Dual 10-Inch 2-Ohm 800-Watt Thin Subwoofer-Enclosure for Select 2019-UP Chevrolet-Silverado and GMC-Sierra Double-Cab Trucks
The fourth generation of GM’s full-size truck boasts major enhancements in technology and power, all packed in a larger body with a refined interior. Sadly, the factory audio options are still deficient in the bass delivery department.
JL Audio's Stealthbox® for the Double Cab version features an all-fiberglass, sealed enclosure design that mounts under the rear seat and requires no holes to be drilled for installation. Outfitted with a pair of JL's revolutionary 10TW3 thin-line subwoofers, this Stealthbox® fills your truck with stunning amounts of JL Audio bass, with no intrusion on cab space. They even left a recess on the Stealthbox's top for amplifier installation, if desired.
The Hard Data: Contains two 10TW3-D8 subwoofers in a down-firing sealed enclosure. 800 watt power handling. Wired for a 2 ohm load. Installs under rear bench seat. Will not affect the folding of the rear seat or rear leg room. Requires removal of under-seat storage tray, if so equipped.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
CHEVROLET
Silverado 1500, 2500, 3500
Double Cab
2019-2025
GMC
Sierra 1500, 2500, 3500
Double Cab
2019-2025
JL Audio SB-GM-SLVD4/10TW3 Installation Manual
TW1-Series 400-Watt Amplified 10-Inch Subwoofer System
In PowerWedge+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this subwoofer system employs JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Harnessing the performance and insanely small box requirements of the TW1 subwoofer driver, this subwoofer system is designed to deliver amazing sub-bass from an enclosure that is only 5 inches (127 mm) deep. Its low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10TW1 driver and has been fine-tuned through extensive real-world listening.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
Enclosure and Subwoofer Built in USA with global components
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
W1-Series 10-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The JL Audio 10" W1v3 subwoofer driver is a very suitable option when space is limited with smaller amplifiers. It features a low mounting depth of 4.6 inches and a compact motor structure that allows it to comfortably fit in tight mounting locations. There is no pole vent on the rear of the subwoofer which allows the motor structure to be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow the 10W1v3 to reproduce sub-bass with shocking extension and quality.
The JL Audio 10W1v3 is best used with an amplifier in the 75W - 300W RMS range and is optimized to operate in a compact 0.55 cu. ft. (15.57 l) sealed enclosure.
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
2Ω/4Ω
JL Audio 10W1v3 Manual
10-Inch 250-Watt Thin Subwoofer Enclosure, 2-Ohm Final Impedance
The CompC Thin Profile 10-Inch Subwoofer Enclosure includes a single 2 Ohm terminal.
Features:
Fits Perfectly Under Or Behind A Seat
Genuine CompC Subwoofer Reengineered for Increased Excursion and Deeper Bass
Sub Incorporates Forced-Air Cooling™ for Outstanding Durability
Custom Port Design
Made Of Heavy MDF
Spring Loaded Speaker Terminal
Thick Black Carpet Protects the Enclosure
Emblazoned KICKER Logo
This enclosure works best with 250 watts of recommended power. See below for more details.
Specifications
Subwoofer (in, cm)
10, 25
Impedance (Ohms)
2
Recommended Amplifier Power (watts RMS)
250
Peak Power (watts, per ANSI/CTA-2031-A)
500
Sensitivity (dB 1w/1m)
91
Box Top Depth (in, cm)
4 3/8, 11
Box Bottom Depth (in, cm)
7 7/8, 20
Box Height (in, cm)
15, 38.1
Box Width (in, cm)
21 1/2, 54.6
Kicker CompC Subwoofer Enclosure Manual
StowAway-Series 10-Inch 300-Watt Enclosed Subwoofer System, 2-Ohm or 4-Ohm Downfiring Sealed Enclosure
JL-Audio StowAway subwoofer systems are engineered to deliver amazing subwoofer performance in challenging environments and applications.
Featuring a down-firing hard-shell design, StowAway subwoofers are well suited for mounting areas shared with cargo or exposed to the elements. Constructed from marine-grade materials, this low-profile enclosure design harnesses the incredible small box requirements of the TW1 subwoofer to generate smooth and powerful bass from a remarkably compact enclosure. Slotted mounting feet located at each corner of the enclosure’s base assist with “off-the-floor” installations or in tight spaces where access is limited.
The StowAway subwoofer system is prewired with selectable harness exits located underneath at opposite ends.
Finish: black texture with debossed logo on top; a protective mesh grille is included to protect the subwoofer
Recommended amplifier power: 75–300 watts
Nominal impedance: 2 ohms
Note: Mounting hardware is not included with StowAway systems. The installation method and mounting hardware used will vary based on the requirements of your specific application. The final mounting method must affix the enclosure securely to prevent movement and vibration.
Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed
Finish
Black Texture
Grille Included
Yes
Physical Specifications
Height (H)
7.0 in / 178 mm
Width (W)
18.0 in / 457 mm
Depth (D)
12.5 in / 318 mm
JL Audio PES110-TW1 Manual
Single 400-Watt 2-Ohm 10-Inch Stealthbox Subwoofer Enclosure for Select 2015-UP Ford F-150 SuperCab and 2017-UP SuperDuty SuperCab Trucks
Benefitting from JL's revolutionary thin-woofer technology, this Stealthbox® for F-150 SuperCab and SuperDuty SuperCab trucks is designed to install neatly under the rear seat with no intrusion on cab space.
Featuring an all-fiberglass, sealed enclosure design, JL's Stealthbox® houses a 10-inch TW3 thin-line subwoofer and fills your truck with loads of deep bass output. Seat folding and reclining are unaffected, and JL even incorporated a recess on the Stealthbox’s top for mounting an amplifier, if desired.
The Hard Data: Contains one 10TW3-D4 subwoofer in a sealed enclosure. 400 watt power handling. Wired for 2 ohm mono. Installs under rear bench seat and requires removal of the storage divider panel. Stealthbox® includes a steel-mesh grille to protect the driver. Does not affect folding or reclining of seat.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
F-150
SuperCab
2015-2025
F-250, 350, 450, 550
SuperCab
2017-2025
JL Audio SB-F-F150SPRCB/10TW3 Installation Manual
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2010-2015 Toyota-Tacoma Access-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Fits: 2010-2015 Toyota Tacoma Access Cab Trucks
Installs between rear center seats
Mounting Depth: 8.5"
Volume: .96 cu.ft
Installation Note: Removal of the rear armrest is required along with Temporary removal of the front console which helps during installation. Does not affect rear seating.
10-Inch 2-Ohm 300-Watt Subwoofer-Enclosure for Select 2007-2013 Chevrolet and GMC Full-Size SUV’s or Trucks with Front-Bucket-Seats
This generation of GM's big trucks and SUV's sets new standards for interior quality and luxury. There also isn't much wasted space in which to install a conventional subwoofer design without giving up cargo and people space.
JL's Stealthbox® solution installs inside the forward section of the factory center console for complete invisibility. Intense, up-front bass is produced by a down-firing 10-inch subwoofer in a sealed enclosure. The console's functionality and storage space is unaffected by the Stealthbox®.
The Hard Data: Contains one 10W1v3-2 in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Stealthbox® installs inside forward-most portion of front center console and replaces the OEM “subwoofer” system, if vehicle is so equipped. Will not fit Trucks with AC vents on the back of the center console or vehicles with deep storage area in front of cup holders. Will not fit Full-Size “Classic” Trucks, Chevrolet SSR, Cadillac Escalade, Cadillac Escalade ESV, Cadillac Escalade EXT, Hummer H2, Hummer H2 SUT.
Applications
CHEVROLET
Avalanche
2007-2013
Silverado 1500, 2500 HD, 3500 HD
2007-2013
Suburban
2007-2013
Tahoe
2007-2013
Yukon
2007-2013
Yukon XL
2007-2013
GMC
Sierra 1500, 2500 HD, 3500 HD
2007-2013
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-TAHOCNSL/10W1v3 Installation Manual
BassWedge-Series 10-Inch 300-Watt Enclosed Subwoofer System, 4Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofer to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofer firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 4 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
4 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
15.51 in / 394 mm
External Height (H)
13.77 in / 350 mm
External Depth (D1)
17.38 in / 441 mm
External Top Surface Depth (D2)
14 in / 356 mm
Net Weight
29 lb / 13.15 kg
JL Audio CP110-W0v3 Brochure
W0-Series 10-Inch 300-Watt Subwoofer Driver, 4-Ohm SVC
The JL Audio 10" W0v3 subwoofer driver is a rugged performer with excellent excursion capability and linearity while sporting a 2 inch diameter voice coil and JL's patented Elevated Frame Cooling design for enhanced power handling and reliability.
This 10 inch subwoofer is best used with an amplifier in the 75W - 300W range and is optimized to operate in a compact 0.65 cu. ft. (18.4 l) sealed enclosure, or a 1.125 cu. ft. (31.9 l) ported enclosure.
General Specifications
Continuous Power Handling (RMS)
300W RMS
Recommended Amplifier Power (RMS)
75W - 300W RMS
Nominal Impedance (Znom)
4Ω
JL Audio 10W0v3 Manual
Alpine S2-Series 600-Watt 10-Inch Subwoofer Driver, 2Ω or 4Ω Dual Voice Coil
With an impressive power handling of 600W RMS and a peak power handling of 1800W, the Next-Gen 10” S-Series Subwoofers deliver outstanding performance value. Boasting a wide frequency response range of 25Hz to 215Hz and a sensitivity of 85dB (1W/1m), these subs ensure powerful and accurate bass reproduction across a diverse range of music genres.
Featuring the lightweight yet sturdy combination of carbon fiber and polypropylene, the Next-Gen S-Series Subwoofer cone delivers deep, low-distortion bass that enhances the depth and richness of your music.
The Next-Generation S-Series Subwoofers contain Alpine's High Amplitude Multi-Roll (H.A.M.R.) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 15mm of one-way excursion that creates incredible accuracy from the subwoofer.
A Dual Voice Coil (DVC) with easy configuration jumpers make installing the S-Series subwoofers a breeze. A new twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone.
Maximize the potential of your S-Series subwoofers with Alpine's perfectly power-matched S-Series amps. Power a single S2-W10DVC subwoofer effortlessly with the 600W S2-A60M mono amplifier, or for an even bigger impact, pair two or more S2-W10DVC subs with the powerful 1200W S2- A120M amp to ensure optimal sound quality and performance.
Features
Dual Voice Coil Subwoofers with Configuration Jumpers
Carbon Fiber / Poly Propylene Cone
Poly Propylene / Ceramic Dust Cap
High-Grade Strontium Ferrite Magnets
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
Specifications
Power Handling: 600W RMS / 1800W Peak
Nominal Impedance: 4Ω
Frequency Response: 25Hz - 215Hz
Sensitivity (1W/1M): 84.9dB
Voice Coil: 2.6"
X-Max (1-Way): 15mm
Magnet Weight: 64oz
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2005-2009 Toyota-Tacoma Access-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX
Fits: 2005-2009 Toyota Tacoma Access Cab Trucks
Installs on center hump behind front console and contours up over rear seats.
Mounting Depth: 9"
Volume: .82 cu.ft
Additional Note: This box fits directly behind the front console and extends over the rear bench for increased volume. As an added bonus, the top of the box serves as a great armrest for the rear passengers--or mount your amp on top if you like. The box fits perfectly in the space provided and is designed to lock itself into place, but can also be easily moved if needed. This box is a down fire box meaning the sub faces the floor. What this means is that your bass will reflect off the floor for an even greater bass response. There is 2" of clearance between the baffle and the hump, so no worries about your sub contacting the floor. This setup is not only a solid performer but is also very stealthy since the woofer cannot be seen.
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2009-2018 Ford F-150 & 2017-2018 F-250, F-350 and F-450 SuperCrew and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 2009-2018 Ford F150 Super Crew/Super Cab
Will also work in 2017 - 2018 F250/350/450 Super Crew / Super Cab
Premium Carpeted Finish
3/4" Hardwood MDF
Glued and Braced construction
CNC Grooved custom finish
Rounded edges
Silver spring loaded terminal cups
Subwoofer mounting depth: 4.5"
Box volume: 0.8 cubic feet (per chamber)
Sub Cut Out: 9.125”, Width:26”, Height: 9”, Depth: 13.25”
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:26.00"
Height:4.63"
Depth:13.25"
Max Mounting Depth:4.50"
Gross VolumePer Sub:1.37
Net Volume Per Sub:0.92
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2002-2018 Ram Quad-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
Premium Carpet Finish
OEM-Fit is designed and engineered specifically for the 2002-2018 Dodge Ram Quad Cab *2019 Legacy trucks to ensure an OEM fit without impeding the operation of the back seat.
Soft Woven Polyfill Damping Material helps create a flatter frequency response, low bass extension, and simulates a larger net volume air space.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with the second application of glue around all internal joints after final assembly.
Dimensions Sub cut out: 9.125”, mounting depth: 6”, height: 7.25”, width: 32.7”, depth: 13.25”
May work with Legacy 2019 Vehicle Models
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width: 32.75"
Height: 7.25"
Depth:13.25"
Max Mounting Depth: 6.00"
Gross VolumePer Sub: 0.63
Net Volume Per Sub: 0.63
Dual 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2007-2014 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom downfire fit under rear seat. Fits bench style, 60/40 style seats
Designed specifically for 2007-2014 Chevy Silverado and GMC Sierra Extended Cab Trucks
Dual 10" Subwoofer Enclosure
Premium Carpet Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 6.25"
Box volume: 0.8 cubic feet (per chamber)
Specifications
Width
52.75
Height
6.875
Depth
11.875
Mounting Depth
6.25
Gross Cubic Feet Per Side
0.8
Net Cubic Feet Per Side
0.8
Excursion
3.625
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1999-2007 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 7.25”, Width: 24”, Height: 9.125”, Depth: 24”
Specifications
Width
24
Height
9.125
Depth
24
Vent Width
1.25
Vent Height
5
Vent Depth
9
Mounting Depth
7.25
Gross Cubic Feet Per Side
1
Net Cubic Feet Per Side
0.93
HZ
41
Excursion
1.625
10-Inch 300-Watt 2-Ohm or 4-Ohm Thin Subwoofer-Enclosure for Select 2018-2023 Jeep Wrangler-Unlimited, Passenger-Side
Combining JL's advanced thin-line subwoofer technology with a form fitting enclosure design, these Stealthbox® systems deliver outstanding sub-bass performance in your 4-door Wrangler, without consuming excess cargo space.
Constructed from 100% fiberglass, each Stealthbox® houses a 10TW1 thin-line subwoofer and mounts solidly above each rear wheel well. A matching trim panel and sturdy steel-mesh grille are included, so you can carry plenty of gear without worrying about damage. Separate driver and passenger side Stealthbox® models are available, each with 2 or 4 ohm drivers.
The Hard Data: Contains one 10TW1 in a sealed enclosure with 300 watt power handling. Choose from 2 ohm or 4 ohm models, driver or passenger side. Each enclosure installs above one rear wheel well. Black steel mesh grille is included with each.
If vehicle is factory-equipped with Premium Audio, passenger side Stealthbox® installation requires removal of OEM “subwoofer” and purchase of interior trim parts from Jeep®.
Will not fit any "JK" Jeep® model or 2-Door "JL" models.
Soft-top models: Stealthbox® installation does not interfere with normal top operation, except for the final position where the top mechanism is detached from the rails.
Jeep Part #CFWLR-74-24 carpet needs to be ordered from jeep to remove the Factor Subwoofer.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-J-JL4DPAS/10TW1-2 Installation Manual
High Output Series 10-Inch 500-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
JL Audio's patented High Output Enclosures are designed to deliver the ultimate high-performance bass experience with a rare combination of superb sound quality and awesome output.
JL Audio's patented, chamber-coupled port design (U.S. patent #6,625,292) wraps around the inner enclosure boundary and terminates on one side of the woofer, coupling the port output to the woofer's direct output. This also provides the necessary surface area and port length to maximize the performance of the W3v3 driver.
This enclosure design has been carefully engineered to the optimum ported alignment for the 10W3v3, and has been fine-tuned through extensive real-world listening. This efficient system will produce superb output with as little as 150W of amplifier power, but performs best with 300 - 500W of power.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. Three solid aluminum bars provide stylish and rugged woofer protection.
The angled-back design saves precious cargo space by allowing the enclosure to fit tightly against the back of a vehicle's rear seat.
Finish: Dark gray, high-grade automotive carpet, with black carpet on woofer baffle. "JL AUDIO" is embroidered in silver on the top surface of the enclosure.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 150 - 500WNominal Impedance: 2Ω
General Specifications
Continuous Power Handling (RMS)
500 W
System Nominal Impedance
2 Ω
Enclosure Type
Chamber-coupled, slot-ported, rear-firing design
Finish
Dark gray carpet with black insert
Grille Included
Aluminum Bar Grille
Physical Specifications
External Width (W)
29.5 in / 749 mm
External Height (H)
13.5 in / 343 mm
External Depth (D1)
12.0 in / 305 mm
External Top Surface Depth (D2)
7.5 in / 190.5 mm
Net Weight
34.7 lb / 15.74 kg
JL Audio HO110RG-W3v3 Brochure
PowerWedge-Series 10-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this sealed Truck PowerWedge™ subwoofer system, JL harnesses the performance of the 10TW3 to deliver amazing sub-bass from an enclosure that is only 6.25 in. (159 mm) deep at its base and 4.1 in. (104 mm) at the top.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10TW3 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
400 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed, truck enclosure
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
19 in / 483 mm
External Height (H)
12.375 in / 314 mm
External Depth (D1)
6.25 in / 159 mm
External Top Surface Depth (D2)
4.1 in / 104 mm
Net Weight
21.2 lb / 9.6 kg
JL Audio CS110TG-TW3 Brochure
TW1-Series 400-Watt Amplified 10-Inch Ported Subwoofer System
With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 10TW1 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
10-Inch 750-Watt Alpine R-Series Halo Loaded Subwoofer Enclosure with ProLink Connectivity
Alpine’s unique ProLink technology was designed with the sound system builder in mind. ProLink allows more flexibility in both power and price to start with a single subwoofer enclosure and add an additional subwoofer using a Linking Kit (sold separately) to link two enclosures together to create a dual system when more bass is desired.
The enclosures share the premium, unmistakable design of the Alpine Halo Family. The enclosures pull design cues from the Alpine Halo Display with unique, curved edges outlined by a silver trim and a front baffle for a matching system aesthetic. Built with sturdy, 3/4” MDF construction and covered in a premium black carpet, these enclosures give the impression of a custom look, without the custom work.
Features
Groundbreaking Alpine Halo Design
ProLink™ ported enclosure design
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
CARB compliant 3/4-inch MDF construction
Premium black carpet
Silver Alpine embossed side logo badge
Brushed aluminum finished metallic front baffle
Threaded Subwoofer Mounting Inserts (for reversible subwoofer orientation)
Specifications
Dimensions: 16” W x 12.6825” H x 14.5”
750W RMS
2250W Peak Power Handling
Frequency Response: 26Hz-200Hz
Sensitivity (1W/1m): 82.3dB
Dual 4Ω Voice Coils Wired in Parallel for a 2Ω Load (Compatible with R-A75M)
Voice Coil: 65mm
X-Max: 20mm
Magnet Weight: 123oz
12 Gauge OFC Speaker Box Wire
CTA-2031 Compliant
10-Inch 600-Watt Alpine S-Series Loaded Subwoofer Enclosure with PrismaLink Lighting
Color and sound collide to bring you an intentionally crafted 10-inch wedge style subwoofer enclosure, designed for optimal bass performance and vehicle fitment, and an integrated RGB lighting system that’s multi-link capable for single, dual, and even quad-enclosure installations.
Manage the integrated RGBW trim bars effortlessly through the intuitive Lighting Link control screen on the PrismaLink compatible Alpine receivers. With a simple touch, users can easily change the ambiance, adjust colors, and change modes on the PrismaLink® enclosures. Whether it's setting the perfect vibe for a late-night drive or enhancing the atmosphere of a weekend getaway, the intuitive interface empowers users to tailor their lighting experience with precision and ease.
Features
Preloaded S2-W10D4 10” S-Series Subwoofer
Sealed Wedge Style Enclosure Design
RGBW Multi-color Trim Bar Lighting with IR Remote included
Lighting Modes:12 Static Colors, 4-Dynamic Modes
Multi-Link Capable (Link 2 or more enclosures together)
Lighting Link Control via iLX-W670 Head Unit
Carbon Fiber / Poly Propylene Subwoofer Cone
Lightweight Construction, High Output, Low Distortion
Enhanced “Punch” and Accurate Bass
High-Amplitude Multi-Roll (HAMR) Surround for High Excursion
Compatible with the KTX-EBKT Mounting Brackets
Compatible with the KTX-LK10 10” Linking Bracket for Multi-Link Application
Specifications
Enclosure Dimensions: 14.5” (W) x 13” (H) x 11.25” (D)
Power Handling: 600W RMS / 1800W Peak
Nominal Impedance: 2Ω
Frequency Response: 25Hz - 215Hz
Sensitivity: 85dB
X-Max (1-Way): 15mm
Voice Coil: 2.6”
Magnet Weight: 64oz
Dual 4Ω voice coils wired in parallel for a 2Ω load
10-Inch 600-Watt Alpine S-Series Halo Loaded Subwoofer Enclosure with ProLink Connectivity
Drawing inspiration from the Alpine Halo displays, these subwoofer enclosures feature distinctive curved edges accented by a sleek silver trim and a front baffle, creating a seamlessly matching system aesthetic. Built with sturdy, 3/4” MDF construction and covered in a premium black carpet, these enclosures not only provide durability but give the impression of a custom look, without the custom work.
Alpine’s innovative ProLink technology is tailor-made for bass enthusiasts. With ProLink, experience unparalleled flexibility as you effortlessly add an additional Alpine Halo subwoofer into your setup. Utilize a dedicated linking bracket (sold separately) for seamless integration, doubling the impact of your bass for a truly immersive sound sensation.
Features
Groundbreaking Alpine Halo Design
ProLink™ Ported Enclosure Design
Carbon Fiber / Poly Propylene Cone
Poly Propylene / Ceramic Dust Cap
High-Grade Strontium Ferrite Magnets
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
CARB compliant 3/4-inch MDF construction
Premium Black Carpet
Silver Alpine Embossed Logo Badge
Brushed Aluminum Finished Metallic Front Baffle
Threaded Subwoofer Mounting Inserts (for reversible subwoofer orientation)
Specifications
Dimensions: 16” W x 12.7” H x 14.5” D
600W RMS / 1800W Peak
Frequency Response: 25Hz - 215Hz
Sensitivity (1W/1M): 84.9dB
Voice Coil: 2.6"
X-Max: 15mm
Magnet Weight: 64oz
Dual 4Ω Voice Coils Wired in Parallel for a 2Ω Load (Compatible with S2-A60M)
12 Gauge OFC Speaker Box Wire
Binding Post Terminal Cup
Dual 10-Inch 2-Ohm 1000-Watt Thin Subwoofer-Enclosure for Select 2002-UP Ram Pickup Trucks
Dual L7T Truck-Specific Enclosures provide impactful bass and install under the back seat to retain cab space and legroom.
Requires amp and handles 1,000 watts RMS
Single 2-Ohm terminal
Dual KICKER Solo-Baric L7T Square Subwoofers
Thick black carpeting
Protective grilles included
MDF construction and heavy internal bracing
Made from thick MDF and formed specifically to fit every contour of your RAM, this custom enclosure features a pair of up-firing L7T 10-inch subwoofers and grilles with a monstrous 1,000-watts of recommended power. See details below.
It’s simple – more cone area means more air moves – for more bass and up to 20% more cone area than a conventional round sub. KICKER acoustic engineers put the largest voice coil and magnet we’ve ever integrated into a thin sub, then added a next-level top-plate design, unique heat management system and our signature cone stitching all help to give you deep bass and outstanding reliability in a single, mind-blowing design that gives you max output!
Fits*:RAM 1500 Quad Cab (2002-2018)RAM 1500 Crew Cab (2009-2018)RAM 2500/3500 Quad Cab (2003-newer)RAM 2500/3500 Crew Cab (2009-newer)RAM 1500 Classic Quad/Crew Cab (2019-newer)*Items such as inverters, storage compartments, spare tire tools or floor mats may require removal.
Specifications
TYPE:
Truck-specific
Design:
Dual Up-Fire with grilles
WOOFER SIZE (in, cm):
10, 25
IMPEDANCE (Ohms):
2
Recommended Amplifier Power (watts RMS):
1000
FREQUENCY RESPONSE (Hz):
25-100
BOX DIMENSIONS:
Width: 58-7/16” [148.4cm]
Height: 7-9/16” [19.2cm]
Depth: 16-7/16” [41.7cm]
Kicker 51KFDL7T102 Manual
Dual 10-Inch 2-Ohm 1000-Watt Thin Subwoofer-Enclosure for Select 2009-UP Ford F-150 and 2017-UP Ford SuperDuty Trucks
Dual L7T Truck-Specific Enclosures provide impactful bass and install under the back seat to retain cab space and legroom.
Requires amp and handles 1,000 watts RMS
Single 2-Ohm terminal
Dual KICKER Solo-Baric L7T Square Subwoofers
Thick black carpeting
MDF construction and heavy internal bracing
Made from thick MDF and formed specifically to fit every contour of your F-150 and SuperDuty, this custom enclosure features a pair of down-firing L7T 10-inch subwoofers with a monstrous 1,000-watts of recommended power. See details below.
It’s simple – more cone area means more air moves – for more bass and up to 20% more cone area than a conventional round sub. KICKER acoustic engineers put the largest voice coil and magnet we’ve ever integrated into a thin sub, then added a next-level top-plate design, unique heat management system and our signature cone stitching all help to give you deep bass and outstanding reliability in a single, mind-blowing design that gives you max output!Fits*:Ford F-150 Crew Cab (2009-newer)Ford SuperDuty Crew Cab (2017-newer)*Items such as inverters, storage compartments, spare tire tools or floor mats may require removal.
Specifications
TYPE:
Truck-specific
Design:
Dual Down-Fire
WOOFER SIZE (in, cm):
10, 25
IMPEDANCE (Ohms):
2
Recommended Amplifier Power (watts RMS):
1000
FREQUENCY RESPONSE (Hz):
25-100
BOX DIMENSIONS:
Width: 55-1/8” [140cm]
Height: 8-1/4” [21cm]
Depth: 13-3/8” [34cm]
Kicker 51KFDL7T102 Manual
10-Inch Black-Mesh Grille for Select JL-Audio TW3 Subwoofer-Drivers
Provide attractive, sturdy protection to your Subwoofer with this fine steel mesh grille insert, powder-coated in a satin black finish. The insert is designed to fit snugly onto the woofer's grille receiver ring.
Fits: 10TW3 Only
Alpine Custom High-Resolution Tesla 13-Speaker Sound System Upgrade Package w/DSP for Select 2022-UP Tesla Model-Y Vehicles
Custom-designed for a stealth installation, this 13-speaker, complete sound system upgrade easily replaces the factory speakers with no cutting or modification required. A 10” sealed subwoofer is added in the rear trunk and provides a powerful boost of bass performance to the system.
Crafted from a unique hybrid blue carbon fiber material and paired with a cutting-edge ultra-efficient amplifier, the Hi-Res Audio certified speakers redefine your Tesla experience with unparalleled high-end sound performance. Every note is delivered with precision and clarity, creating a captivating atmosphere that truly elevates your journey.
The included 12-channel Digital Sound Processor (DSP) comes pre-tuned for the unique interior environment of the Tesla Model Y, while the built-in 12-channel amplifier powers the full system with incredible efficiency. This ultra-efficient amplifier is optimized for EVs and uses less than one mile of range per hour when played at full volume.
Alpine PSS-TSLA-22Y Installation Manual
Alpine Custom High-Resolution Tesla 13-Speaker Sound System Upgrade Package w/DSP for Select 2020-2021 Tesla Model-Y Vehicles
Custom-designed for a stealth installation, this 13-speaker, complete sound system upgrade easily replaces the factory speakers with no cutting or modification required. A 10” sealed subwoofer is added in the rear trunk and provides a powerful boost of bass performance to the system.
Crafted from a unique hybrid blue carbon fiber material and paired with a cutting-edge ultra-efficient amplifier, the Hi-Res Audio certified speakers redefine your Tesla experience with unparalleled high-end sound performance. Every note is delivered with precision and clarity, creating a captivating atmosphere that truly elevates your journey.
The included 12-channel Digital Sound Processor (DSP) comes pre-tuned for the unique interior environment of the Tesla Model Y, while the built-in 12-channel amplifier powers the full system with incredible efficiency. This ultra-efficient amplifier is optimized for EVs and uses less than one mile of range per hour when played at full volume.
Alpine PSS-TSLA-21Y Installation Manual
Alpine Custom High-Resolution Tesla Factory-Base-Audio 13-Speaker Sound System Upgrade Package w/DSP for Select 2022-UP Tesla Model-3 Vehicles w/Factory-Premium Stereo
Custom-designed for a stealth installation, this 13-speaker, complete sound system upgrade easily replaces the factory speakers with no cutting or modification required. A 10” sealed subwoofer is added in the rear trunk and provides a powerful boost of bass performance to the system.
Crafted from a unique hybrid blue carbon fiber material and paired with a cutting-edge ultra-efficient amplifier, the Hi-Res Audio certified speakers redefine your Tesla experience with unparalleled high-end sound performance. Every note is delivered with precision and clarity, creating a captivating atmosphere that truly elevates your journey.
The included 12-channel Digital Sound Processor (DSP) comes pre-tuned for the unique interior environment of the Tesla Model 3, while the built-in 12-channel amplifier powers the full system with incredible efficiency. This ultra-efficient amplifier is optimized for EVs and uses less than one mile of range per hour when played at full volume.
Alpine PSS-TSLA-223P Installation Manual
Alpine Custom High-Res Tesla Factory-Base-Audio 11-Speaker Sound System Upgrade Package w/DSP for Select 2022-UP Tesla Model-3 Vehicles w/Factory-Base Stereo
Custom-designed for a stealth installation, this 11-speaker, complete sound system upgrade easily replaces the factory speakers with no cutting or modification required. A 10” sealed subwoofer is added in the rear trunk and provides a powerful boost of bass performance to the system.
Crafted from a unique hybrid blue carbon fiber material and paired with a cutting-edge ultra-efficient amplifier, the Hi-Res Audio certified speakers redefine your Tesla experience with unparalleled high-end sound performance. Every note is delivered with precision and clarity, creating a captivating atmosphere that truly elevates your journey.
The included 12-channel Digital Sound Processor (DSP) comes pre-tuned for the unique interior environment of the Tesla Model 3, while the built-in 12- channel amplifier powers the full system with incredible efficiency. This ultra-efficient amplifier is optimized for EVs and uses less than one mile of range per hour when played at full volume.
Alpine PSS-TSLA-223 Installation Manual
Alpine Custom High-Resolution Tesla Factory-Base-Audio 13-Speaker Sound System Upgrade Package w/DSP for Select 2018-2021 Tesla Model-3 Vehicles w/Factory-Premium Stereo
Custom-designed for a stealth installation, this 13-speaker, complete sound system upgrade easily replaces the factory speakers with no cutting or modification required. A 10” sealed subwoofer is added in the rear trunk and provides a powerful boost of bass performance to the system.
Crafted from a unique hybrid blue carbon fiber material and paired with a cutting-edge ultra-efficient amplifier, the Hi-Res Audio certified speakers redefine your Tesla experience with unparalleled high-end sound performance. Every note is delivered with precision and clarity, creating a captivating atmosphere that truly elevates your journey.
The included 12-channel Digital Sound Processor (DSP) comes pre-tuned for the unique interior environment of the Tesla Model 3, while the built-in 12-channel amplifier powers the full system with incredible efficiency. This ultra-efficient amplifier is optimized for EVs and uses less than one mile of range per hour when played at full volume.
Alpine PSS-TSLA-213P Installation Manual
Alpine Custom High-Res Tesla Factory-Base-Audio 11-Speaker Sound System Upgrade Package w/DSP for Select 2018-2021 Tesla Model-3 Vehicles w/Factory-Base Stereo
Custom-designed for a stealth installation, this 11-speaker, complete sound system upgrade easily replaces the factory speakers with no cutting or modification required. A 10” sealed subwoofer is added in the rear trunk and provides a powerful boost of bass performance to the system.
Crafted from a unique hybrid blue carbon fiber material and paired with a cutting-edge ultra-efficient amplifier, the Hi-Res Audio certified speakers redefine your Tesla experience with unparalleled high-end sound performance. Every note is delivered with precision and clarity, creating a captivating atmosphere that truly elevates your journey.
The included 12-channel Digital Sound Processor (DSP) comes pre-tuned for the unique interior environment of the Tesla Model 3, while the built-in 12- channel amplifier powers the full system with incredible efficiency. This ultra-efficient amplifier is optimized for EVs and uses less than one mile of range per hour when played at full volume.
Alpine PSS-TSLA-213 Installation Manual
TW1-Series 400-Watt Amplified 10-Inch Ported Subwoofer System
With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 10TW1 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
W3-Series 10-Inch 500-Watt Subwoofer Driver, 2-Ohm SVC
The JL Audio 10W3v3 subwoofer driver has excellent power handling, reasonable enclosure requirements, and a long excursion for its chassis to deliver excellent bass reproduction in 500W RMS power applications. JL Audio technologies and proprietary assembly designs in the 10W3v3-2 and 10W3v3-4 subwoofers enhance linearity and reliable performance results.
The JL Audio 10W3v3 is best used with an amplifier in the 150W - 500W RMS range and is optimized to operate in a compact 0.625 cu. ft. (17.7 l) sealed enclosure, or a 1.25 cu. ft. (35.4 l) ported enclosure.
General Specifications
Continuous Power Handling
500W RMS
Recommended Amplifier Power
150- 500W RMS
Nominal Impedance
2Ω
JL Audio 10W3v3 Manual
W1-Series 10-Inch 300-Watt Subwoofer Driver, 2-Ohm SVC
The JL Audio 10" W1v3 subwoofer driver is a very suitable option when space is limited with smaller amplifiers. It features a low mounting depth of 4.6 inches and a compact motor structure that allows it to comfortably fit in tight mounting locations. There is no pole vent on the rear of the subwoofer which allows the motor structure to be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow the 10W1v3 to reproduce sub-bass with shocking extension and quality.
The JL Audio 10W1v3 is best used with an amplifier in the 75W - 300W RMS range and is optimized to operate in a compact 0.55 cu. ft. (15.57 l) sealed enclosure.
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
2Ω
JL Audio 10W1v3 Manual
Single 10-Inch 300-Watt Subwoofer-Enclosure for Select 2020-Up Tesla Model-Y Vehicles
Tesla’s popular compact crossover delivers quick acceleration and a roomy cabin with plenty of space for both passengers and cargo. Sadly though, the factory audio options offer very little to satisfy in the bass reproduction department. Featuring an all-fiberglass, custom-formed, sealed enclosure, this Stealthbox houses JL Audio's innovative, 10-inch TW1 thin-line subwoofer. Designed to drop into the driver’s side, rear storage compartment, this Stealthbox solution produces amazing amounts of deep bass output, while practically vanishing into its surroundings.The Hard Data: Contains one 10TW1-2 Subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Fits two-row, 5-seat vehicles only. Use of driver's side, rear storage compartment is lost with installation.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
TESLA
Model Y
2020-2025
JL Audio SB-TE-YG1-10TW1 Installation Manual
Single 10-Inch 300-Watt 2-Ohm Subwoofer-Enclosure for Select 2017-2023 Tesla Model-3 Vehicles
Tesla’s electric, midsize sedan offers a fun driving experience with athletic handling and remarkable acceleration potential. Unfortunately, the factory audio systems are unable to produce enough bass to match its performance capabilities. Constructed from 100% fiberglass, this Stealthbox houses a 10-inch TW1 thin-line driver in a custom-formed, sealed enclosure. Engineered to address the Model 3’s vault-like, sealed trunk design, this Stealthbox is suspended above the floor, mounted within the rear deck, and generates astonishing amounts of bass output, without sacrificing any precious cargo space.The Hard Data: Contains one 10TW1-2 Subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs within the rear deck and requires permanent modification to the rear deck and to the interior rear deck panel.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
TESLA
Model 3
2017-2023
JL Audio SB-TE-3G1-10TW1 Installation Manual
Single 300-Watt 2-Ohm Thin 10-Inch Stealthbox Subwoofer-Enclosure for Select 2021-UP Ford-Bronco Vehicles
Ford’s legendary SUV combines cool retro styling with impressive on and off-road capabilities, along with a highly functional interior for passengers and cargo alike. Regrettably, this stallion's factory audio options lack the horsepower to quench our thirst for meaningful bass reproduction.
Featuring an all-fiberglass, custom-formed, sealed enclosure, this Stealthbox houses JL Audio's innovative, 10-inch TW1 thin-line driver. The result is powerful, deep bass that's worthy of Ford's celebrated nameplate. Installs behind the passenger side panel in the cargo area and includes a custom grille.The Hard Data: Contains one 10TW1-2 Subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs behind factory panel in the passenger side rear cargo area. Subwoofer is protected by a black steel mesh grille and concealed by a cosmetic grille (both included). Installation requires removal of OEM subwoofer, if equipped and permanent modification of the factory panel. Fits 2-Door and 4-Door models. Will not fit Bronco Sport models.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
Bronco
2021-2025
JL Audio SB-F-BRONCG6/10TW1 Installation Manual
Dual 10-Inch 2-Ohm 600-Watt Subwoofer-Enclosure for Select 2006-UP RAM 2500/3500 Crew-Cab and Mega-Cab Vehicles
Ram's Mega Cab delivers a cavernous cabin with one of the largest interiors available in a pickup. Too bad the factory audio systems are ill-equipped and struggle in the bass reproduction department. To overcome this challenge, JL Audio engineers developed a subwoofer solution that installs neatly, behind the back seat of this monstrous people mover, without compromising rear seat comfort.
Featuring 100% fiberglass construction, this Stealthbox is outfitted with two of JL Audio's innovative, 10-inch TW1 thin-line subwoofers in a custom-formed, sealed enclosure. The result is outstanding sub-bass performance with deep extension and solid impact. For those looking for even more performance, two enclosures can be installed side by side for up to 6dB more of jaw-dropping output.
The Hard Data: Contains two 10TW1-4 in a sealed enclosure. 600 watt power handling. Wired for 2 ohm mono. Installation requires removal of rear seat storage compartment and OEM subwoofer, if equipped.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
DODGE
RAM 2500
2006-2011
RAM 3500
2006-2011
RAM
2500
2012-2025
3500
2012-2025
JL Audio SB-D-MGACABG4/10TW1 Manual
Single 300-Watt 2-Ohm Thin 10-Inch Stealthbox Subwoofer-Enclosure for Select 2018-Up Ford Expedition Vehicles, with OEM Subwoofer
Ford's full-sized SUV delivers first-rate comfort with outstanding gear-hauling capability and towing capacity. This is why JL's Stealthbox solution is designed to retain 100% of your cargo space, while delivering first-class bass performance.
This model replaces the stock subwoofer and installs discreetly behind the factory cargo area trim to protect and hide its 10-inch subwoofer.
The Hard Data: Contains one 10TW1-2 subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs behind driver side panel in the cargo area. Requires removal of the OEM "subwoofer".
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
Expedition
2018-2025
Expedition Max
2018-2025
JL Audio SB-F-EXPED4G/10TW1 Installation Manual
R-Series Loaded 600-Watt Thin 10-Inch 2-Ohm Subwoofer Enclosure
Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow preloaded subwoofer enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.
Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series shallow subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
Integrated cooling fins located in the core of the subwoofer help dissipate the heat generated by the rapid subwoofer movement for enhanced cooling reliability and hours of uninterrupted playtime. The unique CoolMount dual-panel mount subwoofer motor enhances cooling.
Alpine’s Gen2 DD-Linear Magnetic Circuit technology, a compact and efficient dual-gap voice coil structure, allows for better control over the motor, resulting in lower distortion and precise bass control. The preloaded enclosures use the subwoofer frame as bracing fora more ridged design and better bass response.
A lightweight yet rigid aluminum dust cap allows the R-Series shallow subwoofer to transition sound quickly with minimal distortion and project the bass off the surface of the speaker for hard-hitting yet smooth bass performance. The included adjustable mounting brackets allow for a downfire mount configuration.
With dual voice coils wired in parallel for a 2Ω load, the Alpine R-Series 10" shallow subwoofer enclosure is optimized to perform with Alpine's S-A60M or R-A75M mono amplifiers.
Features
Optimal sealed cabinet quality
Aluminum Dust Cap
Neodymium Magnet
Alpine Gen2 DD Linear Magnetic Circuit
CARB compliant ¾” MDF construction
Premium Alpine embroidered black carpet
Alpine-branded terminal cup
Pre-installed steel mesh grille
Includes a 10” R-Shallow Subwoofer (RS-W10D4)
Rubber, modular stackable foot design
Specifications
Dimensions: 21.15” W x 5.25” H x 16” L
600W RMS Power Handling
Frequency response: 29Hz – 200Hz
Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)
Nominal Impedance: 2Ω
Voice Coil: 4”(101.6mm)
R-Series 10-Inch 750-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Dual Voice Coil
Since the Type R platform, Alpine’s R-Series sound system family has been known for its incredible output and reliable performance. Now Alpine introduces the next-generation of sound performance with the 2nd-Gen R-Series Subwoofers with even more bass output.
The 2nd-Gen R-Series Subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control from the subwoofer cone compared to the previous generation. An integrated Faraday ring minimizes distortion for cleaner bass output. A Kevlar-treated cone ensures durability in the subwoofer for reliable performance, even at high volumes.
A new polypropylene/ceramic composite dust cap ensures rigidity while also providing incredible internal damping (vibration absorption) to smooth out the bass response and reproduce tight bass. This premium, unique material also has higher heat reliability that ensures non- stop bass performance.
The 2nd-Gen R-Series Subwoofers contain a Dual Voice Coil (DVC) with easy configuration jumpers that allow for flexible applications. A new “EZ- Change” twist-lock grille mounting system makes it easy to install and remove an optional grille without mounting screws for added protection to the cone. The R2-W10D2 and R2-W10D4 is compatible with the KTE-10G Grille System (sold separately).
The 2nd-Gen R-Series Subwoofers contain Alpine’s High Amplitude Multi- Roll (HAMR) Surround Technology. This rubber surround allows the subwoofer cone to efficiently move air while staying cool. This technology allows for 20mm of total cone excursion and motion that creates incredible accuracy from the subwoofer.
Features
Dual Voice Coil (DVC) Subwoofers with Configuration Jumpers
Polypropylene/Ceramic Composite Dust Cap
Kevlar Reinforced Pulp Cone High-Performance subwoofers
Twist-Lock Grille Mount System
High-Amplitude Multi-Roll (H.A.M.R.) Surround
Large Double-Stacked Magnets
Specifications
750W RMS
2250W Peak Power Handling
Frequency Response: 26Hz-200Hz
Sensitivity (1W/1m): 82.4dB
Nominal Impedance: 4Ω
Voice Coil: 65mm
X-Max: 20mm
Magnet Weight: 123oz
Mounting Depth: 6” (152mm)
Cutout Size: 9-1/16” (231mm)
Push-Type Speaker Terminals (Up to 8AWG Wire Size)
CTA-2031 Compliant
Alpine R2-W10D Manual
Single 10-Inch 2-Ohm 400-Watt Subwoofer-Enclosure for Select 2021-UP Large Chevrolet and GMC SUV Vehicles
GM's fifth-generation full-size SUV gets all-new, luxurious interiors, along with major enhancements in performance and technology. Unfortunately, the factory audio systems still lack quality bass reproduction. There also isn’t much room for a conventional subwoofer design, without compromising people and cargo space.
To overcome this challenge, JL-Audio engineers developed a subwoofer solution that installs invisibly, behind the driver's side cargo panel, with no loss of storage space. Featuring 100% fiberglass construction, this Stealthbox is equipped with one of JL's innovative, 10-inch TW3 thin-line subwoofers in a custom-formed, sealed enclosure.
The Hard Data: Contains one 10TW3-D4 in a sealed enclosure. 400 watt power handling. Wired for 2 ohm mono. Stealthbox® installs behind the driver side cargo trim panel. Replaces the OEM “subwoofer” system, if equipped.
Applications
Escalade
Escalade ESV
Suburban
Tahoe
Yukon
Yukon XL
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-5GSUV/10TW3 Installation Manual
Dual 10-Inch 2-Ohm 800-Watt Subwoofer-Enclosure for Select 2020-UP RAM 1500 Quad-Cab Vehicles
This generation of RAM’s big hauler combines a bold new design with major advancements in aerodynamics, technology and towing capabilities. Disappointingly, the original equipment audio systems lack the low-frequency output and performance you might expect.
Luckily, JL-Audio engineers are experts in maximizing bass from minimal space and developed a subwoofer solution that fills your Quad Cab with loads of powerful bass output. Featuring a 100% fiberglass, sealed enclosure design, this Stealthbox houses two of JL-Audio's innovative 10TW3 thin-line subwoofers and installs neatly under the rear seat, without compromising rear seat comfort or folding. Theyeven left space on the enclosure that’s perfect for a small, hidden amplifier installation!
The Hard Data: Contains two 10TW3-D8 Subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Installation requires removal of rear underseat storage tray, if equipped.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
RAM
1500
Quad Cab
2020-2025
JL Audio SB-D-5GRAMQC/10TW3 Manual
Single 10-Inch 2-Ohm 300-Watt Subwoofer-Enclosure for Select 2019-UP Ford-Ranger SuperCrew Vehicles
Ford's mid-sized pickup promises practical utility and performance for everyday commutes or rugged terrains. To make every drive even more enjoyable, JL-Audio's Stealthbox solution tucks under the rear seat on the passenger side and encloses a 10-inch driver for impressive sub-bass performance. Seat folding is unaffected with plenty of room remaining on the driver side for storage. Best of all, the Stealthbox virtually disappears once installed.
The Hard Data: Contains one 10TW1-2 subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs under passenger side rear seat in place of storage compartment. Will not fit SuperCab.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
Applications
FORD
Ranger
SuperCrew
2019-2025
JL Audio SB-F-RNGSCG4/10TW1 Manual
