Control your music while keeping your eyes on the road with the iLX-W650. Use two-finger swipe motions anywhere on the 7-inch touchscreen to control volume up or down, skip forward or back, and pause by swiping up, down, left, or right.
The iLX-W650 “Works with Apple CarPlay” and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touch screen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later (iPhone must be connected via Apple lightning cable).
The iLX-W650 includes Android Auto and works with the Google Assistant (requires both a USB cable and Bluetooth® connection; requires an AndroidTM phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say "OK Google" or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices and reply to text messages – hands free.
Use your smartphone in your car while keeping your eyes on the road with Apple CarPlay, Android Auto, Waze, and built-in Bluetooth calling and audio streaming. The screen is designed to maximize the app icons on your smartphone, so you can find what you need fast. You can also use voice commands with the external microphone to activate your apps, make calls, send texts, and get directions – all handsfree.
The iLX-W650 is SiriusXM-Ready (SXV300 Connect Vehicle Tuner Kit sold separately; SiriusXM subscription required) and works with Pandora Music so there’s nothing stopping you from listening to your favorite music. You can also access your music, videos, and photos via USB input.
See your drive on a 7-inch, anti-glare screen with the dual camera inputs. Add a front or rear-view camera to your vehicle and control the angles from your screen. The iLX-W650 comes with a built-in rearview camera distance guide display that makes blind spots a distant memory.
Get the most from your music by using the 9-band parametric equalizer and 6-channel time correction tool to control the powerful, built-in amplifier. Control the bass in your music on the fly with the built-in subwoofer level control. If you’re looking for more power, add additional amplifiers using the three sets of true 4V preamp outputs with subwoofer level control on the third set.
Features
7-inch anti-glare WVGA display with a capacitive touchscreen
Two-finger swipe user interface (volume up, volume down, skip forward, skip back, and pause)
50mm shallow mount chassis design
Works with Apple CarPlay®
The Google Assistant is available on Android Auto™
Bluetooth® built-in for hands-free calling and audio streaming
SiriusXM-Ready® (SXV300 Connect Vehicle Tuner Kit sold separately; SiriusXM subscription required)
Works with Pandora® Music for iPhone and Android phones
Rear camera input (camera sold separately)
FLAC/MP3/WMA/WAV/AAC/ music playback via USB
AVI/MP4/MPG/MOV/WMV USB video playback
JPG/PNG/BMP USB photo viewer
MediaXpander®
Compatible with most factory steering wheel audio controls (adapter required)
2 camera input (Rear, Front, Side, Other) configurations
Rearview camera distance guide display
External microphone included
1.0m right angle USB cable included
Specifications
Built-in amplifier (16 watts RMS/45 peak x 4 channels)
3 PreOuts (True 4V)
Subwoofer level control on the third set
24 Bit DAC
3-Band Graphic EQ
9-band Parametric EQ
High pass crossover / low pass crossover
6-channel time correction
CTA-2006 compliant
Alpine iLX-W650 Manual Part 1Alpine iLX-W650 Manual Part 2
Alpine Advanced Bluetooth Mechless Receiver
With advanced Bluetooth® wireless technology, audio streaming, and FLAC support, the UTE-73BT mech-less digital receiver delivers quality phone calls and playback of various digital music files so you stay in touch and in tune.
This one-stop music player has an LCD display with one-line, RGB illumination for your choice of display color. The new high-contrast LCD display has five times the contrast of a conventional screen, so the display is always easy to read.
Alpine's signature rotary knob makes controlling all your music a breeze. This unit also comes with a convenient front panel auxiliary input - so you or your passenger can plug in a portable media player as an additional source.
The UTE-73BT uses a 24-Bit DAC for ultimate sound quality with all your digital media sources. The 3-band parametric EQ and high pass/low pass crossover lets you do fine-tune your sound system. The UTE-73BT can playback FLAC (Free Lossless Audio Codec) files via USB, for a more accurate listening experience.
Don’t get caught holding your phone while driving. The UTE-73BT is equipped with Bluetooth wireless technology so you can carry on your phone conversations without additional adapters or headpieces.
To bring sound balance to your hands-free experience, you can adjust the UTE-73BT’s mic gain, phone output and ringtone volume. If that’s not enough, there are two sound quality settings to choose from to get the balance just right for you. This flexibility will make your phone calls a pleasurable experience.
Specifications
50W x 4 High Power Amp
Built-in Bluetooth Module
BT Audio Streaming
Works with Pandora Music
Mech-less
FLAC/MP3/WMA/AAC Playback
Front USB port
Made for iPod and iPhone (requires KCU-445i)
Siri Eyes Free Mode
Android Open Accessory 2.0
Front AUX Input (3.5mm mini jack)
3-Band Parametric EQ
High-pass/Low-pass Filter
24-Bit DAC
Steering Wheel Remote Control Ready
KTP-445A Power Pack Ready
3 PreOuts (2V)
Hands-free Microphone Included
RGB Lighting
Bass Engine SQ
Radio Broadcast Data System (RBDS) Text Information
Alpine UTE-73BT Manual
The iLX-507 features Apple CarPlay, Android Auto, and built-in bluetooth hands-free which allow access to music, messages, phone calls, and maps on a smartphone via either a wired USB connection or wirelessly. Get even more entertainment options with built-in HD Radio, Pandora Internet Radio (via iPhone or Android connection), and SiriusXM for even more choices in entertainment (tuner and subscription sold separately).
Experience incredible music detail with Hi-Res audio playback. High-precision music reproduction brings out the full potential of every song and makes every drive feel like an intimate recording studio session with your favorite artist. Access your favorite songs on popular Hi-Res streaming services like Apple Music and more. The Alpine iLX-507 plays Hi-Res music at it's intended spec of 96kHz/24Bit via a wired USB connection to a smartphone or wirelessly through Bluetooth connection. You can also purchase and download Hi-Res music files onto a USB drive from platforms like HD-tracks for Hi-Res playback on the iLX-507.
The iLX-507 Works with Apple CarPlay and lets iPhone users make and receive calls, access text messages, play music, and get directions in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touchscreen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later.
The iLX-507 includes Android Auto and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices, and reply to text messages – hands-free.
Enhanced on-board tuning features now include a 13-band parametric EQ per channel, for continuous frequency control. The 6-channel time correction ensures that music is staged properly in the front and center of the vehicle. If more power is needed, additional amplifiers can be added using the three sets of true 4V preamp outputs with front, rear, and subwoofer control.
Experience music as the artist originally intended with the industry’s first full TIDAL integration. The iLX-507 allows you to access select TIDAL features directly on the head unit and receive a high-res streaming experience with the TIDAL catalog of over 90 million songs. Lossless audio and high-fidelity music options are also available for TIDAL HiFi and HiFi Plus members, for superior sound quality that elevates the music experience. A TIDAL subscription is required and sold separately. To access TIDAL on the Alpine head unit, the head unit must be tethered to a mobile or smartphone hotspot. Data rates may apply.
The iLX-507 is compatible with the iDatalink Maestro Module (sold separately) to retain and display vehicle information. Information such as steering wheel controls, tire pressure, engine codes, and HVAC control may be accessible from the iLX-507 (information will vary by vehicle).
The iLX-507 includes two camera inputs to add a front, side, or rearview camera (sold separately). The rearview camera includes a distance guide display that overlays guidelines onto the screen for ease when moving in reverse.
Take driving safety even further by connecting your iLX-507 with the DVR-C320R premium 1080P front and rear dash camera with built-in drive assist (sold separately). View real-time and recorded drives in high definition right on the screen, plus receive drive assist features that help get you to your destination safely.
The new RUX-H02 Alpine Halo subwoofer controller (sold separately) can be mounted to the dash for quick- access controls to the subwoofer and main volume through a wireless bluetooth connection.
Features
7-inch 720p HD Display
Standard Double-Din Fitment
Hi-Res Audio Playback (96kHz / 24bit)
Wireless Hi-Res Audio (requires LDAC compatible device)
Hi-Res Music Streaming with TIDAL (A TIDAL subscription is required and sold separately; Alpine Head Unit must be tethered to a mobile or smartphone hotspot; Data rates may apply)
Apple Carplay® (Wired & Wireless)
Android Auto™ (Wired & Wireless)
The Google Assistant is Available on Android Auto™
Bluetooth® Hands-Free
SiriusXM-Ready® (compatible with SXV300 (G2) add-on tuner, sold separately; SiriusXM subscription required)
Built-in HD Radio®
iDatalink® Maestro Compatible
Alpine DVR-C320E Dash Cam Compatible(sold separately)
Navigation Compatible with KTX-NS01 (sold separately)
Media Xpander®
Specifications
Screen Size: 7”
Screen Resolution: WXGA 1280 x 720px (720p HD)
AUX Input: 1
HDMI Input: 1
HDMI Output: 1
Camera Inputs: 2 Direct (1 Rear input & 1 input that can be set as Front, Side, or Other)
Dash Cam Input: 1 (Alpine DVR-C320R)
USB Inputs: 2 (1 data & 1 charge only port)
4V Pre-Outs: 3
Built-in Amplifier: 18W RMS x 4
EQ: 13-Band Parametric (per channel)
Time Correction: 6-Channel
DAC: 24 Bit
Crossover: High Pass / Low Pass
Audio Playback: AAC, APE, FLAC, MP3, WMA, WAV
Video Playback: AVC, FLV, H.263, H.264, MP4, MPEG-1, MPEG-2, MPEG-4, MKV, MOV
Alpine iLX-507 Tech SheetAlpine iLX-507 Manual Part 1Alpine iLX-507 Manual Part 2
C1-Series 6.5-Inch 50-Watt Component Speaker System
C1 speakers deliver real substance and great audio performance in a format designed for easy fit behind factory grilles.
To facilitate fit, multi-application adaptor rings are included for the C1-650 woofers, allowing easy, drop-in installation in vehicles equipped with oversized 6.5-inch and 6.75-inch speaker openings. Without the ring, the woofers will also fit into many "6-inch" speaker locations as well. Surface and flush mounts are included with C1 tweeters for maximum installation versatility.
C1 woofer drivers benefit from proprietary FEA modeling and JL Audio's expertise in low-frequency driver design. This knowledge is used to create speakers that can play loudly, while maintaining a smooth, dynamic, low distortion sound. At the core of the C1-650 is a proprietary, stamped, steel 6.50-inch (165 mm) frame and a DMA-optimized motor system. A mineral-filled, injection-molded polypropylene cone is suspended with a rubber surround on the front, and a carefully engineered flat Conex® spider at the top of the voice coil, to precisely control the voice coil's motion. Tinsel leads are carefully routed and attached to the spiders to prevent fatigue and buzzing. These are the same kinds of features and materials normally found on much more expensive loudspeakers.
Equipped with a true, edge-driven, aluminum dome tweeter, C1 speakers stand further apart from others in its category with superior high-frequency clarity and definition. The tweeter’s design has inherently excellent off-axis response and high-frequency extension. It also benefits from the damping of a silk surround suspension and Ferrofluid in the voice coil gap, along with the superior strength of a neodymium magnet circuit. An in-line, outboard 2nd order high-pass filter, with Advanced Tweeter Protection Circuitry, is included to further enhance smoothness and improve power handling.
When it comes to value, C1 is the real deal!
Sold as a pair. Grilles not available.
General Specifications
Continuous Power Handling (RMS)
50 W
Peak Music Power
225 W
Recommended Amplifier Power (RMS)
10 - 75 W / Ch.
System Efficiency
91.0 dB @ 1 W / 1 m
System Nominal Impedance
4 Ω
System Frequency Response
59 Hz - 22 KHz ± 3 dB
JL Audio C1-650 Manual
C1-Series 6x9-Inch 60-Watt Component Speaker System
C1 speakers deliver real substance and great audio performance in a format designed for easy fit behind factory grilles.
To facilitate fit, spacer/adaptor rings are included allowing the C1-690 woofers to be installed in bottom-mount applications. Surface and flush mounts are included with C1 tweeters for maximum installation versatility.
C1 woofer drivers benefit from proprietary FEA modeling and JL Audio's expertise in low-frequency driver design. This knowledge is used to create speakers that can play loudly, while maintaining a smooth, dynamic, low distortion sound. At the core of the C1-690 is a proprietary, stamped, steel 6 x 9-inch (150 x 230 mm) oval frame and a DMA-optimized motor system. A mineral-filled, injection-molded polypropylene cone is suspended with a rubber surround on the front, and a carefully engineered flat Conex® spider at the top of the voice coil, to precisely control motion and prevent impact between the voice coil and the back plate. Tinsel leads are carefully routed and attached to the spider to prevent fatigue and buzzing. These are the same kinds of features and materials normally found on much more expensive loudspeakers.
Equipped with a true, edge-driven, 1-inch aluminum dome tweeter, the C1-690 stands further apart from others in its category with superior high-frequency clarity and definition. The tweeter’s design has inherently excellent off-axis response and high-frequency extension. It also benefits from the damping of a silk surround suspension and Ferrofluid in the voice coil gap, along with the superior strength of a neodymium magnet circuit. An in-line, outboard 2nd order high-pass filter, with Advanced Tweeter Protection Circuitry, is included to further enhance smoothness and improve power handling.
When it comes to value, C1 is the real deal!
Sold as a pair. Grilles not available.
General Specifications
Continuous Power Handling (RMS)
60 W
Peak Music Power
225 W
Recommended Amplifier Power (RMS)
10 - 100 W / Ch.
System Efficiency
89.0 dB @ 1 W / 1 m
System Nominal Impedance
4 Ω
System Frequency Response
39 Hz - 22 KHz ± 3 dB
JL Audio C1-690 Manual
6-1/2-Inch Coaxial Speaker Drivers, 100-Watt RMS
The Kicker KS series six-and-a-half-inch coaxial speakers come with three custom bracketing options, built specifically to fit in today’s GM, Chrysler, Subaru, Toyota and Jeep factory speaker locations.
KS series speakers let you play at concert-like volume, yet maintain the smoothness and subtlety to please even the most selective ear. They work best with 15 to 100 watts of recommended power.
High power handling
Tough rubber surrounds
Thin-mount design easily fits behind factory grilles
Brackets for select GM/Chrysler/Subaru/Jeep and Toyota included
Specifications
Speaker Design
2-Way
Woofer [in, mm]
6-1/2, 160
Tweeter [in, mm]
¾, 20
Rated Impedance [Ω]
4
Recommended Amplifier Power [Watts RMS]
15-100
Sensitivity [1W, 1m]
90
Frequency Response [Hz]
43-21k
Mounting Hole Diameter [in, mm]
4-13/16, 123
Top Mount Depth [in, mm]
1-13/16, 46
Bottom Mount Depth [in,mm]
2-3/16, 54
Tweeter Protrusion [in,mm]
5/16, 8
Grilles
Yes
Tweeter Magnet Material
Neodymium
Tweeter Dome Material
Silk
Woofer Cone Material
Polypropylene
Woofer Surround Material
Rubber
Kicker KS Series Coaxial Speaker Manual
C1-Series 6.5-Inch 50-Watt Coaxial Speaker System
C1 speakers deliver real substance and great audio performance in a format designed for easy fit behind factory grilles.
To facilitate fit, multi-application adaptor rings are included with the C1-650x allowing easy, drop-in installation in vehicles equipped with oversized 6.5-inch and 6.75-inch speaker openings. Without the ring, the speaker will fit into many "6-inch" speaker locations as well.
C1 woofer drivers benefit from proprietary FEA modeling and JL Audio's expertise in low-frequency driver design. This knowledge is used to create speakers that can play loudly, while maintaining a smooth, dynamic, low distortion sound. At the core of the C1-650x is a proprietary, stamped, steel 6.50-inch (165 mm) frame and a DMA-optimized motor system. A mineral-filled, injection-molded polypropylene cone is suspended with a rubber surround on the front, and a carefully engineered flat Conex® spider at the top of the voice coil, to precisely control the voice coil's motion. Tinsel leads are carefully routed and attached to the spider to prevent fatigue and buzzing. These are the same kinds of features and materials normally found on much more expensive loudspeakers.
Equipped with a true, edge-driven, aluminum dome tweeter, C1 speakers stand further apart from others in its category with superior high-frequency clarity and definition. The tweeter’s design has inherently excellent off-axis response and high-frequency extension. It also benefits from the damping of a silk surround suspension and Ferrofluid in the voice coil gap, along with the superior strength of a neodymium magnet circuit. A true, 2nd order high-pass filter is employed to further enhance smoothness and improve power handling.
When it comes to value, C1 is the real deal!
Sold as a pair. Grilles not available.
General Specifications
Continuous Power Handling (RMS)
50 W
Peak Music Power
225 W
Recommended Amplifier Power (RMS)
10 - 75 W / Ch.
System Efficiency
90.5 dB @ 1 W / 1 m
System Nominal Impedance
4 Ω
System Frequency Response
48 Hz - 24 KHz ± 3 dB
JL Audio C1-650x Manual
5-1/4-Inch Coaxial Speaker Drivers, 75-Watt RMS
The Kicker KS series five-and-a-quarter-inch coaxial speakers come with three custom bracketing options, built specifically to fit in today’s GM, Chrysler, Subaru, Toyota and Jeep factory speaker locations.
KS series speakers let you play at concert-like volume, yet maintain the smoothness and subtlety to please even the most selective ear. They work best with 15 to 75 watts of recommended power.
High power handling
Tough rubber surrounds
Thin-mount design easily fits behind factory grilles
Brackets for select GM/Chrysler/Subaru/Jeep and Toyota included
Specifications
Speaker Design
2-Way
Woofer [in, mm]
5-1/4, 130
Tweeter [in, mm]
¾, 20
Rated Impedance [Ω]
4
Recommended Amplifier Power [Watts RMS]
15-75
Sensitivity [1W, 1m]
90
Frequency Response [Hz]
45-21k
Mounting Hole Diameter [in, mm]
4-1/2, 115
Top Mount Depth [in, mm]
1-3/4, 45
Bottom Mount Depth [in,mm]
2, 52
Tweeter Protrusion [in,mm]
1/4, 6
Grilles
Yes
Tweeter Magnet Material
Neodymium
Tweeter Dome Material
Silk
Woofer Cone Material
Polypropylene
Woofer Surround Material
Rubber
Kicker KS Series Coaxial Speaker Manual
Six-by-Eight-Inch Coaxial Speaker Drivers, 75-Watt RMS
The Kicker KS series six-by-8-inch coaxial speakers let you play at concert-like volume, yet maintain the smoothness and subtlety to please even the most selective ear. They work best with 15 to 75 watts of recommended power.
High power handling
Tough rubber surrounds
Thin-mount design easily fits behind factory grilles
Brackets for select GM/Chrysler/Subaru/Jeep and Toyota included
Specifications
Speaker Design
2-Way
Woofer [in, mm]
6 x 8, 160 x 200
Tweeter [in, mm]
¾, 20
Rated Impedance [Ω]
4
Recommended Amplifier Power [Watts RMS]
15-75
Sensitivity [1W, 1m]
90
Frequency Response [Hz]
45-21k
Mounting Hole Diameter [in, mm]
5 x 7-3/16, 127 x 182
Top Mount Depth [in, mm]
2-1/4, 58
Bottom Mount Depth [in,mm]
2-5/8, 67
Tweeter Protrusion [in,mm]
1/16, 2
Grilles
No
Tweeter Magnet Material
Neodymium
Tweeter Dome Material
Silk
Woofer Cone Material
Polypropylene
Woofer Surround Material
Rubber
Kicker KS Series Coaxial Speaker Manual
100-Watt 6.5-Inch Coaxial Speakers, 4-Ohm
These CS series 6.5" coaxial speakers by Kicker are a significant upgrade in your sound. A stamped-steel speaker driver chassis supports a rigid polypropylene cone and UV-treated foam surrounds that stand up to heat and direct sunlight. These 100W coaxial's have neodymium tweeter magnets allow for increased volume in high frequencies.
These Kicker CS series 6 and a 1/2" speakers work best with 100 watts of recommended power.
Specifications
Speaker Design
2 - way
Woofer Size | in [mm]
6 1/2 [160]
Tweeter Size | in [mm]
1/2 [13]
DC Resistance | ohm
3.3
Peak Power | Watts
300
Continuous Power | Watts, RMS
100
Sensitivity [SPLo] | dB @ 1W, 1m
90
Effective Frequency Range | Hz
40-20k
Mounting Hole Diameter | in [mm]
4 13/16 [123]
Top Mount Depth | in [mm]
3/8 [9]
Bottom Mount Depth | in [mm]
1 11/16 [43]
Tweeter Protrusion | in [mm]
0
Grilles
Yes
Tweeter Magnet Material
Neodymium
Tweeter Dome Material
PEI [polyether imide]
Tweeter Design
Balanced dome
Woofer Cone Material
Polypropylene
Woofer Surround Material
Polyester foam
Kicker CS Series Coaxial Speaker Manual
Six-by-Nine-Inch 3-Way Coaxial Speaker Drivers, 150-Watt RMS
The Kicker KS series 6x9-inch 3-way coaxial speakers come with custom bracketing options, built specifically to fit in today’s GM, Chrysler, Subaru, Toyota and Jeep factory speaker locations.
KS series speakers let you play at concert-like volume, yet maintain the smoothness and subtlety to please even the most selective ear. They work best with 15 to 150 watts of recommended power.
High power handling
Tough rubber surrounds
Thin-mount design easily fits behind factory grilles
Brackets for select GM/Chrysler/Subaru/Jeep and Toyota included
Specifications
Speaker Design
2-Way
Woofer [in, mm]
6 x 9, 160 x 230
Midrange [in, mm]
1, 25
Tweeter [in, mm]
3/4, 20
Rated Impedance [Ω]
4
Recommended Amplifier Power [Watts RMS]
15-150
Sensitivity [1W, 1m]
92
Frequency Response [Hz]
30-21k
Mounting Hole Diameter [in, mm]
5-11/16 x 8-7/16, 144 x 215
Top Mount Depth [in, mm]
3-1/8, 80
Bottom Mount Depth [in,mm]
3-5/8, 92
Tweeter Protrusion [in,mm]
3/16, 5
Grilles
Yes
Tweeter Magnet Material
Neodymium
Tweeter Dome Material
Silk
Woofer Cone Material
Polypropylene
Woofer Surround Material
Rubber
Kicker KS Series Coaxial Speaker Manual
C3-Series 6.5-Inch 75-Watt Convertible Component Speaker System
There are times when an installation calls for a separate woofer and tweeter and other times when a coaxial is the better approach. With the Evolution® C3 Convertible Component Systems, the same product can be deployed in either configuration, delivering outstanding audio power and quality in each application.
The C3-650 system features 6.5-inch (165 mm) component woofers with oversized 1.2-inch (30.5 mm) voice coils, mineral-filled polypropylene cones and injection-molded polymer baskets. The woofer design benefits from JL Audio's vast woofer design experience and advanced modeling systems.
The C3 tweeters are built with 1-inch silk dome diaphragms that deliver powerful, extended response, on and off axis. Flush-mounting and surface-mounting fixtures are included to fit a wide variety of installation needs. They can also be mounted onto the woofers in a coaxial format using the included fixtures.
C3 crossover networks are compact and built with premium component parts, including Mylar® capacitors and segmented air-core inductors. Four levels of tweeter attenuation are provided, as well as three levels of mid-range presence adjustment, for twelve possible voicing combinations!
Woofer grilles are included, each consisting of a black grille tray and a black steel mesh grille with an electroformed JL Audio logo.
Sonic character: Clean and Powerful
Sold as a pair.
General Specifications
Continuous Power Handling (RMS)
75 W
Peak Music Power
225 W
Recommended Amplifier Power (RMS)
25 - 150 W / Ch.
System Efficiency
90.0 dB @ 1 W / 1 m
System Nominal Impedance
4 Ω
System Frequency Response
48 Hz - 25 KHz ± 3 dB
JL Audio C3-650 Manual
