Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
MM-Series 400-Watt RMS 10-Inch Subwoofer Driver, 4-Ohm SVC
The fiberglass-reinforced ABS basket resists flexing during heavy excursion, so your sub hits hard without distorting. Ultra-Marine certification and an IP56 rating.
Specifications
10" 4-ohm subwoofer
Titanium-plated composite cone
Butyl rubber surround
Fiberglass-reinforced ABS basket
IP56 rating
Power handling: 400W RMS
Peak power handling: 1200W
Frequency response: 28-2000Hz
Sensitivity: 86dB @ 1W/1M
Top mounting depth: 4.35"
Cutout diameter: 9.1"
Grille not included
Warranty: 1 year
Polk Audio MM1 Subwoofer Manual
W1-Series 12-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The 12" W1v3 automotive subwoofer driver by JL Audio is a lightweight 12-inch driver with excellent performance capabilities at a moderate 300-Watts. The design of the chassis allows an average mounting depth with no pole-vent on the back side of the magnet so the rear of the motor structure can be placed directly against an enclosure boundary. This 12" subwoofer can reproduce sub-bass with shocking extension and quality.
The JL Audio 12W1v3-2 and 12W1v3-4 subwoofers are best used with an amplifier in the 75W - 300W range and is optimized to operate in a compact 1.10 cu. ft. (31.5 l) sealed enclosure.
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
2Ω
JL Audio 12W1v3 Manual
W1-Series 10-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The JL Audio 10" W1v3 subwoofer driver is a very suitable option when space is limited with smaller amplifiers. It features a low mounting depth of 4.6 inches and a compact motor structure that allows it to comfortably fit in tight mounting locations. There is no pole vent on the rear of the subwoofer which allows the motor structure to be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow the 10W1v3 to reproduce sub-bass with shocking extension and quality.
The JL Audio 10W1v3 is best used with an amplifier in the 75W - 300W RMS range and is optimized to operate in a compact 0.55 cu. ft. (15.57 l) sealed enclosure.
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
2Ω/4Ω
JL Audio 10W1v3 Manual
BassWedge-Series 12-Inch 300-Watt Enclosed Subwoofer System, 4Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofer to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofer firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 4 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
4 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
16.31 in / 414 mm
External Height (H)
15.18 in / 386 mm
External Depth (D1)
20.3 in / 516 mm
External Top Surface Depth (D2)
15.75 in / 400 mm
Net Weight
33.1 lb / 15 kg
JL Audio CP112-W0v3 Brochure
12-Inch 300-Watt Subwoofer Driver, 4-Ohm SVC or 4-Ohm DVC
This CompC 12" sub driver from Kicker has a thick stamped steel basket that holds an injection-molded polypropylene cone with stabilizing ribs in the surround.
The 44CWCS124 and 44CWCD124 12-Inch subs are available in a 4Ω Single Voice or 4Ω Dual Voice coil design with spring loaded speaker terminals. These CompC drivers are rated for 300W RMS of amplified power.
Specifications
Size (IN.,CM)
12, 30
Impedance (OHMS)
4 SVC or 4 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
600
Sensitivity (dB 1w/1m)
88.3
Frequency Response (Hz)
27-500
Mounting Depth (in, cm)
5-3/8, 13.6
Mounting Cutout (in, cm)
11, 27.9
Min Sealed Box Vol (cu. ft, L)
1.25, 35.4
Max Sealed Box Vol (cu. ft, L)
3.5, 99.1
Min Vented Box Vol (cu. ft, L)
1.75, 49.6
Max Vented Box Vol (cu. ft, L)
2.25, 63.7
Kicker CompC Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2009-2018 Ford F-150 & 2017-2018 F-250, F-350 and F-450 SuperCrew and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 2009-2018 Ford F150 Super Crew/Super Cab
Will also work in 2017 - 2018 F250/350/450 Super Crew / Super Cab
Premium Carpeted Finish
3/4" Hardwood MDF
Glued and Braced construction
CNC Grooved custom finish
Rounded edges
Silver spring loaded terminal cups
Subwoofer mounting depth: 4.5"
Box volume: 0.8 cubic feet (per chamber)
Sub Cut Out: 9.125”, Width:26”, Height: 9”, Depth: 13.25”
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:26.00"
Height:4.63"
Depth:13.25"
Max Mounting Depth:4.50"
Gross VolumePer Sub:1.37
Net Volume Per Sub:0.92
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Single 12-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2002-2018 Ram Quad-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 11” single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
Premium Carpet Finish
OEM-Fit is designed and engineered specifically for the 2002-2018 Dodge Ram Quad Cab *2019 Legacy trucks to ensure an OEM fit without impeding the operation of the back seat.
Soft Woven Polyfill Damping Material helps create a flatter frequency response, low bass extension, and simulates a larger net volume air space.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with the second application of glue around all internal joints after final assembly.
Dimensions Sub cut out: 9.125”, mounting depth:6”, height: 7.25”, width: 32.7”, depth: 13.25”
May work with Legacy 2019 Vehicle Models
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:32.75"
Height:7.25"
Depth:13.25"
Max Mounting Depth:6.00"
Gross VolumePer Sub:0.63
Net Volume Per Sub:0.63
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2007-2014 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom downfire fit under rear seat. Fits bench style, 60/40 style seats
Designed specifically for 2007-2014 Chevy Silverado and GMC Sierra Extended Cab Trucks
Dual 10" Subwoofer Enclosure
Premium Carpet Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 6.25"
Box volume: 0.8 cubic feet (per chamber)
Specifications
Width
52.75
Height
6.875
Depth
11.875
Mounting Depth
6.25
Gross Cubic Feet Per Side
0.8
Net Cubic Feet Per Side
0.8
Excursion
3.625
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 300-Watt Thin Subwoofer-Enclosure for Select 2018-2022 Jeep Wrangler-Unlimited, Passenger-Side
Combining JL's advanced thin-line subwoofer technology with a form fitting enclosure design, these Stealthbox® systems deliver outstanding sub-bass performance in your 4-door Wrangler, without consuming excess cargo space.
Constructed from 100% fiberglass, each Stealthbox® houses a 10TW1 thin-line subwoofer and mounts solidly above each rear wheel well. A matching trim panel and sturdy steel-mesh grille are included, so you can carry plenty of gear without worrying about damage. Separate driver and passenger side Stealthbox® models are available, each with 2 or 4 ohm drivers.
The Hard Data: Contains one 10TW1 in a sealed enclosure with 300 watt power handling. Choose from 2 ohm or 4 ohm models, driver or passenger side. Each enclosure installs above one rear wheel well. Black steel mesh grille is included with each.
If vehicle is factory-equipped with Premium Audio, passenger side Stealthbox® installation requires removal of OEM “subwoofer” and purchase of interior trim parts from Jeep®.
Will not fit any "JK" Jeep® model or 2-Door "JL" models.
Soft-top models: Stealthbox® installation does not interfere with normal top operation, except for the final position where the top mechanism is detached from the rails.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-J-JL4DPAS/10TW1-2 Installation Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
BassWedge-Series Dual 12-Inch 600-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofers to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofers firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 150 - 600WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
31.375 in / 797 mm
External Height (H)
15.18 in / 386 mm
External Depth (D1)
20.3 in / 516 mm
External Top Surface Depth (D2)
15.75 in / 400 mm
Net Weight
60.3 lb / 27.35 kg
JL Audio CP212-W0v3 Brochure
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Single 300-Watt Thin 10-Inch Stealthbox Subwoofer-Enclosure for Select 2018-UP Ford-Expedition Vehicles
Ford's full-sized SUV delivers first-rate comfort with outstanding gear-hauling capability and towing capacity. This is why JL's Stealthbox solution is designed to retain 100% of your cargo space, while delivering first-class bass performance.
This model replaces the stock subwoofer and installs discreetly behind the factory cargo area trim to protect and hide its 10-inch subwoofer.
The Hard Data: Contains one 10TW1-2 subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs behind driver side panel in the cargo area. Requires removal of the OEM "subwoofer".
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-EXPED4G/10TW1 Installation Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
PowerWedge-Series Dual 12-Inch Enclosed Subwoofer System, 2Ω Sealed Enclosure
Harnessing the performance and insanely small box requirements of the TW1 Subwoofers, this PowerWedge subwoofer system houses dual 12TW1 subwoofers in a compact sealed enclosure, resulting in deep, powerful bass output from an enclosure that’s only about the size of most other single driver systems.
This low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for dual 12TW1-4 drivers and has been fine-tuned through extensive real-world listening.
The PowerWedge subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. Steel mesh grilles are included to protect the Subwoofers.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 150-600WNominal Impedance: 2Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2Ω
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
26.25 in / 667 mm
External Height (H)
14 in / 356 mm
External Depth (D1)
8.875 in / 225 mm
Net Weight
49.90 lb / 22.6 kg
JL Audio CS212LG-TW1 Brochure
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
PowerWedge-Series Dual 10-Inch Enclosed Subwoofer System, 2Ω Sealed Enclosure
Harnessing the performance and insanely small box requirements of the TW1 subwoofer drivers, this PowerWedge™ subwoofer system houses dual 10TW1 subwoofers in a compact sealed enclosure, resulting in deep, powerful bass output from an enclosure that’s only about the size of most other single driver systems.
This low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for dual 10TW1-4 drivers and has been fine-tuned through extensive real-world listening.
The PowerWedge™ subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. Steel mesh grilles are included to protect the subwoofer drivers.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 150 - 600WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
22 in / 559 mm
External Height (H)
11.75 in / 298 mm
External Depth (D1)
7.313 in / 186 mm
Net Weight
34.20 lb / 15.51 kg
JL Audio CS210LG-TW1 Brochure
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
PowerWedge-Series 12-Inch 300-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this low-profile PowerWedge™ subwoofer system, JL harnesses the performance and insanely small box requirements of the TW1 subwoofer driver to deliver amazing sub-bass from an enclosure that is only 6.6 in. (168 mm) deep.
This low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12TW1 and has been fine-tuned through extensive real-world listening.
The PowerWedge™ subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the top surface of the enclosure. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
18 in / 457 mm
External Height (H)
13.75 in / 349 mm
External Depth (D1)
6.625 in / 168 mm
Net Weight
26.02 lb / 11.80 kg
JL Audio CS112LG-TW1-2 Brochure
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
ProWedge-Series 13-Inch 1500-Watt Enclosed Subwoofer System, 1.5Ω Sealed Enclosure
For those who seek the ultimate in compact-enclosure sub-bass fidelity, we offer this sealed ProWedge™ system, in which the superb performance capabilities of the W7AE Subwoofer are harnessed within a compact, sealed enclosure. This system has it all: extension, impact, detail and smooth response... at any listening level.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 13W7AE-D1.5 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
The angled-back design saves precious cargo space by allowing the enclosure to fit tightly against the back of a vehicle's rear seat.
Finish: Black, high-grade automotive carpet, with gloss-black laminated decorative front baffle trim. Three solid aluminum bars provide stylish and rugged woofer protection.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 500 - 1500WNominal Impedance: Dual 1.5 Ω
General Specifications
Continuous Power Handling (RMS)
1500 W
System Nominal Impedance
3 Ω
Enclosure Type
Sealed, rear-firing design
Finish
Black carpet / laminate
Grille Included
Aluminum Bar Grille
Physical Specifications
External Width (W)
22.5 in / 572 mm
External Height (H)
18.25 in / 464 mm
External Depth (D1)
18.25 in / 464 mm
External Top Surface Depth (D2)
11.50 in / 292 mm
Net Weight
103.2 lb / 46.79 kg
JL Audio CLS113RG-W7AE Brochure
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
W3-Series 13-Inch 600-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Single Voice Coil
If you have the space, it makes a tremendous sense to maximize your subwoofer system's piston area to enhance efficiency (and output). It gets even better when the larger driver delivers additional power handling and excursion. For the preceding reasons, the 13W3v3 can be the best choice for those seeking high output with great sound quality at medium power levels.
As with the smaller W3v3's, several exclusive JL Audio technologies and proprietary assembly techniques are applied to the 13W3v3 to enhance linearity and reliability.
The 13W3v3 2Ω or 4Ω model is best used with an amplifier powered in the 150W - 600W range and is optimized to operate in a moderate size 1.5 cu. ft. (42.5 l) sealed enclosure, or a 2.25 cu. ft. (63.7 l) ported enclosure. Detailed enclosure recommendations can be found in the "Specifications" tab.
General Specifications
Continuous Power Handling (RMS)
600W
Recommended Amplifier Power (RMS)
150 - 600W
Nominal Impedance (Znom)
4Ω
Nominal Diameter
13.5 in / 345 mm
Overall Diameter (A)
14.0 in / 356 mm
Mounting Hole Diameter (B)
12.5625 in / 319 mm
Bolt Hole Circle Diameter (C)
13.2 in / 335 mm
Motor Outer Diameter (D)
5.79 in / 147 mm
Mounting Depth (E)
7.63 in / 194 mm
Driver Displacement
0.096 cu ft / 2.72 liters
Net Weight
17.75 lb / 8.05 kg
Free Air Resonance (Fs)
23.66 Hz
Electrical “Q” (Qes)
0.465
Mechanical “Q” (Qms)
6.774
Total Speaker “Q” (Qts)
0.435
Equivalent Compliance (Vas)
4.793 cu ft / 135.74 L
One-Way Linear Excursion (Xmax)*
0.610 in / 15.5 mm
Reference Efficiency (no)
0.37%
Efficiency (1 W / 1 m)**
87.90 dB SPL
Effective Piston Area (Sd)
103.850 sq in / 0.0670 sq m
DC Resistance (Re)
3.569 Ω
JL Audio 13W3v3 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series Dual Loaded 750-Watt 8-Inch 2-Ohm Subwoofer Enclosure for Select Jeep Wrangler-JL Gladiator-JT and other Pickup Vehicles
From towing to travel, you depend on your truck to get you where you want to go, but can you rely on getting the best performance from your sound system? Now you can add deep, accurate bass in your truck without compromising valuable cabin space with the new R2-DB8V-TRK dual 8” Alpine Halo R-Series preloaded truck subwoofer enclosure with the ProLink system and amplifier space.
The enclosures were intentionally crafted to fit most full-size trucks. Two 8” subwoofers are preloaded into a compact enclosure for under the seat installation and linked with a ProLink bracket that can adjust from 51”-40”. Centered on the enclosures is an integrated amplifier mount tray that’s optimized for Alpine’s S-A75M Mono Power Amplifier (sold separately). Rubber “feet” are adjustable in height to accommodate uneven truck floors.
These ported subwoofer enclosures feature the next-generation 8” R-Series subwoofers with a more powerful motor that creates deeper bass while Alpine’s High Amplitude Multi-Roll (HAMR) surround technology allows the subwoofer cone to efficiently move air while staying cool for incredible accuracy. A new ceramic composite dust cap has higher heat resistance that ensures non-stop bass performance.
Alpine’s new preloaded truck subwoofer enclosures join the Alpine Halo family with a premium, unmistakable design. The enclosure pulls design cues from the Alpine Halo display with unique, curved edges outlined by a silver trim and a front link bracket cover with an Alpine logo badge. The 5/8” MDF enclosures are covered in a premium black carpet that will elevate the look of your truck.
With two preloaded R2-W8D2 8” R- Series subwoofers that are tuned to 36Hz, R2-DB8V-TRK is optimized to perform with Alpine’s R-Series sound system line. Dual voice coils are wired in parallel for a 2Ω load that’s compatible with Alpine’s R-Series R2-A75M mono power amplifier.
Features
Groundbreaking Alpine Halo Design
ProLink™ Ported Enclosure
Expandable Width from 40" to 51"
Compact, Under-the-Seat Installation in Most Full-Size Trucks
Integrated Amplifier Tray (not applicable with all vehicles)
Rubber, Modular Stackable Foot Design Accommodates Uneven Truck Floor Areas
Ported Enclosures with High-Performance S-Series Subwoofers
Front Link Alpine Branded Bracket
Side-Firing Cabin Loading Ports
Premium Alpine Wire Terminals
CARB Compliant 5/8" MDF Construction
Premium Black Carpet
Specifications
Dimensions: 40"-51" (Adjustable Width) x 8-3/4” (H) x 13-3/4” (D)
750W RMS
Frequency Response: 32Hz-200Hz
Sensitivity: 84dB
Dual voice coils Wired in Parallel for a 2Ω Load (Compatible with R-A75M)
Vented Enclosure Tuning Frequency: 36Hz
Custom spring-loaded speaker terminals fit up to 12AWG speaker wire
Alpine R2-DB8V-TRK BrochureAlpine R2-DB8V-TRK Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
S-Series Dual Loaded 600-Watt 8-Inch 2-Ohm Subwoofer Enclosure for Select Jeep Wrangler-JL Gladiator-JT and other Pickup Vehicles
From towing to travel, you depend on your truck to get you where you want to go, but can you rely on getting the best performance from your sound system? Now you can add deep, accurate bass in your truck without compromising valuable cabin space with the new S-DB8V-TRK dual 8” Alpine Halo S-Series preloaded truck subwoofer enclosure with the ProLink system and amplifier space.
The enclosures were intentionally crafted to fit most full-size trucks. Two 8” subwoofers are preloaded into a compact enclosure for under the seat installation and linked with a ProLink bracket that can adjust from 51”-40”. Centered on the enclosures is an integrated amplifier mount tray that’s optimized for Alpine’s S-A60M Mono Power Amplifier (sold separately). Rubber “feet” are adjustable in height to accommodate uneven truck floors.
The enclosures are designed for the unique cabin environment of your truck. The ported subwoofer enclosures feature Alpine’s reliable 8” S-Series subwoofers. The subwoofers are designed with an improved voice coil that brings out the full potential of the subwoofer. The custom-stamped steel frame is designed to withstand the rigors of the strong S-Series motor. Frame leg vents, as well as a vented backplate, keep the subwoofer cool for non-stop bass performance.
Alpine’s new preloaded truck subwoofer enclosures join the Alpine Halo family with a premium, unmistakable design. The enclosure pulls design cues from the Alpine Halo display with unique, curved edges outlined by a silver trim and a front link bracket cover with an Alpine logo badge. The 5/8” MDF enclosures are covered in a premium black carpet that will elevate the look of your truck.
With two preloaded S-W8D2 8” S- Series subwoofers that are tuned to 36Hz, the S-DB8V-TRK is optimized to perform with Alpine’s S-Series sound system line. Dual voice coils are wired in parallel for a 2Ω load that’s compatible with Alpine’s S-Series S-A60M mono power amplifier.
Features
Groundbreaking Alpine Halo Design
ProLink™ Ported Enclosure
Expandable Width from 40" to 51"
Compact, Under-the-Seat Installation in Most Full-Size Trucks
Integrated Amplifier Tray (not applicable with all vehicles)
Rubber, Modular Stackable Foot Design Accommodates Uneven Truck Floor Areas
Ported Enclosures with High-Performance S-Series Subwoofers
Front Link Alpine Branded Bracket
Side-Firing Cabin Loading Ports
Premium Alpine Wire Terminals
CARB Compliant 5/8" MDF Construction
Premium Black Carpet
Specifications
Dimensions: 40"-51" (Adjustable Width) x 8-3/4” (H) x 13-3/4” (D)
600W RMS
Frequency Response: 34Hz-200Hz
Sensitivity: 84dB
Dual voice coils Wired in Parallel for a 2Ω Load (Compatible with S-A60M)
Vented Enclosure Tuning Frequency: 36Hz
Custom spring-loaded speaker terminals fit up to 12AWG speaker wire
Alpine S-DB8V-TRK BrochureAlpine S-DB8V-TRK Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series Loaded 600-Watt Thin 10-Inch 2-Ohm Subwoofer Enclosure
Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow preloaded subwoofer enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.
Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series shallow subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
Integrated cooling fins located in the core of the subwoofer help dissipate the heat generated by the rapid subwoofer movement for enhanced cooling reliability and hours of uninterrupted playtime. The unique CoolMount dual-panel mount subwoofer motor enhances cooling.
Alpine’s Gen2 DD-Linear Magnetic Circuit technology, a compact and efficient dual-gap voice coil structure, allows for better control over the motor, resulting in lower distortion and precise bass control. The preloaded enclosures use the subwoofer frame as bracing fora more ridged design and better bass response.
A lightweight yet rigid aluminum dust cap allows the R-Series shallow subwoofer to transition sound quickly with minimal distortion and project the bass off the surface of the speaker for hard-hitting yet smooth bass performance. The included adjustable mounting brackets allow for a downfire mount configuration.
With dual voice coils wired in parallel for a 2Ω load, the Alpine R-Series 10" shallow subwoofer enclosure is optimized to perform with Alpine's S-A60M or R-A75M mono amplifiers.
Features
Optimal sealed cabinet quality
Aluminum Dust Cap
Neodymium Magnet
Alpine Gen2 DD Linear Magnetic Circuit
CARB compliant ¾” MDF construction
Premium Alpine embroidered black carpet
Alpine-branded terminal cup
Pre-installed steel mesh grille
Includes a 10” R-Shallow Subwoofer (RS-W10D4)
Rubber, modular stackable foot design
Specifications
Dimensions: 21.15” W x 5.25” H x 16” L
600W RMS Power Handling
Frequency response: 29Hz – 200Hz
Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)
Nominal Impedance: 2Ω
Voice Coil: 4”(101.6mm)
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series Loaded 600-Watt Thin 12-Inch 2-Ohm Subwoofer Enclosure
Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow preloaded subwoofer enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.
Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series shallow subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
Integrated cooling fins located in the core of the subwoofer help dissipate the heat generated by the rapid subwoofer movement for enhanced cooling reliability and hours of uninterrupted playtime. The unique CoolMount dual-panel mount subwoofer motor enhances cooling.
Alpine’s Gen2 DD-Linear Magnetic Circuit technology, a compact and efficient dual-gap voice coil structure, allows for better control over the motor, resulting in lower distortion and precise bass control. The preloaded enclosures use the subwoofer frame as bracing fora more ridged design and better bass response.
A lightweight yet rigid aluminum dust cap allows the R-Series shallow subwoofer to transition sound quickly with minimal distortion and project the bass off the surface of the speaker for hard-hitting yet smooth bass performance. The included adjustable mounting brackets allow for a downfire mount configuration.
With dual voice coils wired in parallel for a 2Ω load, the Alpine R-Series 12" shallow subwoofer enclosure is optimized to perform with Alpine's S-A60M or R-A75M mono amplifiers.
Features
Optimal sealed cabinet quality
Aluminum Dust Cap
Neodymium Magnet
Alpine Gen2 DD Linear Magnetic Circuit
CARB compliant ¾” MDF construction
Premium Alpine embroidered black carpet
Alpine-branded terminal cup
Pre-installed steel mesh grille
Includes a 12” R-Shallow Subwoofer (RS-W12D4)
Rubber, modular stackable foot design
Specifications
Dimensions: 26.5” W x 5.25” H x 17” D
600W RMS Power Handling
Frequency response: 26Hz – 200Hz
Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)
Nominal Impedance: 2Ω
Voice Coil: 4”(101.6mm)
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series 8-Inch 350-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W8D2 and R2-W8D4 is compatible with the KTE-8G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
350W RMS
1000W Peak Power Handling
Frequency Response: 30Hz-200Hz
Sensitivity (1W/1m): 83.5dB
Nominal Impedance: 4Ω
Voice Coil: 35mm
X-Max: 12mm
Magnet Weight: 56oz
Mounting Depth: 4-3/8” (118mm)
Cutout Size: 6-15/16” (176mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W8D Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series 10-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W10D2 and R2-W10D4 is compatible with the KTE-10G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
750W RMS
2250W Peak Power Handling
Frequency Response: 26Hz-200Hz
Sensitivity (1W/1m): 82.4dB
Nominal Impedance: 4Ω
Voice Coil: 65mm
X-Max: 20mm
Magnet Weight: 123oz
Mounting Depth: 6” (152mm)
Cutout Size: 9-1/16” (231mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W10D Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
R-Series 12-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W12D2 and R2-W12D4 is compatible with the KTE-12G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
750W RMS
2250W Peak Power Handling
Frequency Response: 24Hz-200Hz
Sensitivity (1W/1m): 84.5dB
Nominal Impedance: 4Ω
Voice Coil: 65mm
X-Max: 20mm
Magnet Weight: 144oz
Mounting Depth: 6-1/2” (152mm)
Cutout Size: 10-7/8” (231mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W12D Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Dual 10-Inch 2-Ohm 800-Watt Subwoofer-Enclosure for Select 2016-2022 Nissan-Titan Crew-Cab Vehicles
Nissan's full-size truck is built to offer loads of capabilities for work and play, along with a spacious interior cabin. Sadly, the factory audio systems leave a lot to be desired in bass output and performance.
Fortunately, JL-Audio engineers developed a subwoofer solution that fills your Crew Cab with loads of powerful bass output. Featuring a 100% fiberglass, sealed enclosure design, this Stealthbox houses two of JL's innovative 10TW3 thin-line subwoofers and installs neatly under the rear seat, without compromising rear seat comfort or folding.
The Hard Data: Contains two 10TW3-D8 Subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Installation requires removal of rear underseat storage compartment, if equipped.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-N-TTNCRW2G/10TW3 Installation Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Dual 10-Inch 2-Ohm 800-Watt Subwoofer-Enclosure for Select 2020-2022 RAM1500 QuadCab Vehicles
This generation of RAM’s big hauler combines a bold new design with major advancements in aerodynamics, technology and towing capabilities. Disappointingly, the original equipment audio systems lack the low-frequency output and performance you might expect.
Luckily, JL-Audio engineers are experts in maximizing bass from minimal space and developed a subwoofer solution that fills your Quad Cab with loads of powerful bass output. Featuring a 100% fiberglass, sealed enclosure design, this Stealthbox houses two of JL-Audio's innovative 10TW3 thin-line subwoofers and installs neatly under the rear seat, without compromising rear seat comfort or folding. Theyeven left space on the enclosure that’s perfect for a small, hidden amplifier installation!
The Hard Data: Contains two 10TW3-D8 Subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Installation requires removal of rear underseat storage tray, if equipped.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-D-5GRAMQC/10TW3 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Single 10-Inch 2-Ohm 300-Watt Subwoofer-Enclosure for Select 2019-2022 Ford-Ranger SuperCrew Vehicles
Ford's mid-sized pickup promises practical utility and performance for everyday commutes or rugged terrains. To make every drive even more enjoyable, JL-Audio's Stealthbox solution tucks under the rear seat on the passenger side and encloses a 10-inch driver for impressive sub-bass performance. Seat folding is unaffected with plenty of room remaining on the driver side for storage. Best of all, the Stealthbox virtually disappears once installed.
The Hard Data: Contains one 10TW1-2 subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs under passenger side rear seat in place of storage compartment. Will not fit SuperCab.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-RNGSCG4/10TW1 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Single 10-Inch 2-Ohm 400-Watt Subwoofer-Enclosure for Select 2010-2022 Toyota 4Runner Vehicles
The 5th Generation 4Runner has been long-overdue for a Stealthbox® solution. When JL finally approached the challenge, thy knew 4Runner owners cared about the vehicle's cargo space and JL-Audio didn't want to interfere with OEM cargo slides or aftermarket cargo drawer systems. The result is the addition of a spectacular 400 watt, 10-inch subwoofer solution tucked nicely behind the factory cargo panel.
The Hard Data: Contains one 10TW3-D4 subwoofer in a sealed enclosure. 400 watt power handling. Wired for 2 ohm mono. Installs behind factory panel in the passenger side rear cargo area. Subwoofer is protected by the included black steel mesh grille and concealed by a fabric grille. Installation requires permanent modification to the factory panel. Installation in models equipped with an "OEM" subwoofer require purchase of a standard factory panel from Toyota Parts. Will not fit models with third row seating.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-T-4RNRG5/10TW3 Installation Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch 300-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompRT 8-inch subwoofer is an all-weather thin bass driver with a pair of 2-Ohm or 4-Ohm voice coils. With a mounting depth under three inches and plenty of power handling, this go-anywhere sub is as flexible as it is powerful. A UV-resistant cone and surround help make the CompRT sound great wherever the road (or trail) takes you.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent. To make Kicker subs even more reliable, their engineers developed Forced-Air Cooling™ to help these thin subs run 20 percent cooler than before.
Kicker signature red double stitching makes an outstanding bond between the improved Santoprene surround and polypropylene woofer cone. Revolutionary SoloKon™ technology joins the cone to the vented back brace, creating a single integrated unit that both cools the motor and eliminates distortion.
The CompRT 8-Inch 48CWRT82 and 48CWRT84 subwoofers work best with a sealed or ported enclosure and 300 watts of recommended power.
Specifications
SIZE [in, cm]:
8, 20
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
600
SENSITIVITY [dB 1w/1m]:
81.8
MOUNTING DEPTH [in, cm]:
2 11/16, 6.7
MOUNTING DIAMETER [in, cm]:
7, 17.7
MIN SEALED BOX VOL [cu. ft, L]:
0.2, 5.66
MAX SEALED BOX VOL [cu. ft, L]:
1.0, 28.32
MIN VENTED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX VENTED BOX VOL [cu. ft, L]:
1.2, 34
Kicker CompRT Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR8 8" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.The Kicker 48CWR82 and 48CWR84 8" subs work best with a sealed or ported enclosure and 300 watts of recommended power.
Specifications
SIZE [in, cm]:
8, 20
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
600
SENSITIVITY [dB 1w/1m]:
82.1
MOUNTING DEPTH [in, cm]:
4-1/8, 10.5
MOUNTING DIAMETER [in, cm]:
7, 17.7
MIN SEALED BOX VOL [cu. ft, L]:
0.4, 11.3
MAX SEALED BOX VOL [cu. ft, L]:
1.0, 28.52
MIN VENTED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX VENTED BOX VOL [cu. ft, L]:
1.2, 34
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 800-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR15 15" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.
The Kicker 48CWR152 and 48CWR154 15" subs work best with a sealed or ported enclosure and 800 watts of recommended power.
Specifications
SIZE [in, cm]:
15, 38
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
800
Peak Power (watts, per ANSI/CTA-2031-A)
1600
SENSITIVITY [dB 1w/1m]:
89.4
MOUNTING DEPTH [in, cm]:
7 15/16, 20
MOUNTING DIAMETER [in, cm]:
13 3/4, 35
MIN SEALED BOX VOL [cu. ft, L]:
1.8, 51
MAX SEALED BOX VOL [cu. ft, L]:
3.0, 85
MIN VENTED BOX VOL [cu. ft, L]:
3.0, 85
MAX VENTED BOX VOL [cu. ft, L]:
5.0, 142
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR12 12" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.The Kicker 48CWR122 and 48CWR124 12" subs work best with a sealed or ported enclosure and 500 watts of recommended power.
Specifications
SIZE [in, cm]:
12, 30
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
500
Peak Power (watts, per ANSI/CTA-2031-A)
1000
SENSITIVITY [dB 1w/1m]:
86.9
MOUNTING DEPTH [in, cm]:
5 3/4, 14.6
MOUNTING DIAMETER [in, cm]:
11, 27.9
MIN SEALED BOX VOL [cu. ft, L]:
1.0, 28.3
MAX SEALED BOX VOL [cu. ft, L]:
2.0, 56.64
MIN VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
MAX VENTED BOX VOL [cu. ft, L]:
2.25, 63.7
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 400-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The 48CWR10 10" subwoofer is available in a 2Ω or 4Ω dual voice coil design, making it easy to get the most out of your amp.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent – all without a hint of distortion. KICKER developed Forced Air Cooling to helps their subs run 25% cooler.The Kicker 48CWR102 and 48CWR104 12" subs work best with a sealed or ported enclosure and 400 watts of recommended power.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
84.6
MOUNTING DEPTH [in, cm]:
5-1/4, 13.3
MOUNTING DIAMETER [in, cm]:
9-1/8, 23.1
MIN SEALED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX SEALED BOX VOL [cu. ft, L]:
1.25, 35.4
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
8-Inch 200-Watt Subwoofer Driver, 4-Ohm SVC or 4-Ohm DVC
This CompC 8" sub driver from Kicker has a thick stamped steel basket that holds an injection-molded polypropylene cone with stabilizing ribs in the surround.
The 44CWCS84 and 44CWCD84 8-Inch subs are available in a 4Ω Single Voice or 4Ω Dual Voice coil design with spring loaded speaker terminals. These CompC drivers are rated for 200W RMS of amplified power.
Specifications
Size (IN.,CM)
8, 20
Impedance (OHMS)
4 SVC or 4 DVC
Recommended Amplifier Power (watts RMS)
200
Peak Power (watts, per ANSI/CTA-2031-A)
400
Sensitivity (dB 1w/1m)
85.6
Mounting Depth (in, cm)
3 7/8, 9.8
Mounting Diameter (in, cm)
7, 17.7
Min Sealed Box Vol (cu. ft, L)
0.5, 14.2
Max Sealed Box Vol (cu. ft, L)
1.2, 34
Min Vented Box Vol (cu. ft, L)
0.66, 18.7
Max Vented Box Vol (cu. ft, L)
1.2, 34
Kicker CompC Subwoofer Manual
10-Inch 300-Watt Subwoofer Driver, 4-Ohm SVC or 4-Ohm DVC
This CompC 10" sub driver from Kicker has a thick stamped steel basket that holds an injection-molded polypropylene cone with stabilizing ribs in the surround.
The 44CWCS104 and 44CWCD104 10-Inch subs are available in a 4Ω Single Voice or 4Ω Dual Voice coil design with spring loaded speaker terminals. These CompC drivers are rated for 300W RMS of amplified power.
Specifications
Size (IN.,CM)
10, 25
Impedance (OHMS)
4 SVC or 4 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
500
Sensitivity (dB 1w/1m)
86.2
Frequency Response (Hz)
30-500
Mounting Depth (in, cm)
4 13/16, 12.2
Mounting Cutout (in, cm)
9 1/8, 23.1
Min Sealed Box Vol (cu. ft, L)
1.0, 28.3
Max Sealed Box Vol (cu. ft, L)
2.4, 68
Min Vented Box Vol (cu. ft, L)
1.25, 35.4
Max Vented Box Vol (cu. ft, L)
1.75, 49.6
Kicker CompC Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 600-Watt Subwoofer Driver, 4-Ohm SVC or 4-Ohm DVC
This CompC 15" sub driver from Kicker has a thick stamped steel basket that holds an injection-molded polypropylene cone with stabilizing ribs in the surround.
The 44CWCS154 and 44CWCD154 15-Inch subs are available in a 4Ω Single Voice or 4Ω Dual Voice coil design with spring loaded speaker terminals. These CompC drivers are rated for 600W RMS of amplified power.
Specifications
Size (IN.,CM)
15, 38
Impedance (OHMS)
4 SVC or 4 DVC
Recommended Amplifier Power (watts RMS)
600
Peak Power (watts, per ANSI/CTA-2031-A)
1200
Sensitivity (dB 1w/1m)
90.3
Frequency Response (Hz)
25-500
Mounting Depth (in, cm)
7, 17.7
Mounting Cutout (in, cm)
13 3/4, 35
Min Sealed Box Vol (cu. ft, L)
2.25, 63.7
Max Sealed Box Vol (cu. ft, L)
5.0, 141.6
Min Vented Box Vol (cu. ft, L)
3.0, 85
Max Vented Box Vol (cu. ft, L)
4.0, 113.3
Kicker CompC Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 350-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The CompVT 10" subwoofer by Kicker is a thin slimline driver that pounds in a limited space. A special four-layer voice coil provides the ability to work with serious amounts of power without the bulk of a standard subwoofer.
The Kicker 43CVT102 and 43CVT104 subs work best with a sealed or ported enclosure and 350 watts of recommended power.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 SVC
Recommended Amplifier Power (watts RMS)
350
Peak Power (watts, per ANSI/CTA-2031-A)
700
SENSITIVITY [dB 1w/1m]:
87.2
MOUNTING DEPTH [in, cm]:
4 1/4, 10.8
MOUNTING DIAMETER [in, cm]:
9 3/16, 23.3
MIN SEALED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX SEALED BOX VOL [cu. ft, L]:
3, 85
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Kicker CompVT Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 400-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The CompVT 12" subwoofer by Kicker is a thin slimline driver that pounds in a limited space. A special four-layer voice coil provides the ability to work with serious amounts of power without the bulk of a standard subwoofer.
The Kicker 43CVT122 and 43CVT124 subs work best with a sealed or ported enclosure and 400 watts of recommended power.
Specifications
SIZE [in, cm]:
12, 30
IMPEDANCE [Ohms]:
2 or 4 SVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
87.1
MOUNTING DEPTH [in, cm]:
4 3/8, 11.1
MOUNTING DIAMETER [in, cm]:
11, 28.1
MIN SEALED BOX VOL [cu. ft, L]:
1, 28.3
MAX SEALED BOX VOL [cu. ft, L]:
4.6, 130
MIN VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
MAX VENTED BOX VOL [cu. ft, L]:
2.25, 63.7
Kicker CompVT Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
6.75-Inch 150-Watt Thin Subwoofer Driver, 1-Ohm or 2-Ohm DVC
The CompRT 6.75" thin subwoofer by Kicker is a weather resistant thin sub with a 1Ω or 2Ω dual voice coil design. This thin 6.75 inch sub magnet structure delivers 150W RMS of power with a chassis mounting depth of 2 3/4". The Kicker designed UniPlate™ back plate and solid pole piece serve as a single heat-absorbing unit to keep this 6.75" CompRT thin subwoofer driver nice and cool.The CompRT 6.75-Inch subwoofer works best with a sealed or ported enclosure and 150 watts of recommended power.
Specifications
SIZE [in, cm]:
6 13/16, 17.3
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
150
Peak Power (watts, per ANSI/CTA-2031-A)
300
SENSITIVITY [dB 1w/1m]:
82.6
MOUNTING DEPTH [in, cm]:
2 3/4, 7
MOUNTING DIAMETER [in, cm]:
5 5/8, 14.3
MIN SEALED BOX VOL [cu. ft, L]:
0.18, 5.1
MAX SEALED BOX VOL [cu. ft, L]:
0.75, 21.24
Kicker CompRT Subwoofer Manual
8-Inch 300-Watt Thin Subwoofer Driver, 2-Ohm DVC
The CompRT 8" thin subwoofer by Kicker is a weather resistant thin sub with a 2Ω dual voice coil design. This thin 8 inch sub magnet structure delivers 300W RMS of power with a chassis mounting depth of just under 2 3/4". The Kicker designed UniPlate™ back plate and solid pole piece serve as a single heat-absorbing unit to keep this 8" CompRT thin subwoofer driver nice and cool.The CompRT 8-Inch subwoofer works best with a sealed or ported enclosure and 300 watts of recommended power.
Specifications
SIZE [in, cm]:
8, 20
IMPEDANCE [Ohms]:
2 DVC
Recommended Amplifier Power (watts RMS)
300
Peak Power (watts, per ANSI/CTA-2031-A)
600
SENSITIVITY [dB 1w/1m]:
81.8
MOUNTING DEPTH [in, cm]:
2 11/16, 6.7
MOUNTING DIAMETER [in, cm]:
7, 17.7
MIN SEALED BOX VOL [cu. ft, L]:
0.2, 5.66
MAX SEALED BOX VOL [cu. ft, L]:
1.0, 28.32
MIN VENTED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX VENTED BOX VOL [cu. ft, L]:
1.2, 34
Kicker CompR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 400-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompRT 10-inch subwoofer is an all-weather thin bassb driver with a pair of 2-Ohm or 4-Ohm voice coils. With a mounting depth under four inches and plenty of power handling, this go-anywhere sub is as flexible as it is powerful. A UV-resistant cone and surround help make the CompRT sound great wherever the road (or trail) takes you.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent. To make Kicker subs even more reliable, their engineers developed Forced-Air Cooling™ to help these thin subs run 20 percent cooler than before.
Kicker signature red double stitching makes an outstanding bond between the improved Santoprene surround and polypropylene woofer cone. Revolutionary SoloKon™ technology joins the cone to the vented back brace, creating a single integrated unit that both cools the motor and eliminates distortion.The CompRT 10-Inch 48CWRT102 and 48CWRT104 subwoofers work best with a sealed or ported enclosure and 400 watts of recommended power.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
84.8
MOUNTING DEPTH [in, cm]:
3 7/16, 8.8
MOUNTING DIAMETER [in, cm]:
9 1/8, 23.1
MIN SEALED BOX VOL [cu. ft, L]:
0.4, 11.3
MAX SEALED BOX VOL [cu. ft, L]:
1.25, 35 .4
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 500-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm DVC
The CompRT 12-inch subwoofer is an all-weather thin bassb driver with a pair of 2-Ohm or 4-Ohm voice coils. With a mounting depth under four inches and plenty of power handling, this go-anywhere sub is as flexible as it is powerful. A UV-resistant cone and surround help make the CompRT sound great wherever the road (or trail) takes you.
An advanced suspension and heat management system helps to keep the bass powerful, deep and consistent. To make Kicker subs even more reliable, their engineers developed Forced-Air Cooling™ to help these thin subs run 20 percent cooler than before.
Kicker signature red double stitching makes an outstanding bond between the improved Santoprene surround and polypropylene woofer cone. Revolutionary SoloKon™ technology joins the cone to the vented back brace, creating a single integrated unit that both cools the motor and eliminates distortion.The CompRT 12-Inch 48CWRT122 and 48CWRT124 subwoofers work best with a sealed or ported enclosure and 500 watts of recommended power.
Specifications
SIZE [in, cm]:
12, 30
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
500
Peak Power (watts, per ANSI/CTA-2031-A)
1000
SENSITIVITY [dB 1w/1m]:
85.5
MOUNTING DEPTH [in, cm]:
3 3/4,9.6
MOUNTING DIAMETER [in, cm]:
11, 27.9
MIN SEALED BOX VOL [cu. ft, L]:
0.55, 15.57
MAX SEALED BOX VOL [cu. ft, L]:
2.0, 56.64
MIN VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
MAX VENTED BOX VOL [cu. ft, L]:
2.25, 63.7
Kicker CompRT Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
10-Inch 350-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This 43CVR 10" subwoofer by Kicker uses an advanced heat dispersion system with perimeter venting to allow air to circulate while the Kicker proprietary UniPlate™ system redirects even more heat away from the motor.
The chassis of this 10-Inch sub holds a pair of high-temp voice coils that move an injection molded woofer. The CompVR 10" subwoofer is available in a 2Ω or 4Ω dual voice coil design.
The 43CVR102 and 43CVR104 10-Inch subwoofers works best with a sealed or ported enclosure and 350 watts of recommended power. See below for more details.
Specifications
SIZE [in, cm]:
10, 25
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
350
Peak Power (watts, per ANSI/CTA-2031-A)
700
SENSITIVITY [dB 1w/1m]:
83.6
MOUNTING DEPTH [in, cm]:
5 1/2, 14
MOUNTING DIAMETER [in, cm]:
9 3/16, 23.3
MIN SEALED BOX VOL [cu. ft, L]:
0.8, 22.7
MAX SEALED BOX VOL [cu. ft, L]:
3, 85
MIN VENTED BOX VOL [cu. ft, L]:
1.25, 35.4
MAX VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
Kicker CompVR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
12-Inch 400-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This 43CVR 12" subwoofer by Kicker uses an advanced heat dispersion system with perimeter venting to allow air to circulate while the Kicker proprietary UniPlate™ system redirects even more heat away from the motor.
The chassis of this 12-Inch sub holds a pair of high-temp voice coils that move an injection molded woofer. The CompVR 12" subwoofer is available in a 2Ω or 4Ω dual voice coil design.
The 43CVR122 and 43CVR124 12-Inch subwoofers works best with a sealed or ported enclosure and 400 watts of recommended power. See below for more details.
Specifications
SIZE [in, cm]:
12, 30
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
400
Peak Power (watts, per ANSI/CTA-2031-A)
800
SENSITIVITY [dB 1w/1m]:
86.9
MOUNTING DEPTH [in, cm]:
6-1/4, 15.9
MOUNTING DIAMETER [in, cm]:
11, 27.8
MIN SEALED BOX VOL [cu. ft, L]:
1, 28.3
MAX SEALED BOX VOL [cu. ft, L]:
4.6, 130
MIN VENTED BOX VOL [cu. ft, L]:
1.75, 49.6
MAX VENTED BOX VOL [cu. ft, L]:
2.25, 63.7
Kicker CompVR Subwoofer Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
15-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm DVC
This 43CVR 15" subwoofer by Kicker uses an advanced heat dispersion system with perimeter venting to allow air to circulate while the Kicker proprietary UniPlate™ system redirects even more heat away from the motor.
The chassis of this 15-Inch sub holds a pair of high-temp voice coils that move an injection molded woofer. The CompVR 15" subwoofer is available in a 2Ω or 4Ω dual voice coil design.
The Kicker 43CVR152 and 43CVR154 15" subs works best with a sealed or ported enclosure and 500 watts of recommended power. See below for more details.
Specifications
SIZE [in, cm]:
15, 38
IMPEDANCE [Ohms]:
2 or 4 DVC
Recommended Amplifier Power (watts RMS)
500
Peak Power (watts, per ANSI/CTA-2031-A)
1000
SENSITIVITY [dB 1w/1m]:
89.2
MOUNTING DEPTH [in, cm]:
8 3/16, 20.7
MOUNTING DIAMETER [in, cm]:
13 11/16, 34.7
MIN SEALED BOX VOL [cu. ft, L]:
1.8, 51
MAX SEALED BOX VOL [cu. ft, L]:
5.2, 147
MIN VENTED BOX VOL [cu. ft, L]:
3, 85
MAX VENTED BOX VOL [cu. ft, L]:
5, 142
Kicker CompVR Subwoofer Manual
