Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Amplified and Non-Amplified Head-Unit Replacement Wiring-Harness Interface for Select 2012-2016 Chevy and GMC Vehicles with Factory Navigation
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (Retained Accessory Power)
Provides NAV output (parking brake, reverse and speed sense)
Retains chimes
Retains audio controls on the steering wheel
Retains OnStar®/OEM Bluetooth®
Adjustable volume for OnStar®
Retains the factory AUX-IN jack
Can be used in non-amplified, or analog/digital amplified models
Retains balance and fade (excluding digital amplified models)
Micro-B USB updatable
Applications
Chevrolet
Avalanche 2012-2013 (1) (3)
Express 2013-2015 (3)
Malibu (with monochrome display) 2013-2015
Malibu Limited (with monochrome display) 2016
Silverado 2500 / 3500 2014 (1) (3)
Silverado 2012-2013 (1) (3)
Suburban 2012-2014 (2) (3)
Tahoe 2012-2014 (2) (3)
Trax 2015-2016
GMC
Savana 2013-2015 (3)
Sierra 2500 / 3500 2014 (1) (3)
Sierra 2012-2013 (1) (3)
Yukon / Yukon XL 2012-2014 (2) (3)
(1) These vehicles have a digital amp option. Please reference the “Service Parts Identification” sticker located in the glove box for the RPO code Y91. If Y91 is present, then the vehicle is equipped witha digital amplifier.
(2) These vehicles have a digital amp option. Please reference the “Service Parts Identification” sticker located in the glove box for the RPO codes; Y91, STZ, UQS. If Y91, STZ or UQS is present, then thevehicle is equipped with a digital amplifier.
(3) Only for models with NAV.
Axxess AXDIS-GMLN44 Installation Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Amplifier Add-On OEM Line-Converter T-Harness for Select 2006-2013 Non-Amplified BMW and MINI Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
BMW
1 Series
2008-2013
3 Series
2006-2013
M3
2007-2013
MINI
Cooper
2007-2015
Axxess AXDSPH-BM1 ManualAxxess AXDSPL-BM1 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Amplifier Add-On OEM Line-Converter T-Harness for Select 2011-UP Amplified and Non-Amplified Chrysler Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
CHRYSLER
300
2011-2014
DODGE
Charger
2011-2014
Journey
2011-2022
Axxess AXDSPH-CH3 ManualAxxess AXDSPL-CH3 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2007-2017 Amplified and Non-Amplified Chrysler and Jeep Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
JEEP
Grand Cherokee
2011-2013
Wrangler (JK)
2007-2017
RAM
1500
2010-2012
Axxess AXDSPH-CH4 ManualAxxess AXDSPL-CH4 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2014-UP Amplified and Non-Amplified Chrysler and Jeep Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
CHRYSLER
200
2015-2017
300
2015-2022
Pacifica
2017-2020
DODGE
Challenger
2015-2022
Charger
2015-2022
Durango
2014-2020
Viper
2015-2017
JEEP
Cherokee
2014-2020
Compass
2017-2022
Grand Cherokee
2014-2022
Wrangler (JL)
2018-2022
RAM
1500
2013-2021
Axxess AXDSPH-CH5 ManualAxxess AXDSPL-CH5 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2020-UP Non-Amplified Chrysler, Dodge, Jeep and RAM Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
CHRYSLER
Pacifica
2021-2022
DODGE
Durango
2021-2022
Voyager
2022
JEEP
Compass
2022
Grand Wagoneer
2022
RAM
1500
2022
2500/3500
2022
Promaster
2022
Axxess AXDSPH-CH8 ManualAxxess AXDSPL-CH8 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2006-2014 Amplified and Non-Amplified Ford Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
FORD
Edge
2007-2010
Escape
2008-2012
Expedition
2007-2014
F-150
2006-2013
Flex
2009-2012
Focus
2008-2011
Fusion
2006-2012
Mustang
2006-2014
Taurus
2008-2011
Axxess AXDSPH-FD1 ManualAxxess AXDSPL-FD1 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2016-UP Non-Amplified Ford Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
FORD
Bronco
2020-2023
Bronco Sport
2020-2023
EcoSport
2020-2022
Escape
2020-2022
E series
2021-2022
Explorer
2020-2022
F-150
2021-2022
Axxess AXDSPH-FD3 ManualAxxess AXDSPL-FD3 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2014-2020 Non-Amplified Chevrolet and GMC Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
CHEVY
Colorado
2015-2019
Cruze
2016-2018
Equinox
2018
Malibu
2016-2018
Silverado (LD)
2019
Silverado
2014-2018
Suburban
2015-2020
Tahoe
2015-2020
GMC
Canyon
2015-2018
Sierra Limited
2019
Sierra
2014-2018
Yukon
2015-2018
Axxess AXDSPH-GL9 ManualAxxess AXDSPL-GL9 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2011-UP Non-Amplified Hyundai and KIA Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
HYUNDAI
Accent
2012-2017
Genesis Coupe
2014-2016
Sonata
2011-2017
KIA
Forte
2014-2018
Niro (Hybrid Electrical)
2017-2019
Optima
2011-2018
Rio
2012-2017
Sedona
2015-2022
Sorento
2014-2018
Soul
2012-2016
Soul EV
2015-2019
Sportage
2011-2016
Axxess AXDSPH-HK1 ManualAxxess AXDSPL-HK1 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2017-UP Non-Amplified Hyundai and KIA Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
HYUNDAI
Elantra
2017-2020
Elantra GT
2018-2022
KIA
Cadenza
2017-2020
Forte
2017-2022
Niro (EV)
2019-2020
Niro (Hybrid Electrical)
2017-2022
Niro (Plug-In Hybrid)
2018-2020
Optima
2019-2022
Rio
2018-2022
Sedona
2017-2022
Sorento
2017-2022
Soul
2017-2022
Soul EV
2017-2022
Sportage
2017-2022
Axxess AXDSPH-HK3 ManualAxxess AXDSPL-HK3 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2016-UP Non-Amplified Honda Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
HONDA
Accord
2016-2022
Civic / Si
2016-2019
CR-V
2017-2020
Axxess AXDSPH-HN2 ManualAxxess AXDSPL-HN2 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2008-2017 Amplified and Non-Amplified Nissan Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
NISSAN
2013
Altima (Coupe)
2010-2012
Altima
2008-2017
Armada
2009-2014
Maxima
2009-2014
Murano
2011-2012
Murano Cabriolet
2016
Pathfinder S
Axxess AXDSPH-NI2 ManualAxxess AXDSPL-NI2 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2018-UP Amplified and Non-Amplified Scion and Toyota Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
TOYOTA
4Runner
2020-2022
Avalon
2019-2022
Camry
2018-2022
C-HR
2019-2022
Highlander
2020-2022
Mirai
2016-2022
RAV-4
2019-2022
Sequoia
2020-2022
Axxess AXDSPH-TY3 ManualAxxess AXDSPL-TY3 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2003-2017 Non-Amplified Volkswagen Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
VOLKSWAGON
Beetle
2012-2014
CC
2009-2017
EOS
2007-2016
Golf
2002-2014
Golf R
2012-2013
GTI
2002-2014
Jetta GLI
2002-2015
Jetta Sportwagen
2010-2014
Passat
2002-2015
Rabbit
2007-2009
Tiguan
2009-2015
Excludes models equipped with a Fender sound system
Axxess AXDSPH-VW1 ManualAxxess AXDSPL-VW1 Manual
Amplifier Add-On OEM Line-Converter T-Harness for Select 2006-2020 Non-Amplified Volkswagen Vehicles
For use with the Axxess AXDSP-L line converter.
Applications - confirmed as of 2/7/2023
VOLKSWAGON
Beetle
2015-2016
Golf
2016-2019
Jetta
2016-2020
Passat
2016-2018
Axxess AXDSPH-VW2 ManualAxxess AXDSPL-VW2 Manual
Add-On Amplifier OEM Integration Interface for Select 2001-2017 Non-Amplified BMW, MINI and Volkswagen Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-BM1 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications
BMW
3 Series 2002-2006
5 Series 2001-2003
M3 2002-2006
X3 2004-2010
X5 2001-2006
Z4 2003-2008
MINI
Clubman 2008-2014
Convertible 2009-2015
Coupe 2012-2015
Hatchback 2007-2013
Roadster 2012-2015
Volkswagon
Beetle 2012-2015
CC 2009-2017
EOS 2007-2016
Golf 2002-2014
GTI 2006-2014
Jetta 2002-2015
Jetta Sportwagon 2010-2014
Passat 2002-2015
R32 2007-2008
Tiguan 2009-2015
Touareg 2004-2010
Axxess AXLOC-BM1 Manual
Add-On Amplifier OEM Integration Interface for Select 2011-2020 Non-Amplified Chrysler and Dodge Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-CH3 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/5/2023
Chrysler
300 2011-2014
300C 2011-2014
Dodge
Charger 2011-2014
Journey 2011-2020
Axxess AXLOC-CH3 Manual
Add-On Amplifier OEM Integration Interface for Select 2007-2021 Non-Amplified Chrysler, Dodge and Jeep Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-CH4 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/5/2023
Chrysler
200 2011-2014
300 2008-2010
Aspen 2008-2009
Sebring 2007-2010
Town & Country 2008-2017
Dodge
Avenger 2008-2014
Caliber 2009-2012
Caravan 2008-2020
Grand Caravan 2008-2020
Challenger 2008-2014
Charger 2008-2010
Dakota 2008-2011
Durango 2008-2013
Journey 2009-2010
Magnum 2008-2009
RAM 2009-2011
Jeep
Commander 2008-2010
Compass 2009-2017
Grand Cherokee 2008-2013
Liberty 2008-2012
Patriot 2009-2017
Wrangler(JK) 2007-2021
Axxess AXLOC-CH4 Manual
Add-On Amplifier OEM Integration Interface for Select 2007-2021 Non-Amplified Chrysler, Dodge, Fiat, Jeep and RAM Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
INTERFACE COMPONENTS
AXLOC-CH5 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/5/2023
Chrysler
200 2015-2017
Pacifica 2017-2020
Dodge
Dart 2011-2014
Durango 2011-2020
1500, 2500, 3500 2013-Up
Fiat
500 2016-2019
500L 2014-2020
500X 2016-2021
Jeep
Cherokee 2013-2021
Compass 2017-2021
Renegade 2015-2021
RAM
Chassis Cab 2500/3500/4500/5500 2013-2021
Promaster 1500/2500/3500 2014-2021
Promaster City 2015-2021
Axxess AXLOC-CH5 Manual
Add-On Amplifier OEM Integration Interface for Select 2003-2019 Non-Amplified Ford, Lincoln, Mazda and Mercury Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-FD1 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Ford
Crown Victoria 2003-2011
E-Series 2014-2019
Econoline 2009-2013
Edge 2007-2010
Escape 2008-2012
Expedition 2003-2015
Explorer 2006-2010
F-150 2004-2014
F250/350/450/550 2005-2016
F650/750 2011-2019
Five Hundred 2005-2007
Flex 2009-2012
Focus 2005-2011
Freestar 2004-2007
Freestyle 2005-2007
Fusion 2006-2012
Mustang 2004-2014
Taurus 2008-2012
Thunderbird 2004-2005
Transit Connect 2010-2013
Lincoln
LS 2003-2006
MKX 2007-2010
MKZ 2007-2009
Navigator 2003-2006
Town Car 2003-2011
Zephyr 2006
Mazda
Tribute 2008-2011
Mercury
Grand Marquis 2003-2011
Mariner 2005-2011
Milan 2006-2011
Montego 2005-2007
Monterey 2004-2007
Mountaineer 2006-2010
Sable 2008-2009
Axxess AXLOC-FD1 Manual
Add-On Amplifier OEM Integration Interface for Select 2011-2021 Non-Amplified Ford Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-FD2 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Ford
Edge 2011-2020
Escape 2013-2019
Explorer 2011-2019
F-150 2013-2020
F250/350/450/550 2017-2019
Fiesta 2011-2021
Focus 2012-2018
Fusion 2013-2019
Mustang 2015-2020
Ranger 2019-2020
Transit 150/250/350 2015-2019
Transit Connect 2014-2018
Axxess AXLOC-FD2 Manual
Add-On Amplifier OEM Integration Interface for Select 2019-2021 Non-Amplified Chevy and GMC Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Note: A single pole double throw (SPDT) relay is recommended when installing multiple amplifiers.
Contents
AXLOC-GM31 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Chevy
Camaro (RPO IOR) 2019-2021
Cheyenne (RPO IOR) 2019-2021
Colorado (RPO IOR) 2019-2021
Cruze 2019
Equinox (RPO IOR) 2019-2021
Malibu (RPO IOR) 2019-2021
Silverado (RPO IOR) 2019-2021
Sonic 2019-2021
Spark (RPO IOR) 2019-2021
GMC
Canyon (RPO IOR) 2019-2021
Sierra (RPO IOR) 2019-2021
Terrain (RPO IOR) 2019-2021
Axxess AXLOC-GM31 Manual
Add-On Amplifier OEM Integration Interface for Select 2010-2017 Non-Amplified Chevy and GMC Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-GM44 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Chevy
Avalanche 2012-2013
Camaro 2010-2015
Cruze 2011-2015
Equinox 2010-2017
Express 2013-2015
Malibu 2013-2015
Sonic 2012-2014
Spark 2013-2015
Suburban 2012-2014
Tahoe 2012-2014
Trax 2015-2016
GMC
Savana 2013-2015
Sierra 2012-2013
Terrain 2010-2017
Yukon/XL 2012-2014
Axxess AXLOC-GM44 Manual
Add-On Amplifier OEM Integration Interface for Select 2006-2021 Non-Amplified Buick, Cadillac, Chevy, GMC, Hummer, Pontiac, Saturn and Suzuki Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-GMLN1 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Buick
Lucerne 2006-2011
Cadillac
DTS 2006-2011
Escalade 2007-2014
SRX 2007-2009
Chevrolet
Avalanche 2007-2013
Captiva Sport 2012-2015
Cheyenne (RPO IOB) 2016-2018
Cheyenne 2012-2014
Equinox 2007-2009
Express van (Full Size) 2008-2021
Impala Limited (Fleet) 2014
Impala 2006-2013
Monte Carlo 2006-2007
Silverado Pickup 2007-2013
Spark (RPO IOB) 2016-2018
Suburban 2007-2014
Tahoe 2007-2014
Traverse 2009-2017
GMC
Acadia 2007-2016
Savana Full Size Van 2008-2014
Sierra (New Body) 2007-2013
Sierra 2500/3500 2014
Yukon XL / Denali 2007-2014
Yukon 2007-2014
Hummer
H2 2008-2009
Pontiac
Torrent 2007-2009
Saturn
Outlook 2007-2009
VUE 2008-2009
Suzuki
XL-7 2007-2009
Axxess AXLOC-GMLN1 Manual
Add-On Amplifier OEM Integration Interface for Select 2016-2020 Non-Amplified Chevy and GMC Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-GM10 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Chevrolet
Camaro 2016-2018 ‡
Colorado 2016-2018 ‡
Cruze 2016-2018 †
Equinox 2018-2018 ‡
Malibu 2016-2018 †
Silverado LD 2019-2019 ‡
Silverado 2016-2018 ‡
Silverado 2500/3500 2016-2019 ‡
Trax 2017-2020 †
GMC
Acadia 2017-2019 ‡
Canyon 2017-2018 ‡
Sierra 2016-2018 ‡
Sierra Limited 2019-2019 ‡
Sierra 2500/2500 HD 2016-2019 ‡
† RPO IOA‡ RPO IOB
Axxess AXLOC-GMLN10 Manual
Add-On Amplifier OEM Integration Interface for Select 2008-2021 Non-Amplified Acura and Honda Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-HN2 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Acura
TL 2009-2014
TSX 2009-2014
ZDX 2010-2013
Honda
Accord 2008-2012
Civic 2009-2015
CR-V 2012-2016
Fit 2009-2017
HR-V 2016-2018
Insight 2010-2014
Odyssey 2011-2017
Pilot 2009-2017
Ridgeline 2009-2021
Axxess AXLOC-HN2 Manual
Add-On Amplifier OEM Integration Interface for Select 2016-2021 Non-Amplified Honda Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-HN3 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Honda
Civic 2016-2018
Civic Hatchback 2017-2018
CR-V 2017-2021
Fit 2018-2021
HR-V 2019-2021
Insight 2019-2021
Axxess AXLOC-HN3 Manual
Add-On Amplifier OEM Integration Interface for Select 2016-2021 Non-Amplified Hyundai and KIA Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-HYKIA3 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Hyundai
Accent 2018-2021
Elantra 2017-2021
Elantra GT 2018-2021
IONIQ 2018-2021
Kona 2018-2021
Santa Fe 2019-2021
Santa Fe XL 2019
Sonata 2018-2021
Tucson 2019-2021
Veloster 2019-2021
KIA
Cadenza 2017-2021
Forte 2017-2021
Forte 5 2017-2021
K5 2021-2021
Optima 2019- 2020
Sedona 2017-2021
Sorento 2017-2021
Stinger 2018-2021
Axxess AXLOC-HYKIA3 Manual
Add-On Amplifier OEM Integration Interface for Select 1995-2013 Non-Amplified Infinity and Nissan Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-NIS Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications
Infiniti
FX35 2003-2008
FX45 2003-2008
G20 1995-1996
Nissan
200SX 1995-1998
240SX 1995-1998
350Z 2003-2009
Altima 1995-2006
Armada 2004-2007
Frontier 1998-2012
Hardbody Pickup 1995-1997
Maxima 1995-2006
Murano 2003-2007
Pathfinder S 2008-2012
Pathfinder 1995-2007
Pathfinder Armada 2004-2005
Quest 2004-2009
Sentra 1995-2006
Titan 2004-2012
Xterra 2000-2013
Axxess AXLOC-NIS Manual
Add-On Amplifier OEM Integration Interface for Select 2007-2021 Non-Amplified Nissan, Subaru and Suzuki Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-NIS1 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Nissan
370Z 2009-2021
Altima 2007-2021
Cube 2009-2014
Frontier 2008-2021
Juke 2011-2017
Kicks 2018-2021
Leaf 2012-2021
Maxima 2007-2021
Murano 2009-2021
Murano (Cross-Cabriolet) 2011-2014
NV – 1500/2500/3500 2012-2021
NV200 2013-2021
Pathfinder 2013-2020
Quest 2011-2016
Rogue 2008-2017
Sentra 2007-2019
Titan, Titan XD 2017-2021
Titan 2008-2015
Versa 2007-2021
Versa Note 2014-2019
Xterra 2008-2015
Subaru
Forester 2009-2015
Impreza 2008-2014
Legacy 2010-2014
Outback 2010-2014
WRX 2015
XV Crosstrek 2013-2014
Suzuki
Equator 2009-2011
Axxess AXLOC-NIS1 Manual
Add-On Amplifier OEM Integration Interface for Select 1987-2020 Non-Amplified Toyota Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-TY1 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Toyota
4Runner 1987-2019
86 2017-2020
Avalon 1995-2018
C-HR 2018-2018
Solara 1999-2008
Camry 1987-2017
Celica 1989-2005
Corolla 1987-2019
Cressida 1987-1992
Echo 2000-2005
FJ Cruiser 2007-2014
Highlander 2001-2019
Land Cruiser 1988-1993
Matrix 2005-2013
MR2 1987-1995
MR2 Spyder 2000-2005
Paseo 1992-1997
Pickup 1987-1995
Previa 1991-1997
Prius 2001-2019
Prius C 2012-2019
Prius Prime 2017-2020
Prius V 2012-2017
RAV-4 1996-2018
Sequoia 2001-2019
Sienna 1996-2017
Solara 1999-2008
Supra 1986-1992
T-100 1993-1998
Tacoma 1995-2019
Tundra 2000-2019
Van 1987-1990
Venza 2009-2015
Yaris 2007-2018
Axxess AXLOC-TY1 Manual
Pre-Order Today! - we will notify you when to pick-up or to schedule an installation!
Add-On Amplifier OEM Integration Interface for Select 2018-2021 Non-Amplified Toyota Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-TY3 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Toyota
4Runner 2020-2021
Avalon 2019-2021
C-HR 2019-2021
Camry 2018-2021
Corolla 2019-2021
Highlander 2020-2021
Prius 2020-2021
RAV-4 2019-2021
Sequoia 2020-2021
Sienna 2018-2021
Tacoma 2020-2021
Tundra 2020-2021
Axxess AXLOC-TY3 Manual
Add-On Amplifier OEM Integration Interface for Select 2015-2021 Non-Amplified Volkswagen Vehicles
This vehicle-specific line output converter features a T-harness that installs quickly and makes it easy for installers to add an amplifier for subwoofers or speakers to a factory radio. It is designed to provide (2) channels of low-level audio output from the factory system, with 55 watts per channel. A Gain Controller is included to adjust overall output, and it is 12v-500mA remote-wire activated with signal sense.
Designed to provide (2) channels of low-level audio output from the factory system
Allows for the installation of an amplifier for speakers or subwoofers
Gain Controller included to adjust the overall output
12v-500mA remote wire activated with signal sense
55 watts per channel
Contents
AXLOC-VW2 Wiring Harness
Gain Controller
12v-500mA Remote Wire
Auxiliary Cable
Applications - confirmed as of 2/6/2023
Volkswagen
Beetle 2016-2021
Golf 2015-2021
Jetta 2016-2021
Passat 2016-2021
Tiguan 2016-2021
Axxess AXLOC-VW2 Manual
