From towing to travel, you depend on your truck to get you where you want to go, but can you rely on getting the best performance from your sound system? Now you can add deep, accurate bass in your truck without compromising valuable cabin space with the new R2-DB8V-TRK dual 8” Alpine Halo R-Series preloaded truck subwoofer enclosure with the ProLink system and amplifier space.
The enclosures were intentionally crafted to fit most full-size trucks. Two 8” subwoofers are preloaded into a compact enclosure for under the seat installation and linked with a ProLink bracket that can adjust from 51”-40”. Centered on the enclosures is an integrated amplifier mount tray that’s optimized for Alpine’s S-A75M Mono Power Amplifier (sold separately). Rubber “feet” are adjustable in height to accommodate uneven truck floors.
These ported subwoofer enclosures feature the next-generation 8” R-Series subwoofers with a more powerful motor that creates deeper bass while Alpine’s High Amplitude Multi-Roll (HAMR) surround technology allows the subwoofer cone to efficiently move air while staying cool for incredible accuracy. A new ceramic composite dust cap has higher heat resistance that ensures non-stop bass performance.
Alpine’s new preloaded truck subwoofer enclosures join the Alpine Halo family with a premium, unmistakable design. The enclosure pulls design cues from the Alpine Halo display with unique, curved edges outlined by a silver trim and a front link bracket cover with an Alpine logo badge. The 5/8” MDF enclosures are covered in a premium black carpet that will elevate the look of your truck.
With two preloaded R2-W8D2 8” R- Series subwoofers that are tuned to 36Hz, R2-DB8V-TRK is optimized to perform with Alpine’s R-Series sound system line. Dual voice coils are wired in parallel for a 2Ω load that’s compatible with Alpine’s R-Series R2-A75M mono power amplifier.
Features
Groundbreaking Alpine Halo Design
ProLink™ Ported Enclosure
Expandable Width from 40" to 51"
Compact, Under-the-Seat Installation in Most Full-Size Trucks
Integrated Amplifier Tray (not applicable with all vehicles)
Rubber, Modular Stackable Foot Design Accommodates Uneven Truck Floor Areas
Ported Enclosures with High-Performance S-Series Subwoofers
Front Link Alpine Branded Bracket
Side-Firing Cabin Loading Ports
Premium Alpine Wire Terminals
CARB Compliant 5/8" MDF Construction
Premium Black Carpet
Specifications
Dimensions: 40"-51" (Adjustable Width) x 8-3/4” (H) x 13-3/4” (D)
750W RMS
Frequency Response: 32Hz-200Hz
Sensitivity: 84dB
Dual voice coils Wired in Parallel for a 2Ω Load (Compatible with R-A75M)
Vented Enclosure Tuning Frequency: 36Hz
Custom spring-loaded speaker terminals fit up to 12AWG speaker wire
Alpine R2-DB8V-TRK BrochureAlpine R2-DB8V-TRK Manual
R-Series Loaded 600-Watt Thin 10-Inch 2-Ohm Subwoofer Enclosure
Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow preloaded subwoofer enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.
Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series shallow subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
Integrated cooling fins located in the core of the subwoofer help dissipate the heat generated by the rapid subwoofer movement for enhanced cooling reliability and hours of uninterrupted playtime. The unique CoolMount dual-panel mount subwoofer motor enhances cooling.
Alpine’s Gen2 DD-Linear Magnetic Circuit technology, a compact and efficient dual-gap voice coil structure, allows for better control over the motor, resulting in lower distortion and precise bass control. The preloaded enclosures use the subwoofer frame as bracing fora more ridged design and better bass response.
A lightweight yet rigid aluminum dust cap allows the R-Series shallow subwoofer to transition sound quickly with minimal distortion and project the bass off the surface of the speaker for hard-hitting yet smooth bass performance. The included adjustable mounting brackets allow for a downfire mount configuration.
With dual voice coils wired in parallel for a 2Ω load, the Alpine R-Series 10" shallow subwoofer enclosure is optimized to perform with Alpine's S-A60M or R-A75M mono amplifiers.
Features
Optimal sealed cabinet quality
Aluminum Dust Cap
Neodymium Magnet
Alpine Gen2 DD Linear Magnetic Circuit
CARB compliant ¾” MDF construction
Premium Alpine embroidered black carpet
Alpine-branded terminal cup
Pre-installed steel mesh grille
Includes a 10” R-Shallow Subwoofer (RS-W10D4)
Rubber, modular stackable foot design
Specifications
Dimensions: 21.15” W x 5.25” H x 16” L
600W RMS Power Handling
Frequency response: 29Hz – 200Hz
Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)
Nominal Impedance: 2Ω
Voice Coil: 4”(101.6mm)
R-Series Loaded 600-Watt Thin 12-Inch 2-Ohm Subwoofer Enclosure
Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow preloaded subwoofer enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.
Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series shallow subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
Integrated cooling fins located in the core of the subwoofer help dissipate the heat generated by the rapid subwoofer movement for enhanced cooling reliability and hours of uninterrupted playtime. The unique CoolMount dual-panel mount subwoofer motor enhances cooling.
Alpine’s Gen2 DD-Linear Magnetic Circuit technology, a compact and efficient dual-gap voice coil structure, allows for better control over the motor, resulting in lower distortion and precise bass control. The preloaded enclosures use the subwoofer frame as bracing fora more ridged design and better bass response.
A lightweight yet rigid aluminum dust cap allows the R-Series shallow subwoofer to transition sound quickly with minimal distortion and project the bass off the surface of the speaker for hard-hitting yet smooth bass performance. The included adjustable mounting brackets allow for a downfire mount configuration.
With dual voice coils wired in parallel for a 2Ω load, the Alpine R-Series 12" shallow subwoofer enclosure is optimized to perform with Alpine's S-A60M or R-A75M mono amplifiers.
Features
Optimal sealed cabinet quality
Aluminum Dust Cap
Neodymium Magnet
Alpine Gen2 DD Linear Magnetic Circuit
CARB compliant ¾” MDF construction
Premium Alpine embroidered black carpet
Alpine-branded terminal cup
Pre-installed steel mesh grille
Includes a 12” R-Shallow Subwoofer (RS-W12D4)
Rubber, modular stackable foot design
Specifications
Dimensions: 26.5” W x 5.25” H x 17” D
600W RMS Power Handling
Frequency response: 26Hz – 200Hz
Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)
Nominal Impedance: 2Ω
Voice Coil: 4”(101.6mm)
S-Series Dual Loaded 600-Watt 8-Inch 2-Ohm Subwoofer Enclosure for Select Jeep Wrangler-JL Gladiator-JT and other Pickup Vehicles
From towing to travel, you depend on your truck to get you where you want to go, but can you rely on getting the best performance from your sound system? Now you can add deep, accurate bass in your truck without compromising valuable cabin space with the new S-DB8V-TRK dual 8” Alpine Halo S-Series preloaded truck subwoofer enclosure with the ProLink system and amplifier space.
The enclosures were intentionally crafted to fit most full-size trucks. Two 8” subwoofers are preloaded into a compact enclosure for under the seat installation and linked with a ProLink bracket that can adjust from 51”-40”. Centered on the enclosures is an integrated amplifier mount tray that’s optimized for Alpine’s S-A60M Mono Power Amplifier (sold separately). Rubber “feet” are adjustable in height to accommodate uneven truck floors.
The enclosures are designed for the unique cabin environment of your truck. The ported subwoofer enclosures feature Alpine’s reliable 8” S-Series subwoofers. The subwoofers are designed with an improved voice coil that brings out the full potential of the subwoofer. The custom-stamped steel frame is designed to withstand the rigors of the strong S-Series motor. Frame leg vents, as well as a vented backplate, keep the subwoofer cool for non-stop bass performance.
Alpine’s new preloaded truck subwoofer enclosures join the Alpine Halo family with a premium, unmistakable design. The enclosure pulls design cues from the Alpine Halo display with unique, curved edges outlined by a silver trim and a front link bracket cover with an Alpine logo badge. The 5/8” MDF enclosures are covered in a premium black carpet that will elevate the look of your truck.
With two preloaded S-W8D2 8” S- Series subwoofers that are tuned to 36Hz, the S-DB8V-TRK is optimized to perform with Alpine’s S-Series sound system line. Dual voice coils are wired in parallel for a 2Ω load that’s compatible with Alpine’s S-Series S-A60M mono power amplifier.
Features
Groundbreaking Alpine Halo Design
ProLink™ Ported Enclosure
Expandable Width from 40" to 51"
Compact, Under-the-Seat Installation in Most Full-Size Trucks
Integrated Amplifier Tray (not applicable with all vehicles)
Rubber, Modular Stackable Foot Design Accommodates Uneven Truck Floor Areas
Ported Enclosures with High-Performance S-Series Subwoofers
Front Link Alpine Branded Bracket
Side-Firing Cabin Loading Ports
Premium Alpine Wire Terminals
CARB Compliant 5/8" MDF Construction
Premium Black Carpet
Specifications
Dimensions: 40"-51" (Adjustable Width) x 8-3/4” (H) x 13-3/4” (D)
600W RMS
Frequency Response: 34Hz-200Hz
Sensitivity: 84dB
Dual voice coils Wired in Parallel for a 2Ω Load (Compatible with S-A60M)
Vented Enclosure Tuning Frequency: 36Hz
Custom spring-loaded speaker terminals fit up to 12AWG speaker wire
Alpine S-DB8V-TRK BrochureAlpine S-DB8V-TRK Manual
Alpine 350-Watt 10-Inch Truck Subwoofer Enclosure, 2Ω Final Impedance
With a compact wedge-style design and shallow mount, the SBT-S10V (2-ohm system) is a perfect fit for truck applications, with a design that works in small spaces. Radial Vented VC Heat Sink & Airflow Management System actively manages voice coil temperatures by forcing air directly across the heat sink system.
FEA Optimized Dual-Sided Machined CRC Motor Structure creates a symmetrical magnetic field with evenly distributed flux density to greatly reduce distortion, while further improving power handling and output. The High-Amplitude Multi Roll Surround Design allows for extreme excursions without sacrificing valuable cone area. FEA Optimized for linearity and made with injection-molded Santoprene ®, the HAMR surround is a key part of the suspension system that provides accurate, distortion-free control at extreme excursions.
Specifications
2Ω Impedance
Ported Enclosure Design
Frequency Response: 28Hz-200Hz
Dimensions 21-5/8" Wide x 15-1/4" Tall x 7-1/4" Deep 1x 3-15/16"
Alpine SBT-S10V Manual
Alpine 350-Watt Loaded 10-Inch Subwoofer-Enclosure for 2007-2018 Jeep-Wrangler JK-Unlimited, 2Ω Final Impedance
When you have a Wrangler, you don’t have extra space to spare. Alpine engineered the SBV-10-WRA to conveniently fit under the front passenger’s seat making efficient use of space. The SBV-10-WRA is a custom-shaped enclosure that fits snugly under the seat frame, so no mounting hardware is required. (NOTE: designed for fitment in Jeeps with the factory carpet. Fitment is not guaranteed with aftermarket or removed carpet)
Enjoy impactful bass, with your Wrangler’s top on or off. The SBV-10-WRA loads the lower frequency sound into the passenger’s foot well to deliver quality sound and maximized bass extension at all times, so your music continues even when the asphalt ends.
Specifications
10” Pre-loaded Sealed Custom-fit Enclosure
Weather Resistant (IP66 rating)
Power Handling: 350WRMS/1050W Peak
Nominal Impedance 2Ω
Frequency Response: 45-200Hz
OEM-grade Molex 2-pin connector w/pigtail wire harness
Alpine SBV-10-WRA Manual
Alpine 350-Watt Thin 10-Inch Subwoofer Driver, 2Ω or 4Ω Impedance
The SWT 10” Truck Subwoofer has been engineered to offer more installation flexibility without sacrificing big output to build the ideal sound system for your truck. At 4-1/8” deep, these subs provide deep bass performance where it normally couldn’t fit in a truck. And the vented pole optimized for 4-1/8” deep box is the ideal enclosure size meaning great bass performance can fit just about anywhere in your truck.
The FEA-Optimized Motor Structure together with Alpine's revolutionary High-Amplitude Multi Roll (HAMR) Suspension Design gives the new SWT Truck Subwoofers the highest X-max and SPL output in its category.
The new SWT Truck Subwoofers deliver the best-in-class bass output, ultra-low distortion, and unparalleled sound quality. With a real world, measured 11mm of X-max, the SWT subwoofers perform like traditional models, yet fit in smaller spaces.
4 UNIQUE ALPINE TECHNOLOGIES
Radial Vented VC Heat Sink & Airflow Management SystemActively manages voice coil temperatures by forcing air directly across the heat sink system.
FEA Optimized Dual-Sided Machined CRC Motor StructureCreates a symmetrical magnetic field with evenly distributed flux density to greatly reduce distortion, while further improving power handling and output.
FEA Optimized Injection Molded TPE Spider with Pass-Through Gap DesignProvides the mechanical clearance needed for over 50mm of peak-to-peak excursion, unleashing massive output potential from a small package
FEA Optimized HAMR SurroundThe High-Amplitude Multi Roll Surround Design allows for extreme excursions without sacrificing valuable cone area. FEA Optimized for linearity and made with injection-molded Santoprene ®, the HAMR surround is a key part of the suspension system that provides accurate, distortion-free control at extreme excursions.
Specifications
350W RMS, 1000W Peak Power Handling
Frequency Response: 30Hz-200Hz
Mounting Depth 4-3/16"
2Ω or 4Ω Voice Coil
10-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The JL Audio 10" TW1 automotive thin subwoofer driver chassis offers a shallow mounting depth and excellent linear excursion capability while requiring a small enclosure (0.35 cu.ft. / 10 liters). The cast alloy frame design on the JL 10TW1 is capable of operating in very tight spaces like under-seat installations in trucks.
The 10TW1 design uses a "concentric tube" structure built into the injection-molded cone body. This structure supports the voice coil and a full annular spider, while permitting the placement of a large motor structure further forward in the speaker than with conventional designs.
The 10TW1 thin subwoofer also features a clever frame design that minimizes the frontal clearance required for the excursion of the driver. This is accomplished by recessing the suspension attachment surface, so that most of the forward excursion occurs within the frame's dimensions. Thanks to this feature, the 10TW1 requires only 0.87 inches (22 mm) of frontal clearance, even with its grille installed. This allows for more efficient use of space and increased enclosure volume within a given overall depth.
Although the JL Audio 10TW1-2 and 10TW1-4 thin subwoofer drivers are optimized for an enclosure much smaller than most other 10 inch subwoofer drivers, they never sound like a big woofer struggling in a tiny box...instead, the 10TW1's delivers all the rich, deep, controlled bass you have come to expect from a JL Audio subwoofer system.
Very shallow mounting depth (4.36 in / 111 mm)
No pole vent: permits mounting close to rear wall of enclosure
Extremely small sealed enclosure volume requirements
Long linear excursion capability (0.40 in / 10 mm, one-way)
DMA-optimized motor design
Patented "concentric tube" architecture
Patented "floating cone attach method" technology
Cast alloy frame with flat edges for tight driver grouping
Injection molded, mica-filled polypropylene cone
Rubber surround
Steel mesh grille included with each driver
Precision-built in USA at JL Audio’s Miramar, Florida factory with global components
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
2Ω/4Ω
JL Audio 10TW1 Manual
W1-Series 10-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The JL Audio 10" W1v3 subwoofer driver is a very suitable option when space is limited with smaller amplifiers. It features a low mounting depth of 4.6 inches and a compact motor structure that allows it to comfortably fit in tight mounting locations. There is no pole vent on the rear of the subwoofer which allows the motor structure to be placed directly against an enclosure boundary. Excellent excursion capability and linearity allow the 10W1v3 to reproduce sub-bass with shocking extension and quality.
The JL Audio 10W1v3 is best used with an amplifier in the 75W - 300W RMS range and is optimized to operate in a compact 0.55 cu. ft. (15.57 l) sealed enclosure.
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
2Ω/4Ω
JL Audio 10W1v3 Manual
W3-Series 10-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The JL Audio 10W3v3 subwoofer driver has excellent power handling, reasonable enclosure requirements, and a long excursion for its chassis to deliver excellent bass reproduction in 500W RMS power applications. JL Audio technologies and proprietary assembly designs in the 10W3v3-2 and 10W3v3-4 subwoofers enhance linearity and reliable performance results.
The JL Audio 10W3v3 is best used with an amplifier in the 150W - 500W RMS range and is optimized to operate in a compact 0.625 cu. ft. (17.7 l) sealed enclosure, or a 1.25 cu. ft. (35.4 l) ported enclosure.
General Specifications
Continuous Power Handling
500W RMS
Recommended Amplifier Power
150- 500W RMS
Nominal Impedance
2Ω
JL Audio 10W3v3 Manual
TW1-Series 12-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The 12" TW1 thin subwoofer driver by JL Audio has a shallow mounting depth while maintaining excellent excursion capability in a thin mounty chassis design to fit into an enclosure no bigger than (0.65 cu.ft. / 18.4 liters). This 12TW1 subwoofer is capable of operating in extremely tight spaces including under-seat installations in trucks and other automotive applications requiring a compact, low profile subwoofer design.
JL Audio's patented thin-line woofer technology utilizes a "concentric tube" structure built into the injection-molded cone body supporting the voice coil and spider. This patented design places the large motor structure further forward in the speaker than conventional thin subwoofer designs.
The JL Audio 12TW1 sub also features a chassis design that minimizes the top clearance required for the linear excursion limits of the subwoofer driver. This is accomplished by recessing the suspension attachment surface, so that most of the forward excursion occurs within the frame's dimensions. The 12TW1 requires only 0.87 inches (22 mm) of frontal clearance with or without the subwoofer grille installed.
The JL Audio 12" 12TW1-2 and 12TW1-4 subwoofer drivers are optimized for an enclosure much smaller than any other JL Audio twelve-inch subwoofer driver, it never sounds like a big woofer struggling in a tiny box...instead, it delivers all the rich, deep, controlled bass you have come to expect from a JL Audio subwoofer system.
Very shallow mounting depth (4.62 in / 117 mm)
No pole vent: permits mounting close to rear wall of enclosure
Extremely small sealed enclosure volume requirements
Long linear excursion capability (0.40 in / 10 mm, one-way)
DMA-optimized motor design
Patented "concentric tube" architecture
Patented "floating cone attach method" technology
Cast alloy frame with flat edges for tight driver grouping
Injection molded, mica-filled polypropylene cone
Rubber surround
Steel mesh grille included with each driver
Precision-built in USA at JL Audio’s Miramar, Florida factory with global components
General Specifications
Continuous Power Handling ()
300W RMS
Recommended Amplifier Power (RMS)
75W - 300W RMS
Nominal Impedance (Znom)
2Ω
JL Audio 12TW1 Manual
W1-Series 12-Inch 300-Watt Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The 12" W1v3 automotive subwoofer driver by JL Audio is a lightweight 12-inch driver with excellent performance capabilities at a moderate 300-Watts. The design of the chassis allows an average mounting depth with no pole-vent on the back side of the magnet so the rear of the motor structure can be placed directly against an enclosure boundary. This 12" subwoofer can reproduce sub-bass with shocking extension and quality.
The JL Audio 12W1v3-2 and 12W1v3-4 subwoofers are best used with an amplifier in the 75W - 300W range and is optimized to operate in a compact 1.10 cu. ft. (31.5 l) sealed enclosure.
General Specifications
Continuous Power Handling
300W RMS
Recommended Amplifier Power
75W - 300W RMS
Nominal Impedance
2Ω
JL Audio 12W1v3 Manual
W3-Series 12-Inch 500-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Single Voice Coil
This 12-inch W3v3 subwoofer driver by JL Audio delivers world-class sound quality in a 500W RMS power package.
The JL Audio 12W3v3-2 and 12W3v3-4 automotive subs are best used with an amplifier in the 150-Watt - 500-Watt RMS range and are optimized to operate in a compact 1.25 cu. ft. (35.4 l) sealed enclosure, or a 1.75 cu. ft. (49.6 l) ported enclosure.
General Specifications
Continuous Power Handling (RMS)
500 W
Recommended Amplifier Power (RMS)
150 - 500 W
Nominal Impedance (Znom)
2 Ω
JL Audio 12W3v3 Manual
TW5-Series 13.5-Inch 600-Watt Thin Subwoofer Driver, 2-Ohm or 4-Ohm SVC
The JL Audio 13.5" TW5v2 thin subwoofer driver uses a chassis with a “concentric tube” structure that supports the 7-inch diameter voice coil and the suspension attachments. This permits placement of the large motor structure much further forward in the subwoofer chassis than with conventional thin sub designs, while allowing excellent linear excursion capability and mechanical stability.
The 13TW5v2 improves upon the original 13-Inch TW5 driver with 13% greater linear excursion capability. The cast alloy chassis has also been modified for greater strength and the redesigned motor now features an annular vent. The v2 is available in single 2-ohm and single 4-ohm voice coil configurations.
In keeping with its “tight-spaces” mission, the 13TW5v2 is optimized for enclosures that are far smaller than most 12-inch woofers require and only a bit larger than the air space needs of a typical, small-box 12-inch woofer. The mounting system is designed to fit in about the same footprint as a typical 12-inch woofer.
The JL Audio 13TW5v2-2 and the 13TW5v2-4 thin subwoofers are best used with amplifier power in the 250-Watt - 600-Watt range and is optimized to operate in a 0.80 cu. ft. (22.7 l) sealed enclosure.
Never has such high-quality subwoofers-bass been possible in the most challenging thin installation applications.
General Specifications
Continuous Power Handling
600W RMS
Recommended Amplifier Power
250W - 600W RMS
Nominal Impedance
2Ω
JL Audio 13TW5v2 Manual
W3-Series 13-Inch 600-Watt Subwoofer Driver, 2-Ohm or 4-Ohm Single Voice Coil
If you have the space, it makes a tremendous sense to maximize your subwoofer system's piston area to enhance efficiency (and output). It gets even better when the larger driver delivers additional power handling and excursion. For the preceding reasons, the 13W3v3 can be the best choice for those seeking high output with great sound quality at medium power levels.
As with the smaller W3v3's, several exclusive JL Audio technologies and proprietary assembly techniques are applied to the 13W3v3 to enhance linearity and reliability.
The 13W3v3 2Ω or 4Ω model is best used with an amplifier powered in the 150W - 600W range and is optimized to operate in a moderate size 1.5 cu. ft. (42.5 l) sealed enclosure, or a 2.25 cu. ft. (63.7 l) ported enclosure. Detailed enclosure recommendations can be found in the "Specifications" tab.
General Specifications
Continuous Power Handling (RMS)
600W
Recommended Amplifier Power (RMS)
150 - 600W
Nominal Impedance (Znom)
4Ω
Nominal Diameter
13.5 in / 345 mm
Overall Diameter (A)
14.0 in / 356 mm
Mounting Hole Diameter (B)
12.5625 in / 319 mm
Bolt Hole Circle Diameter (C)
13.2 in / 335 mm
Motor Outer Diameter (D)
5.79 in / 147 mm
Mounting Depth (E)
7.63 in / 194 mm
Driver Displacement
0.096 cu ft / 2.72 liters
Net Weight
17.75 lb / 8.05 kg
Free Air Resonance (Fs)
23.66 Hz
Electrical “Q” (Qes)
0.465
Mechanical “Q” (Qms)
6.774
Total Speaker “Q” (Qts)
0.435
Equivalent Compliance (Vas)
4.793 cu ft / 135.74 L
One-Way Linear Excursion (Xmax)*
0.610 in / 15.5 mm
Reference Efficiency (no)
0.37%
Efficiency (1 W / 1 m)**
87.90 dB SPL
Effective Piston Area (Sd)
103.850 sq in / 0.0670 sq m
DC Resistance (Re)
3.569 Ω
JL Audio 13W3v3 Manual
MicroSub-Series 10-Inch 300-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
This incredible MicroSub™ subwoofer system delivers the kind of output and extension that is normally possible with only much larger systems. The key to its performance lies in the precise tuning of its 10TW1 subwoofer driver into an efficient slot-ported design.
Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The flared port entry and exit further enhance sound quality by minimizing air-flow noises through the port.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 75 - 300WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
300 W
System Nominal Impedance
2 Ω
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
20.875 in / 530 mm
External Height (H)
13.25 in / 337 mm
External Depth (D1)
6.375 in / 162 mm
Net Weight
25.70 lb / 11.66 kg
JL Audio CP110LG-TW1-2 Brochure
MicroSub-Series 8" Enclosed Dual 8-Inch 500-Watt Subwoofer System, 2Ω Ported Enclosure
This incredible MicroSub™ subwoofer system delivers the kind of output and extension that is normally possible with only much larger systems. The key to its performance lies in the precise tuning of its dual 8W3v3 subwoofer drivers, each in separate airspace, with an efficient slot-ported design.
Extensive interior bracing permits the use of thinner wall material that maximizes the enclosure's internal volume relative to its exterior volume. The port for each driver wraps around two walls of the enclosure to produce the necessary low tuning frequency that ensures excellent extension and response smoothness. The two flared port entries/exits, one on each end of the enclosure, further enhance sound quality by minimizing air-flow noises through these ports.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with silver "JL AUDIO" embroidery on front baffle. Steel mesh grilles are included to protect the subwoofer drivers.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 200 - 500WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
500 W
System Nominal Impedance
2 Ω
Enclosure Type
Slot-ported, Low-profile
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
Net Weight
32.2 lb / 14.61 kg
External Width (W)
35.5 in / 902 mm
External Height (H)
11.0 in / 279 mm
External Depth (D1)
5.125 in / 130 mm
JL Audio CP208LG-W3v3 Brochure
BassWedge-Series Dual 10-Inch 600-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofers to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofers firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 150 - 600WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
29.61 in / 752 mm
External Height (H)
13.77 in / 350 mm
External Depth (D1)
17.38 in / 441 mm
External Top Surface Depth (D2)
14 in / 356 mm
Net Weight
50.7 lb / 23 kg
JL Audio CP210-W0v3 Brochure
BassWedge-Series Dual 12-Inch 600-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
This powerful slot-ported BassWedge™ subwoofer system delivers awesome output at an unsurpassed value.
The slot-port runs along the bottom of the enclosure and fires on the same plane as the woofers to produce excellent extension and response smoothness. The port mouth is flared to minimize air-flow noises.
The ultra-versatile BassWedge™ shape has extended sides so that it can be placed with the woofers firing out or straight down, off the floor of the vehicle. The shape works equally well in forward or rear-firing installations. This gives you plenty of options for tweaking the loading of the enclosure into your vehicle.
This subwoofer system is shipped wired, loaded and ready to connect via a push-button terminal.
Finish: Dark gray, high-grade automotive carpet with "JL AUDIO" embroidery on the top edge and "Slot-Ported BassWedge™" embroidered on the port mouth.
Construction: MDF
Recommended amplifier power: 150 - 600WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2 Ω
Enclosure Type
Slot-ported
Finish
Gray carpet
Grille Included
No
Physical Specifications
External Width (W)
31.375 in / 797 mm
External Height (H)
15.18 in / 386 mm
External Depth (D1)
20.3 in / 516 mm
External Top Surface Depth (D2)
15.75 in / 400 mm
Net Weight
60.3 lb / 27.35 kg
JL Audio CP212-W0v3 Brochure
PowerWedge-Series 10-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this low-profile PowerWedge™ subwoofer system, JL harnesses the performance of the 10TW3 to deliver amazing sub-bass from an enclosure that is only 4.5 in. (114 mm) deep.
This low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10TW3-D4 and has been fine-tuned through extensive real-world listening.
The PowerWedge™ subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
400 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
20.75 in / 527 mm
External Height (H)
14 in / 357 mm
External Depth (D1)
4.5 in / 114 mm
Net Weight
21.2 lb / 9.6 kg
JL Audio CS110LG-TW3 Brochure
PowerWedge-Series 10-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this sealed Truck PowerWedge™ subwoofer system, JL harnesses the performance of the 10TW3 to deliver amazing sub-bass from an enclosure that is only 6.25 in. (159 mm) deep at its base and 4.1 in. (104 mm) at the top.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 10TW3 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
400 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed, truck enclosure
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
19 in / 483 mm
External Height (H)
12.375 in / 314 mm
External Depth (D1)
6.25 in / 159 mm
External Top Surface Depth (D2)
4.1 in / 104 mm
Net Weight
21.2 lb / 9.6 kg
JL Audio CS110TG-TW3 Brochure
PowerWedge-Series 12-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this low-profile PowerWedge™ subwoofer system, JL harnesses the performance of the 12TW3 to deliver amazing sub-bass from an enclosure that is only 4.5 in. (114 mm) deep.
This low-profile enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12TW3-D4 and has been fine-tuned through extensive real-world listening.
The PowerWedge™ subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
400 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
23.75 in / 603 mm
External Height (H)
15.625 in / 397 mm
External Depth (D1)
5.0625 in / 129 mm
Net Weight
30.5 lb / 13.8 kg
JL Audio CS112LG-TW3 Brochure
PowerWedge-Series 12-Inch 400-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
In this sealed Truck PowerWedge™ subwoofer system, JL harnesses the performance of the 12TW3 to deliver amazing sub-bass from an enclosure that is only 7 in. (178 mm) deep at its base and 4.5 in. (114 mm) at the top.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 12TW3 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 100 - 400WNominal Impedance: 2 Ω
General Specifications
System Nominal Impedance
2 Ω
Grille Included
Black Steel Mesh
Finish
Black carpet
Enclosure Type
Sealed, truck enclosure
Continuous Power Handling (RMS)
400 W
Physical Specifications
External Width (W)
21.75 in / 537 mm
External Height (H)
14.625 in / 371 mm
External Depth (D1)
7 in / 178 mm
External Top Surface Depth (D2)
4.5 in / 114 mm
Net Weight
29 lb / 13.2 kg
JL Audio CS112TG-TW3 Brochure
PowerWedge-Series 13-Inch 600-Watt Enclosed Subwoofer System, 2Ω Sealed Enclosure
The 13TW5v2 low-profile subwoofer driver has received awards from around the world for its breakthrough performance capabilities in impossibly tight spaces. In this sealed Truck PowerWedge™ subwoofer system, JL harnessed the performance of this patented subwoofer driver to deliver amazing sub-bass performance from an enclosure that is only 7.25 in. (184 mm) deep at its base and 4.5 in. (114 mm) at the top.
This enclosure design has been carefully engineered to the optimum sealed enclosure alignment for the 13TW5v2 and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal.
Finish: Black, high-grade automotive carpet with "JL AUDIO" embroidered in silver on the front baffle. A steel mesh grille is included to protect the subwoofer driver.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 250 - 600WNominal Impedance: 2 Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2 Ω
Enclosure Type
Sealed, truck enclosure
Finish
Black carpet
Grille Included
Black Steel Mesh
Physical Specifications
External Width (W)
21.25 in / 540 mm
External Height (H)
15.75 in / 400 mm
External Depth (D1)
7.25 in / 184 mm
External Top Surface Depth (D2)
4.5 in / 114 mm
Net Weight
34 lb / 15.42 kg
JL Audio CS113TG-TW5v2 Brochure
High Output Series 10-Inch 600-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
JL Audio's patented High Output Enclosures are designed to deliver the ultimate high-performance bass experience with a rare combination of superb sound quality and awesome output. In the HO110-W6v3, the high power handling of the 10W6v3 subwoofer driver, combined with its small enclosure requirements, results in a very compact subwoofer system that is capable of impressive output with moderate amplification.
JL Audio's patented, chamber-coupled port design (U.S. patent #6,625,292) wraps around the inner enclosure boundary and terminates just above the woofer, coupling the port output to the woofer's direct output. This also provides the necessary surface area and port length to maximize the performance of the W6v3 driver. This enclosure design has been carefully engineered to the optimum ported alignment for the 10W6v3, and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. While no grille is provided, the recessed mounting baffle provides some protection for the woofer. A steel mesh woofer grille insert can be purchased separately (Model: SGR-10W6v2/v3), if additional woofer protection is desired.
Finish: Dark gray, high-grade automotive carpet, with black carpet on woofer baffle. "JL AUDIO" is embroidered in silver on the side surface of the enclosure.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 200 - 600WNominal Impedance: 2Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2 Ω
Enclosure Type
Chamber-coupled, slot-ported, rear-firing design
Finish
Dark gray carpet with black insert
Grille Included
No
Physical Specifications
External Width (W)
12.125 in / 308 mm
External Height (H)
14 in / 356 mm
External Depth (D1)
21.75 in / 552 mm
Net Weight
47.8 lb / 21.7 kg
JL Audio HO110-W6v3 Brochure
High Output Series 10-Inch 500-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
JL Audio's patented High Output Enclosures are designed to deliver the ultimate high-performance bass experience with a rare combination of superb sound quality and awesome output.
JL Audio's patented, chamber-coupled port design (U.S. patent #6,625,292) wraps around the inner enclosure boundary and terminates on one side of the woofer, coupling the port output to the woofer's direct output. This also provides the necessary surface area and port length to maximize the performance of the W3v3 driver.
This enclosure design has been carefully engineered to the optimum ported alignment for the 10W3v3, and has been fine-tuned through extensive real-world listening. This efficient system will produce superb output with as little as 150W of amplifier power, but performs best with 300 - 500W of power.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. Three solid aluminum bars provide stylish and rugged woofer protection.
The angled-back design saves precious cargo space by allowing the enclosure to fit tightly against the back of a vehicle's rear seat.
Finish: Dark gray, high-grade automotive carpet, with black carpet on woofer baffle. "JL AUDIO" is embroidered in silver on the top surface of the enclosure.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 150 - 500WNominal Impedance: 2Ω
General Specifications
Continuous Power Handling (RMS)
500 W
System Nominal Impedance
2 Ω
Enclosure Type
Chamber-coupled, slot-ported, rear-firing design
Finish
Dark gray carpet with black insert
Grille Included
Aluminum Bar Grille
Physical Specifications
External Width (W)
29.5 in / 749 mm
External Height (H)
13.5 in / 343 mm
External Depth (D1)
12.0 in / 305 mm
External Top Surface Depth (D2)
7.5 in / 190.5 mm
Net Weight
34.7 lb / 15.74 kg
JL Audio HO110RG-W3v3 Brochure
High Output Series 12-Inch 600-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
JL Audio's patented High Output Enclosures are designed to deliver the ultimate high-performance bass experience with a rare combination of superb sound quality and awesome output. In the HO112-W6v3, the high power handling of the 12W6v3 subwoofer driver, combined with its small enclosure requirements, results in a very compact subwoofer system that is capable of impressive output with moderate amplification.
JL Audio's patented, chamber-coupled port design (U.S. patent #6,625,292) wraps around the inner enclosure boundary and terminates just above the woofer, coupling the port output to the woofer's direct output. This also provides the necessary surface area and port length to maximize the performance of the W6v3 driver. This enclosure design has been carefully engineered to the optimum ported alignment for the 12W6v3, and has been fine-tuned through extensive real-world listening.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. While no grille is provided, the recessed mounting baffle provides some protection for the woofer. A steel mesh woofer grille insert can be purchased separately (Model: SGR-12W6v2/v3), if additional woofer protection is desired.
Finish: Dark gray, high-grade automotive carpet, with black carpet on woofer baffle. "JL AUDIO" is embroidered in silver on the side surface of the enclosure.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 200 - 600WNominal Impedance: 2Ω
General Specifications
Continuous Power Handling (RMS)
600 W
System Nominal Impedance
2 Ω
Enclosure Type
Chamber-coupled, slot-ported, rear-firing design
Finish
Dark gray carpet with black insert
Grille Included
No
Physical Specifications
External Width (W)
14.5 in / 368 mm
External Height (H)
16 in / 406 mm
External Depth (D1)
24 in / 610 mm
Net Weight
60.7 lb / 27.52 kg
JL Audio HO112-W6v3 Brochure
High Output Series 12-Inch 500-Watt Enclosed Subwoofer System, 2Ω Ported Enclosure
JL Audio's patented High Output Enclosures are designed to deliver the ultimate high-performance bass experience with a rare combination of superb sound quality and awesome output.
JL Audio's patented, chamber-coupled port design (U.S. patent #6,625,292) wraps around the inner enclosure boundary and terminates on one side of the woofer, coupling the port output to the woofer's direct output. This also provides the necessary surface area and port length to maximize the performance of the W3v3 driver.
This enclosure design has been carefully engineered to the optimum ported alignment for the 12W3v3, and has been fine-tuned through extensive real-world listening. This efficient system will produce superb output with as little as 150W of amplifier power, but performs best with 300 - 500W of power.
This subwoofer system is shipped wired, loaded and ready to connect via a five-way binding post terminal. Three solid aluminum bars provide stylish and rugged woofer protection.
The angled-back design saves precious cargo space by allowing the enclosure to fit tightly against the back of a vehicle's rear seat.
Finish: Dark gray, high-grade automotive carpet, with black carpet on woofer baffle. "JL AUDIO" is embroidered in silver on the top surface of the enclosure.
Construction: CNC-Cut High-Grade MDF
Recommended amplifier power: 150 - 500WNominal Impedance: 2Ω
General Specifications
Continuous Power Handling (RMS)
500 W
System Nominal Impedance
2 Ω
Enclosure Type
Chamber-coupled, slot-ported, rear-firing design
Finish
Dark gray carpet with black insert
Grille Included
Aluminum Bar Grille
Physical Specifications
External Width (W)
32.25 in / 819 mm
External Height (H)
15.25 in / 387 mm
External Depth (D1)
13.5 in / 343 mm
External Top Surface Depth (D2)
7.5 in / 190.5 mm
Net Weight
46.9 lb / 21.27 kg
JL Audio HO112RG-W3v3 Brochure
Dual 12-Inch 2-Ohm 800-Watt Subwoofer-Enclosure for Select 2019-UP RAM-1500 Crew-Cab Models with Fixed Rear-Seat
This generation of RAM’s big hauler combines a bold new design with major advancements in aerodynamics, technology and towing capabilities. Unfortunately, the factory sound systems are greatly deficient in the bass reproduction department.
Fortunately, JL's engineers tackled this challenge head on and developed a subwoofer solution that fills your Crew Cab with stunning amounts of deep bass output. Featuring a 100% fiberglass, sealed enclosure design, this Stealthbox® houses two of JL Audio's revolutionary 12TW3 thin-line subwoofers and installs neatly under the rear seat, without compromising rear seat comfort. Rear seat folding is unaffected, and we even left space on the enclosure that’s perfect for a clean, hidden amplifier installation!
Specifications
The Hard Data: Contains two 12TW3-D8 Subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Fits 1500 Crew Cab with fixed (non- reclining) rear seat. Will not fit 2500 or 3500 models.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-D-5GRAMCCF/12TW3 Installation Manual
Dual 10-Inch 2-Ohm 800-Watt Subwoofer-Enclosure for Select 2019-UP RAM-1500 Crew-Cab Trucks, with Reclining Rear-Seat
This generation of RAM’s big hauler combines a bold new design with major advancements in aerodynamics, technology and towing capabilities. Sadly, the spacious interior leaves little room for a high-performance subwoofer enclosure.
Fortunately, JL's engineers welcomed this challenge head on and developed a subwoofer solution that fills your Crew Cab with loads of deep bass output. Featuring an all-fiberglass, sealed enclosure design, this Stealthbox® houses two of JL Audio's revolutionary 10TW3 thin-line subwoofers and installs neatly under the rear seat, without compromising rear seat comfort. Rear seat folding and recline are unaffected, and we even left a spot on the enclosure that’s perfect for a clean, hidden amplifier installation!
Specifications
Contains two 10TW3-D8 Subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Installation requires removal of under-seat storage divider panel, if equipped. Fits 1500 Crew Cab with reclining rear seat. Will not fit 2500 or 3500 models.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-D-5GRAMCCR/10TW3 Installation Manual
Dual 10-Inch 2-Ohm 800-Watt Subwoofer-Enclosure for Select 2020-UP RAM 1500 Quad-Cab Vehicles
This generation of RAM’s big hauler combines a bold new design with major advancements in aerodynamics, technology and towing capabilities. Disappointingly, the original equipment audio systems lack the low-frequency output and performance you might expect.
Luckily, JL-Audio engineers are experts in maximizing bass from minimal space and developed a subwoofer solution that fills your Quad Cab with loads of powerful bass output. Featuring a 100% fiberglass, sealed enclosure design, this Stealthbox houses two of JL-Audio's innovative 10TW3 thin-line subwoofers and installs neatly under the rear seat, without compromising rear seat comfort or folding. Theyeven left space on the enclosure that’s perfect for a small, hidden amplifier installation!
The Hard Data: Contains two 10TW3-D8 Subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Installation requires removal of rear underseat storage tray, if equipped.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-D-5GRAMQC/10TW3 Manual
Single 12-Inch 2-Ohm 500-Watt Subwoofer-Enclosure for Select 2009-UP Dodge-Challenger
This reborn American legend just might be the most faithful interpretation of the classic “muscle car” formula to date. It has it all... raw power, aggressive looks, a comfortable interior... but, it certainly could use a serious audio system upgrade to erase the wimpy performance of the factory system.
JL's Stealthbox® for the Challenger is the perfect product to begin your audio transformation. It installs neatly into the driver-side corner of the trunk with minimal impact on usable cargo area. Spectacular sound quality and impressive output are delivered by a high-performance JL Audio 12-inch subwoofer in a sealed enclosure precisely matched to the Challenger's acoustics by our engineering team.
Great audio in your Challenger begins here.
The Hard Data: Contains one 12W3v3-2 subwoofer in a sealed enclosure. 500 watt power handling. Wired for 2 ohm mono. Installs against driver-side wheel well. Stealthbox® includes a steel-mesh grille to protect the driver. Access to the spare tire, jack and tools remains unaffected. Installation requires removal of factory-installed ‘subwoofer' if vehicle is equipped with ‘Kicker® SRT® Audio Package'.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-D-CHLGR/12W3v3 Installation Manual
Single 10-Inch 500-Watt 2-Ohm Carpeted Fiberglass Subwoofer-Enclosure for Select 2002-2018 Dodge Ram 1500 Quad Cab, 2003-Up 2500 & 3500 Quad Cab & 2009-2018 1500 Crew Cab & 2009-Up 2500 & 3500 Crew Cab Trucks
Dodge's big hauler combines large sedan passenger comfort with tough pickup truck capabilities.
JL's Stealthbox® for the Quad Cab tucks under the rear seat on the passenger side and encloses a 10-inch driver for impressive sub-bass performance. Seat folding is unaffected and plenty of room is left on the driver side for amplifier installation or storage. Best of all, the Stealthbox® is essentially invisible once installed.
The Hard Data: Contains one 10W3v3-2 in a sealed enclosure. 500 watt power handling. Wired for 2 ohm mono. Installs under passenger side rear-bench seat. The seat folding function remains unaffected. Cup holders are not affected. Some models require removal of the passenger side metal floor extension located under the rear seat. Some models may require cutting and removal of the underseat carpet and/or carpet padding. Will not fit Mega Cab.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-D-QDRAM/10W3v3 Installation Manual
Dual 10-Inch 600-Watt 2-Ohm Carpeted Fiberglass Subwoofer-Enclosure for Select 2002-2018 Dodge Ram 1500 Quad Cab, 2003-Up 2500 & 3500 Quad Cab & 2009-2018 1500 Crew Cab & 2009-Up 2500 & 3500 Crew Cab Trucks
Dodge’s big hauler combines large sedan passenger comfort with tough pickup truck capabilities, but does not have a lot of extra interior space for a bulky subwoofer enclosure.
JL's Stealthbox® for the Quad Cab® neatly negotiates these challenges and tucks under the rear seat, enclosing dual 10-inch thin line subwoofer drivers for impressive sub-bass performance. Seat folding and comfort are unaffected, and plenty of room is left in the center for amplifier installation or storage. Best of all, this Stealthbox® is essentially invisible once installed, but certainly noticeable when you fire up your favorite music and experience world-class sub-bass.
The Hard Data:Contains two 10TW1-4 subwoofer drivers in a sealed enclosure. 600 watt power handling. Wired for 2 ohm mono. Some models may require cutting and removal of the underseat carpet and/or carpet padding. Will not fit Standard Cab, '02-'08 Crew Cab, or Mega Cab.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-D-QDRAMD/10TW1 Installation Manual
Dual 12-Inch 800-Watt 2-Ohm Carpeted Fiberglass Subwoofer-Enclosure for Select 2009-Up Ford F-150 SuperCrew, 2017-Up SuperDuty Crew Cab Trucks
The Ford F-150 is an American icon with impressive hauling capabilities and a spacious interior, especially in SuperCrew configurations. Unfortunately, Ford’s factory sound systems leave a lot to be desired in the low frequency department.
JL's Stealthbox® for F-150 SuperCrew and SuperDuty Crew Cab trucks fills your truck with stunning sub bass output and quality, with no intrusion on cab space. Featuring an all-fiberglass, sealed enclosure design, this Stealthbox® houses two of JL Audio's revolutionary 12TW3 thin-line subwoofers and installs neatly under the rear seat, without compromising rear seat comfort.
The Hard Data: Contains two 12TW3-D8 subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Installs under rear bench seat and requires removal of under-seat storage tray, if so equipped. Installation requires removal of OEM “subwoofer”, if so equipped. Does not affect folding or reclining of seat.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-150-SCDBL/12TW3 Installation Manual
Single 300-Watt 2-Ohm Thin 10-Inch Stealthbox Subwoofer-Enclosure for Select 2018-Up Ford Expedition Vehicles, with OEM Subwoofer
Ford's full-sized SUV delivers first-rate comfort with outstanding gear-hauling capability and towing capacity. This is why JL's Stealthbox solution is designed to retain 100% of your cargo space, while delivering first-class bass performance.
This model replaces the stock subwoofer and installs discreetly behind the factory cargo area trim to protect and hide its 10-inch subwoofer.
The Hard Data: Contains one 10TW1-2 subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs behind driver side panel in the cargo area. Requires removal of the OEM "subwoofer".
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-EXPED4G/10TW1 Installation Manual
Single 400-Watt 2-Ohm 10-Inch Stealthbox Subwoofer Enclosure for Select 2015-UP Ford F-150 SuperCab and 2017-UP SuperDuty SuperCab Trucks
Benefitting from JL's revolutionary thin-woofer technology, this Stealthbox® for F-150 SuperCab and SuperDuty SuperCab trucks is designed to install neatly under the rear seat with no intrusion on cab space.
Featuring an all-fiberglass, sealed enclosure design, JL's Stealthbox® houses a 10-inch TW3 thin-line subwoofer and fills your truck with loads of deep bass output. Seat folding and reclining are unaffected, and JL even incorporated a recess on the Stealthbox’s top for mounting an amplifier, if desired.
The Hard Data: Contains one 10TW3-D4 subwoofer in a sealed enclosure. 400 watt power handling. Wired for 2 ohm mono. Installs under rear bench seat and requires removal of the storage divider panel. Stealthbox® includes a steel-mesh grille to protect the driver. Does not affect folding or reclining of seat.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-F150SPRCB/10TW3 Installation Manual
Single 400-Watt 2-Ohm Thin 12-Inch Subwoofer-Enclosure for Select 2015-UP Ford Mustang-Coupe Vehicles
The latest all-American pony car gets a big dose of horsepower and major technology enhancements, all packaged in a new sleek and sexy body. Sadly though, the stock audio systems just can't deliver enough bass to keep up with the Mustang's high-performance muscle.
JL's Stealthbox® features an all-fiberglass, sealed enclosure design that fits in the same location as the optional factory subwoofer (and requires no holes to be drilled for installation). Equipped with their revolutionary 12TW3 thin-line subwoofer, this Stealthbox delivers deep, powerful bass that's worthy of your Mustang's heritage.
The Hard Data: Contains one 12TW3-D4 in a sealed enclosure. 400 watt power handling. Wired for 2 ohm mono. Installs in the passenger side rear corner of the trunk. Factory subwoofer (if equipped) must be removed for installation of Stealthbox®. Installation in Mustang Shelby GT350 models requires relocation of additional OEM equipment. Will not fit convertible models!
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-MUSCPE/12TW3 Installation Manual
Single 10-Inch 2-Ohm 300-Watt Subwoofer-Enclosure for Select 2019-UP Ford-Ranger SuperCrew Vehicles
Ford's mid-sized pickup promises practical utility and performance for everyday commutes or rugged terrains. To make every drive even more enjoyable, JL-Audio's Stealthbox solution tucks under the rear seat on the passenger side and encloses a 10-inch driver for impressive sub-bass performance. Seat folding is unaffected with plenty of room remaining on the driver side for storage. Best of all, the Stealthbox virtually disappears once installed.
The Hard Data: Contains one 10TW1-2 subwoofer in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Installs under passenger side rear seat in place of storage compartment. Will not fit SuperCab.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-RNGSCG4/10TW1 Manual
Single 600-Watt 2-Ohm Thin 13-Inch Subwoofer-Enclosure for Select 2004-2016 Ford SuperDuty Crew-Cab Trucks with FlexFold 60/40 Split-Bench Rear-Seat
Ford's big trucks were designed to haul people and serious payloads with ease. They also present a tough challenge for a conventional subwoofer solution due to a severe shortage of unused space in the cab. It's a good thing JL didn't let convention get in the way of creating outstanding sub-bass.
JL Audio now offers two clever Stealthbox® solutions for Ford's biggest hauler: one that installs inside the center console and this one: a super-thin, all fiberglass enclosure loaded with JL's revolutionary 13TW5v2 subwoofer and designed to install under the rear bench seat. So, if your console space is non-negotiable, you can still get world-class sub-bass that remains invisible and doesn't compromise your truck's people space.
Whether your miles pile up towing a boat or using your truck for work, you can now enjoy every one of them with one of our Stealthbox® solutions.
The Hard Data: Contains one 13TW5v2-2 subwoofer in a sealed enclosure. 600 watt power handling. Wired for 2 ohm mono. Installs under driver side of rear bench seat. Does not affect folding or reclining of seat.
Please Note: “Black (leather)”, as indicated in the chart below is the OEM color/material. The Stealthbox® model that matches that OEM color is carpeted
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-SUPRCC/13TW5v2 Installation Manual
Single 500-Watt 2-Ohm 10-Inch Subwoofer-Enclosure for Select 1998-2007 Ford-Excursion and F-Series SuperDuty Trucks with Front Bucket-Seats
If you drive Ford's biggest SUV or if your SuperDuty truck is equipped with bucket seats and a center console, this Stealthbox® model is right up your alley. Without infringing on people space and without being visible, it will fill your interior with rich, deep bass.
This compact unit installs inside the factory center console. The cup holders remain unaffected and some console storage is retained. A powerful JL Audio 10-inch subwoofer driver fires down into the floor for intense up-front bass presence.
The Hard Data: Contains one 10W3v3-2 in a sealed enclosure. 500 watt power handling. Wired for 2 ohm mono. Stealthbox® installs inside factory center console and fires down on the floor. Cupholders are not affected. For installation into front console only. Console storage is reduced. The factory console is not supplied with the Stealthbox®. After installation, the factory console is raised approximately 1.5 inches above the floor. Will not fit in SuperDuty trucks with bench seats. Will not fit consoles with rear cup holders and rear audio controls.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-F-SUPRCNSL/10W3v3 Installation Manual
Single 10-Inch 2-Ohm Thin 300-Watt Subwoofer-Enclosure for Select 2014-2018 Chevrolet-Silverado and GMC-Sierra Pickups, with Front Bucket-Seats and Factory-Console
GM’s third generation Silverado/Sierra gets a full redesign with a variety of enhancements including engine and technology upgrades. Regrettably, the factory audio systems still come up short when it comes to bass reproduction.
Designed to invisibly install in the factory console, this Stealthbox® adds impressive, high-quality bass, with zero loss of passenger space, storage space, or utility. The only thing you lose is that weak factory bass performance.
Featuring 100% fiberglass construction, this Stealthbox® is equipped with a down-firing 10-inch TW1 thin-line subwoofer in a sealed enclosure design.
The Hard Data: Contains one 10TW1-2 in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Stealthbox® installs inside forward-most portion of front center console, without affecting storage space or cup holders. Replaces the OEM “subwoofer” system, if vehicle is so equipped. Will not fit trucks equipped with eAssist powertrain.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-3GSLVCNSL/10TW1 Installation Manual
Single 10-Inch Thin 300-Watt Subwoofer-Enclosure for Select 2015-2020 Cadillac-Escalade, Chevy-Suburban, Chevy-Tahoe and GMC-Yukon Vehicles, with front bucket-seats and factory center-console
The fourth generation full-size SUV from GM gets all-new, luxurious interiors, along with major enhancements in performance and technology. Unfortunately, the stock audio systems continue a track record of weak bass reproduction. There also isn’t much room for a conventional subwoofer design, without compromising people and cargo space.
To neatly solve this problem, JL's engineers have designed a subwoofer solution that installs invisibly, inside the factory console, with zero loss of console storage space.
Featuring 100% fiberglass construction, this Stealthbox® is equipped with a down-firing 10-inch TW1 thin-line subwoofer in a sealed enclosure design.
The Hard Data: Contains one 10TW1-2 in a sealed enclosure. 300 watt power handling. Wired for 2 ohm mono. Stealthbox® installs inside forward-most portion of front center console, without affecting storage space or cup holders. Replaces the OEM “subwoofer” system, if vehicle is so equipped.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-4GSUVCNSL/10TW1 Installation Manual
Single 10-Inch 2-Ohm 400-Watt Thin Subwoofer-Enclosure for Select 2014-Up Corvette C7 Stingray Vehicles
The seventh-generation Corvette establishes a new benchmark for performance and style, but like most sports cars, presents a challenge when it comes to achieving excellent bass performance.
This Stealthbox® solution is engineered for those wanting to keep most of the cargo space in the hatch. It is also designed to install without any screws or bolts and can be removed in seconds for track day and reinstalled just as fast. The factory targa-top stowage is not affected in any way by the Stealthbox®, so you can enjoy great bass with or without the top installed.
Inside this Stealthbox® is a potent JL Audio 10-inch thinline subwoofer driver in a sealed enclosure that is expertly matched to the Corvette's acoustics. Also available with dual 10TW3 drivers model.
The Hard Data: Contains one 10TW3-D4 subwoofer in a sealed enclosure. 400 watt power handling. Wired for 2-ohm mono. Installs into driver side hatch storage compartment. Steel mesh grille is included to protect the subwoofer driver. Installation does not affect storage of targa-top. No holes need to be drilled for installation. Easy to remove and replace. Use of driver's side, rear storage compartment is lost with installation. Storage compartment lid must be removed for installation, but can be replaced if Stealthbox® is removed. Will not fit convertible model.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-C7CP1/10TW3 Installation Manual
Dual 10-Inch 2-Ohm 800-Watt Thin Subwoofer-Enclosure for Select 2014-Up Corvette C7 Stingray Dual-Driver Vehicles
The C7 Corvette offers an aggressive exterior and a jetfighter-like cockpit, along with major increases in horsepower, torque and technology. Still missing, however, is a real subwoofer system… even with the premium audio option.
To solve this problem, the JL Audio engineers developed a potent Stealthbox® design housing twin 10TW3 subwoofers in a sealed enclosure that mounts ahead of the rear axle, so as to preserve precious cargo space and maintain the C7’s excellent weight distribution. With up to 800W of power handling, this Stealthbox® delivers amazing sub-bass output matching your Corvette’s powerful engine, adding even more enjoyment to every minute you spend on the road. Also available with single 10TW3 driver model.
The Hard Data: Contains two 10TW3-D8 subwoofers in a sealed enclosure. 800 watt power handling. Wired for 2 ohm mono. Installs behind front seats in the forward section of the cargo area. Installation does not affect storage of targa-tops. Steel mesh grilles are included to protect the subwoofer drivers. Will not fit convertible model.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-C7CP2/10TW3 Installation Manual
Single 12-Inch 2-Ohm 600-Watt Subwoofer-Enclosure for Select 2016-Up Chevrolet-Camaro Coupe Vehicles
Chevrolet’s 6th generation Camaro delivers a powerful shot of adrenalin and all-American, classic muscle car looks. Unfortunately, its stock sound system lacks real low-frequency punch and definitely needs some help in the bass department.
This Stealthbox® is designed to produce powerful amounts of ultra-deep bass with minimal loss of useful cargo space. Its 100% fiberglass sealed enclosure houses a highly potent 12W6v3 JL Audio 12-inch subwoofer and neatly tucks into the driver side, rear corner of the trunk. Rear-seat pass-through functionality remains unaffected, and full access to the under floor battery compartment is retained. Also available in 12TW3 driver model.
The Hard Data: Contains one 12W6v3-D4 in a sealed enclosure. 600 watt power handling. Wired for a 2 ohm load. Installs in the driver side rear corner of the trunk. Minimal loss of trunk space. Black steel mesh woofer grille included. Installation requires permanent modification to the driver’s side trunk liner. Will not fit convertible models!
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-CAM6G/12W6v3 Installation Manual
10-Inch 2-Ohm 400-Watt Thin Subwoofer-Enclosure for Select 2015-2022 Chevrolet-Colorado and GMC-Canyon Crew-Cab Vehicles
GM’s mid-size truck returns with major enhancements in power and technology, all packaged in a larger body and upscale interior with all the trimmings. Unfortunately, the factory audio systems are still lacking in the bass delivery department.
JL's Stealthbox® features an all-fiberglass, sealed enclosure design that installs under the rear seat and requires no holes to be drilled for installation. Equipped with their revolutionary 10TW3 thin-line subwoofer, this Stealthbox® fills your truck with powerful, deep JL Audio bass, with no intrusion on cab space.
The Hard Data: Contains one 10TW3-D4 subwoofer in a sealed enclosure. 400 watt power handling. Wired for 2 ohm mono. Installs under the rear bench seat. Does not affect folding or reclining of seat. Requires removal of under seat storage tray.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-COCREW2G/10TW3 Installation Manual
Dual 12-Inch 2-Ohm 800-Watt Thin Subwoofer-Enclosure for Select 2007-2013 Chevrolet-Silverado and GMC-Sierra Crew-Cab Trucks with Ebony-Interior
Whether your truck is used to work hard or play even harder, this vehicle brings a whole lot to the table: from great towing and hauling capabilities to powerful engine options, a spacious interior and a smooth ride. Amidst an evolving truck market complicated with special features and touch screens, the massive GM Crew Cab trucks have stuck to their model of simplicity and comfort.
JL Audio's Stealthbox® enhances this design by adding quality bass without losing precious space or functionality. The Stealthbox® slips under the truck's rear seat and features two of JL's revolutionary 12TW3 thin-line subwoofers, giving you absolutely stellar sub-bass impact and quality. They even left a perfect spot for a clean amplifier installation!
The Hard Data: Contains two 12TW3-D8 subwoofers in a down-firing sealed enclosure. 800 watt power handling. Wired for a 2 ohm load. Installs under rear seat. Will not affect the folding of the rear seat or rear leg room.Will not fit “Classic” models.
Stealthbox® products are built to order and generally ship within 5-6 business days of receiving your order.
JL Audio SB-GM-SLVCC2/12TW3/BK Installation Manual
