75W x 2 @ 4Ω

MX-Series 75-Watts x 2-Channel Class-D Marine-Grade Amplifier + 400-Watt Subwoofer Out @ 2-Ohm Engineered specifically for powersports applications, the 3-channel MX600/3 amplifier employs JL's high-speed NexD™ switching design to deliver plenty of clean power, without straining charging systems. Its tiny, cast aluminum chassis is highly resistant to corrosion, with an IPX7 water-resistance rating, making it perfect for motorcycles, ATV’s or other utility vehicles. Generating a solid 75W x 2 into 4 ohms (14.4V, 1% THD), the MX600/3 is the perfect solution for driving a pair of speakers and a subwoofer. Other features include independent front and rear crossovers with selectable full-range, high-pass or low-pass filter controls and a dual-range input section that accepts a wide range of input voltage levels, from line-level all the way to high-power speaker level signals. This amplifier features a black powder-coated finish, a gasketed cover for the controls and stainless steel hardware for durability. Specifications Frequency Response 20 Hz - 20 kHz (+0, -1dB) S/N Ratio, referred to highest rated power >88 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W >68 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Damping Factor @ 4 Ω >92 / 50 Hz Damping Factor @ 2 Ω >43 / 50 Hz THD+N @ Rated Power (Main Channels) <1% @ 2 Ω per Ch. THD+N @ Rated Power (Subwoofer Channels) <1% @ 2 Ω per Ch. Input Voltage Range @ RCA Inputs Switchable from 250 mV - 4 V RMS (Low) to 580 mV - 14 V RMS (High) Min.Copper Power / Ground Wire Gauge 4 AWG wire Fuse Rating 60 A (AFS, AGU or MaxiFuse™) Main Channels @ 4 Ω 75 W RMS x 2 Main Channels @ 2 Ω 100 W RMS x 2 Main Channels - Bridged @ 4Ω 200 W RMS x 1 Subwoofer Channel @ 4 Ω 250 W RMS x 1 Subwoofer Channel @ 3 Ω 300 W RMS x 1 Subwoofer Channel @ 2 Ω 400 W RMS x 1 Subwoofer Channel @ 1.5 Ω N/A JL Audio MX600/3 Manual

Read more less

XDM-Series 2-Channel Class-D Marine-Grade Amplifier, 100-Watts x 2-Channels @ 2-Ohm or 75-Watts x 2-Channels @ 4-Ohm The tiny XDM200/2 packs a serious full-range punch, delivering a staggering 100-watts per channel into 2-ohms (14.4V, 1% THD). The technology that makes this much power possible in such a compact chassis is JL's advanced high-speed switching design, which permits full bandwidth Class D operation with extremely low distortion and remarkable efficiency. Suitable for car or boat installations, the XDM200/2 is built with marine-grade materials and features an exclusive, dual-mode input filter for noise-free performance in boats or cars. Automatic turn-on capability (via signal sensing or DC-offset sensing) is also onboard for easy factory system upgrades. The XDM200/2 includes a 12dB / octave filter which can be configured as a low-pass or high-pass filter and offers continuously variable cutoff frequency selection from 50-500Hz. With the addition of an optional HD-RLC or MHD-RLC (water-resistant) remote level controller (each sold separately), the amplifier's level can be adjusted directly from the driver's seat or cockpit. Finished in a sleek, black powder-coat, all controls are protected beneath a gasketed, removable top cover for easy access. Specifications @ 4 Ω 75 W RMS x 2 @ 14.4V @ 2 Ω 100 W RMS x 2 @ 14.4V Bridged @ 4Ω 200 W RMS x 1 @ 14.4V @ 4 Ω 60 W RMS x 2 @ 12.5V @ 2 Ω 90 W RMS x 2 @ 12.5V Bridged @ 4Ω 180 W RMS x 1 @ 12.5V Frequency Response 12 Hz - 22 kHz (+0, -1dB) S/N Ratio, referred to highest rated power >104 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W >84 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Damping Factor @ 4 Ω >150 / 50 Hz Damping Factor @ 2 Ω >75 / 50 Hz THD+N @ Rated Power <1% @ 2 Ω per Ch. Input Voltage Range @ RCA Inputs 200 mV - 4 V RMS  Min.Copper Power / Ground Wire Gauge 8 AWG wire Fuse Rating 20 A (AFS, AGU or MaxiFuse™) Filter Mode(s) Low-Pass or High-Pass Filter Slope(s) 12 dB/octave Filter Frequency Range 50 Hz - 500 Hz Detented, Calibrated Filter Freq. Potentiometer Yes Filter Defeat Function Yes Remote Level Control Optional HD-RLC or MHD-RLC (water-resistant) Security Cover for Controls Yes Pass-Through Preamp Output Buffered Height (H) 2.05 in / 52 mm Width (W) 6.85 in / 174 mm Depth (D) 7.09 in / 180 mm Net Weight 3.75 lb / 1.70 kg JL Audio XDM200/2 Manual

Read more less

XDM-Series Three-Channel Class-D Marine-Grade Amplifier, 75-Watts x Two-Channels @ 4-Ohm and 300-Watt Mono @ 2-Ohm Small enough to fit in just about any tight space application, the XDM500/3 is the perfect amplifier for a simple audiophile-grade, subwoofer / satellite system. With its three channels of versatile output, you can drive a pair of quality component speaker systems with plenty of clean power, while also delivering a stout 300W to your subwoofer system. The technology that makes this much power possible in such a small chassis is JL-Audio's advanced NexD switching amplifier design. Suitable for car or boat installations, the XDM500/3 is built with marine-grade materials and features an exclusive, dual-mode input filter for noise-free performance in boats or cars. Automatic turn-on capability (via signal sensing or DC-offset sensing) is also onboard for easy factory system upgrades. The XDM500/3 includes a 12dB / octave high-pass filter for its main channels, plus a variable slope low-pass filter for its subwoofer channel. Both filters offer continuously variable cutoff frequency selection from 50-500Hz. With the addition of an optional HD-RLC or MHD-RLC (water-resistant) remote level controller (each sold separately), you have the ability to adjust the level of all amplifier channels or just the subwoofer channel directly from the driver's seat or helm. Finished in a sleek, black powder-coat, all controls are protected beneath a gasketed, removable top cover for easy access. Specifications Main Channels @ 4 Ω 75 W RMS x 2 @ 14.4V Main Channels @ 2 Ω 100 W RMS x 2 @ 14.4V Main Channels - Bridged @ 4Ω 200 W RMS x 1 @ 14.4V Subwoofer Channel @ 4 Ω 180 W RMS x 1 @ 14.4V Subwoofer Channel @ 3 Ω 240 W RMS x 1 @ 14.4V Subwoofer Channel @ 2 Ω 300 W RMS x 1 @ 14.4V Subwoofer Channel @ 1.5 Ω N/A Main Channels @ 4 Ω 60 W RMS x 2 @ 12.5V Main Channels @ 2 Ω 90 W RMS x 2 @ 12.5V Main Channels - Bridged @ 4Ω 180 W RMS x 1 @ 12.5V Subwoofer Channel @ 4 Ω 180 W RMS x 1 @ 12.5V Subwoofer Channel @ 3 Ω 240 W RMS x 1 @ 12.5V Subwoofer Channel @ 2 Ω 300 W RMS x 1 @ 12.5V Subwoofer Channel @ 1.5 Ω N/A Frequency Response (Main Channels) 12 Hz - 22 kHz (+0, -1dB) Frequency Response (Subwoofer Channel) 10 Hz - 1 kHz (+0, -1dB) S/N Ratio, referred to highest rated power (Main Channels) >104 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W >84 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Damping Factor @ 4 Ω >120 / 50 Hz Damping Factor @ 2 Ω >60 / 50 Hz THD+N @ Rated Power (Main Channels) <1% @ 2 Ω per Ch. THD+N @ Rated Power (Subwoofer Channels) <1% @ 2 Ω per Ch. Input Voltage Range @ RCA Inputs 200 mV - 4 V RMS Min.Copper Power / Ground Wire Gauge 4 AWG wire Fuse Rating 50 A (AFS, AGU or MaxiFuse™) Filter Mode(s): Channels 1 & 2 (front) High-Pass only Filter Slope(s): Channels 1 & 2 (front) 12 dB/octave Filter Frequency Range: Channels 1 & 2 (front) 50 Hz - 500 Hz Filter Mode(s): Channels 3 & 4 (rear) N/A Filter Slope(s): Channels 3 & 4 (rear) N/A Filter Frequency Range: Channels 3 & 4 N/A Filter Mode(s): Subwoofer Channel Low-Pass only Filter Slope(s): Subwoofer Channel 12/24 dB/octave Filter Frequency Range: Subwoofer Channel 50 Hz - 500 Hz Detented, Calibrated Filter Freq. Potentiometers Yes Filter Defeat Function Yes Infrasonic Filter: Subwoofer Channel none Remote Level Control Optional HD-RLC or MHD-RLC (water-resistant) Remote Level Modes Sub Ch. or All Channels Channel Input Mode Switch Yes (2/4 ch.) Pass-Through Preamp Output Buffered Source Channel Selection for PreOuts Yes (1&2/Sum/Sub) Height (H) 2.05 in / 52 mm Width (W) 8.52 in / 216 mm Depth (D) 7.09 in / 180 mm Net Weight 4.8 lb / 2.18 kg JL Audio XDM500/3v2 Manual

Read more less
