: All models, except XD800/8v2, XD1000/1v2 and XD1000/5v2.*M-Series: All models, except M800/8v2, M1000/1v2 and M1000/5v2.RD: All models, except RD1000/1, RD1500/1 and RD900/5.MX: All models; up to two of MX280/4 and MX300/1.*** includes XD versions** includes HX and MHX versions
JL Audio SBA-J-JLU-UAR Manual
