Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1988-1998 Chevrolet-Silverado and GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1988 – 1998 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
0.9 Cubic Feet Net Volume internal air space is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.25” which is ideal for most standard * lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, Mounting Depth: 6.25”, Height: 9”, Width: 30.25
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width: 30.25"
Height: 9.00"
Depth: 15.50"
Max Mounting Depth: 6.25"
Gross Volume Per Sub: 1.00
Net Volume Per Sub: 1.00
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2004-2014 Chevrolet-Colorado or GMC-Canyon Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1999-2007 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
1.1 Cubic Feet Gross and 1.0 Net Volume internal net air space are ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.25” which is ideal for full size and lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 6.25”, Width: 27.25”, Height: 8.75”, Depth: 11.875”
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width: 27.25"
Height: 8.25"
Depth: 11.88"
Max Mounting Depth: 6.25"
Gross VolumePer Sub: 1.35
Net Volume Per Sub: 1.00
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 2007-2013 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2007-2013 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
1.1 Cubic Feet Gross and 1.0 Net Volume internal net air space are ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 6.25” which is ideal for full size and lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 6.25”, Width: 27.25”, Height: 8.75”, Depth: 11.875”
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width: 27.25"
Height: 8.25"
Depth: 11.88"
Max Mounting Depth: 6.25"
Gross VolumePer Sub: 1.35
Net Volume Per Sub: 1.00
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 2014-2018 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Single 10" Vented Subwoofer Enclosure
Designed specifically for 2014 - 2018 Chevy Silverado and GMC Sierra Extended Cab Trucks
May work with some 2019 Models
Premium carpeted finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 6.25"
Box volume: 0.9 cubic feet (per chamber)
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width: 27.25"
Height: 6.25"
Depth:11.88"
Max Mounting Depth: 6.25"
Gross VolumePer Sub: 0.91
Net Volume Per Sub: 0.91
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 1999-2007 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 7.25”, Width: 24”, Height: 9.125”, Depth: 24”
Specifications
Width
24
Height
9.125
Depth
24
Vent Width
1.25
Vent Height
5
Vent Depth
9
Mounting Depth
7.25
Gross Cubic Feet Per Side
1
Net Cubic Feet Per Side
0.93
HZ
41
Excursion
1.625
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom downfire fit under rear driver side seat. No modification required. Doesn't affect rear seat latching.
Single 10" Subwoofer Enclosure
Designed specifically for 1999-2007 Chevy Silverado and GMC Sierra Extended Cab Trucks
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 7.25"
Box volume: 0.93 cubic feet (per chamber)
Specifications
Width
24
Height
9.125
Depth
14.75
Mounting Depth
7.25
Gross Cubic Feet Per Side
0.93
Net Cubic Feet Per Side
0.93
Excursion
1.625
Single 12-Inch Sealed Carpeted Subwoofer-Enclosure for Select 1999-2007 Chevrolet-Silverado or GMC-Sierra Extended-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Custom down fire fit under rear driver side seat. No modification required. Doesn't affect rear seat latching.
Single 12" Carpeted Finish Subwoofer Enclosure
Designed specifically for 1999-2007 Chevy Silverado and GMC Sierra Extended Cab Trucks
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 7.25"
Box volume: 0.93 cubic feet (per chamber)
Specifications
Width
24
Height
9.125
Depth
14.75
Mounting Depth
7.25
Gross Cubic Feet Per Side
0.93
Net Cubic Feet Per Side
0.93
Excursion
1.625
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 2007-2020 Chevrolet-Silverado or GMC-Sierra HD-Crew-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
New body style Silverado or GM Sierra CrewCabs. Custom downfire fit under rear seat, enclosure will only fit heavy duty crew cabs (1500, 2500, 3500).
Single 10" Vented Subwoofer Enclosure
Designed specifically for 2007-2020 Chevrolet-GMC Silverado / Sierra Crew Cab
Premium Carpet Finish
Underseat Upfire
No Modification is required
Easy drop-in installation
5.5" Mounting depth
Installation Note: Does not fit Xcab, New body style Silverado, or GMC Sierra CrewCabs. Custom down fire fit under the rear seat, the enclosure will only fit heavy-duty crew cabs (1500, 2500, 3500)
Specifications
Width
28.875
Height
6.75
Depth
17.75
Vent Width
1.37
Vent Height
5
Vent Depth
10
Mounting Depth
6.5
Gross Cubic Feet Per Side
1
Net Cubic Feet Per Side
0.83
HZ
39
Excursion
1.875
Single 12-Inch Vented Carpeted Subwoofer-Enclosure for Select 2007-2020 Chevrolet-Silverado or GMC-Sierra HD-Crew-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Installation Note: Does not fit Xcab, New body style Silverado or GM Sierra CrewCabs. Custom down fire fit under the rear seat, the enclosure will only fit heavy-duty crew cabs (1500, 2500, 3500)
Single 12" Vented Subwoofer Enclosure
Designed specifically for 2007-2020 Chevrolet-GMC Silverado / Sierra Crew Cab
Premium Carpet Finish
Underseat Upfire
No Modification is required
Easy drop-in installation
5.5" Mounting depth
Installation Note: Does not fit Xcab, New body style Silverado or GM Sierra CrewCabs. Custom down fire fit under the rear seat, the enclosure will only fit heavy-duty crew cabs (1500, 2500, 3500)
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width: 28.88"
Height: 4.50"
Depth: 17.75"
Max Mounting Depth: 6.50"
Gross VolumePer Sub: 1.50
Net Volume Per Sub: .95
Single 12-Inch Vented Tuff-Coat Lined Sub-Box for Select 2007-2020 Chevrolet-Silverado and GMC-Sierra Crew-Cab Trucks
Accu-Tuned 12” Single vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2007-2020 Chevrolet / GMC trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
1.7 Cubic Feet Gross and 0.83 Net Volume internal net air space are ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 9” which is ideal for full size and lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium Rugged Spray Liner for durability and enhanced airtight seal.
Dimensions Sub Cut Out: 9.125”, Mounting Depth: 6.5”, Width: 28.87”, Height: 6.75”, Depth: 17.75”
Specifications
Configuration: Single Vented
Finish: Tuff Coat Finish
Width: 28.88"
Height: 4.50"
Depth: 17.75"
Max Mounting Depth: 6.50"
Gross VolumePer Sub: 1.50
Net Volume Per Sub: .95
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2002-2018 Ram Quad-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
Premium Carpet Finish
OEM-Fit is designed and engineered specifically for the 2002-2018 Dodge Ram Quad Cab *2019 Legacy trucks to ensure an OEM fit without impeding the operation of the back seat.
Soft Woven Polyfill Damping Material helps create a flatter frequency response, low bass extension, and simulates a larger net volume air space.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with the second application of glue around all internal joints after final assembly.
Dimensions Sub cut out: 9.125”, mounting depth: 6”, height: 7.25”, width: 32.7”, depth: 13.25”
May work with Legacy 2019 Vehicle Models
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width: 32.75"
Height: 7.25"
Depth:13.25"
Max Mounting Depth: 6.00"
Gross VolumePer Sub: 0.63
Net Volume Per Sub: 0.63
Single 12-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2002-2018 Ram Quad-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 11” single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
Premium Carpet Finish
OEM-Fit is designed and engineered specifically for the 2002-2018 Dodge Ram Quad Cab *2019 Legacy trucks to ensure an OEM fit without impeding the operation of the back seat.
Soft Woven Polyfill Damping Material helps create a flatter frequency response, low bass extension, and simulates a larger net volume air space.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with the second application of glue around all internal joints after final assembly.
Dimensions Sub cut out: 9.125”, mounting depth:6”, height: 7.25”, width: 32.7”, depth: 13.25”
May work with Legacy 2019 Vehicle Models
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:32.75"
Height:7.25"
Depth:13.25"
Max Mounting Depth:6.00"
Gross VolumePer Sub:0.63
Net Volume Per Sub:0.63
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2009-2018 Ford F-150 & 2017-2018 F-250, F-350 and F-450 SuperCrew and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 2009-2018 Ford F150 Super Crew/Super Cab
Will also work in 2017 - 2018 F250/350/450 Super Crew / Super Cab
Premium Carpeted Finish
3/4" Hardwood MDF
Glued and Braced construction
CNC Grooved custom finish
Rounded edges
Silver spring loaded terminal cups
Subwoofer mounting depth: 4.5"
Box volume: 0.8 cubic feet (per chamber)
Sub Cut Out: 9.125”, Width:26”, Height: 9”, Depth: 13.25”
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:26.00"
Height:4.63"
Depth:13.25"
Max Mounting Depth:4.50"
Gross VolumePer Sub:1.37
Net Volume Per Sub:0.92
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2009-2018 Ford F-150 SuperCrew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 2009-2018 Ford F150 Crew Cab Trucks
May fit some 2019 legacy models
Premium Carpeted Finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 6"
Box volume: 0.8 cubic feet
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:26.00"
Height:5.75"
Depth:13..625"
Max Mounting Depth:5.00"
Gross VolumePer Sub:1.49
Net Volume Per Sub:1.01
Installation Note: Installs under the rear seat with Subwoofers facing down.
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2004-2008 Ford F-150 SuperCrew and Super-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single sealed subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2004-2008 Super Crew / Super Cab trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
.76 Cubic Feet Net Volume internal air space is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.25” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, mounting depth: 7” Front Height: 7.75”, Rear Height: 6.75”, Depth: 11.75”
Specifications
Configuration: Single Sealed
Finish: Charcoal Carpeted
Width:23.38"
Height:6.75"
Depth:11.75"
Max Mounting Depth:5.25"
Gross VolumePer Sub:1.15
Net Volume Per Sub:0.76
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 2004-2008 Ford F-150 SuperCrew and Super-Cab Trucks
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Accu-Tuned 10” Single Vented subwoofer enclosure designed for optimum bass response and low-frequency reproduction which is ideal for lower profile sound quality subwoofers.
OEM-Fit is designed and engineered specifically for the 2004-2008 Super Crew / Super Cab trucks to ensure an OEM fit without impeding the operation of the back seat.
High-Grade MDF for Ultimate structural rigidity and no-flex construction.
.76 Cubic Feet Net Volume internal air space is ideal for tight accurate bass reproduction.
Subwoofer Mounting Depth is 5.25” which is ideal for lower profile subwoofers.
Specially Formulated Aliphatic Wood Glue to ensure an airtight seal between all MDF parts with a second application of glue around all internal joints after final assembly.
Pneumatic Applied Brad Nails to pull tight and hold the MDF parts during the glue drying process and help assure a no-leak, no-rattle air chamber.
Premium OEM Grade Carpeting for factory look and durability.
Dimensions Sub cut out: 9.125”, mounting depth: 7” Front Height: 7.75”, Rear Height: 6.75”, Depth: 11.75”
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width:32.00"
Height:6.75"
Depth:11.75"
Max Mounting Depth:5.25"
Gross VolumePer Sub:1.58
Net Volume Per Sub:1.04
Single 10-Inch Vented Carpeted Subwoofer-Enclosure for Select 1999-2007 Ford F-250, F-350 and F-450 Crew-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Designed specifically for 1999-2007 Ford F250/F350/F450 Crew Cab Trucks
Premium carpeted finish
3/4" Mounting Baffle
Hardwood MDF construction
Rounded edges
Glued and Braced construction
Subwoofer mounting depth: 4.75"
Box volume: 1.19 cubic feet (per chamber)
Installation Note: Fits behind the rear seat, removal of jack kit is required along with rear seat belt cover and carpet. The power motor will need to be removed during installation
Specifications
Configuration: Single Vented
Finish: Charcoal Carpeted
Width:55.25"
Height:16.13"
Depth:6.13"
Max Mounting Depth:5.50"
Gross VolumePer Sub:2.46
Net Volume Per Sub:1.55
Installation Note: Fits behind the rear seat, removal of jack kit is required along with rear seat belt cover and carpet. The power motor will need to be removed during installation
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2010-2015 Toyota-Tacoma Access-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX!
Fits: 2010-2015 Toyota Tacoma Access Cab Trucks
Installs between rear center seats
Mounting Depth: 8.5"
Volume: .96 cu.ft
Installation Note: Removal of the rear armrest is required along with Temporary removal of the front console which helps during installation. Does not affect rear seating.
Single 10-Inch Sealed Carpeted Subwoofer-Enclosure for Select 2005-2009 Toyota-Tacoma Access-Cab Pickups
CLICK HERE TO VIEW SUBWOOFERS THAT FIT THIS BOX
Fits: 2005-2009 Toyota Tacoma Access Cab Trucks
Installs on center hump behind front console and contours up over rear seats.
Mounting Depth: 9"
Volume: .82 cu.ft
Additional Note: This box fits directly behind the front console and extends over the rear bench for increased volume. As an added bonus, the top of the box serves as a great armrest for the rear passengers--or mount your amp on top if you like. The box fits perfectly in the space provided and is designed to lock itself into place, but can also be easily moved if needed. This box is a down fire box meaning the sub faces the floor. What this means is that your bass will reflect off the floor for an even greater bass response. There is 2" of clearance between the baffle and the hump, so no worries about your sub contacting the floor. This setup is not only a solid performer but is also very stealthy since the woofer cannot be seen.
The compact PWE-S8 amplified subwoofer system lets you add deep, accurate bass to your sound system without taking up much space in your vehicle.
With the PWE-S8, the high-excursion 8-inch subwoofer and 120W gives strong bass output.
Specifications
RCA and speaker level inputs
120 Watt amp
Frequency Response: 25Hz-152Hz
Dimensions 13- 7/16" Wide x 9-1/16" Long x 2-13/16" Deep
Alpine PWE-S8 Manual
Alpine 350-Watt 10-Inch Truck Subwoofer Enclosure, 2Ω Final Impedance
With a compact wedge-style design and shallow mount, the SBT-S10V (2-ohm system) is a perfect fit for truck applications, with a design that works in small spaces. Radial Vented VC Heat Sink & Airflow Management System actively manages voice coil temperatures by forcing air directly across the heat sink system.
FEA Optimized Dual-Sided Machined CRC Motor Structure creates a symmetrical magnetic field with evenly distributed flux density to greatly reduce distortion, while further improving power handling and output. The High-Amplitude Multi Roll Surround Design allows for extreme excursions without sacrificing valuable cone area. FEA Optimized for linearity and made with injection-molded Santoprene ®, the HAMR surround is a key part of the suspension system that provides accurate, distortion-free control at extreme excursions.
Specifications
2Ω Impedance
Ported Enclosure Design
Frequency Response: 28Hz-200Hz
Dimensions 21-5/8" Wide x 15-1/4" Tall x 7-1/4" Deep 1x 3-15/16"
Alpine SBT-S10V Manual
Alpine 350-Watt Loaded 10-Inch Subwoofer-Enclosure for 2007-2018 Jeep-Wrangler JK-Unlimited, 2Ω Final Impedance
When you have a Wrangler, you don’t have extra space to spare. Alpine engineered the SBV-10-WRA to conveniently fit under the front passenger’s seat making efficient use of space. The SBV-10-WRA is a custom-shaped enclosure that fits snugly under the seat frame, so no mounting hardware is required. (NOTE: designed for fitment in Jeeps with the factory carpet. Fitment is not guaranteed with aftermarket or removed carpet)
Enjoy impactful bass, with your Wrangler’s top on or off. The SBV-10-WRA loads the lower frequency sound into the passenger’s foot well to deliver quality sound and maximized bass extension at all times, so your music continues even when the asphalt ends.
Specifications
10” Pre-loaded Sealed Custom-fit Enclosure
Weather Resistant (IP66 rating)
Power Handling: 350WRMS/1050W Peak
Nominal Impedance 2Ω
Frequency Response: 45-200Hz
OEM-grade Molex 2-pin connector w/pigtail wire harness
Alpine SBV-10-WRA Manual
W3-Series 250-Watt Amplified 8-Inch Ported Subwoofer System
With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL Audio's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance W3v3 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 8Wv3 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (250 W @ 0.40 Ω)Nominal Impedance: 0.40 Ω
Enclosure and Subwoofer Built in USA with global components.
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 250 W @ 0.40 Ω
System Nominal Impedance
0.40 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
W3-Series 250-Watt Amplified 8-Inch Ported Subwoofer System
With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL Audio's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance W3v3 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 8Wv3 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (250 W @ 0.40 Ω)Nominal Impedance: 0.40 Ω
Enclosure and Subwoofer Built in USA with global components.
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 250 W @ 0.40 Ω
System Nominal Impedance
0.40 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
TW1-Series 400-Watt Amplified 10-Inch Ported Subwoofer System
With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 10TW1 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
TW1-Series 400-Watt Amplified 10-Inch Ported Subwoofer System
With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 10TW1 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
TW1-Series 400-Watt Amplified 12-Inch Ported Subwoofer System
With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 12TW1 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
Enclosure and Subwoofer Built in USA with global components
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
TW1-Series 400-Watt Amplified 12-Inch Ported Subwoofer System
With MicroSub+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this incredible subwoofer system utilizes JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Key to the enclosure’s performance is its efficient slot-ported design and precise tuning of its 12TW1 subwoofer driver. Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space. As with all MicroSub™ systems, these amplified versions produce the kind of output and extension normally associated with much larger systems.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
Enclosure and Subwoofer Built in USA with global components
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
TW1-Series 400-Watt Amplified 10-Inch Subwoofer System
In PowerWedge+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this subwoofer system employs JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Harnessing the performance and insanely small box requirements of the TW1 subwoofer driver, this subwoofer system is designed to deliver amazing sub-bass from an enclosure that is only 5 inches (127 mm) deep. Its low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10TW1 driver and has been fine-tuned through extensive real-world listening.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
Enclosure and Subwoofer Built in USA with global components
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
TW1-Series 400-Watt Amplified 10-Inch Subwoofer System
In PowerWedge+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this subwoofer system employs JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Harnessing the performance and insanely small box requirements of the TW1 subwoofer driver, this subwoofer system is designed to deliver amazing sub-bass from an enclosure that is only 5 inches (127 mm) deep. Its low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10TW1 driver and has been fine-tuned through extensive real-world listening.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
Enclosure and Subwoofer Built in USA with global components
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
TW1-Series 400-Watt Amplified 12-Inch Subwoofer System
In PowerWedge+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this subwoofer system employs JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Harnessing the performance and insanely small box requirements of the TW1 subwoofer driver, this subwoofer system is designed to deliver amazing sub-bass from an enclosure that is only 6.625 in. (168 mm) deep. Its low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12TW1 driver and has been fine-tuned through extensive real-world listening.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
Enclosure and Subwoofer built in USA with global components
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
TW1-Series 400-Watt Amplified 12-Inch Subwoofer System
In PowerWedge+™ systems, the power is built right into the subwoofer system. Housing a proprietary Class D amplifier, this subwoofer system employs JL's exclusive DCD™ amplifier technology to extract maximum output from its specially engineered, ultra low-impedance TW1 driver. By combining direct power conversion with an ultra-high current output section, DCD™ amplifiers are free of conventional switching power supplies, enabling them to generate remarkable power with unprecedented efficiency.
Harnessing the performance and insanely small box requirements of the TW1 subwoofer driver, this subwoofer system is designed to deliver amazing sub-bass from an enclosure that is only 6.625 in. (168 mm) deep. Its low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12TW1 driver and has been fine-tuned through extensive real-world listening.
Integration to OEM and aftermarket head units is a snap thanks to a variety of input options and automatic turn-on capability (via signal sensing or DC offset sensing). Also included is a variable frequency low-pass filter (50-200 Hz), along with output polarity control switch. Adding an optional RBC-1 remote level control (sold separately) lets you control subwoofer levels directly from the driver’s seat. A quick-disconnect power connector makes it easy to remove the subwoofer when you need the extra space.
Note: DCD™ amplified systems use very specific components. Never use a DCD™ amplifier or its companion subwoofer(s) with incompatible, non-DCD™ products. Doing so will void the warranty and may cause severe damage.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Amplifier power: Built-in DCD™ Class D amplifier (400 W @ 0.25 Ω)Nominal Impedance: 0.25 Ω
Enclosure and Subwoofer built in USA with global components
General Specifications
Continuous Power Handling (RMS)
Built-in amplifier 400 W @ 0.25 Ω
System Nominal Impedance
0.25 Ω
Input Voltage Range @ RCA Inputs
70 mV - 1.40 V RMS
Input Voltage Range @ High-Level Inputs
280 mV - 5.4 V RMS
Recommended Copper Power / Ground Wire Gauge
8 AWG wire
Fuse Rating
30 A (ATO or ATC)
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
JL Audio MicroSub+/PowerWedge+ Manual
ProWedge-Series 10-Inch 750-Watt Enclosed Subwoofer System, 3Ω Sealed Enclosure
For those who seek the ultimate in compact-enclosure sub-bass fidelity, we offer this sealed ProWedge™ system, in which the superb performance capabilities of the W7AE subwoofer driver are harnessed within a compact, sealed enclosure. This system has it all: extension, impact, detail and smooth response... at any listening level.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10W7AE-3 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
The angled-back design saves precious cargo space by allowing the enclosure to fit tightly against the back of a vehicle's rear seat.
Finish: Black, high-grade automotive carpet, with gloss-black laminated decorative front baffle trim. Three solid aluminum bars provide stylish and rugged woofer protection.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 300 - 750WNominal Impedance: 3 Ω
General Specifications
Continuous Power Handling (RMS)
750 W
System Nominal Impedance
3 Ω
Enclosure Type
Sealed, rear-firing design
Finish
Black carpet / laminate
Grille Included
Aluminum Bar Grille
Physical Specifications
External Width (W)
17.75 in / 451 mm
External Height (H)
14.625 in / 371 mm
External Depth (D1)
16.625 in / 422 mm
External Top Surface Depth (D2)
11.50 in / 292 mm
Net Weight
61.2 lb / 27.77 kg
JL Audio CLS110RG-W7AE Brochure
ProWedge-Series 12-Inch 1000-Watt Enclosed Subwoofer System, 3Ω Sealed Enclosure
For those who seek the ultimate in compact-enclosure sub-bass fidelity, we offer this sealed ProWedge™ system, in which the superb performance capabilities of the W7AE subwoofer driver are harnessed within a compact, sealed enclosure. This system has it all: extension, impact, detail and smooth response... at any listening level.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12W7AE-3 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
The angled-back design saves precious cargo space by allowing the enclosure to fit tightly against the back of a vehicle's rear seat.
Finish: Black, high-grade automotive carpet, with gloss-black laminated decorative front baffle trim. Three solid aluminum bars provide stylish and rugged woofer protection.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 400 - 1000WNominal Impedance: 3 Ω
General Specifications
Continuous Power Handling (RMS)
1000 W
System Nominal Impedance
3 Ω
Enclosure Type
Sealed, rear-firing design
Finish
Black carpet / laminate
Grille Included
Aluminum Bar Grille
Physical Specifications
External Width (W)
21.25 in / 540 mm
External Height (H)
16.50 in / 419 mm
External Depth (D1)
17 in / 432 mm
External Top Surface Depth (D2)
11.25 in / 286 mm
Net Weight
81.7 lb / 37.10 kg
JL Audio CLS112RG-W7AE Brochure
ProWedge-Series 13-Inch 1500-Watt Enclosed Subwoofer System, 1.5Ω Sealed Enclosure
For those who seek the ultimate in compact-enclosure sub-bass fidelity, we offer this sealed ProWedge™ system, in which the superb performance capabilities of the W7AE Subwoofer are harnessed within a compact, sealed enclosure. This system has it all: extension, impact, detail and smooth response... at any listening level.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 13W7AE-D1.5 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
The angled-back design saves precious cargo space by allowing the enclosure to fit tightly against the back of a vehicle's rear seat.
Finish: Black, high-grade automotive carpet, with gloss-black laminated decorative front baffle trim. Three solid aluminum bars provide stylish and rugged woofer protection.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 500 - 1500WNominal Impedance: Dual 1.5 Ω
General Specifications
Continuous Power Handling (RMS)
1500 W
System Nominal Impedance
3 Ω
Enclosure Type
Sealed, rear-firing design
Finish
Black carpet / laminate
Grille Included
Aluminum Bar Grille
Physical Specifications
External Width (W)
22.5 in / 572 mm
External Height (H)
18.25 in / 464 mm
External Depth (D1)
18.25 in / 464 mm
External Top Surface Depth (D2)
11.50 in / 292 mm
Net Weight
103.2 lb / 46.79 kg
JL Audio CLS113RG-W7AE Brochure
MicroSub-Series 6-Inch 150-Watt Enclosed Subwoofer System, 4Ω Ported Enclosure
This incredible MicroSub™ subwoofer system delivers the kind of output and extension that is normally possible with only much larger systems. The key to its performance lies in the precise tuning of its 6W3v3 subwoofer driver into an efficient slot-ported design.
Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 50 - 150WNominal Impedance: 4 Ω
General Specifications
Continuous Power Handling (RMS)
150 W
System Nominal Impedance
4 Ω
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
14.125 in / 359 mm
External Height (H)
9.625 in / 245 mm
External Depth (D1)
5.125 in / 130 mm
Net Weight
12 lb / 5.44 kg
JL Audio CP106LG-W3v3 Brochure
MicroSub-Series 8-Inch 250-Watt Enclosed Subwoofer System, 4Ω Ported Enclosure
This incredible MicroSub™ subwoofer system delivers the kind of output and extension that is normally possible with only much larger systems. The key to its performance lies in the precise tuning of its 8W3v3 subwoofer driver into an efficient slot-ported design.
Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 250WNominal Impedance: 4 Ω
General Specifications
Continuous Power Handling (RMS)
250 W
System Nominal Impedance
4 Ω
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
18.625 in / 473 mm
External Height (H)
11.0 in / 279 mm
External Depth (D1)
5.125 in / 130 mm
Net Weight
17.40 lb / 7.89 kg
JL Audio CP108LG-W3v3 Brochure
BassWedge-Series 10-Inch 300-Watt Enclosed Subwoofer System, 4Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofer to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofer firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 4 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
4 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
15.51 in / 394 mm
External Height (H)
13.77 in / 350 mm
External Depth (D1)
17.38 in / 441 mm
External Top Surface Depth (D2)
14 in / 356 mm
Net Weight
29 lb / 13.15 kg
JL Audio CP110-W0v3 Brochure
BassWedge-Series 10-Inch 300-Watt Enclosed Subwoofer System, 4Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofer to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofer firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 4 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
4 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
15.51 in / 394 mm
External Height (H)
13.77 in / 350 mm
External Depth (D1)
17.38 in / 441 mm
External Top Surface Depth (D2)
14 in / 356 mm
Net Weight
29 lb / 13.15 kg
JL Audio CP110-W0v3 Brochure
MicroSub-Series 10-Inch 300-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
This incredible MicroSub™ subwoofer system delivers the kind of output and extension that is normally possible with only much larger systems. The key to its performance lies in the precise tuning of its 10TW1 subwoofer driver into an efficient slot-ported design.
Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
2 Ω
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
20.875 in / 530 mm
External Height (H)
13.25 in / 337 mm
External Depth (D1)
6.375 in / 162 mm
Net Weight
25.70 lb / 11.66 kg
JL Audio CP110LG-TW1-2 Brochure
BassWedge-Series 12-Inch 300-Watt Enclosed Subwoofer System, 4Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofer to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofer firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 4 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
4 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
16.31 in / 414 mm
External Height (H)
15.18 in / 386 mm
External Depth (D1)
20.3 in / 516 mm
External Top Surface Depth (D2)
15.75 in / 400 mm
Net Weight
33.1 lb / 15 kg
JL Audio CP112-W0v3 Brochure
BassWedge-Series 12-Inch 300-Watt Enclosed Subwoofer System, 4Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofer to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofer firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 4 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
4 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
16.31 in / 414 mm
External Height (H)
15.18 in / 386 mm
External Depth (D1)
20.3 in / 516 mm
External Top Surface Depth (D2)
15.75 in / 400 mm
Net Weight
33.1 lb / 15 kg
JL Audio CP112-W0v3 Brochure
PowerWedge-Series 10-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this low-profile PowerWedge™ subwoofer system, JL harnesses the performance of the 10TW3 to deliver amazing sub-bass from an enclosure that is only 4.5 in. (114 mm) deep.
This low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10TW3-D4 and has been fine-tuned through extensive real-world listening.
The PowerWedge™ subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
400 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
20.75 in / 527 mm
External Height (H)
14 in / 357 mm
External Depth (D1)
4.5 in / 114 mm
Net Weight
21.2 lb / 9.6 kg
JL Audio CS110LG-TW3 Brochure
PowerWedge-Series 10-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this sealed Truck PowerWedge™ subwoofer system, JL harnesses the performance of the 10TW3 to deliver amazing sub-bass from an enclosure that is only 6.25 in. (159 mm) deep at its base and 4.1 in. (104 mm) at the top.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10TW3 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
400 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed, truck enclosure
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
19 in / 483 mm
External Height (H)
12.375 in / 314 mm
External Depth (D1)
6.25 in / 159 mm
External Top Surface Depth (D2)
4.1 in / 104 mm
Net Weight
21.2 lb / 9.6 kg
JL Audio CS110TG-TW3 Brochure
PowerWedge-Series 12-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this low-profile PowerWedge™ subwoofer system, JL harnesses the performance of the 12TW3 to deliver amazing sub-bass from an enclosure that is only 4.5 in. (114 mm) deep.
This low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12TW3-D4 and has been fine-tuned through extensive real-world listening.
The PowerWedge™ subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
400 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
23.75 in / 603 mm
External Height (H)
15.625 in / 397 mm
External Depth (D1)
5.0625 in / 129 mm
Net Weight
30.5 lb / 13.8 kg
JL Audio CS112LG-TW3 Brochure
PowerWedge-Series 12-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this sealed Truck PowerWedge™ subwoofer system, JL harnesses the performance of the 12TW3 to deliver amazing sub-bass from an enclosure that is only 7 in. (178 mm) deep at its base and 4.5 in. (114 mm) at the top.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12TW3 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
System Nominal Impedance
2 Ω
Grille Included
Black Steel Mesh
Finish
Black carpet
Enclosure Type
Sealed, truck enclosure
Continuous Power Handling (RMS)
400 W
Physical Specifications
External Width (W)
21.75 in / 537 mm
External Height (H)
14.625 in / 371 mm
External Depth (D1)
7 in / 178 mm
External Top Surface Depth (D2)
4.5 in / 114 mm
Net Weight
29 lb / 13.2 kg
JL Audio CS112TG-TW3 Brochure
PowerWedge-Series 13-Inch 600-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
The 13TW5v2 low-profile subwoofer driver has received awards from around the world for its breakthrough performance capabilities in impossibly tight spaces. In this sealed Truck PowerWedge™ subwoofer system, JL harnessed the performance of this patented subwoofer driver to deliver amazing sub-bass performance from an enclosure that is only 7.25 in. (184 mm) deep at its base and 4.5 in. (114 mm) at the top.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 13TW5v2 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 250 - 600WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed, truck enclosure
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
21.25 in / 540 mm
External Height (H)
15.75 in / 400 mm
External Depth (D1)
7.25 in / 184 mm
External Top Surface Depth (D2)
4.5 in / 114 mm
Net Weight
34 lb / 15.42 kg
JL Audio CS113TG-TW5v2 Brochure
